2A2UU-K1133Mini POS Terminal

Technical Specs ATTENTION Warning Read all instructions and safety information before use to avoid injury. The limit operating ambient temperature of the device declared by the manufacturer is -10~45°C. Battery safety Charge battery only at ambient temperatures ranging from 0~40°C. Dispose of used batteries according to manufacturer’s instructions. Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type of batt ery recommended by the manufacturer. Statement The equipment damage caused by natural disasters, falling, self disassembly and non-compliance with the operation specifications is not covered by the free warranty. Some details of this document may be inconsistent with the real object due to the update iteration of the product. Please take the real object as the standard, and our company reserves the right to interpret this document. K1133 Quick Guide ItemsSpecification Operating SystemAndroid 11.0 go [email protected] Memory1GB RAM + 8GB ROM (LPDDR4x) Display4.0” IPS, 480*480 Camera2M FFoptional ScannerN/A Cellular NetworkSupport 2g/3g/4g WIFI BluetoothVersion 4.2, support BLE PaymentSupport IC/NFC Card/QR Code InterfaceUSB type-C/POGOoptional AudioBuzzer/Speakeroptional Battery 1800mAh/3.87V (Rated capacity) IEEE 802.11 a/b/g/n/ac (2.4G&5G) Product Diagram NFC Card Reader NFC antenna locates at the bottom of the screen. It’s used to sense chip and acquire data through contactless way. IC Card Reader Used for inserting the bank chip card and getting information securely. Display Set for merchants to complete business settlement and for customers to input the password to finish the payment . Power Button Used for change the running states of device, such as pressing 2~3 seconds to power on/off or screen capture and pressing 10 seconds to restart automatically when device is crashed. Card Slo t The card slot is on the right side of the device and can be pushed out by holding the card pin like smart phones. USB type-C Used for device charging and plugging in peripheral device which supports OTG. Card Selection Instruction Package List NO.Items listDescription 1DeviceDefault 2Battery 1800mAh/3.87V (unremovable) 3USB cable1pcs,1m/white/type-c 4Adapter1pcs,5V 2A/Whiteoptional 5User manualNeutral 6Card PinDefault IC Card Reader Power Button Card Slot NFC Card Reader Buzzer/Speaker(optional) USB type-C Front Cameraoptional Decoration POGO-PIN(optional) 4"Display with touch panel FCC Statement Any Changes or modifications not expressly approved by the party responsibl e for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference (2)This device must accept any interference received, including interference that may cause undesired operation. Note : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates,uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. RF Exposure Information (SAR) : This device meets the government's requirements for exposure to radio waves. This device is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. The exposure standard for wireless devices employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg for body and 4.0W/kg for Limbs. *Tests for SAR are conducted using standard operating positions accepted by the FCC with the device transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the device while operating can be well below the maximum value. This is because the device is designed to operate at multiple power levels so as to use only the poser required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output. The highest SAR value for the device as reported to the FCC when worn on the body, as described in this user guide, is 1.13W/kg Body SAR (Body-worn measurements differ among devices, depending upon available enhancements and FCC requirements.) The FCC has granted an Equipment Authorization for this device with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this device is on file with the FCC and can be found under the Display Grant section of http://www.fcc.gov/oet/fccid after searching on FCC ID: 2A2UU-K1133 For body worn operation, this device has been tested and meets the FCC RF exposure guidelines for use with an accessory that contains no metal and the positions the device minimum of 10 mm from the body . Use of other enhancements may not ensure compliance with FCC RF exposure guidelines.

APPENDIX C_Band edge_ Report No.: RKSA260107001-00F Page 1 of 10 LTE Band 2, Normal Mode Result (dBm) Limit Verdict 1.4MHz_Low_QPSK_1@0 -19.45 See Graphs Pass 1.4MHz_Low_QPSK_6@0 -20.83 See Graphs Pass 1.4MHz_Low_16QAM_1@0 -21.39 See Graphs Pass 1.4MHz_Low_16QAM_6@0 -23.11 See Graphs Pass 1.4MHz_High_QPSK_1@5 -20.17 See Graphs Pass 1.4MHz_High_QPSK_6@0 -24.44 See Graphs Pass 1.4MHz_High_16QAM_1@5 -23.01 See Graphs Pass 1.4MHz_High_16QAM_6@0 -25.31 See Graphs Pass 3MHz_Low_QPSK_1@0 -19.44 See Graphs Pass 3MHz_Low_QPSK_15@0 -21.10 See Graphs Pass 3MHz_Low_16QAM_1@0 -21.31 See Graphs Pass 3MHz_Low_16QAM_15@0 -21.66 See Graphs Pass 3MHz_High_QPSK_1@14 -21.93 See Graphs Pass 3MHz_High_QPSK_15@0 -24.24 See Graphs Pass 3MHz_High_16QAM_1@14 -22.89 See Graphs Pass 3MHz_High_16QAM_15@0 -23.53 See Graphs Pass 5MHz_Low_QPSK_1@0 -22.87 See Graphs Pass 5MHz_Low_QPSK_25@0 -23.98 See Graphs Pass 5MHz_Low_16QAM_1@0 -23.63 See Graphs Pass 5MHz_Low_16QAM_25@0 -23.33 See Graphs Pass 5MHz_High_QPSK_1@24 -24.04 See Graphs Pass 5MHz_High_QPSK_25@0 -27.19 See Graphs Pass 5MHz_High_16QAM_1@24 -23.72 See Graphs Pass 5MHz_High_16QAM_25@0 -26.52 See Graphs Pass 10MHz_Low_QPSK_1@0 -28.38 See Graphs Pass 10MHz_Low_QPSK_50@0 -28.14 See Graphs Pass 10MHz_Low_16QAM_1@0 -29.14 See Graphs Pass 10MHz_Low_16QAM_50@0 -27.83 See Graphs Pass 10MHz_High_QPSK_1@49 -29.48 See Graphs Pass 10MHz_High_QPSK_50@0 -30.36 See Graphs Pass APPENDIX C_Band edge_ Report No.: RKSA260107001-00F Page 2 of 10 Mode Result (dBm) Limit Verdict 10MHz_High_16QAM_1@49 -29.79 See Graphs Pass 10MHz_High_16QAM_50@0 -31.33 See Graphs Pass 15MHz_Low_QPSK_1@0 -31.58 See Graphs Pass 15MHz_Low_QPSK_75@0 -28.18 See Graphs Pass 15MHz_Low_16QAM_1@0 -32.79 See Graphs Pass 15MHz_Low_16QAM_75@0 -29.15 See Graphs Pass 15MHz_High_QPSK_1@74 -32.30 See Graphs Pass 15MHz_High_QPSK_75@0 -31.61 See Graphs Pass 15MHz_High_16QAM_1@74 -33.24 See Graphs Pass 15MHz_High_16QAM_75@0 -32.02 See Graphs Pass 20MHz_Low_QPSK_1@0 -36.00 See Graphs Pass 20MHz_Low_QPSK_100@0 -31.28 See Graphs Pass 20MHz_Low_16QAM_1@0 -35.93 See Graphs Pass 20MHz_Low_16QAM_100@0 -31.30 See Graphs Pass 20MHz_High_QPSK_1@99 -36.94 See Graphs Pass 20MHz_High_QPSK_100@0 -31.90 See Graphs Pass 20MHz_High_16QAM_1@99 -30.51 See Graphs Pass 20MHz_High_16QAM_100@0 -32.78 See Graphs Pass APPENDIX C_Band edge_ Report No.: RKSA260107001-00F Page 3 of 10 LTE Band 2, Normal 1.4MHz_Low_QPSK_1@0 1.4MHz_Low_QPSK_6@0 1.4MHz_Low_16QAM_1@0 1.4MHz_Low_16QAM_6@0 1.4MHz_High_QPSK_1@5 1.4MHz_High_QPSK_6@0 APPENDIX C_Band edge_ Report No.: RKSA260107001-00F Page 4 of 10 1.4MHz_High_16QAM_1@5 1.4MHz_High_16QAM_6@0 3MHz_Low_QPSK_1@0 3MHz_Low_QPSK_15@0 3MHz_Low_16QAM_1@0 3MHz_Low_16QAM_15@0 APPENDIX C_Band edge_ Report No.: RKSA260107001-00F Page 5 of 10 3MHz_High_QPSK_1@14 3MHz_High_QPSK_15@0 3MHz_High_16QAM_1@14 3MHz_High_16QAM_15@0 5MHz_Low_QPSK_1@0 5MHz_Low_QPSK_25@0 APPENDIX C_Band edge_ Report No.: RKSA260107001-00F Page 6 of 10 5MHz_Low_16QAM_1@0 5MHz_Low_16QAM_25@0 5MHz_High_QPSK_1@24 5MHz_High_QPSK_25@0 5MHz_High_16QAM_1@24 5MHz_High_16QAM_25@0 APPENDIX C_Band edge_ Report No.: RKSA260107001-00F Page 7 of 10 10MHz_Low_QPSK_1@0 10MHz_Low_QPSK_50@0 10MHz_Low_16QAM_1@0 10MHz_Low_16QAM_50@0 10MHz_High_QPSK_1@49 10MHz_High_QPSK_50@0 APPENDIX C_Band edge_ Report No.: RKSA260107001-00F Page 8 of 10 10MHz_High_16QAM_1@49 10MHz_High_16QAM_50@0 15MHz_Low_QPSK_1@0 15MHz_Low_QPSK_75@0 15MHz_Low_16QAM_1@0 15MHz_Low_16QAM_75@0 APPENDIX C_Band edge_ Report No.: RKSA260107001-00F Page 9 of 10 15MHz_High_QPSK_1@74 15MHz_High_QPSK_75@0 15MHz_High_16QAM_1@74 15MHz_High_16QAM_75@0 20MHz_Low_QPSK_1@0 20MHz_Low_QPSK_100@0 APPENDIX C_Band edge_ Report No.: RKSA260107001-00F Page 10 of 10 20MHz_Low_16QAM_1@0 20MHz_Low_16QAM_100@0 20MHz_High_QPSK_1@99 20MHz_High_QPSK_100@0 20MHz_High_16QAM_1@99 20MHz_High_16QAM_100@0 ***** END *****

APPENDIX E_RF Output Power Report No.: RKSA260107001-00F Page 1 of 5 LTE Band 5, Normal Mode Average Conducted Power(dBm) ERP (dBm) ERP (W) Limit (W) Verdict 1.4MHz_Low_QPSK_1@0 23.27 19.70 0.093 7 Pass 1.4MHz_Low_QPSK_1@3 23.37 19.80 0.095 7 Pass 1.4MHz_Low_QPSK_1@5 23.25 19.68 0.093 7 Pass 1.4MHz_Low_QPSK_3@0 23.19 19.62 0.092 7 Pass 1.4MHz_Low_QPSK_3@1 23.22 19.65 0.092 7 Pass 1.4MHz_Low_QPSK_3@3 23.22 19.65 0.092 7 Pass 1.4MHz_Low_QPSK_6@0 22.11 18.54 0.071 7 Pass 1.4MHz_Low_16QAM_1@0 22.48 18.91 0.078 7 Pass 1.4MHz_Low_16QAM_1@3 22.62 19.05 0.080 7 Pass 1.4MHz_Low_16QAM_1@5 22.47 18.90 0.078 7 Pass 1.4MHz_Low_16QAM_3@0 22.47 18.90 0.078 7 Pass 1.4MHz_Low_16QAM_3@1 22.47 18.90 0.078 7 Pass 1.4MHz_Low_16QAM_3@3 22.52 18.95 0.079 7 Pass 1.4MHz_Low_16QAM_6@0 21.04 17.47 0.056 7 Pass 1.4MHz_Middle_QPSK_1@0 22.95 19.38 0.087 7 Pass 1.4MHz_Middle_QPSK_1@3 23.10 19.53 0.090 7 Pass 1.4MHz_Middle_QPSK_1@5 22.95 19.38 0.087 7 Pass 1.4MHz_Middle_QPSK_3@0 23.15 19.58 0.091 7 Pass 1.4MHz_Middle_QPSK_3@1 23.22 19.65 0.092 7 Pass 1.4MHz_Middle_QPSK_3@3 23.17 19.60 0.091 7 Pass 1.4MHz_Middle_QPSK_6@0 22.15 18.58 0.072 7 Pass 1.4MHz_Middle_16QAM_1@0 21.90 18.33 0.068 7 Pass 1.4MHz_Middle_16QAM_1@3 21.98 18.41 0.069 7 Pass 1.4MHz_Middle_16QAM_1@5 21.88 18.31 0.068 7 Pass 1.4MHz_Middle_16QAM_3@0 22.34 18.77 0.075 7 Pass 1.4MHz_Middle_16QAM_3@1 22.37 18.80 0.076 7 Pass 1.4MHz_Middle_16QAM_3@3 22.34 18.77 0.075 7 Pass 1.4MHz_Middle_16QAM_6@0 21.36 17.79 0.060 7 Pass 1.4MHz_High_QPSK_1@0 22.99 19.42 0.087 7 Pass 1.4MHz_High_QPSK_1@3 23.20 19.63 0.092 7 Pass APPENDIX E_RF Output Power Report No.: RKSA260107001-00F Page 2 of 5 Mode Average Conducted Power(dBm) ERP (dBm) ERP (W) Limit (W) Verdict 1.4MHz_High_QPSK_1@5 22.97 19.40 0.087 7 Pass 1.4MHz_High_QPSK_3@0 23.17 19.60 0.091 7 Pass 1.4MHz_High_QPSK_3@1 23.18 19.61 0.091 7 Pass 1.4MHz_High_QPSK_3@3 23.21 19.64 0.092 7 Pass 1.4MHz_High_QPSK_6@0 22.15 18.58 0.072 7 Pass 1.4MHz_High_16QAM_1@0 21.91 18.34 0.068 7 Pass 1.4MHz_High_16QAM_1@3 22.13 18.56 0.072 7 Pass 1.4MHz_High_16QAM_1@5 21.92 18.35 0.068 7 Pass 1.4MHz_High_16QAM_3@0 22.35 18.78 0.076 7 Pass 1.4MHz_High_16QAM_3@1 22.41 18.84 0.077 7 Pass 1.4MHz_High_16QAM_3@3 22.36 18.79 0.076 7 Pass 1.4MHz_High_16QAM_6@0 21.37 17.80 0.060 7 Pass 3MHz_Low_QPSK_1@0 23.03 19.46 0.088 7 Pass 3MHz_Low_QPSK_1@8 23.07 19.50 0.089 7 Pass 3MHz_Low_QPSK_1@14 23.05 19.48 0.089 7 Pass 3MHz_Low_QPSK_8@0 22.21 18.64 0.073 7 Pass 3MHz_Low_QPSK_8@4 22.19 18.62 0.073 7 Pass 3MHz_Low_QPSK_8@7 22.18 18.61 0.073 7 Pass 3MHz_Low_QPSK_15@0 22.17 18.60 0.072 7 Pass 3MHz_Low_16QAM_1@0 22.01 18.44 0.070 7 Pass 3MHz_Low_16QAM_1@8 21.98 18.41 0.069 7 Pass 3MHz_Low_16QAM_1@14 21.94 18.37 0.069 7 Pass 3MHz_Low_16QAM_8@0 21.18 17.61 0.058 7 Pass 3MHz_Low_16QAM_8@4 21.21 17.64 0.058 7 Pass 3MHz_Low_16QAM_8@7 21.19 17.62 0.058 7 Pass 3MHz_Low_16QAM_15@0 21.18 17.61 0.058 7 Pass 3MHz_Middle_QPSK_1@0 23.10 19.53 0.090 7 Pass 3MHz_Middle_QPSK_1@8 23.13 19.56 0.090 7 Pass 3MHz_Middle_QPSK_1@14 23.17 19.60 0.091 7 Pass 3MHz_Middle_QPSK_8@0 22.16 18.59 0.072 7 Pass 3MHz_Middle_QPSK_8@4 22.25 18.68 0.074 7 Pass 3MHz_Middle_QPSK_8@7 22.17 18.60 0.072 7 Pass 3MHz_Middle_QPSK_15@0 22.19 18.62 0.073 7 Pass 3MHz_Middle_16QAM_1@0 22.20 18.63 0.073 7 Pass APPENDIX E_RF Output Power Report No.: RKSA260107001-00F Page 3 of 5 Mode Average Conducted Power(dBm) ERP (dBm) ERP (W) Limit (W) Verdict 3MHz_Middle_16QAM_1@8 22.17 18.60 0.072 7 Pass 3MHz_Middle_16QAM_1@14 22.11 18.54 0.071 7 Pass 3MHz_Middle_16QAM_8@0 21.22 17.65 0.058 7 Pass 3MHz_Middle_16QAM_8@4 21.31 17.74 0.059 7 Pass 3MHz_Middle_16QAM_8@7 21.23 17.66 0.058 7 Pass 3MHz_Middle_16QAM_15@0 21.28 17.71 0.059 7 Pass 3MHz_High_QPSK_1@0 23.36 19.79 0.095 7 Pass 3MHz_High_QPSK_1@8 23.31 19.74 0.094 7 Pass 3MHz_High_QPSK_1@14 23.36 19.79 0.095 7 Pass 3MHz_High_QPSK_8@0 22.16 18.59 0.072 7 Pass 3MHz_High_QPSK_8@4 22.25 18.68 0.074 7 Pass 3MHz_High_QPSK_8@7 22.17 18.60 0.072 7 Pass 3MHz_High_QPSK_15@0 22.23 18.66 0.073 7 Pass 3MHz_High_16QAM_1@0 22.56 18.99 0.079 7 Pass 3MHz_High_16QAM_1@8 22.56 18.99 0.079 7 Pass 3MHz_High_16QAM_1@14 22.58 19.01 0.080 7 Pass 3MHz_High_16QAM_8@0 21.31 17.74 0.059 7 Pass 3MHz_High_16QAM_8@4 21.37 17.80 0.060 7 Pass 3MHz_High_16QAM_8@7 21.29 17.72 0.059 7 Pass 3MHz_High_16QAM_15@0 21.23 17.66 0.058 7 Pass 5MHz_Low_QPSK_1@0 23.05 19.48 0.089 7 Pass 5MHz_Low_QPSK_1@12 23.29 19.72 0.094 7 Pass 5MHz_Low_QPSK_1@24 23.09 19.52 0.090 7 Pass 5MHz_Low_QPSK_12@0 22.21 18.64 0.073 7 Pass 5MHz_Low_QPSK_12@7 22.28 18.71 0.074 7 Pass 5MHz_Low_QPSK_12@13 22.22 18.65 0.073 7 Pass 5MHz_Low_QPSK_25@0 22.21 18.64 0.073 7 Pass 5MHz_Low_16QAM_1@0 22.13 18.56 0.072 7 Pass 5MHz_Low_16QAM_1@12 22.25 18.68 0.074 7 Pass 5MHz_Low_16QAM_1@24 22.15 18.58 0.072 7 Pass 5MHz_Low_16QAM_12@0 21.27 17.70 0.059 7 Pass 5MHz_Low_16QAM_12@7 21.34 17.77 0.060 7 Pass 5MHz_Low_16QAM_12@13 21.29 17.72 0.059 7 Pass 5MHz_Low_16QAM_25@0 21.24 17.67 0.058 7 Pass APPENDIX E_RF Output Power Report No.: RKSA260107001-00F Page 4 of 5 Mode Average Conducted Power(dBm) ERP (dBm) ERP (W) Limit (W) Verdict 5MHz_Middle_QPSK_1@0 23.11 19.54 0.090 7 Pass 5MHz_Middle_QPSK_1@12 23.34 19.77 0.095 7 Pass 5MHz_Middle_QPSK_1@24 23.08 19.51 0.089 7 Pass 5MHz_Middle_QPSK_12@0 22.20 18.63 0.073 7 Pass 5MHz_Middle_QPSK_12@7 22.29 18.72 0.074 7 Pass 5MHz_Middle_QPSK_12@13 22.17 18.60 0.072 7 Pass 5MHz_Middle_QPSK_25@0 22.17 18.60 0.072 7 Pass 5MHz_Middle_16QAM_1@0 22.11 18.54 0.071 7 Pass 5MHz_Middle_16QAM_1@12 22.39 18.82 0.076 7 Pass 5MHz_Middle_16QAM_1@24 22.14 18.57 0.072 7 Pass 5MHz_Middle_16QAM_12@0 21.27 17.70 0.059 7 Pass 5MHz_Middle_16QAM_12@7 21.35 17.78 0.060 7 Pass 5MHz_Middle_16QAM_12@13 21.22 17.65 0.058 7 Pass 5MHz_Middle_16QAM_25@0 21.22 17.65 0.058 7 Pass 5MHz_High_QPSK_1@0 23.06 19.49 0.089 7 Pass 5MHz_High_QPSK_1@12 23.26 19.69 0.093 7 Pass 5MHz_High_QPSK_1@24 23.05 19.48 0.089 7 Pass 5MHz_High_QPSK_12@0 22.18 18.61 0.073 7 Pass 5MHz_High_QPSK_12@7 22.22 18.65 0.073 7 Pass 5MHz_High_QPSK_12@13 22.12 18.55 0.072 7 Pass 5MHz_…

Text truncated - open the document above for the full version.

APPENDIX E_ RF Output Power Report No.: RKSA260107001-00F Page 1 of 31 LTE Band 4, Normal Mode Average Conducted Power(dBm) EIRP (dBm) EIRP (W) Limit (W) Verdict 1.4MHz_Low_QPSK_1@0 22.87 23.17 0.207 1 Pass 1.4MHz_Low_QPSK_1@3 22.98 23.28 0.213 1 Pass 1.4MHz_Low_QPSK_1@5 22.82 23.12 0.205 1 Pass 1.4MHz_Low_QPSK_3@0 22.77 23.07 0.203 1 Pass 1.4MHz_Low_QPSK_3@1 22.84 23.14 0.206 1 Pass 1.4MHz_Low_QPSK_3@3 22.80 23.10 0.204 1 Pass 1.4MHz_Low_QPSK_6@0 21.69 21.99 0.158 1 Pass 1.4MHz_Low_16QAM_1@0 22.04 22.34 0.171 1 Pass 1.4MHz_Low_16QAM_1@3 22.20 22.50 0.178 1 Pass 1.4MHz_Low_16QAM_1@5 22.02 22.32 0.171 1 Pass 1.4MHz_Low_16QAM_3@0 22.06 22.36 0.172 1 Pass 1.4MHz_Low_16QAM_3@1 22.07 22.37 0.173 1 Pass 1.4MHz_Low_16QAM_3@3 22.06 22.36 0.172 1 Pass 1.4MHz_Low_16QAM_6@0 20.71 21.01 0.126 1 Pass 1.4MHz_Middle_QPSK_1@0 22.66 22.96 0.198 1 Pass 1.4MHz_Middle_QPSK_1@3 22.80 23.10 0.204 1 Pass 1.4MHz_Middle_QPSK_1@5 22.65 22.95 0.197 1 Pass 1.4MHz_Middle_QPSK_3@0 22.79 23.09 0.204 1 Pass 1.4MHz_Middle_QPSK_3@1 22.86 23.16 0.207 1 Pass 1.4MHz_Middle_QPSK_3@3 22.83 23.13 0.206 1 Pass 1.4MHz_Middle_QPSK_6@0 21.85 22.15 0.164 1 Pass 1.4MHz_Middle_16QAM_1@0 21.53 21.83 0.152 1 Pass 1.4MHz_Middle_16QAM_1@3 21.71 22.01 0.159 1 Pass 1.4MHz_Middle_16QAM_1@5 21.54 21.84 0.153 1 Pass 1.4MHz_Middle_16QAM_3@0 21.92 22.22 0.167 1 Pass 1.4MHz_Middle_16QAM_3@1 22.03 22.33 0.171 1 Pass 1.4MHz_Middle_16QAM_3@3 21.95 22.25 0.168 1 Pass 1.4MHz_Middle_16QAM_6@0 21.04 21.34 0.136 1 Pass 1.4MHz_High_QPSK_1@0 22.83 23.13 0.206 1 Pass 1.4MHz_High_QPSK_1@3 23 23.30 0.214 1 Pass APPENDIX E_ RF Output Power Report No.: RKSA260107001-00F Page 2 of 31 Mode Average Conducted Power(dBm) EIRP (dBm) EIRP (W) Limit (W) Verdict 1.4MHz_High_QPSK_1@5 22.84 23.14 0.206 1 Pass 1.4MHz_High_QPSK_3@0 22.99 23.29 0.213 1 Pass 1.4MHz_High_QPSK_3@1 23.06 23.36 0.217 1 Pass 1.4MHz_High_QPSK_3@3 23.01 23.31 0.214 1 Pass 1.4MHz_High_QPSK_6@0 21.97 22.27 0.169 1 Pass 1.4MHz_High_16QAM_1@0 21.72 22.02 0.159 1 Pass 1.4MHz_High_16QAM_1@3 21.85 22.15 0.164 1 Pass 1.4MHz_High_16QAM_1@5 21.73 22.03 0.160 1 Pass 1.4MHz_High_16QAM_3@0 22.09 22.39 0.173 1 Pass 1.4MHz_High_16QAM_3@1 22.14 22.44 0.175 1 Pass 1.4MHz_High_16QAM_3@3 22.10 22.40 0.174 1 Pass 1.4MHz_High_16QAM_6@0 21.15 21.45 0.140 1 Pass 3MHz_Low_QPSK_1@0 22.69 22.99 0.199 1 Pass 3MHz_Low_QPSK_1@8 22.69 22.99 0.199 1 Pass 3MHz_Low_QPSK_1@14 22.68 22.98 0.199 1 Pass 3MHz_Low_QPSK_8@0 21.76 22.06 0.161 1 Pass 3MHz_Low_QPSK_8@4 21.82 22.12 0.163 1 Pass 3MHz_Low_QPSK_8@7 21.75 22.05 0.160 1 Pass 3MHz_Low_QPSK_15@0 21.77 22.07 0.161 1 Pass 3MHz_Low_16QAM_1@0 21.63 21.93 0.156 1 Pass 3MHz_Low_16QAM_1@8 21.57 21.87 0.154 1 Pass 3MHz_Low_16QAM_1@14 21.55 21.85 0.153 1 Pass 3MHz_Low_16QAM_8@0 20.79 21.09 0.129 1 Pass 3MHz_Low_16QAM_8@4 20.82 21.12 0.129 1 Pass 3MHz_Low_16QAM_8@7 20.78 21.08 0.128 1 Pass 3MHz_Low_16QAM_15@0 20.78 21.08 0.128 1 Pass 3MHz_Middle_QPSK_1@0 22.79 23.09 0.204 1 Pass 3MHz_Middle_QPSK_1@8 22.84 23.14 0.206 1 Pass 3MHz_Middle_QPSK_1@14 22.83 23.13 0.206 1 Pass 3MHz_Middle_QPSK_8@0 21.84 22.14 0.164 1 Pass 3MHz_Middle_QPSK_8@4 21.93 22.23 0.167 1 Pass 3MHz_Middle_QPSK_8@7 21.83 22.13 0.163 1 Pass 3MHz_Middle_QPSK_15@0 21.83 22.13 0.163 1 Pass 3MHz_Middle_16QAM_1@0 21.82 22.12 0.163 1 Pass APPENDIX E_ RF Output Power Report No.: RKSA260107001-00F Page 3 of 31 Mode Average Conducted Power(dBm) EIRP (dBm) EIRP (W) Limit (W) Verdict 3MHz_Middle_16QAM_1@8 21.75 22.05 0.160 1 Pass 3MHz_Middle_16QAM_1@14 21.75 22.05 0.160 1 Pass 3MHz_Middle_16QAM_8@0 20.93 21.23 0.133 1 Pass 3MHz_Middle_16QAM_8@4 20.95 21.25 0.133 1 Pass 3MHz_Middle_16QAM_8@7 20.89 21.19 0.132 1 Pass 3MHz_Middle_16QAM_15@0 20.92 21.22 0.132 1 Pass 3MHz_High_QPSK_1@0 23.07 23.37 0.217 1 Pass 3MHz_High_QPSK_1@8 23.13 23.43 0.220 1 Pass 3MHz_High_QPSK_1@14 23.12 23.42 0.220 1 Pass 3MHz_High_QPSK_8@0 21.93 22.23 0.167 1 Pass 3MHz_High_QPSK_8@4 22.01 22.31 0.170 1 Pass 3MHz_High_QPSK_8@7 21.94 22.24 0.167 1 Pass 3MHz_High_QPSK_15@0 21.95 22.25 0.168 1 Pass 3MHz_High_16QAM_1@0 22.31 22.61 0.182 1 Pass 3MHz_High_16QAM_1@8 22.35 22.65 0.184 1 Pass 3MHz_High_16QAM_1@14 22.34 22.64 0.184 1 Pass 3MHz_High_16QAM_8@0 21.14 21.44 0.139 1 Pass 3MHz_High_16QAM_8@4 21.13 21.43 0.139 1 Pass 3MHz_High_16QAM_8@7 21.05 21.35 0.136 1 Pass 3MHz_High_16QAM_15@0 21.02 21.32 0.136 1 Pass 5MHz_Low_QPSK_1@0 22.68 22.98 0.199 1 Pass 5MHz_Low_QPSK_1@12 22.95 23.25 0.211 1 Pass 5MHz_Low_QPSK_1@24 22.77 23.07 0.203 1 Pass 5MHz_Low_QPSK_12@0 21.79 22.09 0.162 1 Pass 5MHz_Low_QPSK_12@7 21.88 22.18 0.165 1 Pass 5MHz_Low_QPSK_12@13 21.82 22.12 0.163 1 Pass 5MHz_Low_QPSK_25@0 21.77 22.07 0.161 1 Pass 5MHz_Low_16QAM_1@0 21.74 22.04 0.160 1 Pass 5MHz_Low_16QAM_1@12 21.93 22.23 0.167 1 Pass 5MHz_Low_16QAM_1@24 21.75 22.05 0.160 1 Pass 5MHz_Low_16QAM_12@0 20.89 21.19 0.132 1 Pass 5MHz_Low_16QAM_12@7 20.95 21.25 0.133 1 Pass 5MHz_Low_16QAM_12@13 20.93 21.23 0.133 1 Pass 5MHz_Low_16QAM_25@0 20.83 21.13 0.130 1 Pass APPENDIX E_ RF Output Power Report No.: RKSA260107001-00F Page 4 of 31 Mode Average Conducted Power(dBm) EIRP (dBm) EIRP (W) Limit (W) Verdict 5MHz_Middle_QPSK_1@0 22.80 23.10 0.204 1 Pass 5MHz_Middle_QPSK_1@12 23.05 23.35 0.216 1 Pass 5MHz_Middle_QPSK_1@24 22.76 23.06 0.202 1 Pass 5MHz_Middle_QPSK_12@0 21.92 22.22 0.167 1 Pass 5MHz_Middle_QPSK_12@7 21.91 22.21 0.166 1 Pass 5MHz_Middle_QPSK_12@13 21.85 22.15 0.164 1 Pass 5MHz_Middle_QPSK_25@0 21.88 22.18 0.165 1 Pass 5MHz_Middle_16QAM_1@0 21.81 22.11 0.163 1 Pass 5MHz_Middle_16QAM_1@12 22.09 22.39 0.173 1 Pass 5MHz_Middle_16QAM_1@24 21.79 22.09 0.162 1 Pass 5MHz_Middle_16QAM_12@0 21 21.30 0.135 1 Pass 5MHz_Middle_16QAM_12@7 21.03 21.33 0.136 1 Pass 5MHz_Middle_16QAM_12@13 20.93 21.23 0.133 1 Pass 5MHz_Middle_16QAM_25@0 20.92 21.22 0.132 1 Pass 5MHz_High_QPSK_1@0 22.85 23.15 0.207 1 Pass 5MHz_High_QPSK_1@12 23.06 23.36 0.217 1 Pass 5MHz_High_QPSK_1@24 22.88 23.18 0.208 1 Pass 5MHz_High_QPSK_12@0 22 22.30 0.170 1 Pass 5MHz_High_QPSK_12@7 22.05 22.35 0.172 1 Pass 5MHz_High_QPSK_12@13 21.96 22.26 0.168 1 Pas…

Text truncated - open the document above for the full version.

APPENDIX E_ RF Output Power Report No.: RKSA260107001-00F Page 1 of 8 LTE Band 2, Normal Mode Average Conducted Power(dBm) EIRP (dBm) EIRP (W) Limit (W) Verdict 1.4MHz_Low_QPSK_1@0 23.17 22.81 0.191 2 Pass 1.4MHz_Low_QPSK_1@3 23.29 22.93 0.196 2 Pass 1.4MHz_Low_QPSK_1@5 23.12 22.76 0.189 2 Pass 1.4MHz_Low_QPSK_3@0 23.10 22.74 0.188 2 Pass 1.4MHz_Low_QPSK_3@1 23.12 22.76 0.189 2 Pass 1.4MHz_Low_QPSK_3@3 23.12 22.76 0.189 2 Pass 1.4MHz_Low_QPSK_6@0 22.03 21.67 0.147 2 Pass 1.4MHz_Low_16QAM_1@0 22.33 21.97 0.157 2 Pass 1.4MHz_Low_16QAM_1@3 22.53 22.17 0.165 2 Pass 1.4MHz_Low_16QAM_1@5 22.35 21.99 0.158 2 Pass 1.4MHz_Low_16QAM_3@0 22.41 22.05 0.160 2 Pass 1.4MHz_Low_16QAM_3@1 22.37 22.01 0.159 2 Pass 1.4MHz_Low_16QAM_3@3 22.40 22.04 0.160 2 Pass 1.4MHz_Low_16QAM_6@0 20.97 20.61 0.115 2 Pass 1.4MHz_Middle_QPSK_1@0 22.66 22.3 0.170 2 Pass 1.4MHz_Middle_QPSK_1@3 22.82 22.46 0.176 2 Pass 1.4MHz_Middle_QPSK_1@5 22.69 22.33 0.171 2 Pass 1.4MHz_Middle_QPSK_3@0 22.84 22.48 0.177 2 Pass 1.4MHz_Middle_QPSK_3@1 22.92 22.56 0.180 2 Pass 1.4MHz_Middle_QPSK_3@3 22.90 22.54 0.179 2 Pass 1.4MHz_Middle_QPSK_6@0 21.82 21.46 0.140 2 Pass 1.4MHz_Middle_16QAM_1@0 21.56 21.2 0.132 2 Pass 1.4MHz_Middle_16QAM_1@3 21.75 21.39 0.138 2 Pass 1.4MHz_Middle_16QAM_1@5 21.63 21.27 0.134 2 Pass 1.4MHz_Middle_16QAM_3@0 22.03 21.67 0.147 2 Pass 1.4MHz_Middle_16QAM_3@1 22.09 21.73 0.149 2 Pass 1.4MHz_Middle_16QAM_3@3 22.06 21.7 0.148 2 Pass 1.4MHz_Middle_16QAM_6@0 21.07 20.71 0.118 2 Pass 1.4MHz_High_QPSK_1@0 22.61 22.25 0.168 2 Pass 1.4MHz_High_QPSK_1@3 22.79 22.43 0.175 2 Pass APPENDIX E_ RF Output Power Report No.: RKSA260107001-00F Page 2 of 8 Mode Average Conducted Power(dBm) EIRP (dBm) EIRP (W) Limit (W) Verdict 1.4MHz_High_QPSK_1@5 22.59 22.23 0.167 2 Pass 1.4MHz_High_QPSK_3@0 22.77 22.41 0.174 2 Pass 1.4MHz_High_QPSK_3@1 22.81 22.45 0.176 2 Pass 1.4MHz_High_QPSK_3@3 22.76 22.4 0.174 2 Pass 1.4MHz_High_QPSK_6@0 21.71 21.35 0.136 2 Pass 1.4MHz_High_16QAM_1@0 21.52 21.16 0.131 2 Pass 1.4MHz_High_16QAM_1@3 21.66 21.3 0.135 2 Pass 1.4MHz_High_16QAM_1@5 21.51 21.15 0.130 2 Pass 1.4MHz_High_16QAM_3@0 21.89 21.53 0.142 2 Pass 1.4MHz_High_16QAM_3@1 21.95 21.59 0.144 2 Pass 1.4MHz_High_16QAM_3@3 21.94 21.58 0.144 2 Pass 1.4MHz_High_16QAM_6@0 20.92 20.56 0.114 2 Pass 3MHz_Low_QPSK_1@0 22.88 22.52 0.179 2 Pass 3MHz_Low_QPSK_1@8 22.89 22.53 0.179 2 Pass 3MHz_Low_QPSK_1@14 22.87 22.51 0.178 2 Pass 3MHz_Low_QPSK_8@0 22.01 21.65 0.146 2 Pass 3MHz_Low_QPSK_8@4 22.02 21.66 0.147 2 Pass 3MHz_Low_QPSK_8@7 21.95 21.59 0.144 2 Pass 3MHz_Low_QPSK_15@0 21.99 21.63 0.146 2 Pass 3MHz_Low_16QAM_1@0 21.83 21.47 0.140 2 Pass 3MHz_Low_16QAM_1@8 21.79 21.43 0.139 2 Pass 3MHz_Low_16QAM_1@14 21.75 21.39 0.138 2 Pass 3MHz_Low_16QAM_8@0 21 20.64 0.116 2 Pass 3MHz_Low_16QAM_8@4 21.05 20.69 0.117 2 Pass 3MHz_Low_16QAM_8@7 20.99 20.63 0.116 2 Pass 3MHz_Low_16QAM_15@0 20.98 20.62 0.115 2 Pass 3MHz_Middle_QPSK_1@0 22.79 22.43 0.175 2 Pass 3MHz_Middle_QPSK_1@8 22.78 22.42 0.175 2 Pass 3MHz_Middle_QPSK_1@14 22.77 22.41 0.174 2 Pass 3MHz_Middle_QPSK_8@0 21.84 21.48 0.141 2 Pass 3MHz_Middle_QPSK_8@4 21.84 21.48 0.141 2 Pass 3MHz_Middle_QPSK_8@7 21.80 21.44 0.139 2 Pass 3MHz_Middle_QPSK_15@0 21.78 21.42 0.139 2 Pass 3MHz_Middle_16QAM_1@0 21.82 21.46 0.140 2 Pass APPENDIX E_ RF Output Power Report No.: RKSA260107001-00F Page 3 of 8 Mode Average Conducted Power(dBm) EIRP (dBm) EIRP (W) Limit (W) Verdict 3MHz_Middle_16QAM_1@8 21.75 21.39 0.138 2 Pass 3MHz_Middle_16QAM_1@14 21.71 21.35 0.136 2 Pass 3MHz_Middle_16QAM_8@0 20.86 20.5 0.112 2 Pass 3MHz_Middle_16QAM_8@4 20.93 20.57 0.114 2 Pass 3MHz_Middle_16QAM_8@7 20.83 20.47 0.111 2 Pass 3MHz_Middle_16QAM_15@0 20.91 20.55 0.114 2 Pass 3MHz_High_QPSK_1@0 22.86 22.5 0.178 2 Pass 3MHz_High_QPSK_1@8 22.89 22.53 0.179 2 Pass 3MHz_High_QPSK_1@14 22.87 22.51 0.178 2 Pass 3MHz_High_QPSK_8@0 21.72 21.36 0.137 2 Pass 3MHz_High_QPSK_8@4 21.74 21.38 0.137 2 Pass 3MHz_High_QPSK_8@7 21.69 21.33 0.136 2 Pass 3MHz_High_QPSK_15@0 21.72 21.36 0.137 2 Pass 3MHz_High_16QAM_1@0 22.04 21.68 0.147 2 Pass 3MHz_High_16QAM_1@8 22.06 21.7 0.148 2 Pass 3MHz_High_16QAM_1@14 22.06 21.7 0.148 2 Pass 3MHz_High_16QAM_8@0 20.87 20.51 0.112 2 Pass 3MHz_High_16QAM_8@4 20.85 20.49 0.112 2 Pass 3MHz_High_16QAM_8@7 20.78 20.42 0.110 2 Pass 3MHz_High_16QAM_15@0 20.76 20.4 0.110 2 Pass 5MHz_Low_QPSK_1@0 22.90 22.54 0.179 2 Pass 5MHz_Low_QPSK_1@12 23.11 22.75 0.188 2 Pass 5MHz_Low_QPSK_1@24 22.84 22.48 0.177 2 Pass 5MHz_Low_QPSK_12@0 22.07 21.71 0.148 2 Pass 5MHz_Low_QPSK_12@7 22.09 21.73 0.149 2 Pass 5MHz_Low_QPSK_12@13 22.04 21.68 0.147 2 Pass 5MHz_Low_QPSK_25@0 22.01 21.65 0.146 2 Pass 5MHz_Low_16QAM_1@0 21.95 21.59 0.144 2 Pass 5MHz_Low_16QAM_1@12 22.15 21.79 0.151 2 Pass 5MHz_Low_16QAM_1@24 21.96 21.6 0.145 2 Pass 5MHz_Low_16QAM_12@0 21.15 20.79 0.120 2 Pass 5MHz_Low_16QAM_12@7 21.16 20.8 0.120 2 Pass 5MHz_Low_16QAM_12@13 21.12 20.76 0.119 2 Pass 5MHz_Low_16QAM_25@0 21.09 20.73 0.118 2 Pass APPENDIX E_ RF Output Power Report No.: RKSA260107001-00F Page 4 of 8 Mode Average Conducted Power(dBm) EIRP (dBm) EIRP (W) Limit (W) Verdict 5MHz_Middle_QPSK_1@0 22.80 22.44 0.175 2 Pass 5MHz_Middle_QPSK_1@12 22.99 22.63 0.183 2 Pass 5MHz_Middle_QPSK_1@24 22.78 22.42 0.175 2 Pass 5MHz_Middle_QPSK_12@0 21.86 21.5 0.141 2 Pass 5MHz_Middle_QPSK_12@7 21.89 21.53 0.142 2 Pass 5MHz_Middle_QPSK_12@13 21.86 21.5 0.141 2 Pass 5MHz_Middle_QPSK_25@0 21.85 21.49 0.141 2 Pass 5MHz_Middle_16QAM_1@0 21.86 21.5 0.141 2 Pass 5MHz_Middle_16QAM_1@12 22.02 21.66 0.147 2 Pass 5MHz_Middle_16QAM_1@24 21.81 21.45 0.140 2 Pass 5MHz_Middle_16QAM_12@0 20.90 20.54 0.113 2 Pass 5MHz_Middle_16QAM_12@7 20.94 20.58 0.114 2 Pass 5MHz_Middle_16QAM_12@13 20.93 20.57 0.114 2 Pass 5MHz_Middle_16QAM_25@0 20.92 20.56 0.114 2 Pass 5MHz_High_QPSK_1@0 22.58 22.22 0.167 2 Pass 5MHz_High_QPSK_1@12 22.84 22.48 0.177 2 Pass 5MHz_High_QPSK_1@24 22.61 22.25 0.168 2 Pass 5MHz_High_QPSK_12@0 21.73 21.37 0.137 2 Pass 5MHz_High_QPSK_12@7 21.78 21.42 0.139 2 Pass 5MHz_High_QPSK_12@13 21.64 21.28 0.134 2 Pass 5MHz_High_Q…

Text truncated - open the document above for the full version.

APPENDIX D_TX spurious Report No.: RKSA260107001-00F Page 1 of 5 LTE Band 5, Normal Mode Va l u e (dBm) Limit Verdict 1.4MHz_Low_QPSK_1@0(30MHz~9.49GHz) -19.09 See Graphs Pass 1.4MHz_Low_QPSK_6@0(30MHz~9.49GHz) -19.51 See Graphs Pass 1.4MHz_Middle_QPSK_1@0(30MHz~9.49GHz) -19.27 See Graphs Pass 1.4MHz_Middle_QPSK_6@0(30MHz~9.49GHz) -19.45 See Graphs Pass 1.4MHz_High_QPSK_1@0(30MHz~9.49GHz) -18.85 See Graphs Pass 1.4MHz_High_QPSK_6@0(30MHz~9.49GHz) -19.03 See Graphs Pass 3MHz_Low_QPSK_1@0(30MHz~9.49GHz) -19.00 See Graphs Pass 3MHz_Low_QPSK_15@0(30MHz~9.49GHz) -19.26 See Graphs Pass 3MHz_Middle_QPSK_1@0(30MHz~9.49GHz) -19.33 See Graphs Pass 3MHz_Middle_QPSK_15@0(30MHz~9.49GHz) -19.41 See Graphs Pass 3MHz_High_QPSK_1@0(30MHz~9.49GHz) -18.57 See Graphs Pass 3MHz_High_QPSK_15@0(30MHz~9.49GHz) -19.06 See Graphs Pass 5MHz_Low_QPSK_1@0(30MHz~9.49GHz) -19.68 See Graphs Pass 5MHz_Low_QPSK_25@0(30MHz~9.49GHz) -19.21 See Graphs Pass 5MHz_Middle_QPSK_1@0(30MHz~9.49GHz) -19.42 See Graphs Pass 5MHz_Middle_QPSK_25@0(30MHz~9.49GHz) -18.85 See Graphs Pass 5MHz_High_QPSK_1@0(30MHz~9.49GHz) -19.33 See Graphs Pass 5MHz_High_QPSK_25@0(30MHz~9.49GHz) -19.31 See Graphs Pass 10MHz_Low_QPSK_1@0(30MHz~9.49GHz) -18.74 See Graphs Pass 10MHz_Low_QPSK_50@0(30MHz~9.49GHz) -19.19 See Graphs Pass 10MHz_Middle_QPSK_1@0(30MHz~9.49GHz) -19.27 See Graphs Pass 10MHz_Middle_QPSK_50@0(30MHz~9.49GHz) -19.39 See Graphs Pass 10MHz_High_QPSK_1@0(30MHz~9.49GHz) -19.65 See Graphs Pass 10MHz_High_QPSK_50@0(30MHz~9.49GHz) -19.09 See Graphs Pass Note:1RB was the worst case. APPENDIX D_TX spurious Report No.: RKSA260107001-00F Page 2 of 5 LTE Band 5, Normal 1RB was the worst case 1.4MHz_Low_QPSK_1@0(30MHz~9.49GHz) 1.4MHz_Low_QPSK_6@0(30MHz~9.49GHz) 1.4MHz_Middle_QPSK_1@0(30MHz~9.49GHz) 1.4MHz_Middle_QPSK_6@0(30MHz~9.49GHz) 1.4MHz_High_QPSK_1@0(30MHz~9.49GHz) 1.4MHz_High_QPSK_6@0(30MHz~9.49GHz) APPENDIX D_TX spurious Report No.: RKSA260107001-00F Page 3 of 5 3MHz_Low_QPSK_1@0(30MHz~9.49GHz) 3MHz_Low_QPSK_15@0(30MHz~9.49GHz) 3MHz_Middle_QPSK_1@0(30MHz~9.49GHz) 3MHz_Middle_QPSK_15@0(30MHz~9.49GHz) 3MHz_High_QPSK_1@0(30MHz~9.49GHz) 3MHz_High_QPSK_15@0(30MHz~9.49GHz) APPENDIX D_TX spurious Report No.: RKSA260107001-00F Page 4 of 5 5MHz_Low_QPSK_1@0(30MHz~9.49GHz) 5MHz_Low_QPS…

Text truncated - open the document above for the full version.
