Wireless Charger InstructionsConnect to Wall AdapterProduct ParametersFCC Warning Statement Applicable equipments User Manual Connect the adapter and the charger with the provided USB cable. Power Adapter USB-C Cable Type Cinput Input: 5V---2A/9V---2A/12V---1.5A Output: 5W/7.5W/10W/15W(self adjustable) Frequency: Dimension: 118*70*78mm Net Weight: 125g Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference in a residential installation.This equipmentgenerates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that towhich the receiver is connected. --Consult the dealer or an experienced radio/TVtechnician for help. Working Condition Power on Standby Charging Charging Completed FOD & Error Plug the Wall Adapter into the socket. Reminder: You'll need a USB-C charger LED indicator Color&Status Apple: iPhone 12 /12 Pro /12 Pro Max /12 Mini iPhone 13 /13 Pro /13 Pro Max /13 Mini iPhone 14 /14 Plus / 14 Pro /14 Pro Max iPhone 15 /15 Plus / 15 Pro /15 Pro Max Others: Coil LED Indicator Tips 1.Do not disassemble or throw into fire or water to avoid causinga short circuit. 2. Do not use wireless charger in extremely hot, humid or corrosiveenvironment. 3.Do not use near magnetic bank card or lC card to avoidmalfunctioning. 4. Keep out of reach of children and pets. 5. The images in this manual are sketch drawing of actual product only,actual product might beslightly different. *Adapter is not included in this package, please purchase in separately 12345 Green light is on for 0.5 seconds ,blue light is on for 0.5 ,and the blue and green light is on for 0.5 seconds Green light on,and turn off after 30 seconds Blue light off Blue and green light flashing Blue light breathing,and turn off after 30 seconds DGPLUS Qi-compatible Phone with Magnetic Case iPhone 16 Series and Later 113kHz-205kHz The FCC certification of this device refers to RF exposure testing perfomed in typical operating conditions,where a person is no closer than 20 centimeters from the device surface at all times, except for non-repetitivepatterns with transient time intervals in the order of a second.Only in the stated conditions,the device is shownto fully comply with the FCC RF Exposure requirements of KDB 447498. arning Statement W IC This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. The equipment meets the ISED radiation exposure limits set for an uncontrolled environment. During the operation of the device, a distance of 10cm should be kept around the device and above the top surface of the device. Cet appareil est conforme aux CNR exemptes de licence d'Industrie Canada . Son fonctionnement est soumis aux deux conditions suivantes : ( 1 ) Ce d ispositif ne peut causer d'interfé rences ; et ( 2 )Ce d ispositif doit accepter toute interférence ,y compris les interfé rences qui peuvent causer un mauvais fonctionnement de l'appareil. L’équipement respecte les limites d’exposition aux rayonnements ionisants fixées pour un environnement non contr?lé . Pendant le fonctionnement du d ispositif, une distance de 10cm devrait être maintenue autour du d ispositif et au-dessus de la surface supé rieure du d ispositif.
-Guanyu(Dongguan)IntelligentTechnologyCo.,Ltd- FederalCommunicationsCommission AuthorizationandEvaluationDivision EquipmentAuthorizationBranch 7435OaklandMillsRoad Columbia,MD21046 4/3/24 U.S.AgentDesignation Guanyu(Dongguan)IntelligentTechnologyCo.,Ltdacknowledgestheirconsentforthefollowingcontact locatedintheUnitedStatestoactastheiragentforserviceofprocessfortheequipmentforwhichauthorization issought(FCCID:2A2NS-GY-Q7402): NameandcompanyofU.S.agent: REPAmericaLLC PhysicalU.S.addressofagent:BenXU,6510SAcademyBlvd,SteA#523,ColoradoSprings,CO 80906 FRNofU.S.agent: 0034192500 EmailaddressofU.S.agent: [email protected] REPAmericaLLCacknowledgestheirobligationtoacceptserviceofprocessonbehalfof Guanyu(Dongguan)IntelligentTechnologyCo.,Ltd. Guanyu(Dongguan)IntelligentTechnologyCo.,LtdwiththeFRN0031164734acceptsitsobligation tomaintainanagentforserviceofprocessintheUnitedStatesfornolessthanoneyearaftereitherthegrantee haspermanentlyterminatedallmarketingandimportationoftheapplicableequipmentwithintheU.S.,orthe conclusionofanyCommission-relatedadministrativeorjudicialproceedinginvolvingtheequipment,whicheveris later. Bysigningthisform,weconfirmtheaboveandthatweareawareoftheapplicationrequirementslistedunder§ 2.911(d)(7). TheinformationprovidedinthisletterisbasedonthereferencedrulepartsofTitle47oftheCFRaswellasKDB 986446D01. Anexpirationdateforthisletterdoesnotexist.IncasetheU.S.agentchanges,thegranteeisobligatedtonotify theFCCwithin30daysviathegrantingTCB. Sincerely, Signature ManFangWu generalmanager Guanyu(Dongguan)IntelligentTechnologyCo.,Ltd Signature BenXU Manager REPAmericaLLC 4 8 _ [ m o d e l ] U S _ A g e n t _ 2 . 9 1 1 ( d ) ( 7 ) - U , V 0 5
Page 1 of 4 FCC ID: 2A2NS-GY-Q7402 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. EUT Constructional Details External EUT Photo Photo 1 Photo 2 Page 2 of 4 FCC ID: 2A2NS-GY-Q7402 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 3 Photo 4 Page 3 of 4 FCC ID: 2A2NS-GY-Q7402 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 5 Photo 6 Page 4 of 4 FCC ID: 2A2NS-GY-Q7402 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 7 ---The End---
Label Size: L20mm * W15mm 1. The label is silk-screen on the sample Wireless Charger Model Name: GY-Q740-2 FCC ID: 2A2NS-GY-Q7402 L W
Page 1 of 3 FCC ID: 2A2NS-GY-Q7402 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. EUT Constructional Details Internal EUT Photo Photo 1 Photo 2 Page 2 of 3 FCC ID: 2A2NS-GY-Q7402 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 3 Photo 4 Antenna Page 3 of 3 FCC ID: 2A2NS-GY-Q7402 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Photo 5 Photo 6 ------End------
Page 1 of 8 Report No.: AITSZ24031502W2 RF Exposure Evaluation FCC ID: 2A2NS-GY-Q7402 1 Measuring Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. According KDB680106 D01: KDB 680106 D01 Wireless Power Transfer v04. 2 Requirements According to the item 3 of KDB 680106 D01v04: Inductive wireless power transfer applications that meet all of the following requirements are excluded from submitting an RF exposure evaluation. (1) Mobile Device and Portable Device Configurations (2) Equipment Authorization Procedures for Devices Operating at Frequencies Below 4 MHz (3) The aggregate H-field strengths anywhere at or beyond 15 cm surrounding the device, and 20 cm away from the top surface. Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Page 2 of 8 Report No.: AITSZ24031502W2 3 Test Setup 4 Test Procedure 1) The RF exposure test was performed in anechoic chamber. 2) The measurement probe was placed at test distance (15 cm from all sides and 20 cm from the top) which is between the edge of the charger and the geometric center of probe. 3) The highest emission level was recorded and compared with limit as soon as measurement of each points (A, B, C, D, E,F) were completed. 4) The EUT was measured according to the dictates of KDB 680106 D01 Wireless Power Transfer v04. Remark:The EUT’s test position A, B, C, D,E and F is valid for the E and H field measurements. Page 3 of 8 Report No.: AITSZ24031502W2 5 Equipment Approval Considerations The EUT does comply with KDB 680106 D01 as follow table. Requirements of section 5 of KDB 680106 D01 Yes / No Description Mobile Device and Portable Device Configurations Yes Mobile Device Equipment Authorization Procedures for Devices Operating at Frequencies Below 4 MHz Yes The device operate in the frequency range 113kHz-205kHz RF Exposure compliance may be ensured only for a minimum separation distance that is greater than 20 cm, while use conditions at smaller distances can still be considered unlikely. Yes The EUT H-field strengths at 15 cm surrounding the device and 20 cm above the top surface. Page 4 of 8 Report No.: AITSZ24031502W2 6 Description of the test mode Equipment under test was operated during the measurement under the following conditions: Test Mode Description Mode 1 AC Adapter + EUT + Wireless charger receiver Record Mode 2 Test the EUT in idle mode. Pre-tested Note: 1. All test modes were pre-tested, but we only recorded the worst case in this report. 7 Peripheral List 8 Test Instruments list Test Equipment Manufacturer Model No. SN. Cal.Date (mm-dd-yy) Cal.Due date (mm-dd-yy) Magnetic Amplitude and Gradient Probe System SPEAG MAGPy-8H3D+E3D V2 & MAGPy-DAS V2 SZ186-0 6 & 3061 04.13.2023 04.12.2024 No. Equipment Manufacturer Model No. Serial No. Power cord signal cable 1 Wireless charger receiver YBZ 15W N/A N/A N/A Page 5 of 8 Report No.: AITSZ24031502W2 9 Test Result MPE Test distance Battery levels Probe from EUT Side E-field (V/m) H-field (A/m) 20cm < 1% Top 14.15 0.51 15cm < 1% Top 14.00 0.54 15cm < 1% Left 14.11 0.58 15cm < 1% Right 14.16 0.55 15cm < 1% Front 14.22 0.46 15cm < 1% Rear 14.36 0.44 Limit 614 1.63 Margin Limit (%) 2.34% 35.58% MPE Test distance Battery levels Probe from EUT Side E-field (V/m) H-field (A/m) 20cm < 50% Top 13.43 0.42 15cm < 50% Top 12.11 0.35 15cm < 50% Left 12.83 0.45 15cm < 50% Right 12.99 0.47 15cm < 50% Front 13.37 0.33 15cm < 50% Rear 12.82 0.43 Limit 614 1.63 Margin Limit (%) 2.19% 28.83% MPE Test distance Battery levels Probe from EUT Side E-field (V/m) H-field (A/m) 20cm < 99% Top 12.89 0.29 15cm < 99% Top 11.51 0.28 15cm < 99% Left 12.23 0.19 15cm < 99% Right 12.51 0.36 15cm < 99% Front 12.53 0.30 15cm < 99% Rear 12.17 0.27 Limit 614 1.63 Margin Limit (%) 2.10% 22.09% Note: All test modes were pre-tested, but we only recorded the worst case in this report. Page 6 of 8 Report No.: AITSZ24031502W2 10 Test Setup photo Front Left Page 7 of 8 Report No.: AITSZ24031502W2 Rear Right Page 8 of 8 Report No.: AITSZ24031502W2 Top ***End of report***
Page 1 of 24 Report No.: AITSZ24031502W1 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. FCC TEST REPORT Client Information: Applicant: Guanyu(Dongguan) Intelligent Technology Co.,Ltd Applicant add.: 402 Room, NO#801 Building, Zhen'an Middle Road, Changan Town, Dongguan City Guangdong, China Manufacturer: Guanyu(Dongguan) Intelligent Technology Co.,Ltd Manufacturer add.: 402 Room, NO#801 Building, Zhen'an Middle Road, Changan Town, Dongguan City Guangdong, China Product Information: Product Name: Wireless Charger Model No.: GY-Q740-2 Brand Name: N/A FCC ID: 2A2NS-GY-Q7402 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Prepared By: Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Tel.: +86 0755-230967639 Fax.: +86 0755-230967639 Date of Receipt: Mar. 15, 2024 Date of Test: Mar. 15, 2024 ~ Mar. 22, 2024 Date of Issue: Mar. 22, 2024 Test Result: Pass This device described above has been tested by Guangdong Asia Hongke Test Technology Limited and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. Note: This report shall not be reproduced except in full, without the written approval of Guangdong Asia Hongke Test Technology Limited, this document may be altered or revised by Guangdong Asia Hongke Test Technology Limited, personal only, and shall be noted in the revision of the document. This test report must not be used by the client to claim product endorsement. Reviewed by: Approved by: Sean She Eder Zhan Page 2 of 24 Report No.: AITSZ24031502W1 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. 1 Contents Page COVER PAGE 1 CONTENTS ........................................................................................................................................................... 2 2 TEST SUMMARY .................................................................................................................................................. 5 2.1 STATEMENT OF THE MEASUREMENT UNCERTAINTY ............................................................................................. 5 2.2 MEASUREMENT UNCERTAINTY ............................................................................................................................ 5 3 TEST FACILITY ..................................................................................................................................................... 6 3.1 DEVIATION FROM STANDARD ............................................................................................................................... 6 3.2 ABNORMALITIES FROM STANDARD CONDITIONS .................................................................................................... 6 3.3 TEST LOCATION ................................................................................................................................................. 6 4 GENERAL INFORMATION ................................................................................................................................... 7 4.1 EUT TEST MODE ............................................................................................................................................... 8 4.2 DESCRIPTION OF TEST SETUP............................................................................................................................. 8 4.3 PERIPHERAL LIST ............................................................................................................................................... 9 4.4 EUT PERIPHERAL LIST ....................................................................................................................................... 9 5 EQUIPMENTS LIST FOR ALL TEST ITEMS ..................................................................................................... 10 6 CONDUCTED EMISSION TEST ......................................................................................................................... 11 6.1 CONDUCTED EMISSION MEASUREMENT ................................................................................................ 11 6.2 POWER LINE CONDUCTED EMISSION LIMITS ........................................................................................... 11 6.3 TEST PROCEDURE ...................................................................................................................................... 11 6.4 DEVIATION FROM TEST STANDARD ......................................................................................................... 11 6.5 TEST SETUP ................................................................................................................................................. 12 6.6 EUT OPERATING CONDITIONS .................................................................................................................. 12 6.7 TEST RESULT .................................................................................................................................................. 13 7 RADIATED EMISSION MEASUREMENT .......................................................................................................... 15 7.1 RADIATED EMISSION LIMITS .............................................................................................................................. 15 7.2 ANECHOIC CHAMBER TEST SETUP DIAGRAM ..................................................................................................... 16 7.3 TEST PROCEDURE .............................................…
Text truncated - open the document above for the full version.
东莞市德弗力五金电子材料有限公司 Dongguan city DFL Electronic Technology Co.,LTD 承 认 书 客户名称(CUSTOMER): 客户料号(PART NO.): 品 名(DESCRIPTION): 规格(SPECIFICATION): 东莞市石碣镇新风西路107号 电话:0769-86016320 传真:0769-86372427 第 1 页 共 2 页 日 期(DATE): 0.08*105P丝包线,∅38.5x15,电感量6.7uH,隔磁片 ∅44X0.8(开线槽)磁边起180 MM 20230331 SPECIFICATION FOR APPROVEAL ZLGD A1-0059 本司确认(TRX APPROVAL) 制作 审核 客户确认(CUSTOMER APPROVAL) 确认结果(Result): 合格不合格 其它 承认日期 工程 批准 承认日期 潘锡明 邱志辉 20230331 线圈+磁片 ZLGD make check Engineer Approver 113kHz-205kHz Operation frequency: Antenna gain: 0dBi 产品型号: SPECIFICATION 二、原理图(schematic diagram:) 拟制/日期PREPARED BY/DATE 审核/日期CHECKED BY/DATE 东莞市德弗力五金电子材料有限公司 Dongguan city DFL Electronic Technology Co.,LTD DESC Rev:A 版本 Customer: Date: Description: 一、尺寸DIMENSION:(mm) A B C D G H I 注: 三、绕线参数(WindingSpecification:) 序号 NO. 端子 TERMINAL 线径 WIRE 圈数 Turns 绕线方向 Winding Direction 四、电气特性 ELECTRICAL CHARACTERISTICS: 温度 TEMPERATURE:25±10°C,湿度 RELATIVE HUMIDITY:65±20% 序号 NO. 客户/日期CUSTOMEU/DATE 端子 TERMINAL 项目 ITEM 标准 SPECIFICATION 测试条件 TEST FREQUENCY 测试仪器 TEST EQUIPMENTS 1 2 3 4 IND. IND. Q值 DCR 20230331 44.0±1.0 15.0±1.0 38.52.0 1 6.8UH(必须在6.5-7.1内) 100KHZ/1.0V 1.线圈反贴硬磁,磁 片有孔带双槽且磁片 厚度在0.7-0.90之间, 线圈位置居中 2.磁片背面贴带耳朵 白色双面背胶 3.线圈出线位置缠 8mm高温胶带 4.线圈不可松线 J K L SHDA 1062 180 .05.0 0.08X105P丝包线 12TS 逆时针 3.5±1.5 B C A E D ZLGD E F ZLGD0-15*38.5 -180 -FR 第 2 页 共 2 页 + + Coil + diskette
Page 1 of 2 FCC ID: 2A2NS-GY-Q7402 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Test Setup Photo DCD Conduction Radiation (9KHz-30MHz) Page 2 of 2 FCC ID: 2A2NS-GY-Q7402 Guangdong Asia Hongke Test Technology Limited B1/F, Building 11, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China. Radiation (30MHz-1000MHz) ------End------
