AInanny A4 Kit Plus Smart baby monitor User manual Email: [email protected] Phone: 1-866-999-7868, Mon-Fri 9AM-5PM (PT) Toll free for USA&Canada, subject to charges for other regions Phone Service Language only available in English [email protected] EN Product description Please read this manual carefully before using the product and keep it properly. Label information is located on the side of the camera. Packing list OK UP L O C K U N L O C K CameraMonitorHeadgearBracket Screw package Reset pinPower cablePower adapterQuick guide Product nameAInanny A4 Kit PlusAInanny A4-2Cam Kit PlusAInanny A4-4Cam Kit Plus Packing list Camera X1 Monitor X1 Headgear X1 Bracket X1 Screw package X1 Reset pin X1 Power cable X2 Power adapter X2 Quick guide X1 Camera X2 Monitor X1 Headgear X2 Bracket X2 Screw package X2 Reset pin X1 Power cable X3 Power adapter X3 Quick guide X1 Camera X4 Monitor X1 Headgear X4 Bracket X4 Screw package X4 Reset pin X1 Power cable X5 Power adapter X5 Quick guide X1 Speake r Microphone Call/Pairing Status light RESET TF card slot [email protected] EN Status light• Flashing red light (slow): wait for network configuration • Flashing red light(fast): connecting the network • Fixed blue light on: camera is working correctly • Fixed red light on: network is malfunctional Call/PairingPress to make a call; long press to pair RESETPress and hold for 5s to reset the camera (if you have modified settings, they will return to factory defaults) Microphone Status light of charging Status light of using Zoom in/out Menu Dire ction OK Call Back Speak er ON/O FF button Antenna Stand TF card slot RESET Status light of charging• Orange light: charging • Green light: fully charged Status light of using• Yellow light: monitor on • No light: monitor off AntennaAdjust the angle to get better signals ON/OFF buttonLong press 5s to turn on/turn off the monitor Zoom in/outZoom the image in 1X, 2X or 4X [email protected] EN MenuOn the homepage, press to enter the menu interface; On the homepage, long press to enter the setting interface DirectionControl the rotation directions; select the menu items OKConfirm or awake the screen CallMake a call after pressing the button BackPress to back up; On the homepage, long press to stop playing music Installation Find a position where you can get the desired field of view. You can put the camera on a flat surface or mount it on the wall. Mounting on the wall Tips: • The installation wall needs to be able to bear at least 3 times the total weight of the camera. • In case your camera is mounted upside down, its picture shall be flipped as well. Please set from Arenti App >> Device (tap device to live video page) >> Settings >> Basic Function >> Image Setting >> Screen Flip. • Do not point the camera toward a glass window. Or it may result in poor image performance because of the window glare by infrared LEDs, ambient lights, or status light. Camera using tips • Work indicator: The blue light indicator can be turned off manually when the camera is in working condition. Set from: App>> Device (tap device to live video page) >> Settings >> Work Indicator. • Live video viewing: In the camera control interface of the App you can view the camera monitoring in real-time, adjust the resolution, capture images, record video, and make 2-way talking. • Infrared night vision: [email protected] EN The camera can automatically switch to night vision mode (black&white view) at night according to the degree of change in surrounding light. With built-in invisible red Infrared LED lights, the night vision distance can reach 10 meters, and it can be viewed super clearly in the dark. • Motion detection: The camera can detect movement changes in the camera view and you will receive push alerts from App when movement is detected. Set from: App >> Device (tap device to live video page) >> Settings >> Alert Settings >> Motion Detection. Specifications ModelAInanny A4 Angle of view100° Working temp0°Cto 40°C Local storageTF card(up to 256GB) Resolution2560x1440 Size70x63x120 mm Power inputDC 5V/1A ConsumptionUp to 4.5W Supported phone OSiOS 9 / Android 5.0 or later 2.4GHz Wi-Fi2412-2462MHz (Max. power<30dBm ) 5GHz Wi-Fi5150-5850MHz (Max. power<23dBm ) Wi-Fi Halow905-925MHz (Max. power<30dBm ) Bluetooth2400-2483.5MHz (Max. power<20dBm ) ModelAInanny-Screen2 Battery capacity3350mAh Working temp0°Cto 40°C Local storageTF card(up to 128GB) Resolution720P (1280x720) Size157x81x40mm Power inputDC 5V/1A Wi-Fi Halow905-925MHz (Max. power<30dBm ) [email protected] EN Product configuration Scan QR code to download and install the Arenti App. Or you can search "Arenti" on App Store (iOS) or Google Play (Android). Registration Open the App. If you are a new user, tap to create a new account and follow the prompts to complete account setup. Note: Before creating a new account, please read the Privacy Policy and Terms of Use carefully. • Set up a router Make sure the router is connected to the Wi-Fi network. Please set the parameters of the router before connecting to the Wi-Fi network, and record the SSID and password of your Wi-Fi. [email protected] EN Please keep the network available • Power on the device Power on the camera. Status light flashing red indicates that the camera is ready for pairing. Pairing method 1: pairing via QR code on device Open App home page, click "+" >> "Scan Code", then scan the QR code pasted on the device casing with the App of your phone. The device will then appear on the page, click the device. Scan the QR code on device Select the Wi-Fi network and input the password, and press "Next". Make sure that your phone has connected to a fluent and steady Wi-Fi already. Note: The number of bits in the SSID and passwords of the router should not exceed 31 digits. [email protected] EN The device can be added to App after the network connection. Note: When pairing, please put the camera and mobile phone close to the router. If camera is not in the red slow blinking aft…
