2A2UK-JJT-A60Wireless Charger

watch charging Airpods wireless charging Phone charging Time Set Alarm Set 12/24H Configuration list: Wireless charger, type-c data cable, user manual. The instructions and pictures are schematic diagrams, and the final product is subject to the matters needing attention: model ：A60 Please pay attention to the following problems, otherwise it may lead to abnormal charging, high charging temperature, intermittent charging, or even no charging. 1. Please use QC3.0 fast charger adapter (9V/3A, 12V/2.5A) for better charging effect. 5V/2A will lead to insufficient power supply. This product supports adapters for QC and PD protocols. 2. Please place the mobile phone in the center of the wireless charging sensing area. 3. The charging distance is 2-6mm. Please do not install a protective case thicker than 2mm. 4. When charging wirelessly, there should be no metal or magnetic objects within the distance of 6cm from the center point on the back of the phone. 5. Lower temperature, faster charging speed. The charging speed is faster in winter than in summer. 6. Children must use this product under the guidance of adults. real object. parameterSymbolRatingCompany Operating ambient temperature Storage temperature Storage humidity Supply voltage Power supply current Ta Tstg Tstr Vcc Imax 0~35 -10~+60 ＜95% 8.5~12.5 3 °C °C RH V A Multifunction Wireless Charger Instruction Manual Clock mode debugging parameters: ① Press and hold the time key time Set for 3 seconds to enter the clock setting mode. Press and hold the time key briefly to set the time. Press and hold again to change the number area. ② Short press to set the minutes. After adjusting the hours and minutes correctly, wait for 5 seconds or long press for 3 seconds to complete the time setting. Alarm mode adjustment parameters: ① Press and hold the alarm key Alarm Set for 3 seconds to enter the alarm setting mode; ② Short press the setting time, and long press again to switch the digital area; ③ Short press Set Minutes, adjust the hours and minutes correctly, wait for 5 seconds to complete the alarm setting, and then the small alarm icon lights up. Alarm cancellation: Press and hold the Alarm set button for 3 times (3 seconds each time); Precautions for alarm clock: When in the 12 hour mode, adjust the alarm time according to the PM AM icon Time format operation: Long press the 12/24H button to switch the 12/24 hour mode The time is equipped with a 3V button battery. When the input terminal is not connected to the power supply, the button battery supplies power to the clock chip (time is not displayed) to ensure that the time is on time after power failure and reconnection. Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for help. FCC Requirement Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC

Date:04/17/2018VCB_F-01:OperatingProceduresForm–FCCAuthorizationv02Page1of1 DongguanjiajiatongplasticmouldCo.,Ltd FederalCommunicationsCommission AuthorizationandEvaluationDivision 1435OaklandMillsRoad Columbia,MD21046 Date:2022-12-6 SUBJECT:FCCApplicationfor(FCCID:2A2UK-JJT-A60) ToWhomItMayConcern: We,theundersigned,herebyauthorizeYoyoZhouin ShenzhenHuaxiaTesting TechnologyCo.,Ltdat1F.,BlockAofTongshengTechnologyBuilding,HuahuiRoad, DalangStreet,LonghuaDistrict,Shenzhen,Chinaonourbehalf,toapplytotheFederal CommunicationsCommissiononourequipment.Anyandallactscarriedoutby ShenzhenHuaxiaTestingTechnologyCo.,Ltd onourbehalfshallhavethesame effectasactsofourown. ThisistoadvisethatweareinfullcompliancewiththeAnti-DrugAbuseAct.We, theapplicant,arenotsubjecttoadenialoffederalbenefitspursuanttoSection 5301oftheAnti-DrugActof1988,21USC853a,andnopartytotheapplicationis subjecttoadenialoffederalbenefitspursuanttothatsection. Sincerely, (MustbesignedbythepersonthatislistedontheFCCWebsite) Signature: Contactname:LiEnping Companyname:DongguanjiajiatongplasticmouldCo.,Ltd Address:No.10,QiaojiaoMiddleRoad,Pingshan188IndustrialZone,TangxiaTown, DongguanCity,GuangdongProvince,China

Date:04/17/2018VCB_F-01:OperatingProceduresForm–FCCConfidentialityv02Page1of1 DongguanjiajiatongplasticmouldCo.,Ltd FederalCommunicationsCommission AuthorizationandEvaluationDivision ConfidentialityRequestregardingapplicationforcertificationofFCCID:2A2UK-JJT-A60 PursuanttoSections0.457and0.459oftheCommission’sRules,weherebyrequest confidentialtreatmentofinformationaccompanyingthisapplicationasoutlinedbelow: ExhibitTypeFileName 1.BlockDiagram, 2.Schematics, 3.OperationalDescription 1.2A2UK-JJT-A60-Blockdiagram 2.2A2UK-JJT-A60-SCH 3.2A2UK-JJT-A60-Operationaldescription Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarily releasedtothepublic.Thepublicdisclosureofthesematerialsmaybeharmfultothe applicantandprovideunjustifiedbenefitstoitscompetitors. TheapplicantunderstandsthatpursuanttoSection0.457oftheRules,disclosureofthis applicationandallaccompanyingdocumentationwillnotbemadebeforethedateofthe Grantforthisapplication. PursuanttoDA04-1705June15,2004oftheCommission’spublicnotice,wealso requesttemporaryconfidentialtreatmentofinformationaccompanyingthisapplication asoutlinedbelowforaninitialperiodofxxxx(ie-“45”,“90”or“180”)days: ExhibitTypeFileName N/AN/A Signature: Contactname:LiEnping Companyname:DongguanjiajiatongplasticmouldCo.,Ltd Address:No.10,QiaojiaoMiddleRoad,Pingshan188IndustrialZone,TangxiaTown, DongguanCity,GuangdongProvince,China

Externalphotos

F Size:40*30mm

Internalphotos

ShenzhenHuaxiaTestingTechnologyCo.,Ltd. 1F.,BlockAofTongshengTechnologyBuilding,HuahuiRoad,DalangStreet,LonghuaDistrict, Shenzhen,China Telephone:+86-755-26648640 Fax:+86-755-26648637 Website:www.cqa-cert.com ReportTemplateVersion:V05 ReportTemplateRevisionDate:2021-11-03 RFExposureEvaluationReport Thetestreportiseffectiveonlywithbothsignatureandspecializedstamp,Theresult(s)showninthisreportreferonlytothesample(s) tested.WithoutwrittenapprovalofCQA,thisreportcan’tbereproducedexceptinfull. ReportNo.: CQASZ20221101975E-02 Applicant:DongguanjiajiatongplasticmouldCo.,Ltd AddressofApplicant:No.10,QiaojiaoMiddleRoad,Pingshan188IndustrialZone,TangxiaTown, DongguanCity,GuangdongProvince,China EquipmentUnderTest(EUT): Product:MultifunctionWirelessCharger ModelNo.:A60 TestModelNo.:A60 BrandName: N/A FCCID:2A2UK-JJT-A60 Standards:47CFRPart1.1307 47CFRPart1.1310 KDB680106D01RFExposureWirelessChargingBaseAppv03r01 DateofReceipt:2022-11-22 DateofTest:2022-11-22to2022-11-29 DateofIssue: 2022-11-30 TestResult:PASS* *Intheconfigurationtested,theEUTcompliedwiththestandardsspecifiedabove TestedBy: (JoeWang) ReviewedBy: (TimoLei) ApprovedBy: (JackAi) ShenzhenHuaxiaTestingTechnologyCo.,Ltd. ReportNo.:CQASZ20221101975E-02 Page:2of10 1Version RevisionHistoryOfReport ReportNo.Version Description IssueDate CQASZ20221101975E-02Rev.01 Initialreport 2022-11-30 ShenzhenHuaxiaTestingTechnologyCo.,Ltd. ReportNo.:CQASZ20221101975E-02 Page:3of10 2Contents Page 1VERSION............................................................................................................................................................................2 2CONTENTS........................................................................................................................................................................3 ..................................................................................................................................................................................................3 3GENERALINFORMATION..............................................................................................................................................4 3.1CLIENTINFORMATION...................................................................................................................................................4 3.2GENERALDESCRIPTIONOFEUT...................................................................................................................................4 3.3PRODUCTSPECIFICATIONSUBJECTIVETOTHISSTANDARD...........................................................................................4 3.4TESTENVIRONMENT......................................................................................................................................................5 3.5DESCRIPTIONOFSUPPORTUNITS..................................................................................................................................5 3.6TESTLOCATION.............................................................................................................................................................6 3.7TESTFACILITY...............................................................................................................................................................6 3.8EQUIPMENTLIST............................................................................................................................................................6 4RFEXPOSUREEVALUATION.......................................................................................................................................7 4.1RFEXPOSURECOMPLIANCEREQUIREMENT.................................................................................................................7 4.1.1Limits....................................................................................................................................................................7 4.1.2TestProcedure...................................................................................................................................................7 4.1.3TestSetup...........................................................................................................................................................8 4.1.4TestResults........................................................................................................................................................8 APPENDIXA:PHOTOGRAPHSOFTESTSETUP.....................................................................................................10 ShenzhenHuaxiaTestingTechnologyCo.,Ltd. ReportNo.:CQASZ20221101975E-02 Page:4of10 3GeneralInformation 3.1ClientInformation Applicant:DongguanjiajiatongplasticmouldCo.,Ltd AddressofApplicant:No.10,QiaojiaoMiddleRoad,Pingshan188IndustrialZone,TangxiaTown, DongguanCity,GuangdongProvince,China Manufacturer:DongguanjiajiatongplasticmouldCo.,Ltd AddressofManufacturer:No.10,QiaojiaoMiddleRoad,Pingshan188IndustrialZone,TangxiaTown, DongguanCity,GuangdongProvince,China Factory:DongguanjiajiatongplasticmouldCo.,Ltd AddressofFactory:No.10,QiaojiaoMiddleRoad,Pingshan188IndustrialZone,TangxiaTown, DongguanCity,GuangdongProvince,China 3.2GeneralDescriptionofEUT ProductName: MultifunctionWirelessCharger ModelNo.: A60 TestModelNo.: A60 BrandName: N/A SoftwareVersion: V1.0 HardwareVersion: V1.0 EUTPowerSupply: INPUT:9.0V/3.0A;12V/2.5A 3.3ProductSpecificationsubjectivetothisstandard EquipmentCategory:Non-ISMfrequency OperationFrequencyrange:110~205KHz ModulationType:Induction AntennaType:Inductioncoil AntennaGain:0dBi Power:Output:15W(Max) Note: 1.Insection15.31(m),regardstotheoperatingfrequencyrangeless1MHz. ShenzhenHuaxiaTestingTechnologyCo.,Ltd. ReportNo.:CQASZ20221101975E-02 Page:5of10 3.4TestEnvironment OperatingEnvironment: Temperature: 25.5  C Humidity:53%RH AtmosphericPressure:1009mbar TestMode: Modea:WirelessoutputModeat15W(Max) Moded:WirelesstotaloutputModeat22.5…

Text truncated - open the document above for the full version.

ShenzhenHuaxiaTestingTechnologyCo.,Ltd. 1F.,BlockAofTongshengTechnologyBuilding,HuahuiRoad,DalangStreet,LonghuaDistrict, Shenzhen,China Telephone:+86-755-26648640 Fax:+86-755-26648637 Website:www.cqa-cert.com ReportTemplateVersion:V05 ReportTemplateRevisionDate:2021-11-03 TestReport Thetestreportiseffectiveonlywithbothsignatureandspecializedstamp,Theresult(s)showninthisreportreferonly tothesample(s)tested.WithoutwrittenapprovalofCQA,thisreportcan’tbereproducedexceptinfull. ReportNo.:CQASZ20221101975E-01 Applicant:DongguanjiajiatongplasticmouldCo.,Ltd AddressofApplicant:No.10,QiaojiaoMiddleRoad,Pingshan188IndustrialZone,TangxiaTown, DongguanCity,GuangdongProvince,China EquipmentUnderTest(EUT): Product:MultifunctionWirelessCharger ModelNo.:A60 TestModelNo.:A60 BrandName: N/A FCCID:2A2UK-JJT-A60 Standards:47CFRPart15,SubpartC DateofReceipt:2022-11-22 DateofTest:2022-11-22to2022-11-29 DateofIssue: 2022-11-30 TestResult:PASS* *Intheconfigurationtested,theEUTcompliedwiththestandardsspecifiedabove TestedBy: (JoeWang) ReviewedBy: (TimoLei) ApprovedBy: (JackAi) ShenzhenHuaxiaTestingTechnologyCo.,Ltd. ReportNo.:CQASZ20221101975E-01 Page: 2 of 32 1Version RevisionHistoryOfReport ReportNo.Version Description IssueDate CQASZ20221101975E-01Rev.01 Initialreport 2022-11-30 ShenzhenHuaxiaTestingTechnologyCo.,Ltd. ReportNo.:CQASZ20221101975E-01 Page: 3 of 32 2TestSummary TestItemTestRequirementTestmethodResult AntennaRequirement 47CFRPart15,SubpartCSection 15.203 ANSIC63.102013PASS ACPowerLine Conducted Emission 47CFRPart15,SubpartCSection 15.207 ANSIC63.102013PASS 20dBOccupied Bandwidth 47CFRPart15,SubpartCSection 15.215 ANSIC63.102013PASS RadiatedEmission, RadiatedSpurious Emissions 47CFRPart15,SubpartCSection 15.209 ANSIC63.102013PASS ShenzhenHuaxiaTestingTechnologyCo.,Ltd. ReportNo.:CQASZ20221101975E-01 Page: 4 of 32 3Contents Page 1VERSION..........................................................................................................................................................................2 2TESTSUMMARY............................................................................................................................................................3 3CONTENTS......................................................................................................................................................................4 4GENERALINFORMATION...........................................................................................................................................5 4.1CLIENTINFORMATION.................................................................................................................................................5 4.2GENERALDESCRIPTIONOFEUT.................................................................................................................................5 4.3PRODUCTSPECIFICATIONSUBJECTIVETOTHISSTANDARD........................................................................................5 4.4TESTENVIRONMENT...................................................................................................................................................6 4.5DESCRIPTIONOFSUPPORTUNITS...............................................................................................................................6 4.6STATEMENTOFTHEMEASUREMENTUNCERTAINTY....................................................................................................7 4.7TESTLOCATION..........................................................................................................................................................7 4.8TESTFACILITY............................................................................................................................................................7 4.9DEVIATIONFROMSTANDARDS....................................................................................................................................7 4.10OTHERINFORMATIONREQUESTEDBYTHECUSTOMER............................................................................................7 4.11EQUIPMENTLIST.......................................................................................................................................................8 5TESTRESULTSANDMEASUREMENTDATA.......................................................................................................9 5.1ANTENNAREQUIREMENT............................................................................................................................................9 5.2CONDUCTEDEMISSIONS............................................................................................................................................10 5.320DBOCCUPYBANDWIDTH......................................................................................................................................15 5.4RADIATEDSPURIOUSEMISSION&RESTRICTEDBANDS...........................................................................................17 5.4.1SpuriousEmissions......................................................................................................................................17 6PHOTOGRAPHS-EUTTESTSETUP.....................................................................................................................24 6.1RADIATEDEMISSION.................................................................................................................................................24 6.2CONDUCTEDEMISSION..............................................................................................................................................25 7PHOTOGRAPHS-EUTCONSTRUCTIONALDETAILS......................................................................................26 ShenzhenHuaxiaTestingTechnologyCo.,Ltd. ReportNo.:CQASZ20221101975E-01 Page: 5 of 32 4GeneralInformation 4.1ClientInformation Applicant:DongguanjiajiatongplasticmouldCo.,Ltd AddressofApplicant:No.10,QiaojiaoM…

Text truncated - open the document above for the full version.

ShenzhenHuaxiaTestingTechnologyCo.,Ltd. ReportNo.:CQASZ20221101975E-01 Page: 29 of 32 ShenzhenHuaxiaTestingTechnologyCo.,Ltd. ReportNo.:CQASZ20221101975E-01 Page: 30 of 32 ShenzhenHuaxiaTestingTechnologyCo.,Ltd. ReportNo.:CQASZ20221101975E-01 Page: 31 of 32 ShenzhenHuaxiaTestingTechnologyCo.,Ltd. ReportNo.:CQASZ20221101975E-01 Page: 32 of 32 ***ENDOFREROPT***

产 品 规 格 书 Product specification book 规格编号 Specification number 20220727001 生效日期 effective date 2022/7/27 客户名称 customer name 产品类型 product type 料号 P/N(Part Number) 客户料号 Customer Material Number 【 □ 新版发行 , □ 版本修订】 【 本规范含目录共 3 页 】 【 RoHS Compliant Parts Dongguan jiajiatong plastic mould Co., Ltd 无线充A60 Wireless charging A60 2022-07-27-9T-L=90 无线充A60-10W双线圈 Wireless charging A60-10W dual coil 】 【 RoHS Compliant Parts 】 【 RoHS Compliant Parts 】 【 RoHS Compliant Parts 】 编制 authorized strength 审核 audit 批准 ratify 本承认书在客户收到30天内，请务必签章返回，逾期视为生产时按此承认书的标准执行 Please sign and return this letter of acknowledgement within 30 days after receipt by the customer. If the date is overdue, the production shall be subject to the standards of this letter of acknowledgement。 【客户核准】/[Customer approval] 日期/date : 承认状态： □完全承认 □条件承认 □拒绝承认 Recognition status: □ Full recognition □ Conditional recognition □ Denial 编制 authorized strength 审核 audit 复检 recheck 检查 examine 说明/explain √√ 产 品 规 格 书 Product specification book 客户名称 customer name 客户料号 Customer Material Numbe Dongguan jiajiatong plastic mould Co., Ltd r 无线充 A60-10W 双线圈 Wireless charging A60-10W dual coil 料号 P/N(Part Number) 20220727001-9圈L=110MM，L=105MM 规格编号 Specification number 20220727001 发行/修订记录 版本 versions 生效日期 effective date 变更内容/原因 Change content/reason 核准 examine and approve 012022/7/27 新规格发行 New specifications issued 编制/authorized strength审核/audit批准/ratify 产 品 规 格 书 客户名称 customer name 客户料号 Customer Material Numbe Dongguan jiajiatong plastic mould Co., Ltd r 无线充 A60-10W 双线圈 Wireless charging A60-10W dual coil 料号 P/N(Part Number) 20220727-001 9 turns 规格编号 Specification number 20220727001 版本 versions 01 ♦、外形尺寸/boundary dimension (单位: mm) (Unit: mm) A92.0 ±0.5 B52.0 ±1 C4.0 ±1 D90.0 ±2 E4-4.5 F4.5-5 G47.6 ±0.4 H19.5 ±0.5 I27.5 ±0.5 备注 (1) 线径 : 0.08*105P 丝包线 (1) Wire diameter: 0.08*105P silk covered wire (2) 绕线圈数 :9TS (2) Winding number :9TS (3) 起尾线是否交叉 : W1 是 ;W2 不是 (3) Whether the starting and ending lines cross: W1 Yes; W2 is not (4) 磁片底部贴双面胶 (4) The bottom of the magnetic sheet is affixed with double-sided tape (5) W1线圈需压 W2 线圈 5~6 根 (5)W1 coil needs to pressure 5 to 6 W2 coils (6 ）磁片一面背白胶 , (6) One side of the magnetic sheet is backed with white glue, ♦、电气特性/electrical specification: (6 ）线圈居磁片中间位置贴 (6) the coil is placed in the middle of the magnetic sheet 参数/parameter规格/specification测试条件/test condition测试仪器/test instrument L(W1)6.8±10%μH100KHz/1V■TH1816B L(W2)6.8±10%μH100KHz/1V■TH1817B DCR(W1)56MaxmΩ@ 25°C■CH-502BC DCR(W2)56MaxmΩ@ 25°C■CH-502BC ♦、温度等级/temperaturegrade 操作温度 operating temperature -40°C~ 125°C 材料清单: bill of materials 序号 serial number 品名 Trade name 材料规格 material specification 供应商 supplier 备注 remark 1 磁片 magnetic sheet 52*47*0.8T PC95猛锌隔磁片 PC95 strong zinc separator magnetic sheet 2 铜线 copper wire 0.08*105P 标配丙铜丝包线 Standard with acrylic copper silk covered wire 3 高温胶带 high temperature tape 8MM 环保胶带 Green adhesive tape 4 锡 tin 107H 千岛环保锡 Thousand island environmental protection tin 5 胶 glue 黄胶/monite环保胶 Environmental protection glue 编制/authorized strength审核/audit 批准/ratify Peak gain:0dBi

产 品 规 格 书 Product specification book 规格编号 Specification number 20220914008 生效日期 effective date 2022/9/14 公司名称 company name 产品类型 product typ Dongguan jiajiatong plastic mould Co., Ltd e 苹果手表线圈/Apple Watch coil 辉愽雅料号 O 'Brien O 'Brien HBY20220914008-手表软磁线圈3300高斯 L=10.5MM 客户料号 Customer Material Number 【 □ 新版发行 , □ 版本修订】 【 本规范含目录共 3页 】 【 RoHS Compliant Parts 】 编制 authorized strength 审核 audit 批准 ratify 刘峰丽肖树芳朱辉 本承认书在客户收到30天内，请务必签章返回，逾期视为生产时按此承认书的标准执 行。Please be sure to sign and seal this letter of acceptance within 30 days after receipt by the customer. If the deadline is overdue, it will be deemed that the production shall be performed according to the standard of this letter of acceptance. 【客户核准/Customer approval】 日期/date: 承认状态/Admit status： □完全承认/ □条件承认 □拒绝承认 批准/ratify审核/audit复检/recheck 检查/check 说明/explain : √√ 产 品 规 格 书 Product specification book 客户名称 customer name 客户料号 Custome Dongguan jiajiatong plastic mould Co., Ltd r Material 料号 P/N(Part Number) HBY20220914008-手表软磁线圈3300高斯 L=10.5MM 规格编号 Specification number 20220914008 发行/修订记录 Record of issues/revisions 版本version 生效日期 effective date 变更内容/原因 Change content/reason 核准 exami ne and 012022--9-14 新规格发行 New specifications issued 编制 authorized strength 审核 audit 批准 ratify 刘峰丽 肖树芳朱辉 产 品 规 格 书 Product specification book 客户名称 company name 客户料号 料 Dongguan jiajiatong plastic mould Co., Ltd 号 P/N(Part Number) HBY20220914008-手表软磁线圈3300高斯 L=10.5MM 规格编号 Specificatio n number 20220914008 版本 01 ♦、外形尺寸 (单位: mm) A10.5 ±1.0 B20.1 ±1.0 C22.5 ±0.5 D 24.5 ±1.0 E7.5 *2.2 F13.5 ±1.0 I2.5 ±1.0(磁片厚度) (1) 线径 : 0.08*24P 丝包线 (1) Wire diameter: 0.08*24P covered wire (2) 绕线圈数 :14TS (2) Number of winding turns :14TS (3) 起尾线是否交叉 : 是 (3) Whether the starting line is crossed: Yes (4) 线圈与磁片需粘贴居中 (4) The coil and the magnetic sheet should be stuck in the center (5) 磁片背 19MM 圆 3M 胶 (5) Magnetic chip back 19MM round 3M glue ♦、电气特性/electrical specificatio: 参数/parameter 规格/specification 测试条件/test condition测试仪器/test instrument L08.1 ±0.2%μH100KHz/1V■TH1816B Q>30 min100KHz/1V■TH1816B DCR<50mΩ@ 25°C■CH-502BC ♦、温度等级/temperature grade: 操作温度 operatingtemperature -40°C~ 125°C ♦、温度等级/temperature grade: 序号 serial number 品名 Trade name 材料规格 material specification 供应商 supplier 备注 remark 1 磁片 magnetic sheet 24.5*22.5*2.5软磁 PC95猛锌 PC95 fierce zinc 2 铜线 copper wire 0.08*24 丙铜丝包线 Propane copper covered wire 3 磁铁高斯3200-3300高斯环保胶带 4 锡 tin 107H 千岛环保锡 Thousand island environmental tin 5 胶 glue 定制白胶 环保胶水 Environmental protection glue 6 胶 3M胶 环保 编制 authorized strength 审核 audit 批准 ratify 刘峰丽肖树芳朱辉

产 品 规 格 书 Product specification book 规格编号 Specification number 20220829004 生效日期 effective date 2022/8/29 公司名称 company name 产品类型 product typ Dongguan jiajiatong plastic mould Co., Ltd e A11线圈/A11 coil 天线增益 antenna gain 0dBi 料号 P/N(Part Number) TX-HBY20220829004-45开双槽12TS L=30MM 客户料号 Customer Material Number 【 □ 新版发行 , □ 版本修订】 【 本规范含目录共 3页 】 【 RoHS Compliant Parts 】 编制 authorized strength 审核 audit 批准 ratify 本承认书在客户收到30天内，请务必签章返回，逾期视为生产时按此承认书的标准执行。 Please be sure to sign and seal this letter of acceptance within 30 days after receipt by the customer. If the deadline is overdue, it will be deemed that the production shall be performed according to the standard of this letter of acceptance. 【客户核准/Customer approval】 日期/date: 承认状态/Admit status： □完全承认/ □条件承认 □拒绝承认 批准/ratify审核/audit复检/recheck 检查/check 说明/explain: √√ 产 品 规 格 书 Product specification book 客户名称 customer name 客户料号 Custome Dongguan jiajiatong plastic mould Co., Ltd r Material Number 料号 P/N(Part Number) TX-HBY20220829004-45开双槽12TS L=30MM 规格编号 Specification 20220829004 发行/修订记录 Record of issues/revisions 版本versions 生效日期 effective date 变更内容/原因 Change content/reason 核准 examine and approve 012022/8/29 新规格发行 New specifications issued 编制 authorized strength 审核 audit 批准 ratify 产 品 规 格 书 Product specification book 客户名称 customer name 客户料号 Customer Material Numbe Dongguan jiajiatong plastic mould Co., Ltd r 料号 P/N(Part Number) TX-HBY20220829004-45开双槽12TS L=30MM 规格编号 Specification number 20220829004 版本 01 ♦、外形尺寸/boundary dimension (单位/unit: mm) A44.0 ±1 B40.0 ±0.5 C13.5 ±0.5 D 5.3Ref±0.5 E10.0 Ref F3.0 ±1.0 G2.2 ±0.5 H30.0 ±1.0 I0.8 ±0.1(磁片厚度) The thickness of the disk (1) 线径 : 0.08*105P 丝包线 (1) Wire diameter: 0.08*105P covered wire (2) 绕线圈数 :12TS (2) Number of winding turns :12TS (3) 起尾线是否交叉 : 是 (3) Whether the starting line is crossed: Yes (4) 线圈包 8mm 宽高温胶带 (4) Coil package 8mm wide high temperature tape (5) 线圈与磁片需粘贴居中 (5) The coil and the magnetic chip shall be stuck in the center (6) 磁片背 43 双槽圆双面胶 (6) Magnetic disc back 43 double groove round double-sided adhesive ♦、电气特性/electrical specificatio: 参数/parameter 规格/specification测试条件/test condition 测试仪器/test instrument L06.6±5%μH100KHz/1V■TH1816B Q>60 min100KHz/1V■TH1816B DCR<50mΩ@ 25°C■CH-502BC ♦、温度等级/temperature grade: 操作温度 operatingtemperature -40 °C ~ 125 °C ♦、材料清单: bill of materials 序号 serial number 品名 Trade name 材料规格 material specification 供应商 supplier 备注 remark 1 磁片 magnetic sheet43.5*0.8*10T 开双槽 PC95猛锌 PC95 fierce zinc 2 铜线 copper wire 0.08*105P 丙铜丝包线 Propane copper covered wire 3 高温胶带 high temperature tape 8MM 环保胶带 Masking tape 4 锡 tin 107H 千岛环保锡 Thousand island environmental tin 5 胶 glue 黄胶 cement 环保胶水 Environmental protection glue 6 胶/glue 43双槽圆双面胶 43 double groove round double-sided adhesive 环保 environmental protection 编制 authorized strength 审核 audit 批准 ratify

1Photographs-EUTTestSetup 1.1RadiatedEmission 9kHz~30MHz: 30MHz~1GHz: 1.2 ConductedEmission
