2A26IDFT-CB101DiFluid Omix

1、Label Material: PC with 3M. Color: (PANTONE 10103C ON Black C) Size unit: mm 2、location(at the bottom)

MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ24060118S01 Annex C Plots of System Performance Check Test Laboratory: Shenzhen Morlab Communications Technology Co., Ltd. Date: 2024.07.18 System Check_2450MHz_Head Communication System: UID 0, CW (0); Frequency: 2450 MHz;Duty Cycle: 1:1 Medium: HSL_2450 Medium parameters used: f = 2450 MHz; σ = 1.851 S/m; ε r = 39.422; ρ = 1000 kg/m 3 Ambient Temperature：23.2 °C; Liquid Temperature：22.1 °C DASY5 Configuration: - Probe: EX3DV4 - SN3823; ConvF(7.22, 7.22, 7.22) @ 2450 MHz; Calibrated: 2023.09.14 - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE4 Sn480; Calibrated: 2023.09.19 - Phantom: Twin-SAM; Type: QD 000 P41 Ax; Serial: 2020 - Measurement SW: DASY52, Version 52.10 (4); SEMCAD X Version 14.6.14 (7483) CW2450/Area Scan (71x71x1): Interpolated grid: dx=1.200 mm, dy=1.200 mm Maximum value of SAR (interpolated) = 22.4 W/kg CW2450/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 87.40 V/m; Power Drift = -0.05 dB Peak SAR (extrapolated) = 29.4 W/kg SAR(1 g) = 13.9 W/kg; SAR(10 g) = 6.45 W/kg Smallest distance from peaks to all points 3 dB below = 9.5 mm Ratio of SAR at M2 to SAR at M1 = 47.9% Maximum value of SAR (measured) = 21.3 W/kg 0 dB = 21.3 W/kg MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen, GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ24060118S01

MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ24060118S01 Annex D Plots of Maximum SAR Test Results Test Laboratory: Shenzhen Morlab Communications Technology Co., Ltd. Date: 2024.07.18 WLAN2.4GHz_802.11b 1Mbps_Top Side_0mm_Ch11 Communication System: UID 0, WLAN 2.4GHz 802.11b (0); Frequency: 2462 MHz;Duty Cycle: 1:1.011 Medium: HSL_2450 Medium parameters used: f = 2462 MHz; σ = 1.863 S/m; ε r = 39.335; ρ = 1000 kg/m 3 Ambient Temperature：23.2 °C; Liquid Temperature：22.1 °C DASY5 Configuration: - Probe: EX3DV4 - SN3823; ConvF(7.22, 7.22, 7.22) @ 2462 MHz; Calibrated: 2023.09.14 - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE4 Sn480; Calibrated: 2023.09.19 - Phantom: Twin-SAM; Type: QD 000 P41 Ax; Serial: 2020 - Measurement SW: DASY52, Version 52.10 (4); SEMCAD X Version 14.6.14 (7483) Ch11/Area Scan (111x111x1): Interpolated grid: dx=1.200 mm, dy=1.200 mm Maximum value of SAR (interpolated) = 1.45 W/kg Ch11/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 1.877 V/m; Power Drift = 0.06 dB Peak SAR (extrapolated) = 1.83 W/kg SAR(1 g) = 0.956 W/kg; SAR(10 g) = 0.474 W/kg Smallest distance from peaks to all points 3 dB below = 10.6 mm Ratio of SAR at M2 to SAR at M1 = 52.5% Maximum value of SAR (measured) = 1.40 W/kg 0 dB = 1.40 W/kg MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen, GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ24060118S01 Test Laboratory: Shenzhen Morlab Communications Technology Co., Ltd. Date: 2024.07.18 WLAN2.4GHz_802.11n-HT20 MCS0_Top Side_0mm_Ch11 Communication System: UID 0, WLAN 2.4GHz 802.11n-HT20 MCS0 (0); Frequency: 2462 MHz;Duty Cycle: 1:1.076 Medium: HSL_2450 Medium parameters used: f = 2462 MHz; σ = 1.863 S/m; ε r = 39.335; ρ = 1000 kg/m 3 Ambient Temperature：23.2 °C; Liquid Temperature：22.1 °C DASY5 Configuration: - Probe: EX3DV4 - SN3823; ConvF(7.22, 7.22, 7.22) @ 2462 MHz; Calibrated: 2023.09.14 - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE4 Sn480; Calibrated: 2023.09.19 - Phantom: Twin-SAM; Type: QD 000 P41 Ax; Serial: 2020 - Measurement SW: DASY52, Version 52.10 (4); SEMCAD X Version 14.6.14 (7483) Ch11/Area Scan (111x111x1): Interpolated grid: dx=1.200 mm, dy=1.200 mm Maximum value of SAR (interpolated) = 0.937 W/kg Ch11/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 0 V/m; Power Drift = 0.04 dB Peak SAR (extrapolated) = 1.16 W/kg SAR(1 g) = 0.627 W/kg; SAR(10 g) = 0.316 W/kg Smallest distance from peaks to all points 3 dB below = 10.8 mm Ratio of SAR at M2 to SAR at M1 = 54.3% Maximum value of SAR (measured) = 0.904 W/kg 0 dB = 0.904 W/kg MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen, GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ24060118S01

MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ24060118S01 Annex E Conducted Power Note: Conducted power unit: dBm The target power was recorded in the manufacturer’s document. 2.4GHz WLAN ANT 1 CH 1241215.6516.5017.00 CH 6243716.4617.5017.00 CH 11246216.9418.0017.00 CH 1241214.7315.5016.00 CH 6243715.6216.5016.00 CH 11246216.2217.0016.00 CH 1241215.2816.0017.00 CH 6243716.3717.0017.00 CH 11246217.0218.0017.00 Average power (dBm) Tune-up Limit Average power (dBm) Tune-up Limit Average power (dBm) Tune-up Limit CH 0024021.342.000.151.000.201.00 CH 3924413.314.001.752.502.223.00 CH 7824804.405.002.934.002.823.50 Average power (dBm) Tune-up Limit Average power (dBm) Tune-up Limit CH 002402-0.530.00-2.950.00 CH 1924401.272.00-1.540.00 CH 3924801.813.00-0.660.00 3Mbps Duty Cycle %62.936.5136.51 Channel 1Mbps2Mbps Mode 802.11b 1Mbps 802.11g 6Mbps 802.11n-HT20 MCS0 2.4GHz WLAN ANT 1 Mode BR / EDR Mode LE Duty Cycle % Channel Frequency (MHz) Frequency (MHz) Frequency (MHz) Channel 1Mbps2Mbps 62.936.51 Tune-Up Limit Average power (dBm) Power Setting Duty Cycle % 98.90 93.19 92.91 MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen, GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ24060118S01

MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ24060118S01 Annex F DASY Calibration Certificate

Annual validation for test lab. Appendix Annual validation for Test Lab. General calibration information Date 2022.12.15 Test Laboratory ShenZhen Morlab Communications Technology Co., Ltd. Antenna serial No. D2450V2-SN: 805 Antenna Parameters with Head TSL Impedance, transformed to feed point 50.661Ω-5.59jΩ Return Loss -23.203dB General Antenna Parameters and Design Electrical Delay (one direction) 1.276 ns After long term use with 100W radiated power，only a slight warming of the dipole near the feed point can be measured The dipole is made of standard semirigid coaxial cable. The center conductor of the feeding line is directly connected to the second arm of the dipole. The antenna is therefore short-circuited for DC-signals. On some of the dipoles, small end caps are added to the dipole arms in order to improve matching when loaded according to the position as explained in the "Measurement Conditions" paragraph. The SAR data are not affected by this change. The overall dipole length is still according to the Standard No excessive force must be applied to the dipole arm， because they might bend or the soldered connections near the feed point may be damaged . Annual validation for test lab. Annual validation for test lab. Appendix Impedance Measurement Plot for Head TSL Annual validation for test lab. Appendix Annual validation for Test Lab. General calibration information Date 2023.12.06 Test Laboratory ShenZhen Morlab Communications Technology Co., Ltd. Antenna serial No. D2450V2-SN: 805 Antenna Parameters with Head TSL Impedance, transformed to feed point 53.394Ω+0.632jΩ Return Loss -29.528dB General Antenna Parameters and Design Electrical Delay (one direction) 1.276 ns After long term use with 100W radiated power，only a slight warming of the dipole near the feed point can be measured The dipole is made of standard semirigid coaxial cable. The center conductor of the feeding line is directly connected to the second arm of the dipole. The antenna is therefore short-circuited for DC-signals. On some of the dipoles, small end caps are added to the dipole arms in order to improve matching when loaded according to the position as explained in the "Measurement Conditions" paragraph. The SAR data are not affected by this change. The overall dipole length is still according to the Standard No excessive force must be applied to the dipole arm， because they might bend or the soldered connections near the feed point may be damaged . Annual validation for test lab. Annual validation for test lab. Appendix Impedance Measurement Plot for Head TSL

NOTE: This document is issued by Shenzhen Morlab Communications Technology Co., the test report shall not be reproduced except in full without prior written permission of the company. The test results apply only to the particular sample(s) tested and to the specific tests carried out which is available on request for validation and information confirmed at our website. MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ24060118S01 Page 1 of 42 TEST REPORT APPLICANT : Shenzhen Digitizing Fluid Technology Co., Ltd. PRODUCT NAME : DiFluid Omix MODEL NAME : CB101, CB101 Plus BRAND NAME : DiFluid FCC ID : 2A26IDFT-CB101 STANDARD(S) : FCC 47 CFR Part 2 (2.1093) IEEE 1528-2013 RECEIPT DATE : 2024-07-08 TEST DATE : 2024-07-18 ISSUE DATE : 2024-08-13 Edited by : Xie Yiyun (Rapporteur) Approved by: Gan Yueming (Supervisor) MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ24060118S01 Page 2 of 42 DIRECTORY 1. SAR Results Summary ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 5 2. Technical Information ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 6 2.1. Applicant and Manufacturer Information ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 6 2.2. Equipment under Test (EUT) Description ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 6 2.3. Accessories Information ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 6 2.4. Environment of Test Site/Conditions ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 8 3. Specific Absorption Rate (SAR) ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 9 3.1. Introduction∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 9 3.2. SAR Definition ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 9 4. RF Exposure Limits ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 10 4.1. Uncontrolled Environment ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 10 4.2. Controlled Environment ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 10 5. Applied Reference Documents ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 11 6. SAR Measurement System ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 12 6.1. E-Field Probe ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 13 6.2. Data Acquisition Electronics (DAE) ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 14 6.3. Robot ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 14 6.4. Measurement Server ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 15 6.5. Light Beam Unit ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 15 6.6. Phantom ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 15 6.7. Device Holder ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 16 6.8. Data Storage and Evaluation ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 17 6.9. Test Equipment List ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 19 7. Tissue Simulating Liquids ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 20 8. SAR System Verification ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 22 8.1. Purpose of System Performance check ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 22 MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ24060118S01 Page 3 of 42 8.2. System Setup ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 22 8.3. Validation Results ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 23 9. EUT Testing Position ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 26 9.1. Body-worn Configurations ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 26 9.2. Hotspot Mode Exposure Position Conditions ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 26 10. Measurement Procedures ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 28 10.1. Spatial Peak SAR Evaluation ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 28 10.2. Power Reference Measurement ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙…

Text truncated - open the document above for the full version.

ShenzhenShuodianElectronicTechnologyCo.,Ltd ShenzhenShuodianElectronicTechnologyCo.,Ltd Pagenumber1-12 SPECIFICATION for CB1012.4G-5.8GWIFIFPCAntenna CustomerNo. ProductNo. LS-CB1012.4G-5.8G-FPC-60MM Author：XiaofengZengReview：Liming ReleaseDate：2024.06.01 ShenZhenShuodianElectronicTechnologyCo.,Ltd Room201,Building2,NantaiyunInnovationValleyPark,TangweiCommunity,Fenghuang Street,GuangmingDistrict,Shenzhen,Guangdong E-mail ： [email protected] Tel:0755-86006322 Fax:0755-86006323 ShenzhenShuodianElectronicTechnologyCo.,Ltd Date:2014-6-30Page number2-8 ShenzhenShuodianElectronicTechnologyCo.,Ltd ShenzhenShuodianElectronicTechnologyCo.,Ltd Pagenumber2-12 Contents SPECIFICATION....................................................................................................................1 SHENZHENSHUODIANELECTRONICTECHNOLOGYCO.,LTD.........................................1 CONTENTS..............................................................................................................................2 1.BILATERALCONFIRMATIONPAGE............................................................................3 2.GENERAL.........................................................................................................................4 3.GENERALPRODUCTSPECIFICATIONS..................................................................4 4.SPECIFICATIONDETIALS..............................................................................................5 4.1MECHANICALPROPERTIES.................................................................................................5 4.2ELECTRICPERFORMANCE...............................................................................................7 5.PRODUCTPACKAGING..............................................................................................12 6.DOCUMENTRESUME.................................................................................................12 ShenzhenShuodianElectronicTechnologyCo.,Ltd Date:2014-6-30Page number3-8 ShenzhenShuodianElectronicTechnologyCo.,Ltd ShenzhenShuodianElectronicTechnologyCo.,Ltd Pagenumber3-12 1.BilateralConfirmationpage 1.1Customersignature Customer： Separtment/postSignDate HardwareEngineer/RD Mechanical/MD ProjectManager/PM Commercial/Puchasing Checker 1.2SignatureofShuoDianTechnologycompany Separtment/postSignDate AntennaEngineer/RD Mechanical/MD ProjectManager/PM QA Checker ShenzhenShuodianElectronicTechnologyCo.,Ltd Date :2014 -6-30 Page number4-8 ShenzhenShuodianElectronicTechnologyCo.,Ltd ShenzhenShuodianElectronicTechnologyCo.,Ltd Page number4-1 2 2. General 2.1Scope of application CB1012.4G-5.8GWIFIantenna 2.2Operatingtemperaturerange Temperaturerange of this product:-20 ~ +65 °C 2.3Storagetemperaturerange: This productis stored at - 30 ~ + 75 °C 3. Generalproductspecifications NO.ITEMSDETAILS 1Type CB1012.4 G-5.8G WIFI 2 OperatingFrequency Band 2400-2500MHZ5100-5900MHZ 3VSWR ≤2.0 4Gain 2.0dBi 5RadiationEfficiency ≥50% 6Impedance 50Ω 7AntennaTypePIFA 8Antennacomposition FPC+CABLE 9Entity Picture ShenzhenShuodianElectronicTechnologyCo.,Ltd Date:2014-6-30Page number5-8 ShenzhenShuodianElectronicTechnologyCo.,Ltd ShenzhenShuodianElectronicTechnologyCo.,Ltd Pagenumber5-12 4.SpecificationDetials 4.1MechanicalProperties 4.11ProductComposition ： No.MaterialSize(MM) 1 FPC37*12.9BLACK 2 CABLEIPEX-1Ø1.1360MMBLACK 4.12Apperance Goodappearancewithoutscars、dirts、protuberances,etc. 4.13AntennaPictureandStructureDimension Productdrawings: ShenzhenShuodianElectronicTechnologyCo.,Ltd Date:2014-6-30Page number6-8 ShenzhenShuodianElectronicTechnologyCo.,Ltd ShenzhenShuodianElectronicTechnologyCo.,Ltd Pagenumber6-12 ShenzhenShuodianElectronicTechnologyCo.,Ltd Date:2014-6-30Page number7-8 ShenzhenShuodianElectronicTechnologyCo.,Ltd ShenzhenShuodianElectronicTechnologyCo.,Ltd Pagenumber7-12 4.2ElectricPerformance 4.21Testcondition Environment ： Temperature ： 10 °C ——+30 °C Humidity ： ≤80% （ +40 °C） Atmospher ： 750mmkg±30mmkg Equipment ： NetworkAnalyzer:KEYSIGHTE5071C AnechiorChamber:Multi-probeMicrowave AnechoicChamber 4.22TestDataforElectricalPerformance: 4.22.1S11oftheAntenna: Marker(MH Z) 24002450250051505350550057005850 Returnlos s -16.16-17.15-17.98-7.81-10.72-11.55-13.98-15.60 VSWR1.341.351.322.381.841.701.511.38 ShenzhenShuodianElectronicTechnologyCo.,Ltd Date:2014-6-30Page number8-8 ShenzhenShuodianElectronicTechnologyCo.,Ltd ShenzhenShuodianElectronicTechnologyCo.,Ltd Pagenumber8-12 ShenzhenShuodianElectronicTechnologyCo.,Ltd Date:2014-6-30Page number9-8 ShenzhenShuodianElectronicTechnologyCo.,Ltd ShenzhenShuodianElectronicTechnologyCo.,Ltd Pagenumber9-12 4.22.2 Passivegain 、 efficiencyandRadiationPattern: Marker （MHz） 24002450250051505350550057005850 Gain（dBi） 3.162.613.211.792.402.803.472.58 Efficiency （%） 57.2160.2457.6638.5341.0045.4551.4545.06 ShenzhenShuodianElectronicTechnologyCo.,Ltd Date:2014-6-30Page number10-8 ShenzhenShuodianElectronicTechnologyCo.,Ltd ShenzhenShuodianElectronicTechnologyCo.,Ltd Pagenumber10-12 2450MHz： . 5350MHz： ShenzhenShuodianElectronicTechnologyCo.,Ltd Date:2014-6-30Page number11-8 ShenzhenShuodianElectronicTechnologyCo.,Ltd ShenzhenShuodianElectronicTechnologyCo.,Ltd Pagenumber11-12 5700MHz： ShenzhenShuodianElectronicTechnologyCo.,Ltd Date:2014-6-30Page number12-8 ShenzhenShuodianElectronicTechnologyCo.,Ltd ShenzhenShuodianElectronicTechnologyCo.,Ltd Pagenumber12-12 5.ProductPackaging Mannerofpacking: Packedinselfsealedbags,200pcseach. 6.DocumentResume DocumentNo. ReleaseDate2024/06/01 AuthorXiofengZeng ReviewLiMing RevisedHistory DateVersionRevisedRecord 2024/06/011.00NewProject

NOTE: This document is issued by Shenzhen Morlab Communications Technology Co., Ltd., the test report shall not be reproduced except in full without prior written permission of the company. The test results apply only to the particular sample(s) tested and to the specific tests carried out which is available on request for validation and information confirmed at our website. MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen, GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 1 of 120 REPORT No.：SZ24060118W02 TEST REPORT APPLICANT : Shenzhen Digitizing Fluid Technology Co., Ltd. PRODUCT NAME : DiFluid Omix MODEL NAME : CB101, CB101 Plus BRAND NAME : DiFluid FCC ID :2A26IDFT-CB101 STANDARD(S) :47 CFR Part 15 Subpart C RECEIPT DATE : 2024-06-25 TEST DATE : 2024-07-08 to 2024-08-02 ISSUE DATE : 2024-08-13 Edited by: Peng Mi (Rapporteur) Approved by: Shen Junsheng (Supervisor) MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen, GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 2 of 120 REPORT No.：SZ24060118W02 DIRECTORY 1. Summary of Test Result ·············································································· 4 1.1. Testing Applied Standards ········································································ 5 1.2. Test Equipment List ················································································· 6 1.3. Measurement Uncertainty ········································································· 8 1.4. Testing Laboratory ··················································································· 8 2. General Description ··················································································· 9 2.1. Information of Applicant and Manufacturer ················································· 9 2.2. Information of EUT ··················································································· 9 2.3. Channel List of EUT ··············································································· 11 2.4. Test Configuration of EUT ······································································· 12 2.5. Test Conditions ····················································································· 12 2.6. Test Setup Layout Diagram ····································································· 12 3. Test Results ···························································································· 15 3.1. Antenna Requirement ············································································ 15 3.2. Hopping Mechanism ·············································································· 15 3.3. Number of Hopping Frequency ································································ 16 3.4. Duty Cycle of Test Signal ········································································ 17 3.5. Maximum Peak Conducted Output Power ················································· 18 3.6. Maximum Average Conducted Output Power ············································ 19 3.7. 20 dB Bandwidth ··················································································· 20 3.8. Carried Frequency Separation ································································· 21 3.9. Time of Occupancy (Dwell time) ······························································ 22 3.10. Conducted Spurious Emissions and Band Edge ········································ 23 3.11. Conducted Emission ·············································································· 24 3.12. Restricted Frequency Bands ··································································· 25 3.13. Radiated Emission ················································································· 26 MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen, GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 3 of 120 REPORT No.：SZ24060118W02 Annex A Test Data and Result ······································································· 28 Change History Version Date Reason for change 1.0 2024-08-13 First edition MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen, GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 4 of 120 REPORT No.：SZ24060118W02 1. Summary of Test Result No. Section Description Test Date Test Engineer Result Method Determination /Remark 1 15.203 Antenna Requirement N/A N/A PASS No deviation 2 15.247(a) 15.247(h) Hopping Mechanism N/A N/A PASS No deviation 3 15.247(a) Number of Hopping Frequency Jul. 11, 2024 Li Zikai PASS No deviation 4 ANSI C63.10 Duty Cycle Jul. 11, 2024 Li Zikai PASS No deviation 5 15.247(b) Maximum Peak Conducted Output Power Jul. 11, 2024 Li Zikai PASS No deviation 6 15.247(b) Maximum Average Conducted Output Power Jul. 11, 2024 Li Zikai PASS No deviation 7 15.247(a) 20dB Bandwidth Jul. 11, 2024 Li Zikai PASS No deviation 8 15.247(a) Carrier Frequency Separation Jul. 11, 2024 Li Zikai PASS No deviation 9 15.247(a) Time of Occupancy (Dwell time) Jul. 11, 2024 Li Zikai PASS No deviation 10 15.247(d) Conducted Spurious Emission Jul. 11, 2024 Li Zikai PASS No deviation 11 15.207 Conducted Emission Jul. 16, 2024 Wang Deyong PASS No deviation 12 15.247(d) Restricted Frequency Bands Aug. 02, 2024Yang Lian PASS No deviation 13 15.209, Radiated Aug. 02, 2024 Yang L…

Text truncated - open the document above for the full version.
