FRANCAIS – Manuel d’instruction SCX Design® Bamboo 10W Wireless Charger Reference: W16.30L / 32492 Color: Bamboo Veuillez lire attentivement le mode d'emploi avant d'utiliser le produit. Spécifications du produit : Matériaux : Bambou et ABS avec finition douce au toucher Dim ensions de l'article : 140 × 70 mm Poids : 130g Entrée : 5V/2A, 9V/2A Sortie : DC 5V/1A, 9 V/1,12 A Sortie : 5W, 10W Le produit inclus un câble de chargement Type C. Fonctionnalités Assemblez les 2 parties afin de composer le support. Branchez le côté type C du câble du chargeur sans fil à la station de charge sans fil, branchez le côté USB du câble au port USB de votre PC ou de votre ordinateur portable. Assurez-vous que votre téléphone est compatible pour le chargement sans fil. Posez votre appareil avec la fonction de chargement sans fil activée sur la surface de chargement sans fil. Attention! Ne pas utiliser si l'équipement est endommagé. Certains boîtiers de téléphone peuvent bloquer la fonction de chargement sans fil. Ne placez pas d’autres objets métalliques entre l’appareil mobile et la station de charge sans fil. Contrôlez la charge de batterie de votre téléphone grâce à l’icône de charge qui s’affiche sur l’écran de votre appareil. Si l’appareil mobile n’est pas placé exactement sur la surface de charge, il peut ne pas charger correctement. N’exposez pas ce dispositif à l’humidité ou à des sources de chaleur. Gardez le produit hors de portée des enfants. Ne jamais stocker ou utiliser ce produit à des températures inférieures à 32 °F (0 °C) ou au-dessus de 115 °F (45 °C). ENGLISH – Instruction Manual SCX Design® Bamboo 10W Wireless Charger Reference: W16.30L / 32492 Color: Bamboo Please read the instruction manual carefully before using the product. Product Specifications Materials: Bamboo & ABS with soft touch finish Item dimension: 140×70 mm Weight: 130g Inp ut: 5V/2A, 9V/2A Output: DC 5V/1A, 9V/1.12A Output: 5W, 10W The product includes a USB TYPE C charging cable. Functionalities Assemble the charger by attaching the two pieces. Connect the USB C cable to the wireless charging pad, connect the USB to the USB port of your PC/laptop or charger. Make sure your phone is compatible for wireless charging. Put your wireless charging enabled device on the wireless charging surface. Warning! Some phone cases may block the wireless charging. Do not place other materials between the mobile device and the wireless charger pad. Check your mobile device’s battery percentage using the charging icon displayed on the screen of your phone. When the mobile device is not placed on the charging surface accurately, your mobile device may not charge properly. Please do not expose this device to moisture or heat sources. Keep the product out of reach of children. Using your phone while charging it can cause higher temperatures. FCC Statement: This device complies with Part 18 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation. Never Store or use this product in temperatures below 32°F (0°C) or above 115°F (45°C). IMPORTER FOR USA AND CANADA IMPORTATEUR POUR LES ETATS-UNIS ET LE CANADA Distributed by Koozie Group Distribué par Koozie Group 14421 Myerlake Circle Clearwater, FL 33760 USA IMPORTER FOR USA AND CANADA IMPORTATEUR POUR LES ETATS-UNIS ET LE CANADA Distributed by Koozie Group Distribué par Koozie Group 14421 Myerlake Circle Clearwater, FL 33760 USA Importé en Europe par SCX Design 68 bis boulevard Pereire 75017 Paris France Importé en Europe par SCX Design 68 bis boulevard Pereire 75017 Paris France Manuel d’instruction Instruction Manual Gebrauchsanweisung DEUTSCH – Bedienungsanleitung SCX Design® Bamboo 10W Wireless Charger Reference: W16.30L / 32492 Color: Bamboo Bitte lesen Sie die Bedienungsanleitung sorgfältig durch bevor Sie das Gerät in Betrieb nehmen. Produktspezifikationen Material: Bambus & ABS mit Soft-Touch-Finish Artikelabmessung: 140×70 mm Gewicht: 130g Eingang: 5V/2A, 9V/2A Ausgang: DC 5V/1A, 9V/1,12A Ausgang (drahtlos): 5W, 10W Das Produkt enthält ein USB-Ladekabel vom Typ C. Warnung! Bestimmte Telefonetuis können kabelloses Laden verhindern. Legen Sie keine Fremdkörper wie Metallobjekte, Magnete oder Magnetstreifenkarten zwischen das Mobilgerät und das kabellose Ladepad. Überprüfen Sie anhand des Ladesymbols auf dem Bildschirm Ihres Telefons den Ladezustand Ihres Telefonakkus. Wenn das Mobilgerät nicht korrekt auf der Ladefläche platziert wird, wird es möglicherweise nicht korrekt aufgeladen. Bitte schützen Sie das Gerät vor Feuchtigkeit und Wärmequellen. Sie das Produkt von Kinder fern. Lagern oder verwenden Sie dieses Produkt niemals bei Temperaturen unter 0 °C (32 °F) oder über 45 °C (115 °F). Funktionen Bauen Sie die 2 Teile zusammen, um die Stütze zu bilden Schließen Sie das kabellose Ladegerät an. Schließen Sie das USB-Kabel Typ C an das kabellose Ladegerät an. Schließen Sie den USB-Anschluss an den USB-Anschluss Ihres PCs / Laptops oder Ladegeräts an. Stellen Sie sicher, dass Ihr Telefon für das kabellose Laden kompatibel ist. Stellen Sie Ihr Gerät mit aktivierter drahtloser Aufladung auf die Oberfläche für die drahtlose Aufladung. Importiert von SCX Design 74 avenue de Villiers 75017 Paris - France

SCX DESIGN Date: 12/27/2021 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: 2A2OH-W1630L To whom it may concern: We, the undersigned, hereby authorize SGS-CSTC Standards Technical Services Co., Ltd. (SGS) Guangzhou Branch and Kobe Jian in SGS-CSTC Standards Technical Services Co., Ltd. (SGS) Shenzhen Branch to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with SCX DESIGN This authorization is valid until further written notice from the applicant. Sincerely, Print Name: Caroline Vanderschooten Title: purchasing and marketing manager Signature: On behalf of Company: SCX DESIGN Telephone: +33.1.86.95.99.88 E-mail: [email protected]

SCX DESIGN To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States Regarding: Confidentiality Request regarding application for 2A2OH-W1630L LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. SHORT TERM CONFIDENTIALITY Additionally, the applicant requests the following documents be held confidential until the device is marketed or 0 days from the grant date, whichever is less. If the device is marketed within aforementioned days of the Grant Date, the applicant will notify the TCB per FCC KDB 726920 D01 Confidentiality Request Procedures. External Photos Internal Photos Test Setup Photos User manual(s) Sincerely, Print Name: Caroline Vanderschooten Title: purchasing and marketing manager Signature: On behalf of Company: SCX DESIGN Telephone: +33.1.86.95.99.88 E-mail: [email protected]

Applicant Declaration Applicant Declaration Rev:0.0 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name SCX DESIGN Address 68 bis Boulevard Pereire, Paris 75017, France Grantee Code 2A2OH FCC ID 2A2OH-W1630L Authorized Contact Name Caroline Vanderschooten Contact Email [email protected] Contact Phone +33.1.86.95.99.88 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a)in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b)in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c)if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d)in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e)in accordance with ISO17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f)neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g)the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Applicant Signature: Date: 12/27/2021 Print Name: Caroline Vanderschooten Title: purchasing and marketing manager *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

SCX DESIGN Cover Letter-Wireless Charger Approval Date: 2021-12-27 Gentlemen: There’s a SCX Design 10W Wireless Charging Phone Stand Bamboo that would like to have your authorization as an Inductive wireless power transfer applications approval. The specific product as below, SCX Design 10W Wireless Charging Phone Stand Bamboo, with its designed features and specified description, meets special requirements for KDB 680106 D01 section 5.2 requirements. Company: SCX DESIGN Product Name: 10W Wireless Charging Phone Stand Bamboo Model Number: W16/32492 FCC ID: 2A2OH-W1630L KDB 680106 D01 Section 5.2 Requirements Product Technical Specification Result a) Power transfer frequency is less that 1 MHz118.8KHz – 151.8KHzComplied b) Output power from each primary coil is less than or equal to 15 watts. 5W, 10WComplied c) The transfer system includes only single primary and secondary coils. This includes charging systems that may have multiple primary coils and clients that are able to detect and allow coupling only between individual pairs of coils Complied d)Client device is placed directly in contact with the transmitter. Complied e) Mobile exposure conditions onlyFor inductive applications where the primary does not physically attach to the client, and it is intended for desktop use, the desktop guidance in KDB 680106 D01 may be applied Complied f)The aggregate H-field strengths at 15 cm surrounding the device and 20 cm above the top surface from all simultaneous transmitting coils are demonstrated to be less than 50% of the MPE limit. Please refer to RF exposure report Complied Sincerely, Print Name: Caroline Vanderschooten Title: purchasing and marketing manager Signature: On behalf of Company: SCX DESIGN Telephone: +33.1.86.95.99.88 E-mail: [email protected]

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.0 Page: 1 of 4 Appendix External Photos for GZCR2112021555AT SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Page: 2 of 4 EMC-ARF-02 Rev 1.0 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Page: 3 of 4 EMC-ARF-02 Rev 1.0 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Page: 4 of 4 EMC-ARF-02 Rev 1.0

LED Color:White LED Qty:100pcs With LOGO+900pcs Without LOGO W16/32492 140*70*12 mm 31.9*40.4 mm 10W Wireless Charging Phone Stand Bamboo Product Color:Bamboo + Black FCC ID: 2A2OH-W1630L Item W16.30L / 32492 LOT: 2021/10/29 Input: 5V/2A, 9V/2A Output: DC 5V/1A-5W , 9V/1.12A-10W CAUTION: Risk of Fire and Burns WARNING: Read Instruction Manual Before Use Made in China Designed in France by

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.0 Page: 1 of 5 Appendix Internal Photos for GZCR2112021555AT SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Page: 2 of 5 EMC-ARF-03 Rev 1.0 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Page: 3 of 5 EMC-ARF-03 Rev 1.0 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Page: 4 of 5 EMC-ARF-03 Rev 1.0 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Page: 5 of 5 EMC-ARF-03 Rev 1.0

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.0 Report No.: GZCR211202155502 Page: 1 of 11 FCC ID: 2A2OH-W1630L Kobe Jian EMC Laboratory Manager RF EXPOSURE EVALUATION REPORT Application No.: GZCR2112021555AT (SGS SZ No.: T52110310062EM) Applicant: SCX DESIGN Address of Applicant: 68 bis Boulevard Pereire 75017 Paris, France Manufacturer: SCX DESIGN Address of Manufacturer: 68 bis Boulevard Pereire 75017 Paris, France Equipment Under Test (EUT): EUT Name: 10W Wireless Charging Phone Stand Bamboo Model No.: W16/32492 Standard(s) : 47 CFR PART 1, Subpart I, Section 1.1310 47 CFR PART 2, Subpart J, Section 2.1091 Date of Receipt: 2021-10-16 Date of Evaluation: 2021-11-05 to 2021-12-22 Date of Issue: 2021-12-27 Evaluation Result: Pass* * In the configuration evaluated, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Report No.: GZCR211202155502 EMC-TRF-03 Rev 1.0 Page: 2 of 11 Revision Record Version Chapter Date Modifier Remark 01 2021-12-27 Original Authorized for issue by: Tested By Curry Wu/Project Engineer Reviewed By Ricky Liu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Report No.: GZCR211202155502 EMC-TRF-03 Rev 1.0 Page: 3 of 11 2 Evaluation Summary Radio Spectrum Matter Part Item Standard Method Requirement Result RF Exposure 47 CFR PART 1, Subpart I, Section 1.1310 KDB 680106 D01 TCB Workshop Presentation November 2019 RF Exposure CFR 47 Part 1.1310 Pass Note: E.U.T./EUT means Equipment Under Test. Pass means the test result passed the test standard requirement, please find the detailed decision rule in the report relative section. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Report No.: GZCR211202155502 EMC-TRF-03 Rev 1.0 Page: 4 of 11 3 Contents Page 1 Cover Page ......................................................................................................................................... 1 2 Evaluation Summary .......................................................................................................................... 3 3 Contents ............................................................................................................................................. 4 4 General Information............................................................................................................................ 5 4.1 Details of E.U.T. ........................................................................................................................... 5 4.2 Description of Support Units ......................................................................................................... 5 4.3 Test modes description: ............................................................................................................... 5 4.4 Measurement Uncertainty ............................................................................................................ 5 5 Equipments Used during Test ........................................................................................................... 6 5.1 Evaluating Location ...................................................................................................................... 7 5.2 Facility ......................................................................................................................................... 7 5.3 Deviation from Standards ............................................................................................................. 8 5.4 Abnormalities from Standard Conditions ....................................................................................... 8 5.5 Test Block Diagram ...................................................................................................................... 8 6 Test Results ........................................................................................................................................ 9 6.1 RF Exposure test ......................................................................................................................... 9 6.1.1 E.U.T. Operation .....................................................................................................................10 6.1.2 Measurement Data..................................................................................................................10 7 Photographs- RF exposure Setup photos ........................................................................................11 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Report No.: GZCR211202155502 EMC-TRF-03 Rev 1.0 Page: 5 of 11 4 General Information 4.1 Details of E.U.T. Power supply: Input: 5V/2A, 9V/2A, Output: 5Vdc/1A, 9V/1.12A, 10W Operation Frequency: 118.8KHz-151.8KHz Modulation Type: Load modulation Antenna Type: Loop antenna Remark: 1.This device has been tested the worst status of full load and the device has been tested with load at 5W and 10W. The worst case 10W is reported only. 2. The wireless charger contains two coil antenna, vertical and horizontal. They cannot charge two client devices simultaneously. The client device (e.g. mobile phone) can be placed to the charger in two different polarity for efficiency accordingly. All tests were conducted in two different location and the worst case(vertical) is reported only. 4.2 Description of Support Units Description Manufacturer Model No. Serial No. Mobile Phone Nexus MRA58K REF. No.SEA16P00 SAMSUNG Galaxy S8 SAMSUNG SM-G9500 REF. No.SEA16M01 E-loading SGS N/A REF. No.SEA42A00 Adapter XIAOMI MDY-08 REF. No.SEA05M02F Type-C Cable SGS N/A REF. No.SEA07B00 4.3 Test modes description: Pre-scan / Final test Mode Code Description Pre-scan 00 Charge mode_Keep the EUT charging(5W) Final test 01 Charge mode_Keep the EUT charging(10W) 4.4 Measurement Uncertainty Test Item Measurement Uncertainty RF Exposure Evaluation MF: 0.13dB, EF: 0.4dB SG…
