2A2EL-AOJ-33BArm Blood Pressure Monitor

Arm Blood Pressure Monitor Instruction Manual Model: AOJ-33B Table of Contents 1. Unpacking Inspection ...................................... 1 2. Packing List ..................................................... 1 3. Safety Precautions .......................................... 2 4. Product Composition ....................................... 3 5. Intended Use / Instructions for Use ................. 3 6. Contraindication .............................................. 3 7. Product Parts .................................................. 4 8. Preparation ..................................................... 4 9. Function Setting .............................................. 5 10. How to Take Proper Measurements .............. 5 11. Contraindications, Precautions, Warnings and Prompt Instructions .................... 10 12. Common Q & A on Blood Pressure ............. 13 13. Abnormal Phenomena and Handling ........... 15 14. Cleaning and Disinfection ............................ 16 15. Upkeep and Maintenance ........................... 18 16. Specifications .............................................. 18 17. Appendix 1 EMC Information ....................... 20 1 Thank you for purchasing the Arm Blood Pressure Monitor. The device uses the oscillometric method of blood pressure measurement. It is intended for professional and domestic use in monitoring diastolic and systolic blood pressure and pulse rate. The device is suitable for use at home, at work, and on vacation. It is also suitable for daily blood pressure checks. 1. Unpacking Inspection Before use, please open the package carefully and check whether all the parts are available according to the following packing list and whether the parts are damaged during transporta- tion, and then install and operate in strict accordance with the manual. 2. Packing List No. Name Quantity 1 Arm Blood Pressure Monitor with Cuff 1 2 Type-C Charging Cable 1 3 Instruction Manual 1 4 Quick Start Guide 1 2 3. Safety Precautions The warnings and illustrations shown in the manual are intended to enable you to use the device safely and correctly, thus preventing harm to you and others, specific meanings of which are shown as follows: Symbols, marks and their meaning Warning information, refer to the attached document BF-type anti –shock degree for the application part Comply with local regulations Consult the instructions for use Keep dry Low voltage prompt Keep out of the sun Vertical upward IP22 The device is protected against splashing water. Water splashed against the enclosure from any direction shall have no harmful effects RoHS RoHS mark CE mark 3 Manufacturer Date of manufacture Serial number LOT Lot number EU authorized representative 4. Product Composition This device is composed of the main body and cuff. 5. Intended Use / Instructions for Use The Arm Blood Pressure Monitor is intended to measure the systolic pressure and diastolic pressure, as well as the pulse rate of adult person via non-invasive oscillometric technique at medical facilities or at home. 6. Contraindication No known contraindication existing. 4 Speaker 7. Product Parts Main Body HD LED Screen Systolic Blood Pressure Icon Systolic Blood Pressure Value “Irregular Heartbeat” Indicator Diastolic Blood Pressure Icon Diastolic Blood Pressure Value 8. Preparation Type-C Charging Please check the device's power before using it. When the battery runs out, please use the manufacturer-provided Type-C Charging Cable to charge the device till the “ ” indicator stops flashing. Memory Button Start/Stop Button Cuff Type-C Charging Port 5 9. Function Setting Voice On/Off Setting (for voice version only, optional function) In standby mode, press and hold the " " button, and then simultaneously press the " " button for about 3 seconds to enter the voice setting mode. Then press " " button to confirm the selection (as shown in the figure below); " " means turn on the sound, " " means turn off the sound. Voice On Voice Off 10. How to Take Proper Measurements (1) Preparation before measurement --Always measure in the same arm (generally the left arm). --Remain still and keep quiet during measurement. --Relax as much as possible and do not talk during measurement. --Measure your blood pressure at about the same time every day. --Do not measure right after physical exercise or a bath. Rest for 20 to 30 minutes before taking the measurement. 6 --Readings under the conditions listed below may affect results: Within an hour after dinner, after having wine, coffee, tea, sports; talking, being nervous, being in unsteady mood, bending forward, moving, room temperature dramatically changing during measu- ring; inside a moving vehicle, repeated and contin- uous measuring. (2) Wearing the Cuff Correctly 1) Unroll cuff. Place your arm inside it. (We strong- ly recommend to use your left arm.) 2) Make sure that the device's screen is positioned on your inner arm as illustrated in the diagram. The bottom edge of the cuff should be 0.79-1.18 inches (2 to 3 cm) above the inside elbow. 7 3) Tighten the cuff around your arm, so it can not move around your arm. Note: Repeated measurement may result in blood congestion in the arm, which will affect the meas- urement result. To avoid this situation, we advise that you can raise the left hand and hold the fist for several times, or take off the cuff and rest for at least 2-3 minutes before taking the measure- ment. (3) Measurement Tips • To take a measurement, you need to be relaxed and comfortably seated in a room with a comfo- rtable temperature. • Sit in a comfortable chair with your back and arm supported. • Keep your feet flat and your legs uncrossed. • The device should be placed on 8 your inner arm at the same level as your heart, with the arm resting comfortably on a table. Note: Please use only the manufacturer-provided cuff, as it has passed all required clinical trials. Any replacement of the original components with materials not specified or provided by…

Text truncated - open the document above for the full version.

External Photos

所示 Arm Blood Pressure Monitor Model: AOJ-33B Made in China Power Supply: D.C. 5V 1A Battery: Lithium-ion battery, D.C. 3.7V : 33B22060100001 FCC ID2A2EL-AOJ-33B 2022-06 IP22 Shenzhen AOJ Medical Technology Co., Ltd. Room 301&4F, Block A, Building A, Jingfa Intelligent Manufacturing Park, Xiaweiyuan, Gushu Community, Xixiang Street, Bao'an District, 518126 Shenzhen, CHINA : 33B22060105000

Internal Photos

FCC ID: 2A2EL-AOJ-33B RF Exposure Evaluation REQUIREMENT KDB447498 D01 General RF Exposure Guidance v06, Clause 4.3.1(a) [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 7.5 Where -f(GHz) is the RF channel transmit frequency in GHz -Power and distance are rounded to the nearest mW and mm before calculation -The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm, and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 4.1 f) is applied to determine SAR test exclusion. TEST RESULT Passed Not Applicable Type Conducted Average Power (dBm) Maximum Tune-up (dBm) Calculating data Limit Result BT BLE 1.81 2.00 0.4913 7.5 Pass Note: 1) The maximum antenna gain is -2dBi 2) The exposure evaluation safety distance is 0mm.

Page: 1 of 34 TEST REPORT For Bluetooth-LE Report No. ...................................... : CHTEW22070027 Report Verification: Project No.................................： SHT2206082505EW FCC ID ............................................. : 2A2EL-AOJ-33B Applicant’s name ........................... : Shenzhen AOJ Medical Technology Co., Ltd. Address ............................................. : Room 301&4F, Block A, Building A, Jingfa Intelligent Manufacturing Park, Xiaweiyuan, Gushu Community, Xixiang Street, Bao'an District, 518126 Shenzhen, CHINA Product Name ................................ : Arm Blood Pressure Monitor Trade Mark ....................................... : Model No. ......................................... : AOJ-33B Listed Model(s) ................................. : - Standard ......................................... : FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of receipt of test sample..........: Jun.29, 2022 Date of testing.............................: Jun.29, 2022- Jul.07, 2022 Date of issue...............................: Jul.08, 2022 Result .................. ........................: PASS Compiled by ( Position+Printed name+Signature): File administrator Echo Wei Supervised by (Position+Printed name+Signature): Project Engineer Kiki Kong Approved by (Position+Printed name+Signature): RF Manager Hans Hu Testing Laboratory Name ............. : Shenzhen Huatongwei International Inspection Co., Ltd. Address ............................................. : 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report merely correspond to the test sample. Report No.: CHTEW22070027 Page: 2 of 34 Date of issue: 2022-07-08 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V04 (2022-01) Contents 1. TEST S T AN D AR D S A N D R E P O R T V E R S I O N 3 1.1. Test Standards 3 1.2. Report version 3 2. TEST DESCRIPTION 4 3. SUMMARY 5 3.1. Client Information 5 3.2. Product Description 5 3.3. Radio Specification Description 5 3.4. Testing Laboratory Information 6 4. TEST CONFIGURATION 7 4.1. Test frequency list 7 4.2. Descriptions of Test mode 7 4.3. Test sample information 7 4.4. Support unit used in test configuration and system 8 4.5. Testing environmental condition 8 4.6. Statement of the measurement uncertainty 8 4.7. Equipment Used during the Test 9 5. TEST CONDITIONS AND RESULTS 11 5.1. Antenna Requirement 11 5.2. AC Conducted Emission 12 5.3. Peak Output Power 14 5.4. Power Spectral Density 15 5.5. 6dB bandwidth 16 5.6. 99% Occupied Bandwidth 17 5.7. Duty Cycle 18 5.8. Conducted Band edge and Spurious Emission 19 5.9. Radiated Band edge Emission 20 5.10. Radiated Spurious Emission 22 6. TEST SETUP PHOTOS 27 7. EXTERNAL AND INTERNAL PHOTOS 29 8. APPENDIX REPORT 34 Report No.: CHTEW22070027 Page: 3 of 34 Date of issue: 2022-07-08 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V04 (2022-01) 1. TEST STAND ARDS AND REPORT VERSION 1.1. Test Standards The tests were performed according to following standards: ‒ FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz ‒ ANSI C63.10:2013: American National Standard for Testing Unlicensed Wireless Devices ‒ KDB 558074 D01 15.247 Meas Guidance v05r02: Guidance for Compliance Measurements on Digital Transmission System, Frequency Hopping Spread Spectrum System, and Hybrid System Devices Operating under Section 15.247 of The FCC Rules 1.2. Report version Revision No. Date of issue Description N/A 2022-07-08 Original Report No.: CHTEW22070027 Page: 4 of 34 Date of issue: 2022-07-08 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V04 (2022-01) 2. TEST DESCRIPTION Report clause Test Items Standard Requirement Result Test Engineer 5.1 Antenna Requirement 15.203/15.247(c) PASS Xiaoqin Li 5.2 AC Conducted Emission 15.207 PASS Xiaoqin Li 5.3 Peak Output Power 15.247(b)(3) PASS Xiaoqin Li 5.4 Power Spectral Density 15.247(e) PASS Xiaoqin Li 5.5 6dB Bandwidth 15.247(a)(2) PASS Xiaoqin Li 5.6 99% Occupied Bandwidth - PASS *1 Xiaoqin Li 5.7 Duty cycle - PASS *1 Xiaoqin Li 5.8 Conducted Band Edge and Spurious Emission 15.247(d)/15.205 PASS Xiaoqin Li 5.9 Radiated Band Edge Emission 15.205/15.209 PASS Xiaoqin Li 5.10 Radiated Spurious Emission 15.247(d)/15.205/15.209 PASS Xiaoqin Li Note: ‒ The measurement uncertainty is not included in the test result. ‒ *1: No requirement on standard, only report these test data. Report No.: CHTEW22070027 Page: 5 of 34 Date of issue: 2022-07-08 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V04 (2022-01) 3. SUMMARY 3.1. Client Information Applicant: Shenzhen AOJ Medical Technology Co., Ltd. Address: Room 301&4F, Block A, Building A, Jingfa Intelligent Manufacturing Park, Xiaweiyuan, Gushu Community, Xixiang Street, Bao'an District, 518126 Shenzhen, CHINA Manufacturer: Shenzhen AOJ Medical Technology Co., Ltd. Address: Room 301&4F, Block A, Building A, Jingfa Intelligent Manufacturing Park, Xiaweiyuan, Gushu Community, Xixiang Street, Bao'an District, 518126 Shenzhen, CHINA Factory: Shenzhen AOJ Medical Technology Co., Ltd. Address: Room 301&4F, Block A, Building A, Jingfa Intelligent Manufacturing Park, Xiaweiyuan, Gushu Community, Xixiang Street, Bao'an District, 518126 Shenzhen, CHINA 3.2. …

Text truncated - open the document above for the full version.

ProjectNo.:SHT2206082505EWRadioSpecification:BluetoothBLE ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 1 of 14 APPENDIXREPORT ProjectNo.SHT2206082505EWRadioSpecificationBluetoothBLE TestsampleNo.YPHT22060825004ModelNo.AOJ-33B Starttestdate2022-07-05Finishdate2022-07-05 Temperature 26.1°C Humidity41% TestEngineerXiaoqinLiAuditor Appendix clause TestitemResult APeakOutputPowerPASS BPowerSpectralDensityPASS C6dBBandwidthPASS D99%OccupiedBandwidthPASS EDutycyclePASS FBandedgeandSpuriousEmissions(conducted)PASS ProjectNo.:SHT2206082505EWRadioSpecification:BluetoothBLE ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 2 of 14 AppendixA ： PeakOutputPower TypeChannel PeakOutputpower (dBm) AverageOutput power(dBm) Limit(dBm)Result BT-BLE 001.821.81 ≤30.00Pass191.811.79 391.281.26 ProjectNo.:SHT2206082505EWRadioSpecification:BluetoothBLE ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 3 of 14 CH00 Date: 5.JUL.2022 09:26:20 CH19 Date: 5.JUL.2022 09:30:23 CH39 Date: 5.JUL.2022 09:32:51 ProjectNo.:SHT2206082505EWRadioSpecification:BluetoothBLE ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 4 of 14 AppendixB ： PowerSpectralDensity TypeChannel PowerSpectral Density(dBm/3KHz) Limit(dBm/3KHz)Result BT-BLE 00-14.21 ≤8.00Pass19-14.36 39-14.92 ProjectNo.:SHT2206082505EWRadioSpecification:BluetoothBLE ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 5 of 14 CH00 Date: 5.JUL.2022 09:26:41 CH19 Date: 5.JUL.2022 09:30:42 CH39 Date: 5.JUL.2022 09:33:12 ProjectNo.:SHT2206082505EWRadioSpecification:BluetoothBLE ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 6 of 14 AppendixC ： 6dBbandwidth TypeChannel6dBBandwidth(kHz)Limit(kHz)Result BT-BLE 00806.00 ≥500Pass19820.00 39822.00 ProjectNo.:SHT2206082505EWRadioSpecification:BluetoothBLE ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 7 of 14 CH00 Date: 5.JUL.2022 09:25:52 CH19 Date: 5.JUL.2022 09:29:54 CH39 Date: 5.JUL.2022 09:32:22 ProjectNo.:SHT2206082505EWRadioSpecification:BluetoothBLE ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 8 of 14 AppendixD ： 99%OccupiedBandwidth TypeChannel 99%Occupied Bandwidth(MHz) Limit(kHz)Result BT-BLE 001.11 -Pass191.11 391.10 ProjectNo.:SHT2206082505EWRadioSpecification:BluetoothBLE ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 9 of 14 CH00 Date: 5.JUL.2022 09:26:05 CH19 Date: 5.JUL.2022 09:30:08 CH39 Date: 5.JUL.2022 09:32:36 ProjectNo.:SHT2206082505EWRadioSpecification:BluetoothBLE ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 10 of 14 AppendixE ： Dutycycle TestFrequency （MHz） T ontime for singleburst (ms) T period (ms)Dutycycle 1/T ontime (kHz) 24400.291.0527.6%3.45 Date: 5.JUL.2022 09:29:35 ProjectNo.:SHT2206082505EWRadioSpecification:BluetoothBLE ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 11 of 14 AppendixF ： BandedgeandSpuriousEmissions(conducted) TestItem:Bandedge CH00 Date: 5.JUL.2022 09:26:56 CH39 Date: 5.JUL.2022 09:33:27 ProjectNo.:SHT2206082505EWRadioSpecification:BluetoothBLE ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 12 of 14 TestItem:SE CH00 Referencelevel Date: 5.JUL.2022 09:27:09 CH00 30MHz~1000MHz Date: 5.JUL.2022 09:27:30 CH00 1GHz~26GHz Date: 5.JUL.2022 09:27:52 ProjectNo.:SHT2206082505EWRadioSpecification:BluetoothBLE ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 13 of 14 CH19 Referencelevel Date: 5.JUL.2022 09:30:55 CH19 30MHz~1000MHz Date: 5.JUL.2022 09:31:16 CH19 1GHz~26GHz Date: 5.JUL.2022 09:31:38 ProjectNo.:SHT2206082505EWRadioSpecification:BluetoothBLE ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 14 of 14 CH39 Referencelevel Date: 5.JUL.2022 09:33:39 CH39 30MHz~1000MHz Date: 5.JUL.2022 09:34:01 CH39 1GHz~26GHz Date: 5.JUL.2022 09:34:23 --------EndofReport--------

TEST SETUP PHOTOS Radiated Emission AC Conducted Emission
