2A233-BW01Portable Gaming Computer(Tablet computer)

Part Name PCB Components Plastic Parts Metal Parts Power Cables HgCdCr(VI) Hazardous Substance PBBPBDE Pb connected devicesbPair new devicePair with New Device > Names and Contents of Hazardous Substances in the Product 1. The maximum operating ambient temperature of the product is 35°C. 2. If consumers use a power adapter for power supply, they should purchase and use a power adapter that has obtained CCC certification and meets the standard requirements. 3. Replacing with a battery pack of the wrong model poses a risk of fire or explosion. 4. Do not place the battery pack in extremely high temperature or extremely low pressure environments, or subject the battery pack to mechanical extrusion or cutting, as this may cause an explosion or leakage of flammable liquids or gases. Caution: Please do not listen at high volume for extended periods, as there is a risk of hearing damage. Text Input When you need to input text, simply tap on the text input field to automatically bring up the on-screen keyboard, and use the touch input to type your text. Pull-down Menu To access the pull-down menu, swipe down from the top of the screen for the first time to quickly toggle settings such as WLAN and Bluetooth. Swipe down again to display the full pull-down quick menu. You can adjust the screen brightness by sliding the brightness slider, and perform other quick settings configurations. Battery and Charge Please use the certified adapter correctly for charging to ensure safety compliance. Do not use adapters without safety certification as they may damage internal components and pose unpredictable risks. When plugging in a USB-C cable to a power source, avoid prolonged skin contact with the plug to prevent discomfort or injury.Do not attempt to replace the AYANEO Pocket Block battery on your own, as this may damage the battery, leading to overheating which could cause fires and personal injury. The lithium-ion battery of the AYANEO Pocket Block should be serviced or recycled by AYANEO or authorized service providers. Self replacement of batteries may pose a risk of explosion. Please follow local environmental regulations for battery disposal. The battery should only be replaced by AYANEO or an authorized AYANEO service provider. Using incorrect battery models for replacement poses a risk of explosion. Cleaning Please use a lint free cloth to clean AYANEO Pocket Block. Do not let the opening of the body get damp. Do not use aerosol sprays, solvents, or abrasives for cleaning. Electromagnetic Interference (EMI) The AYANEO Pocket Block contains components with magnets and emits electromagnetic fields from radio waves, which may interfere with medical devices, pacemakers, defibrillators, or other medical equipment. Maintain a safe distance between medical devices and the AYANEO Pocket Block. Consult your physician and the medical device manufacturer for information on your medical devices. If you suspect that the AYANEO Pocket Block is interfering with your pacemaker, defibrillator, or other medical devices, stop using the AYANEO Pocket Block. Warranty AYANEO warrants the hardware products and accessories included with your purchase against defects in materials and workmanship under normal use for one year from the date of original retail purchase. This warranty does not cover normal wear and tear or damage caused by accidents or misuse. For service, visit the AYANEO store or an authorized AYANEO service provider. Available service options may depend on the country or region where the service is requested and may be limited to the country or region of original sale. There may be a charge for call and international shipping fees, depending on your location. Service and Support When you submit a valid claim under the warranty service policy, AYANEO will, at its discretion, repair, replace, or refund your AYANEO Pocket Block. The warranty rights you have are in addition to the rights provided by local consumer law. When you make a claim under this warranty policy, you may be required to provide detailed information about your purchase receipt. For more support and troubleshooting information, please visit www.ayaneo.com Environmental Protection Use Period The symbol indicates the period (ten years) during which the hazardous substances contained in electronic and electrical products will not leak or undergo abrupt changes under normal use conditions. During this period, the use of these electronic and electrical products will not cause severe pollution to the environment or cause serious harm to the user’s health and property. This table is compiled according to SJ/T11364 regulations : Indicates that the content of the hazardous substance in all homogeneous materials of the part is below the limit requirement specified in GB/T26572. : Indicates that the content of the hazardous substance in at least one homogeneous material of the part exceeds the limit requirement specified in GB/T26572. Note: This product applies an environmentally friendly design concept and effectively controls hazardous substances. The "X" indicates that the hazardous substance is primarily due to the limitations of technological development, making substitution of the hazardous substance impossible. Network / Bluetooth AYANEO Pocket Block supports WLAN network. When you need to connect to the network through WLAN, set the " " and enter the settings menu home page, Network and Internet > "Internet". Select the network and enter the password, then click "Connect" to join the WLAN network. To connect to a Bluetooth device, go to the main settings menu and select "Connected Devices" > "Pair with New Device". Once the device search is complete, click on the desired Bluetooth device from the list to initiate the connection. Network and internet Mobile, Wi-Fi, hotspot User Manual Directional Buttons SELECT Button A B X Y Buttons Start Buttons Customizable Button 1 (preset to the Xbox button) Customizable Button 2 (preset to the Back button) …

Text truncated - open the document above for the full version.

FCC ID: 2A233-BW01 www.cotecna-toby.com TB-RF-073-3.1 Appendix III EUT External Photographs Photo 1 Appearance of EUT Photo 2 Appearance of EUT FCC ID: 2A233-BW01 www.cotecna-toby.com TB-RF-073-3.1 Photo 3 Appearance of EUT Photo 4 Appearance of EUT FCC ID: 2A233-BW01 www.cotecna-toby.com TB-RF-073-3.1 Photo 5 Appearance of EUT Photo 6 Appearance of EUT

FCC ID: 2A233-BW01 www.cotecna-toby.com TB-RF-073-3.1 Appendix IID Label Appendix II ID Label Location Portable Gaming Computer(Tablet computer) FCC ID: 2A233-BW01 Model: AYANEO Pocket BLOCK This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2A233-BW01 www.cotecna-toby.com TB-RF-073-3.1 Appendix IV EUT Internal Photographs Photo 7 Internal of EUT Photo 8 Internal of EUT FCC ID: 2A233-BW01 www.cotecna-toby.com TB-RF-073-3.1 Photo 9 Internal of Battery Photo 10 Internal of EUT FCC ID: 2A233-BW01 www.cotecna-toby.com TB-RF-073-3.1 Photo 11 Internal of EUT Photo 12 Internal of Antenna FCC ID: 2A233-BW01 www.cotecna-toby.com TB-RF-073-3.1 Photo 13 Internal of Antenna Photo 14 Appearance of PCB Antenna FCC ID: 2A233-BW01 www.cotecna-toby.com TB-RF-073-3.1 Photo 15 Appearance of PCB Photo 16 Appearance of PCB FCC ID: 2A233-BW01 www.cotecna-toby.com TB-RF-073-3.1 Photo 17 Appearance of PCB Photo 18 Appearance of PCB FCC ID: 2A233-BW01 www.cotecna-toby.com TB-RF-073-3.1 Photo 19 Appearance of PCB Photo 20 Appearance of PCB FCC ID: 2A233-BW01 www.cotecna-toby.com TB-RF-073-3.1 Photo 21 Appearance of PCB

Page: 1/10 Ref : ACR.193.11.24.BES.A WALTEK TESTING GROUP (SHENZHEN) CO., LTD 1/F., ROOM 101, BUILDING 1, HONGWEI INDUSTRIAL PARK, LIUXIAN 2ND ROAD, BLOCK 70 BAO'AN DISTRICT, SHENZHEN, GUANGDONG, 518101 CHINA MVG COMOSAR DOSIMETRIC E-FIELD PROBE SERIAL NO.: 3823-EPGO-435 Calibrated at MVG Z.I. de la pointe du diable Technopôle Brest Iroise – 295 avenue Alexis de Rochon 29280 PLOUZANE - FRANCE Calibration date: 01/09 /2026 Accreditations #2-6789 Scope available on www.cofrac.fr The use of the Cofrac brand and the accreditation references is prohibited from any reproduction. Summary: This document presents the method and results from an accredited COMOSAR Dosimetric E-Field Probe calibration performed at MVG, using the CALIPROBE test bench, for use with a MVG COMO SAR system only. The test results covered by accreditation are traceable to the International System of Units (SI). COMOSAR E-Field Probe Calibration Report


         9 COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref : ACR.193.11.24.BES.A Page: 2/10 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vM This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. Name Function Date Signature Prepared by : Pedro Ruiz 1/09/2026 Checked & approved by: Technical Manager 1/09/2026 Authorized by: Geraldine Toutain Customer Name Distribution : WALTEK TESTING GROUP (SHENZHEN) CO., LTD Issue Name Date Modifications A 1/09/2026 Initial release Technical Manager Quality Manager Pedro Ruiz 1
09
6 Pedro Ruiz COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref : ACR.193.11.24.BES.A Page: 3/10 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vM This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. TABLE OF CONTENTS 1 Device Under Test ..................................................................................................... 4 2 Product Description ................................................................................................... 4 2.1 General Information _______________________________________________________ 4 3 Measurement Method ................................................................................................ 4 3.1 Sensitivity _______________________________________________________________ 4 3.2 Linearity ________________________________________________________________ 5 3.3 Isotropy _________________________________________________________________ 5 3.4 Boundary Effect __________________________________________________________ 5 3.5 Probe Modulation Response _________________________________________________ 6 4 Measurement Uncertainty .......................................................................................... 6 5 Calibration Results ..................................................................................................... 6 5.1 Calibration in air __________________________________________________________ 6 5.2 Calibration in liquid _______________________________________________________ 7 6 Verification Results ................................................................................................... 8 7 List of Equipment ...................................................................................................... 9 COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref : ACR.193.11.24.BES.A Page: 4/ 10 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vM This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 1 DEVICE UNDER TEST Device Under Test Device Type COMOSAR DOSIMETRIC E FIELD PROBE Manufacturer MVG Model SSE2 Serial Number 3823-EPGO-435 Product Condition (new / used) New Frequency Range of Probe 0.15 GHz-7.5GHz Resistance of Three Dipoles at Connector Dipole 1: R1=0.189 M: Dipole 2: R2= 0.212 M: Dipole 3: R3=0.216 M: 2 PRODUCT DESCRIPTION 2.1 GENERAL INFORMATION MVG’s COMOSAR E field Probes are built in accordance to the IEC/IEEE 62209-1528 and FCC KDB865664 D01 standards. Figu re 1 – MVG COMOSAR Dosimetric E field Probe Probe Length 330 mm Length of Individual Dipoles 2 mm Maximum external diameter 8 mm Probe Tip External Diameter 2.5 mm Distance between dipoles / probe extremity 1 mm 3 MEASUREMENT METHOD The IEC/IEEE 62209-1528 and FCC KDB865664 D01 standards provide recommended practices for the probe calibrations, including the performance characteristics of interest and methods by which to assess their effect. All calibrations / measurements performed meet the fore-mentioned standards. 3.1 SENSITIVITY The sensitivity factors of the three dipoles were determined using a two step calibration method (air and tissue simulating liquid) using waveguides as outlined in the standards for frequency range 600- 7500MHz and using the calorimeter cell method (transfer method) as outlined in the standards for frequency 150-450 MHz. COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref : ACR.193.11.24.BES.A Page: 5/ 10 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vM This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 3.2 LINEARITY The evaluation of the linearity was done in free space using the waveguide, performing a power sweep to cover the SAR range 0.01W/kg to 100W/kg. 3.3 ISOTROPY The ax…

Text truncated - open the document above for the full version.

Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 1 of 50 TEST REPORT Reference No. .................... : WTX26X02044115W FCC ID ................................ : 2A233-BW01 Applicant ........................... : Shenzhen Konkr Technology Co.,Ltd Address.............................. : C-2047, Vanke Cloud City Design Commune, Xingke Road, Xili Community, Xili Subdistrict, Nanshan District, Shenzhen of China Manufacturer ..................... Shenzhen Konkr Technology Co.,Ltd Address.............................. C-2047, Vanke Cloud City Design Commune, Xingke Road, Xili Community, Xili Subdistrict, Nanshan District, Shenzhen of China Product Name ................... : Portable Gaming Computer(Tablet computer) Model No.. .......................... : AYANEO Pocket BLOCK Standards .......................... : FCC Part 2.1093, IEEE Std C95.1: 2019 IEEE C95.3: 2021 Date of Receipt sample .... : 2026-02-28 Date of Test........................ : 2026-03-13 to 2026-03-23 Date of Issue ..................... : 2026-03-23 Test Report Form No. ....... : WTX_Part2_1093W Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of approver. Prepared By: Waltek Testing Group (Shenzhen) Co., Ltd. Address: 1/F., Room 101, Building 1, Hongwei Industrial Park, Liuxian 2nd Road, Block 70 Bao'an District, Shenzhen, Guangdong, China Tel.: +86-755-33663308 Fax.: +86-755-33663309 Email: [email protected] Tested by: Approved by: Lily Yang /Project Engineer Jason Su/Manager Reference No.: WTX26X02044115W Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 2 of 50 TABLE OF CONTENTS 1. General Information ...................................................................................................................................................4 1.1 Product Description for Equipment Under Test (EUT) .........................................................................................4 1.2 Test Standards ....................................................................................................................................................6 1.3 Test Methodology ................................................................................................................................................6 1.4 Test Facility .........................................................................................................................................................6 2. Summary of Test Results ..........................................................................................................................................7 3. Specific Absorption Rate (SAR) ................................................................................................................................8 3.1 Introduction ..........................................................................................................................................................8 3.2 SAR Definition .....................................................................................................................................................8 4. SAR Measurement System ........................................................................................................................................9 4.1 The Measurement System ..................................................................................................................................9 4.2 Probe ...................................................................................................................................................................9 4.3 Probe Calibration Process ................................................................................................................................. 11 4.4 Phantom ............................................................................................................................................................ 11 4.5 Device Holder .................................................................................................................................................... 12 4.6 Test Equipment List ........................................................................................................................................... 13 5. Tissue Simulating Liquids ....................................................................................................................................... 14 5.1 Composition of Tissue Simulating Liquid ........................................................................................................... 14 5.2 Tissue Dielectric Parameters for Head and Body Phantoms ............................................................................. 15 5.3 Tissue Calibration Result ................................................................................................................................... 16 6. SAR Measurement Evaluation ................................................................................................................................ 17 6.1 Purpose of System Performance Check ............................................................................................................ 17 6.2 System Setup .................................................................................................................................................... 17 6.3 Validation Results .............................................................................................................................................. 18 7. EUT Testing Position .......................................................................................................................................…

Text truncated - open the document above for the full version.

Documentnumber:QX-FM-EN-M4 ConfidentialInformationStorageyears:2years ShenzhenQinxinTechnologyCo.,LTD SHENZHENSHIQINXINTECHNOLOGYCO.,LTD Antennaacknowledgment ANTENNAAPPROVALSHEET customer name ShenzhenYunTian IntelligentCo.,LTD Project frequenc yband wifi2.4G/wifi5.8G projectname M8695 Tabdate2025/10/28 Machinetype number date changed -- Customer material number orderof the edition 1.0 TheRFEngineer/ RF HuangWenbo construction engineer/MD Xiao-pingye projectmanager /PM Customer confirmation ShenzhenQinxinTechnologyCo., LTD SHENZHENQINXININDUSTRY CO.,LTD 303,BuildingA,SinoBuilding,Zhongshan Road,NanshanDistrict,Shenzhen,Guangdong Province,China Tel.:0755-28404650 Fax:0755-28404639 Companyemailaddress:Sales@ sz-qinxin.com Companywebsite:www.sz-qinxin.com Postcode:518000 ShenzhenNanshanDistrictHi-tech lndustrialpark(CentralDistrict)Sabrina GeneTherapyParkBuildingA3 rd Floor303, TEL:28404650FAX:0755-28404639 E-Mail:[email protected] Website:www.sz-qinxin.com PostCode:518000 Documentnumber:QX-FM-EN-M4 -1- Catalogue Directory:.........................................................................................................................................-2 --2- 1Projectantenna(composition),briefintroduction.............................................................................-2 --2- 1.1Antennasample..................................................................................................................-2- 1.2Compositionoftheantenna................................................................................................-2- 2Theantennatestenvironment.......................................................................................................-3- 2.1Externaltestenvironment............................................................................................-4- 3Mainantenna................................................................................................................................-5- 3.1Matchingcircuit.................................................................................................................-5- 3.2Testresults..........................................................................................................................-5- 4. Efficiency gain and direction diagram................................................................................. - 5 - 5.Project pictures..............................................................................................................................- 9 - 6.andsummarizethe..........................................................................................................................- 9 - 7.Assembly diagram....................................................................................................................- 1 0 - Documentnumber:QX-FM-EN-M4 -2- 1Antennaprofile 1.1Antennasample 1.2Compositionoftheantenna Thereareonekindsofantennasupports:upperbracketandlowerbracket: 2.4GWIFI-/5.8GWIFI,composedofFPC.Thewholeantennaprovidedbyourcompany isasshowninTable1-1. Table1-1,Detailedtableoftheantenna name M8695-wifi materialquality FPC+coaxialcable quantity(pcs)1 Documentnumber:QX-FM-EN-M4 -3- 2Theantennatestenvironment 2.1Externaltestenvironment Ourmaintestequipmentisshowninthetablebelow. Table2-2.Maintestequipment order number devicenameDevicepictures Measureme ntindex operational environment 1 Agilent8960 Integrated tester Active performan ce Normal temperature andhumidity 2 Microwave darkroom 3 ADVANTEST R3765BH Network analyzer Passive performan ce Thereisno largemetal aroundit Normal temperature andhumidity Documentnumber:QX-FM-EN-M4 -4- 2.1.1Apassivetest Theconnectionofthetestdeviceis:networkanalyzertestlinetestequipment. 2.1.2Activetesting Themainperformanceindicatorsofactivetesting:totalradiationpower(TRP), omnidirectionalsensitivity(TIS). Testsite Microwavedarkroom:thefrequencyrangeis700MHz-6GHz,thestaticarearangeis50cm circumference,andthereflectivityislessthan-50dB. Testinstrument Networkanalyzer,CMW500,standardhornantenna,GTS1800testsystem,printer,etc Documentnumber:QX-FM-EN-M4 -5- 3Mainantenna 3.1Matchingcircuit Theboardendmatchinghasnotbeenchanged 3.2Testresult Theantennaoperatingfrequencybandisat2400MHz~2500MHz,5180MHz~5870MHz.Itisthe indexoftheelectricalperformanceofourdesignedandmass-producedantenna. TheTRPandTISvaluesareshowninthefollowingtable: CHannelTRPTIS 2.4G802.11B-11Mbps 112.26-81.6 713.35-82.5 1313.52-82.8 5.8G802.11A-54Mbps 3611.82-71.2 14911.63-70.6 16511.22-71.3 Documentnumber:QX-FM-EN-M4 -6- 4.Efficiencygainanddirectiondiagram FreqEffiGainFreqEffiGain549049.154.44 (MHz)(%)(dBi)(MHz)(%)(dBi)550048.024.49 240037.421.6518040.883.88551046.074.23 241037.21.49519038.733.68552045.994.24 242038.181.54520037.043.5553046.654.4 243037.891.45521037.523.55554046.074.48 244038.251.43522039.093.68555047.124.6 245038.951.57523042.64.12556045.34.39 246038.361.5524043.014.1557044.744.3 247038.321.44525040.953.98558044.324.41 248039.061.56526041.114.02559043.024.42 249038.141.39527039.793.79560046.864.75 250035.410.96528040.283.87561045.994.76 529043.284.13562045.84.75 530042.343.95563046.284.75 531041.843.93564046.424.82 532043.174.06565047.595.21 533041.943.77566048.75.32 534044.473.97567049.995.48 535046.524.135680485.31 536044.373.85569045.015.07 537046.033.97570045.755.28 538043.493.74571045.725.32 539041.933.51572046.975.6 540048.554.38573047.055.7 541048.474.34574045.115.48 542049.664.46575044.985.42 543048.534.32576041.855.27 544047.584.22577044.285.49 545048.624.26578046.495.7 546046.664.23579043.725.6 547049.044.39580045.115.84 548049.164.47581042.215.49 Documentnumber:QX-FM-EN-M4 -7- Documentnumber:QX-FM-EN-M4 - 8 - Documentnumber:QX-FM-EN-M4 5.Projectpicture - 9 - s 6、conclusion Theantennaisdesignedonthebasisofthecustomer-providedprototype.Electricalparametersand structuralperformancehavemetthetechnicalrequirements.Pleaseconfirm! Documentnumber:QX-FM-EN-M4 7、assemblydrawin - 1 0 - g Documentnumber:QX-FM-EN-M4 ConfidentialInform…

Text truncated - open the document above for the full version.

Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202509-0277-16 Page: 1 of 69 FCC ID: 2A233-BW01 TB-RF-073-3.1 RF Test Data for Bluetooth (Conducted Measurements) General Description of EUT Product Name: Portable Gaming Computer(Tablet computer) Test Model: AYANEO Pocket BLOCK Sample ID: HC-C-202509-0277-01-03-2# Test Standard: FCC Part 15.247 Environmental Conditions Temperature: 25°C Relative Humidity: 45%RH Test Voltage: DC 3.85V Test Engineer: Gold. zhang Note: For a more detailed features description, please refer to the report TBR-C-202509-0277-16 The report only show the worst case data. Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202509-0277-16 Page: 2 of 69 FCC ID: 2A233-BW01 TB-RF-073-3.1 Contents 1. Dwell Time ..................................................................................................................................................................................... 3 2. Duty Cycle ..................................................................................................................................................................................... 9 3. Maximum Conducted Output Power .......................................................................................................................................... 15 4. -20dB Bandwidth ......................................................................................................................................................................... 21 5. Occupied Channel Bandwidth .................................................................................................................................................... 27 6. Band Edge ................................................................................................................................................................................... 33 7. Band Edge(Hopping) ................................................................................................................................................................... 40 8. Conducted RF Spurious Emission ............................................................................................................................................. 47 9. Restrict Band ............................................................................................................................................................................... 57 10. Carrier Frequencies Separation ........................................................................................................................................ 64 11. Number of Hopping Channel ............................................................................................................................................. 67 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202509-0277-16 Page: 3 of 69 FCC ID: 2A233-BW01 TB-RF-073-3.1 1. Dwell Time Condition Mode Frequency (MHz) Antenna Pulse Time (ms) Total Dwell Time (ms) Period Time (ms) Limit (ms) Verdict NVNT 1-DH1 2441 Ant1 0.377 120.64 31600 400 Pass NVNT 1-DH3 2441 Ant1 1.633 261.28 31600 400 Pass NVNT 1-DH5 2441 Ant1 2.882 307.413 31600 400 Pass NVNT 2-DH1 2441 Ant1 0.385 123.2 31600 400 Pass NVNT 2-DH3 2441 Ant1 1.637 261.92 31600 400 Pass NVNT 2-DH5 2441 Ant1 2.885 307.733 31600 400 Pass NVNT 3-DH1 2441 Ant1 0.386 123.52 31600 400 Pass NVNT 3-DH3 2441 Ant1 1.636 261.76 31600 400 Pass NVNT 3-DH5 2441 Ant1 2.887 307.947 31600 400 Pass Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202509-0277-16 Page: 4 of 69 FCC ID: 2A233-BW01 TB-RF-073-3.1 Test Graphs Dwell NVNT 1-DH1 2441MHz Ant1 Dwell NVNT 1-DH3 2441MHz Ant1 Shenzhen Toby Technology Co., Ltd. Http://www.cotecna-toby.com Add：1/F.,Building 6,…

Text truncated - open the document above for the full version.
