ZWKEZCODEM300Garage door transmitter

EZ Code-M300 Transmitter PRODUCT INSTRUCTION PRODUCT INSTRUCTIONPRODUCT INSTRUCTION PRODUCT INSTRUCTION EZ Code-M300 is the mini transmitter designed for garage door opener and gate operators f or home, farm and ranch etc... OPERATING INSTRUCTIONS: Code Setting 1. You may set your transmitter to any code you desire but be sure that the code you set matches the code that has been set on your radio receiver.The digital code is determined by the positions of the 10 small switches numbered 1 through 10 located in the receiver and transmitter. 2. Remove the one Philips head screw locat ed on the back of the case and carefully separate the case halves to expose the circuit board and battery. (See Diagram #1) DIAGRAM #1 1. Using a sharp object or tool, such as a paper clip, se the new transmitter code by setting the “ON” and “OFF” switches according t o the exact code setting of your previous transmitter or the receiver. (Note: The switches are in the “ON” positions when the switch is pushed toward the letter ON.) (See Diagram #2) Code switch Battery Door button operation indicator Door (gate) Open/Close 2. Once the codes have been set, replace the top cover, and test the system. Note: In order to avoid duplication of your access code, the following sequences are not recommended. • Alternating from “ON” and “OFF” or “OFF” and “ON” position. • Setting the switch on all “ON” or all “OFF” position. • It is important for the access code to be set exactly in the same order as the receiver for the transmitter to function properly. Testing the Transmitter: 1. Standing approximately 10-30 feet away from the receiver, push the transmitter button to activate. 2. Stand in several different areas of usage to locate possible points where certain structures may interfere wit h the transmission. General specification & Feature: 1. Output Power: -37dBm 2. Output Frequency: 300MHz 3. Power Supply: 12Vdc(5Vdc Regulation) 4. Operation Indicate LED Lamp Note: This equipment has been tested and found t o comply with the limit s for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance wit h the instructions, may cause harmful interference t o radio communication. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures; - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) t his device may not cause harmful interference, and (2) this device must accept any interf erence received, including interference that may cause undesired operation. Caution: Any changes or modifications in construction of this device which are not expressly approved by the party responsible for compliance could void the user’s aut hority to operat e the equipment. DISTRIBUTED BY Export Management System Inc. Hawthorne CA 90250

E.M.S. INC EXPORT MANAGEMENT SYSTEM INC 13532 Hawthorne Blvd Hawthorne, CA 90250 310-676-1131 FAX 310-67 6-2440 8lr6l20tr Federal Communications Commission 7435 Oaklarrd Mills Road Columbia, MD 21046 Subject: Request for Permanent Confidentiality I To whom it may concern: In accordance with 47CFR Section 0.457 and Section 0.459 pertaining to confidential material, we hereby request to hold permanently confidential all information contained within the below identified exhibits/document categories submitted pursuant to radio equipment certification requirements for FCC ID : Z!\'KF,Z{IO t} Iih,{ 3 fi il fr.Wlrri,i@ .*/*#ii l. fl{ock Diagra*r 2. Oper*tional llescription 3. ,tit:/eewatics' 4. Pat"ts List i Tune-Up Prot:edure The above material contains trade secrets and proprietary information as specified by 47CFR 0.457(d) and technical data, which would customarily be guarded from competitors. The public disclosure of this information might be harmful to our company and provide unjustified benefits to our competitors. Sincerely, {lalvin Jao lvianager Iixpeirt h,litnagernent S.vstem tr nc

This report contains a total of 33 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of CKC Laboratories, Inc. Export Management System, Inc. ADDENDUM TEST REPORT TO 92009‐4 Garage Transmitter, EZ Code‐M300 Tested To The Following Standards: FCC Part 15 Part 15.231 Report No.: 92009‐4A Date of issue: August 2, 2011 This test report bears the accreditation symbol indicating that the testing performed herein meets the test and reporting requirements of ISO/IEC 17025 under the applicable scope of EMC testing for CKC Laboratories, Inc. We strive to create long‐term, trust based relationships by providing sound, adaptive, customer first testing services. We embrace each of our customers’ unique EMC challenges, not as an interruption to set processes, but rather as the reason we are in business. Page 2of 33 Report No.: 92009‐4A TABLE OF CONTENTS Administrative Information .......................................................................................................................... 3 Test Report Information ............................................................................................................................................ 3 Revision History ......................................................................................................................................................... 3 Report Authorization ................................................................................................................................................. 3 Test Facility Information ............................................................................................................................................ 4 Site Registration & Accreditation Information .......................................................................................................... 4 Summary of Results ................................................................................................................................................... 5 Conditions During Testing ......................................................................................................................................... 5 Equipment Under Test ............................................................................................................................................... 6 Peripheral Devices ..................................................................................................................................................... 6 FCC Part 15.231 ............................................................................................................................................. 7 15.31(e) Voltage Variations ....................................................................................................................................... 7 15.231(a)(1) Release Time ....................................................................................................................................... 11 15.231(b) Fundamental Field Strength .................................................................................................................... 13 15.231(b) Radiated Spurious Field Strength ............................................................................................................ 18 15.231(c) ‐20dBc Occupied Bandwidth ................................................................................................................... 28 Supplemental Information .......................................................................................................................... 32 Measurement Uncertainty ...................................................................................................................................... 32 Emissions Test Details .............................................................................................................................................. 32 Page 3of 33 Report No.: 92009‐4A ADMINISTRATIVE INFORMATION Test Report Information REPORT PREPARED FOR: REPORT PREPARED BY: Export Management System, Inc. 13532 Hawthorne Blvd. Hawthorne, CA 90250 Joyce Walker CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 Representative: Calvin Joo Project Number: 92009 Customer Reference Number: 91 DATE OF EQUIPMENT RECEIPT: July1, 2011 DATE(S) OF TESTING: July1 ‐5, 2011 Revision History Original: Testing of the Garage Transmitter, EZ Code‐M300 to FCC Part 15 Part 15.231. Addendum A: To add the duty cycle correction factor supporting data. Report Authorization The test data contained in this report documents the observed testing parameters pertaining to and are relevant for only the sample equipment tested in the agreed upon operational mode(s) and configuration(s) as identified herein. Compliance assessment remains the client’s responsibility. This report may not be used to claim product endorsement by A2LA or any government agencies. This test report has been authorized for release under quality control from CKC Laboratories, Inc. Steve Behm Director of Quality Assurance & Engineering Services CKC Laboratories, Inc. Page 4of 33 Report No.: 92009‐4A Test Facility Information Our laboratories are configured to effectively test a wide variety of product types. CKC utilizes first class test equipment, anechoic chambers, data acquisition and information services to create accurate, repeatable and affordable test results. TEST LOCATION(S): CKC Laboratories, Inc. 110 Olinda Place Brea, CA 92823 Site Registration & Accreditation Information Location CB # JAPAN CANADA FCC Brea A US0060 R‐2945, C‐3248 & T‐1572 3082D‐1 90473 Page 5of 33 Report No.: 92009‐4A SUMMARY OF RESULTS Standard / Specification: FCC Part 15.231 Description Test Procedure/Method Results Voltage Variations FCC 15.31(e)Pass Release time FCC Part 15 .231(a)(1)/2.1055(a)Pass Fundamental Field Strength FCC Part 15 .231(b)/2.1046Pass Radiated Spurio…

Text truncated - open the document above for the full version.

X AXIS FRONT VIEW X AXIS BACK VIEW Y AXIS FRONT VIEW Y AXIS BACK VIEW Z AXIS FRONT VIEW Z AXIS BACK VIEW
