ZVK2401APPActive RFID Wireless Receiver

nuRF Wireless System User Guides Rev 1.8.1 By nuRF User Guide FCC Statement: NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. CE Statement: RF INTERFERENCE WARNING: This is a Class A product. In a domestic environment this product may cause radio frequency (RF) interference, in which case the user may be required to take adequate measures. nuRF User Guide Revision History Rev Number Rev Date Revised By Details 1.0 20 May 2010 Stan Chee Draft Version for User Guide 1.1 20 May 2010 Vincent Ng Pre-release revision 1.2 6 July 2010 Marcus Yap Added tag alert guide 1.3 10 July 2010 Stan Chee Reviewed 1.4 22 July 2010 Yogi and Marcus Yap Site Survey, RTLS and Manage User guide 1.5 23 July 2010 Vincent Ng Release revision 1.6 26 July 2010 Marcus Yap Release editing 1.7 30 July 2010 Vincent Ng Revision 1.8 30 July 2010 Marcus Yap Revision Editing nuRF User Guide Table of Contents 1.0 Background ........................................................................................................................... 5 2.0 Starting Up ............................................................................................................................ 6 2.1 Start the nuRF Engine .................................................................................................... 6 2.2 Start the web server, Internet Information Services (IIS) ................................................ 7 2.3 Login ............................................................................................................................... 9 2.4 View Connected Access Points .................................................................................... 10 2.5 Assigning Zones ........................................................................................................... 11 2.6 Register new Tag(s) ..................................................................................................... 13 2.7 Tracking of Tag............................................................................................................. 15 3.0 Configure Tag Alert Trigger ............................................................................................... 16 3.1 Accessing Tag Alert Configuration Screen ................................................................... 16 3.2 Setting an effective period of an alert ........................................................................... 19 3.3 Raising alert when tag is absent for more than x (in seconds) ..................................... 20 3.4 Raising alert based on tag movement .......................................................................... 21 3.5 Raise alert when tag temperature greater than a user specified temperature value .... 22 3.6 Raise alert when tag battery level equal or below than user specified battery level ..... 23 3.7 Raise alert when tag enter specific zone(s) .................................................................. 24 3.8 Raise alert when tag is detected in specific zone without owner .................................. 25 3.9 Raise alert when user presses panic button ................................................................. 26 3.10 Raise alert when tag dwell in specific zone(s) .............................................................. 27 3.11 Raise alert when tag absent specific zone(s) ............................................................... 28 3.12 Alert Action: Send Email Notification ............................................................................ 29 3.13 Alert Action: Send SMS Notification ............................................................................. 30 3.14 Alert Action: CCTV Recording ...................................................................................... 31 3.15 Save Alert Setting ......................................................................................................... 31 3.16 Edit Alert Setting ........................................................................................................... 32 3.17 Delete Alert Setting ....................................................................................................... 33 3.18 Acknowledging Alert(s) ................................................................................................. 34 4.0 Manage Users ..................................................................................................................... 36 4.1 Manage Users Menu .................................................................................................... 36 4.2 Add User ...................................................................................................................... 36 4.3 Block User .................................................................................................................... 38 4.4 Reset Password ........................................................................................................... 38 4.5 Edit User Information .................................................................................................... 39 4.6 Remove User................................................................................................................ 39 4.7 Change Password ........................................................................................................ 40 nuRF U…

Text truncated - open the document above for the full version.

nuRF Enterprise System v2.2 Real Time Location System (RTLS) Setup Guide for System Integrator Rev 1.3.2 By Setup Guide for System Integrator Page 2 of 19 Free Alliance Sdn Bhd. Confidential and Proprietary FCC Statement (nuRF 2401AP): NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at his own expense. FCC Statement (nuRF 2401T-A/ nuRF 2401T-P): NOTE: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CE Statement: RF INTERFERENCE WARNING: This is a Class A product. In a domestic environment this product may cause radio frequency (RF) interference, in which case the user may be required to take adequate measures. Setup Guide for System Integrator Page 3 of 19 Free Alliance Sdn Bhd. Confidential and Proprietary Setup Guide for System Integrator Page 4 of 19 Free Alliance Sdn Bhd. Confidential and Proprietary Table of Contents 1.0 Background ........................................................................................................................... 5 2.0 Real Time Location System Setup ...................................................................................... 6 2.1 Manage Map .................................................................................................................. 7 2.2 Site Survey ................................................................................................................... 10 2.3 Sampling Algorithm ...................................................................................................... 13 2.4 Map View ...................................................................................................................... 19 Setup Guide for System Integrator Page 5 of 19 Free Alliance Sdn Bhd. Confidential and Proprietary 1.0 Background This document is intended as a set up guide to the System Integrator for Free Alliance‟s nuRF Enterprise System 2.2‟s Real Time Locating System. For instructions on installing and setting up the nuRF Enterprise System, refer to the Installation Manual or contact your solution provider. For instructions on configuring the nuRF Enterprise System, refer to the User Manual or contact your solution provider. RTLS feature is only available in nuRF Enterprise System. Setup Guide for System Integrator Page 6 of 19 Free Alliance Sdn Bhd. Confidential and Proprietary 2.0 Real Time Location System Setup Real Time Locating System (RTLS) provides tracking and location of the nuRF Tags in real time, accessible by users via the nuRF Web Application. The RTLS is set up during system deployment after the system infrastructure has been finalized and typically performed as the final process. The set up of the RTLS does not require specialized tools or equipment, and can be performed using the actual infrastructure and nuRF Tags. The process includes the following steps that are undertaken by the system integrator: a. Manage Map  To upload map image file and assign Access Points locations in the map.  Refer to section 2.1. b. Site Survey  To generate an RSSI reference map for the coverage area.  Refer to section 2.2. c. Sampling Algorithm  To select the RTLS sampling method.  Refer to section 2.3. d. nuRF Web Application: Map View  Monitor and track the location of the nuRF Tags in real time.  Refer to section 2.4. Setup Guide for System Integrator Page 7 of 19 Free Alliance Sdn Bhd. Confidential and Proprietary 2.1 Manage Map To upload the map or floorplan of the coverage area and indicate Access Point(s) at their mounting location: 2.1.1 Click on the menu item “System Management” and click on “Manage Maps”. 2.1.2 User will be navigated to the screen shown below. Click on the “Add Map” to add new map. Setup Guide for System Integrator Page 8 of 19 Free Alliance Sdn Bhd. Confidential and Proprietary 2.1.3 “Add Map” Page will be shown as below. 2.1.4 Click on the “Load Map” button and then choose your map layout file. 2.1.5 Select the file and click on the “Open” button to upload the map layout. Setup Guide for System Integrator Page 9 of 19 Free Alliance Sdn Bhd. Confidential and Proprietary 2.1.6 After the file is loaded, “Add Map” Screen will be shown. 2.1.7 Insert the map name in the “Map Name” section. 2.1.8 Insert the width and height of the total area represented in the map in meters 2.1.9 Click and drag the Access Point to the location where the AP is installed and then release the AP. NB: RTLS requires all connected Access Points to be indicated on the map. 2.1.10 Click on the “Save” button. Setup Guide for System Integrator Page 10 of 19 Free Alliance Sdn Bhd. Confidential and Proprietary 2.2 Site Survey Site Survey is a one-time calibration process where the System Integrator performs RF signal mapping in the coverage area to generate an RSSI reference map used by RTLS. Prior to starting the Site Survey, sampling points shall be selected as to minimize possible interruptions and optimize the process. Points must be selected to represent the areas where nuRF Tags are expected to be tracked. The Site Survey requires that one nuRF Tag (preferably an Active Tag to minimize user intervention) be assigned as the Site Survey Tag, whose RF signal will be recorded to generat…

Text truncated - open the document above for the full version.

VERIFICATION Report No.: NEI-FCCE-1-R1012007 Issued Date: Jun. 23, 2011 RV-1106021 This is to certify that the product listed in follows was (were) tested in the Neutron EMC Laboratory to comply with the criteria limits Class A of conducted and radiated emissions of the Technical Standards FCC Part 15, Subpart B, established by the FCC, USA. Equipment Active RFID Wireless Receiver Model Name nuRF 2401AP Brand Name nuRF Applicant Free Alliance Sdn Bhd Address Suite B-3-2 Block B, Plaza Damas, Sri Hartamas, 50480 Kuala Lumpur, MALAYSIA Measurement ANSI C 63.4 (2003) Method CISPR 22: 2005 +A1: 2005 ICES-003: 2004 The test data, data evaluation, and equipment configuration contained in our test report (Report No. NEI-FCCE-1-R1012007) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of NVLAP and TAF according to the ISO-17025 quality assessment standard and technical standard(s). The test data contained in the referenced test report relate only to the EUT sample and item(s) tested. Andy Chiu Authorized Signatory Neutron Engineering Inc. B1, No. 37, Lane 365, YangGuang St., NeiHu District 114, Taipei, Taiwan. TEL: +886-2-2657-3299 FAX: +886-2-2657-3331

RV-0000000 Project No.: R1012007 Page 1 of 5 Neutron Engineering Inc. ATTACHMENT PHOTOGRAPHS OF EUT RV-0000000 Project No.: R1012007 Page 2 of 5 Neutron Engineering Inc. R1012007 RV-0000000 Project No.: R1012007 Page 3 of 5 Neutron Engineering Inc. R1012007 R1012007 RV-0000000 Project No.: R1012007 Page 4 of 5 Neutron Engineering Inc. R1012007 R1012007 RV-0000000 Project No.: R1012007 Page 5 of 5 Neutron Engineering Inc. R1012007 R1012007

nuRF 2401 AP Product Label: nuRF 2401 AP Product:

Free Alliance nuRF 2401AP Internal Photo Picture 1: nuRF 2401AP Internal Photo top Picture 2: nuRF 2401AP Internal Photo bottom

RV-1106021 Report No.: NEI-FCCE-1-R1012007 Page 1 of 21 Neutron Engineering Inc. FCC Test Report Issued Date : Jun. 23, 2011 Project No. : R1012007 Equipment : Active RFID Wireless Receiver Model Name : nuRF 2401AP Applicant : Free Alliance Sdn Bhd Address : Suite B-3-2 Block B, Plaza Damas, Sri Hartamas, 50480 Kuala Lumpur, MALAYSIA Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Dec. 30, 2010 Date of Test: Dec. 30, 2010 ~ Jun. 13, 2011 Testing Engineer : (Peter Li) Technical Manager : (Jeff Yang) Authorized Signatory : (Andy Chiu) Neutron Engineering Inc. B1, No. 37, Lane 365, YangGuang St., NeiHu District 114, Taipei, Taiwan. TEL: +886-2-2657-3299 FAX: +886-2-2657-3331 RV-1106021 Report No.: NEI-FCCE-1-R1012007 Page 2 of 21 Neutron Engineering Inc. Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s) /Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. RV-1106021 Report No.: NEI-FCCE-1-R1012007 Page 3 of 21 Neutron Engineering Inc. Table of Contents Page 1 . CERTIFICATION 4 2 . SUMMARY OF TEST RESULTS 5 2.1 TEST FACILITY 6 2.2 MEASUREMENT UNCERTAINTY 6 3 . GENERAL INFORMATION 7 3.1 GENERAL DESCRIPTION OF EUT 7 3.2 DESCRIPTION OF TEST MODES 8 3.3 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 9 3.4 DESCRIPTION OF SUPPORT UNITS 10 4 . EMC EMISSION TEST 11 4.1 CONDUCTED EMISSION MEASUREMENT 11 4.1.1 POWER LINE CONDUCTED EMISSION 11 4.1.2 MEASUREMENT INSTRUMENTS LIST 11 4.1.3 TEST PROCEDURE 12 4.1.4 DEVIATION FROM TEST STANDARD 12 4.1.5 TEST SETUP 12 4.1.6 EUT OPERATING CONDITIONS 12 4.1.7 TEST RESULTS 13 4.2 RADIATED EMISSION MEASUREMENT 15 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT 15 4.2.2 MEASUREMENT INSTRUMENTS LIST 16 4.2.3 TEST PROCEDURE 16 4.2.4 DEVIATION FROM TEST STANDARD 16 4.2.5 TEST SETUP 17 4.2.6 EUT OPERATING CONDITIONS 17 4.2.7 TEST RESULTS-BETWEEN 30MHZ AND 1000MHZ 18 5 . EUT TEST PHOTO 20 RV-1106021 Report No.: NEI-FCCE-1-R1012007 Page 4 of 21 Neutron Engineering Inc. 1. CERTIFICATION E q u i p m e n t : Active RFID Wireless Receiver Brand Name : nuRF Model Name : nuRF 2401AP A p p l i c a n t : Free Alliance Sdn Bhd Date of Test : Dec. 30, 2010 ~ Jun. 13, 2011 Standards : FCC Part 15, Subpart B Class A CISPR 22: 2005 +A1: 2005 Class A ICES-003: 2004 Class A ANSI C63.4 (2003) The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCE-1-R1012007) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of NVLAP and TAF according to the ISO-17025 quality assessment standard and technical standard(s). RV-1106021 Report No.: NEI-FCCE-1-R1012007 Page 5 of 21 Neutron Engineering Inc. 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: Emission Standard Test Item Limit Judgment Remark FCC Part 15, Subpart B CISPR 22: 2005 +A1: 2005 ICES-003: 2004 Conducted Emission Class A PASS Radiated Emission Class A PASS NOTE: (1) ” N/A” denotes test is not applicable in this Test Report. RV-1106021 Report No.: NEI-FCCE-1-R1012007 Page 6 of 21 Neutron Engineering Inc. 2.1 TEST FACILITY The test facilities used to collect the test data in this report: OS02: (VCCI RN: R-2829; FCC RN: 95335; FCC DN: TW1010) No.132-1, Lane 329, Sec. 2, Palian Road, Shijr City, Taipei, Taiwan. 2.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95%。 The measurement instrumentation uncertainty considerations contained in CISPR 16-4-2. A. Radiated Measurement : Test Site Method Measurement Frequency Range Ant. H / V U，(dB) NOTE OS-01 ANSI 30 MHz ~ 200 MHz V 2.86 30 MHz ~ 200 MHz H 2.56 200 MHz ~ 1, 000 MHz V 2.88 200 MHz ~ 1, 000 MHz H 2.98 Test Site Item Measurement Frequency Range Uncertainty NOTE CB08 Radiated Emission at 3m Horizontal Polarization 30 - 200MHz 3.35 dB 200 - 1000MHz 3.11 dB 1 - 18GHz 3.97 dB 18 - 40GHz 4.01 dB Vertical Polarization 30 - 200MHz 3.22 dB 200 - 1000MHz 3.24 dB 1 - 18GHz 4.05 dB 18 - 40GHz 4.04 dB Our calculated Measurement Instrumentation Uncertainty is shown in the tables above. These are our U lab values in CISPR 16-4-2 terminology. Since Table 1 of CISPR 16-4-2 has values of measurement instrumentation uncertainty, called U CISPR , as follows: Conducted Disturbance (mains port) – 150 kHz – 30 MHz : 3.6 dB Radiated Disturbance (electric field strength …

Text truncated - open the document above for the full version.

RV-0000000 Report No.: NEI-FCCE-1-R1012007A Page 1 of 21 Neutron Engineering Inc. FCC Test Report Issued Date : Sep. 01, 2011 Project No. : R1012007A Equipment : Active RFID Wireless Receiver Model Name : nuRF 2401AP Applicant : Intellisense Sdn Bhd Address : Suite F-1-5, M Avenue, No 1, Jalan 1/38A, Segambut Bahagia 51200 Kuala Lumpur, Malaysia Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Dec. 30, 2010 Date of Test: Dec. 30, 2010 ~ Jun. 13, 2011 Testing Engineer : (Peter Li) Technical Manager : (Jeff Yang) Authorized Signatory : (Andy Chiu) Neutron Engineering Inc. B1, No. 37, Lane 365, YangGuang St., NeiHu District 114, Taipei, Taiwan. TEL: +886-2-2657-3299 FAX: +886-2-2657-3331 RV-0000000 Report No.: NEI-FCCE-1-R1012007A Page 2 of 21 Neutron Engineering Inc. Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s) /Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. RV-0000000 Report No.: NEI-FCCE-1-R1012007A Page 3 of 21 Neutron Engineering Inc. Table of Contents Page 1 . CERTIFICATION 4 2 . SUMMARY OF TEST RESULTS 5 2.1 TEST FACILITY 6 2.2 MEASUREMENT UNCERTAINTY 6 3 . GENERAL INFORMATION 7 3.1 GENERAL DESCRIPTION OF EUT 7 3.2 DESCRIPTION OF TEST MODES 8 3.3 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 9 3.4 DESCRIPTION OF SUPPORT UNITS 10 4 . EMC EMISSION TEST 11 4.1 CONDUCTED EMISSION MEASUREMENT 11 4.1.1 POWER LINE CONDUCTED EMISSION 11 4.1.2 MEASUREMENT INSTRUMENTS LIST 11 4.1.3 TEST PROCEDURE 12 4.1.4 DEVIATION FROM TEST STANDARD 12 4.1.5 TEST SETUP 12 4.1.6 EUT OPERATING CONDITIONS 12 4.1.7 TEST RESULTS 13 4.2 RADIATED EMISSION MEASUREMENT 15 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT 15 4.2.2 MEASUREMENT INSTRUMENTS LIST 16 4.2.3 TEST PROCEDURE 16 4.2.4 DEVIATION FROM TEST STANDARD 16 4.2.5 TEST SETUP 17 4.2.6 EUT OPERATING CONDITIONS 17 4.2.7 TEST RESULTS-BETWEEN 30MHZ AND 1000MHZ 18 5 . EUT TEST PHOTO 20 RV-0000000 Report No.: NEI-FCCE-1-R1012007A Page 4 of 21 Neutron Engineering Inc. 1. CERTIFICATION E q u i p m e n t : Active RFID Wireless Receiver Brand Name : nuRF Model Name : nuRF 2401AP A p p l i c a n t : Intellisense Sdn Bhd Date of Test : Dec. 30, 2010 ~ Jun. 13, 2011 Standards : FCC Part 15, Subpart B Class A CISPR 22: 2005 +A1: 2005 Class A ICES-003: 2004 Class A ANSI C63.4 (2003) The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCE-1-R1012007A) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of NVLAP and TAF according to the ISO-17025 quality assessment standard and technical standard(s). RV-0000000 Report No.: NEI-FCCE-1-R1012007A Page 5 of 21 Neutron Engineering Inc. 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: Emission Standard Test Item Limit Judgment Remark FCC Part 15, Subpart B CISPR 22: 2005 +A1: 2005 ICES-003: 2004 Conducted Emission Class A PASS Radiated Emission Class A PASS NOTE: (1) ” N/A” denotes test is not applicable in this Test Report. RV-0000000 Report No.: NEI-FCCE-1-R1012007A Page 6 of 21 Neutron Engineering Inc. 2.1 TEST FACILITY The test facilities used to collect the test data in this report: OS02: (VCCI RN: R-2829; FCC RN: 95335; FCC DN: TW1010) No.132-1, Lane 329, Sec. 2, Palian Road, Shijr City, Taipei, Taiwan. 2.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95%。 The measurement instrumentation uncertainty considerations contained in CISPR 16-4-2. A. Radiated Measurement : Test Site Method Measurement Frequency Range Ant. H / V U，(dB) NOTE OS-01 ANSI 30 MHz ~ 200 MHz V 2.86 30 MHz ~ 200 MHz H 2.56 200 MHz ~ 1, 000 MHz V 2.88 200 MHz ~ 1, 000 MHz H 2.98 Test Site Item Measurement Frequency Range Uncertainty NOTE CB08 Radiated Emission at 3m Horizontal Polarization 30 - 200MHz 3.35 dB 200 - 1000MHz 3.11 dB 1 - 18GHz 3.97 dB 18 - 40GHz 4.01 dB Vertical Polarization 30 - 200MHz 3.22 dB 200 - 1000MHz 3.24 dB 1 - 18GHz 4.05 dB 18 - 40GHz 4.04 dB Our calculated Measurement Instrumentation Uncertainty is shown in the tables above. These are our U lab values in CISPR 16-4-2 terminology. Since Table 1 of CISPR 16-4-2 has values of measurement instrumentation uncertainty, called U CISPR , as follows: Conducted Disturbance (mains port) – 150 kHz – 30 MHz : 3.6 dB Radiated Disturbance (electri…

Text truncated - open the document above for the full version.
