2A25A-E5000BTWireless Gaming Headset

User Manual BT Wireless Gaming Headset STAR ENGINE E5000 BT Language Guide English Deutsch Français Русский Português 1 13 25 37 49 61 Specification Package Contents EN 滦 滧 滨 滩 滪 滫 滬 滭 滮 溡溥 溧 溨 User Manual BT Wireless Gaming Headset STAR ENGINE 溩 溤溦 1 溢 1* EKSA StarEngine BT Headset 1* EKSA USB-A and TypeC Adapter 1* Pluggable Microphone 1* 3.5mm Audio Cable 1* Charging Cable 1* Microphone Sponge Cover 1* Quick Guide Card 1* User Manual 1* Carry Pouch 溣 Speaker size: 50 mm Speaker impedance: 32 Ω Speaker frequency range: 20 HZ-20 kHz Speaker Sensitivity: 105 ± 3 dB Lighting: RGB Charging time: 2.5 h Speakers: Bluetooth Mode Play Time: 100 hours (Lights off) 2.4G Mode Play Time: 80 hours (Lights off) Bluetooth Mode Play Time: 52 hours 2.4G Mode Play Time: 45 hours Connection distance: 15 m 3.5mm audio cable length: 1.8 m Distance/Hours Mic type: Condenser Mic Talking microphone directivity: Omni-directional Microphone sensitivity: -42 dB ± 3dB Microphone impedance: 2.2 kΩ Microphone placement type: Plug and play Microphone: Operation Guide Volume wheel Turn volume up to + Click microphone to turn off/on; Double-click microphone to switch between 2.4G and Bluetooth; Long press microphone mute button for 5 seconds to pair 2.4G/Bluetooth. Turn volume down to - Microphone mute button / Mode switching / Pairing x1 x2 Ǝ 2 2.4 GHz Long press the button for 3 seconds to turn on/off; Click the button to play/pause; Double-click the button to turn on/switch/off the RGB lights. Operation Guide Switch on/off/Play pause/Light switching Transmitters 3.5mm wired mode: Ǝ x1 x2 When the 3.5 mm audio cable is plugged in, the headset turns off automatically. When the headset is in wired mode, only the volume control wheel works, no other function works. 3 Plug in the transmitter to automatically connect back to the device. All-Platform Compatible 4 The EKSA StarEngine BT headset is configured with USB, Type-c, 3.5mm ports and also features Bluetooth connectivity. The product is compatible with PS5|PS4|Xbox One S/X|Nintendo Switch|PC|Laptop|Mobile phone or Bluetooth enabled devices. 4XJUDI˳ 1$.BD-BQUPQ14m14m 9CPYm
0OF
49NPCJMF
EFWJDFT14m14m Type-C Dongle EKSA USB-A and TypeC Adapter 3.5 mm Audio Cable Type-C interface The first step Please plug the audio cable into the headset first The second step Then plug the other side of the audio cable into the device Note : The Xbox Series only works with 3.5mm wired connections. Built-in powerful 50mm magnetic neodymium drivers and a 7.1 surround sound chip bring you an immersive gaming experience. Download the 7.1 driver, plug in the transmitter and select the 7.1 surround sound mode. You can also download the 7.1 SoundBase driver from our official website (https://www.eksa.net/download). Note: EKSA's 7.1 surround sound driver only supports Windows 10/11. y y y y y y y y y y y y EKSA 7.1 SoundBase 7.1 Sound effect settings: 1Click right mouse button: Speakers 2Select 7.1Virtual Speaker Shifter 3Check the 7.1 surround sound selection 4Click the game mode 5 溣 溤 溡 溢 6 Windows®: macOS: Microphone Settings: [Control Panel] [System Preferences][Sound] [Input] [StarEngine BT] [ StarEngine BT] [Sound] [Playback] [EKSA StarEngine BT (Set as Default Device)] [Recording] [Hardware and Sound] [Control Panel] [Sound] [EKSA StarEngine BT (Set as Default Device)] [Output] [Hardware and Sound] AudioʱSettings: Dongle Sound Settings Please follow the steps below to ensure that your EKSA StarEngine BT headset is the default audio device. How to Use 7 [Settings] [Sound] [Microphone - Input Device - Headset ( EKSA StarEngine BT)] [Adjust Microphone Level] [Audio Output - Output Device - Headset ( EKSA StarEngine BT)] [Switch Output Device Automatically] [Volume - Headphones] PlayStation® 4 / PlayStation® 5: Connect your PS®4/PS®5 directly using a USB, transmitter, then follow the steps below to check the audio settings to ensure that your PS®4/PS®5 automatically switches audio for playback and microphone. PS®4 PS®5 [Settings] [Devices] [Audio Devices] [Output Device - Headset ( EKSA StarEngine BT)] [Input Device - Headset ( EKSA StarEngine BT)] [Volume Control (Headphones)] [Adjust Microphone Level] [Switch Output Device Automatically] 8 How to Use Guide for Xbox® Users The controller has a 3.5 mm jack: no adapter is requiredʱ The controller doesn't have a 3.5 mm jack: a Microsoft adapter is required (not included) Xbox One® S/X controllerXbox® One controller (old version) Xbox One® S / X: To work on the NEW version of the Xbox One® S/X controller, you can directly connect your headset to the controller via the 3.5 mm audio cable. Notes: 1. The headset is not compatible with Xbox®360. 2. Old version of Xbox® One needs a Microsoft adapter (not included). 3. USB doesn't work on the Xbox One S/X. Ǝ 溢 溡 Ǝ 9 Bluetooth Pairing/Connection For the first time pairing, the headset switches to Bluetooth mode after powering on the headset, the headset enters the pairing state, and if it is not connected for 5 minutes, the headset enters the shutdown. After there is a pairing record, the headset is turned on and switched to Bluetooth mode, the headset enters back to the connection state, 10 seconds without back to the connection, the headset enters into the pairing state, 5 minutes without connection, the headset enters into the shutdown. If within 5 minutes with the headset and device pairing connection success, the headset into the connection success state. Headset boot switch to bluetooth mode, long press the microphone mute button for 5 seconds, the headset into the bluetooth clear record, clear the record after the headset into the pairing mode, the headset voice prompts Pairing after releasing the key, when the headset pairing status light is red and blue alternately flashing. Ǝ x2 溢 溡 Ǝ x2 溢 溡 x2 溣 溢 Ǝ 10 Ǝ 溡 Transmitter Pairing/Connection 1.When shipped from the factory, the headset is connected to the transmitter in a binding connection, plug the …

Text truncated - open the document above for the full version.
