ZWT-Y-1Bluetooth Speaker

BluetoothSpeakerQuickStartGuide Poweron/off│MICon/off│rejectacall(onlyactivewithbluetoothlink) Bluetoothon/off│play/pause│de-pair│switch(onlyactivewithbluetoothlink) Volumeup│nexttrack(onlyactivewithbluetoothlink) Volumedown│previoustrack(onlyactivewithbluetoothlink) Answer│finish│switchacall(onlyactivewithbluetoothlink) Poweron/off Touchandholdthekeyfor3secondsuntilyouheara'beep-beep'prompttone. Playviacable Connectthespeakertotheaudiodevicewiththesuppliedcableandplaymusicafter poweron. Turnonbluetooth Afterpoweron,touchthekey(noneedtoholdthekey)untilyouheara'beep-beep' prompttone. Bluetoothpairing 1.Afterpoweron,turnonbluetooth 2.Searchfornewbluetoothdeviceonyouraudio/sourcedevice 3.Selectbluetoothspeakerfromthefounddeviceslist 4.Entercode0000ifrequired Playviabluetooth Aftersuccessfulpairing,playmusicbyselecting'playviabluetooth'modeonthe paireddevices. Volumeup/down Whileplayingviabluetooth,touchthekeyrepeatedly(noneedtoholdthekey)to increasevolume,touchthekeyrepeatedly(noneedtoholdthekey)todecrease volume. Next/previoustrack Whileplayingviabluetooth,touchandholdthekeyfor3secondstoselectnext song(Note:Somedeviceswillnotsupportthisoperation);touchandholdthekey for3secondstoselectprevioussong(Note:Somedeviceswillnotsupportthis operation). Play/Pause Whileplayingviabluetooth,touchthekeytopause(noneedtoholdthekey,touch thekeyagaintoresumeplay(noneedtoholdthekey). Playmodeswitch Whileinplayviabluetoothmode,andmeanwhilethebluetoothspeakerisconnected toanothermultimediaplayerviasuppliedcable,touchandholdthekeyfor3 seconds,theplayviabluetoothmodewillbeswitchedintoplayviacablemode,touch thekeyagain(noneedtoholdthekey)toresumeplayviabluetoothmode. Answeracall Touchthekeyonthespeaker(noneedtoholdthekey)toansweracallwhileyour mobileispairingwiththebluetoothspeaker(Note:Prompttoneswillbeoccurring bothonyourcellphoneandbluetoothspeaker,chooseaccordingly). Dialacall Whileyourmobileispairingwiththebluetoothspeaker,youcanchoosetofinish yourconversationsthroughthespeakerafteryoumakethedialonyourmobile. Rejectacall Whileyourmobileispairingwiththebluetoothspeaker,touchthekey(noneedto holdthekey)torejectcallsyouarenotwillingtoanswer. Finishacall Whileyourmobileispairingwiththebluetoothspeaker,touchthekey(noneedto holdthekey)tofinishacall. TurnoffMIC Touchthekey(noneedtoholdthekey)toturnoffMICifit'snottemporarily neededforaconferencing,touchthekeyagain(noneedtoholdthekey)toturnon MICifneeded. Incomingcallswitch Whileyourmobileispairingwiththebluetoothspeaker,touchandholdthekey for3secondstoswitchthecalltoyourmobileifit'snotsoconvenienttofinishthe callthroughthespeaker. Autore-pair Afterpairingandtheautore-pairfunctionontheaudiodeviceison,thebluetooth speakerwillautomaticallyre-pairtotheaudiodeviceitwasmostrecentlypairedif thede-pairisnotdone. De-pair Wheninstandby/playstatuswhilebluetoothison,touchandholdthekeyfor3 secondstode-pair. Turnoffbluetooth Wheninstandby/playstatuswhilebluetoothison,touchandholdthekeyfor3 secondstoturnoffbluetooth,touchthekeyagain(noneedtoholdthekey)toturn bluetoothon. Note:Thebluetoothspeakercanbepairedwithanybluetoothenableddevicesand mostmobilephonesorPCmultimediaplayerswillsupporttheabovefunctions. changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: RF warning statement: The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. FCC ID: ZWT-Y-1 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

HangZhou Yodee Technology Co., Ltd. SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 HangZhou Yodee Technology Co., Ltd. SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 (August 17, 2011) To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, HangZhou Yodee Technology Co., Ltd. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): (Product description, model name) FCC ID: ZWT-Y-1 Product name: Bluetooth Speaker Model: Y-1, Y-2 We affirm that between SIEMIC and HangZhou Yodee Technology Co., Ltd., any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Signature ZengYong / General Manager Title: General Manager Telephone: +86-571-28068769 Email: [email protected] Date: August 17, 2011

DATE : August 20, 2011 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID:_ZWT-Y-1___________ Product Name:_ Bluetooth Speaker _ ________ Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics Long-term confidential • Block diagram Long-term confidential • Operation description Long-term confidential These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this August 20, 2011 By: ZengYong Signature Printed Title: General Manager On behalf of : (Company Name) HangZhou Yodee Technology Co., Ltd. Telephone: +86-571-28068769

Full View Top View Bottom View Front View Left View Rear View Right View

FCC ID: ZWT-Y-1

Label Location

Top View Top View Top View Bottom View ANTENNA Top View

Shenzhen Certification Technologh Service Co., Ltd 3F, Bldg27,Area A, Tanglang Industrial Zone, Xili Town, Nanshan District, ShenZhen, Guang dong, P.R. China. FCCID: ZWT-Y-1 Page 1 of 33 TEST REPORT FCC ID: ZWT-Y-1 Applicant : Hangzhou Yodee Technology Co., Ltd. Address : 778, West Wenyi Road, Hangzhou, China Equipment under Test (EUT): Name : Bluetooth Speaker Model : Y-1, Y-2 Standards : FCC PART 15, SUBPART C : 2010 (Section 15.249) Report No. : STE110729686 Date of Test : August 7-12, 2011 Date of Issue : August 14, 2011 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above Authorized Signature (Mark Zhu) General Manager The manufacture should ensure that all the products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of Shenzhen Certification Technology Service Co., Ltd. Or test done by Shenzhen Certification Technology Service Co., Ltd. Approvals in connection with, distribution or use of the product described in this report must be approved by Shenzhen Certification Technology Service Co., Ltd. Approvals in writing. Report No.:STE110729686 FCCID: ZWT-Y-1 Page 2 of 33 TABLE OF CONTENT Description Page 1 General Information---------------------------------------------------------------------------------------3 1.1 Description of Device (EUT)---------------------------------------------------------------------3 1.2 Description of Test Facility-----------------------------------------------------------------------4 2 EMC Equipment List-----------------------------------------------------------------------------------4 3 Test Procedure---------------------------------------------------------------------------------------------5 4 Summary of Measurement---------------------------------------------------------------------------6 Occupied bandwidth----------------------------------------------------------------------------------------6 5 POWER LINE CONDUCTED EMISSION----------------------------------------------------------7 5.1 Conducted Emission Limits(15.209&249)--------------------------------------------------7 5.2 Test Setup------------------------------------------------------------------------------------------7 5.3 Test Procedure------------------------------------------------------------------------------------8 5.4 Test Results----------------------------------------------------------------------------------------8 6 Radiation Emission----------------------------------------------------------------------------------10 6.1 Radiation Emission Limits(15.209&249 (a))----------------------------------------------10 6.2 Test Setup-----------------------------------------------------------------------------------------11 6.3 Test Procedure-----------------------------------------------------------------------------------12 6.4 Test Equipment Setting For emission test.-----------------------------------------------13 6.5 Test Condition------------------------------------------------------------------------------------13 6.6 Test Result----------------------------------------------------------------------------------------13 7 Occupied bandwidth---------------------------------------------------------------------------------18 7.1 Test limit-------------------------------------------------------------------------------------------18 7.2 Method of measurement-----------------------------------------------------------------------18 7.3 Test Setup-----------------------------------------------------------------------------------------18 7.4 Test Results---------------------------------------------------------------------------------------18 8 Band Edge Check-------------------------------------------------------------------------------------19 8.1 Test limit-------------------------------------------------------------------------------------------19 8.2 Test Procedure-----------------------------------------------------------------------------------19 8.3 Test Setup-----------------------------------------------------------------------------------------19 8.4 Test Result----------------------------------------------------------------------------------------19 9 Antenna Requirement-------------------------------------------------------------------------------24 9.1 Standard Requirement-------------------------------------------------------------------------24 9.2 Antenna Connected Construction-----------------------------------------------------------24 9.3 Result-----------------------------------------------------------------------------------------------24 10 Photographs of Test Setup------------------------------------------------------------------------25 11 Photographs of EUT---------------------------------------------------------------------------------28 Report No.:STE110729686 FCCID: ZWT-Y-1 Page 3 of 33 1 General Information 1.1 Description of Device (EUT) Trade Name : N/A EUT : Bluetooth Speaker Model No. : Y-1, Y-2 DIFF : Only different in appearance, the other the same. Type of Antenna : Integral Antenna Operation Frequency : 2402-2480MHz Channel number : 79 Modulation type : GFSK Power Supply : DC 3.7V Supply by battery and DC 5V from PC Applicant : Hangzhou Yodee Technology Co., Ltd. Address : 778, West Wenyi Road, Hangzhou, China Manufacturer : Hangzhou Yodee Technology Co., Ltd. Address : 778, West Wenyi Road, Hangzhou, China Report No.:STE110729686 FCCID: ZWT-Y-1 Page 4 of 33 1.2 Description of Test Facility Shenzhen Certification Technology Service Co.,Ltd. 3F, Bldg.27, Area A, Tanglang Industrial Zone, Xili Town, Nanshan District, Shenzhen 518055, Guangdong, P.R. China FCC Registered No.:305283 2 EMC Equipment List Equipment Manufacture Model No. Serial No. Last cal. Cal Interval 3m Semi-Ane…

Text truncated - open the document above for the full version.
