ZZX672MBP MOUSE GLV WHT

FCC ID:ZZX672M

Sep.17, 2014 Federal Communication Commission Authorization and Evaluation Division FCC ID: ZZX672M Re: Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the applicant hereby requests confidential treatment of information applied this application as outlined below: 1: Block Diagram 2: Circuit Diagram 3: Parts List 4.Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rules 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Camino International Limited Contact person: Jessie Tang Title: Senior Merchandiser

External Photos TOTAL VIEW OF EUT TOP VIEW OF EUT BOTTOM VIEW OF EUT FRONT VIEW OF EUT BACK VIEW OF EUT LEFT VIEW OF EUT RIGHT VIEW OF EUT

FCC ID Label Location FCC ID: ZZX672M

Internal Photos OPEN VIEW OF EUT-1 OPEN VIEW OF EUT-2 Antenna OPEN VIEW OF EUT-3 INTERNAL VIEW OF EUT-1 INTERNAL VIEW OF EUT-2 INTERNAL VIEW OF EUT-3 INTERNAL VIEW OF EUT-4

Page 1 of 36 FCC Test Report Report No.: AGC02303140802FE01 FCC ID : ZZX672M APPLICATION PURPOSE : Original Equipment PRODUCT DESIGNATION : BP MOUSE GLV WHT BRAND NAME : Disney MODEL NAME : 760672 CLIENT : Camino International Limited DATE OF ISSUE : Sep.11, 2014 STANDARD(S) : FCC Part 15 Rules REPORT VERSION : V1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd CAUTION: This report shall not be reproduced except in full without the written permission of the test laboratory and shall not be quoted out of context. Report No.: AGC02303140802FE01 Page 2 of 36 Report Revise Record Report Version Revise Time Issued Date Valid VersionNotes V1.0 / Sep.11, 2014 Valid Original Report Report No.: AGC02303140802FE01 Page 3 of 36 TABLE OF CONTENTS 1. VERIFICATION OF CONFORMITY ...................................................................................... 4 2. GENERAL INFORMATION .................................................................................................. 5 2.1. PRODUCT DESCRIPTION ........................................................................................................... 5 2.2. TABLE OF CARRIER FREQUENCYS .......................................................................................... 5 3. MEASUREMENT UNCERTAINTY........................................................................................ 6 4. DESCRIPTION OF TEST MODES ........................................................................................ 6 5. SYSTEM TEST CONFIGURATION ...................................................................................... 6 5.1. CONFIGURATION OF EUT SYSTEM .......................................................................................... 6 5.3. SUMMARY OF TEST RESULTS .................................................................................................. 6 6. TEST FACILITY .................................................................................................................... 7 7. 20DB BANDWIDTH .............................................................................................................. 8 7.1. MEASUREMENT PROCEDURE .................................................................................................. 8 7.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ......................................................... 8 7.3. LIMITS AND MEASUREMENT RESULTS .................................................................................... 8 8. RADIATED EMISSION ....................................................................................................... 11 8.1. MEASUREMENT PROCEDURE ................................................................................................ 11 8.2. TEST SETUP .............................................................................................................................. 13 8.3. TEST RESULT ............................................................................................................................ 14 9. BAND EDGE EMISSION .................................................................................................... 26 9.1. MEASUREMENT PROCEDURE ................................................................................................ 26 9.2. TEST SET-UP ............................................................................................................................. 26 9.3 TEST RESULT ............................................................................................................................. 26 APPENDIX A: PHOTOGRAPHS OF TEST SETUP ............................................................... 29 APPENDIX B: PHOTOGRAPHS OF EUT .............................................................................. 30 Report No.: AGC02303140802FE01 Page 4 of 36 1. VERIFICATION OF CONFORMITY Applicant Camino International Limited Address Flat A, 3rd Floor, International Industrial Building, 501-503 Castle Peak Road, Cheung Sha Wan, Kowloon, Hong Kong Manufacturer Camino Industrial (Huizhou)Co.Ltd Address Lidong Industial Estate, Jiutan,Yuanzhou, Boluo.Huizhou, Guangdong, China Product Designation BP MOUSE GLV WHT (Mouse) Brand Name Disney Test Model 760672 Date of test Aug. 28, 2014 to Sep. 11, 2014 Deviation None Condition of Test Sample Normal Report Template AGCRT-US-BR/RF (2013-03-01) We hereby certify that: The above equipment was tested by Attestation of Global Compliance (Shenzhen) Co., Ltd. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2009) and the energy emitted by the sample EUT tested as described in this report is in compliance with radiated emission limits of FCC Rules Part 15.249. Prepared By Matt Zhang Sep.11, 2014 Checked By Kidd Yang Sep.11, 2014 Authorized By Solger Zhang Sep.11, 2014 Report No.: AGC02303140802FE01 Page 5 of 36 2. GENERAL INFORMATION 2.1. PRODUCT DESCRIPTION The EUT is “BP MOUSE GLV WHT ” designed as a “RF Product”. It is designed by way of utilizing the FHSS technology to achieve the system operation. A major technical description of EUT is described as following Operation Frequency 2.403 GHz to 2.477GHz RF Output Power 0dBm(Max) Modulation GFSK Number of channels 16 Hardware Version N/A Software Version N/A Antenna Designation PCB Antenna Antenna Gain 2 dBi Power Supply DC3V by battery 2.2. TABLE OF CARRIER FREQUENCYS Channel Frequency Channel Frequency 1 2403 9 2442 2 2407 10 2447 3 2412 11 2452 4 2417 12 2457 5 2422 13 2462 6 2427 14 2467 7 2432 15 2472 8 2437 16 2477 Report No.: AGC02303140802FE01 Page 6 of 36 3. MEASUREMENT UNCERTAINTY Conducted measurement: +/- 2.75dB Radiated measurement: +/- 3.2dB 4. DESCRIPTION OF TEST MODES NO. TEST MODE DESCRIPTION 1 Low channel TX 2 Middle channel TX 3 High channel TX 5. SYSTEM TEST CONFIGURATION 5.1. CONFIGURATION OF EUT SYSTEM Configuration: 5.3. SUMMARY OF TEST RESULTS FCC …

Text truncated - open the document above for the full version.

APPENDIX IV PHOTOGRAPHS OF TEST SETUP FCC RADIATED EMISSION TEST SETUP
