User manual Product features Parameters Bluetooth control Time switch Complete range of CCT/RGB+W strip available 1-100% stepless dimming Remote controllable after connect to internet Interface introduction 1: Search the APP- “SMART LIFE”from Apple store or Google Play. 2: Scan the QR code from the label or user manual. The APP compatible with Android 5.0 and IOS 10.0 or higher version. Wiring diagram Installation Attentions 1. Do not put any metal around the controller, which could blocked Bluetooth signal. 2. Ensure the power supply and controller are connected correctly. 3. The power supply output voltage should be same as LED strip working voltage. 4. Do not cover anything on the surface of power supply, controller and LED strip. 5. Ensure the connection is correct before powering. Download APP Log in / Register an account Open the APP - “Smart Life”, sign up for a new account or log in with an existing account. APP connection 1.Preparation jobs: Power on the LED strip and enter the home of APP. 2.Connect the controller Solution 1) : After powering on the strip, turn on and off 3 times, the strip will go into a status of quick flashing.Find the “+” (in the corresponding room of the APP) to add devices.If your mobile have already turned on bluetooth before connecting the LED strip, then no need to turn on bluetooth again, the APP will connect to the LED strip automatically. If your mobile didn’t turn on bluetooh before connecting the LED strip, the APP will pop up an interface with tips to ask you to turn on bluetooth. Then please choose “Allow”, then the bluetooth function of your mobile will be turned on. After that, the APP will pop up tips with info of the LED strips, Will go into an interface of bluetooth device, choose you will need to await for your mobile to pairing with the controller at this step. Choose “Done” when it shows “Added successfully”, then go into operation modes. 1.You can adjust the brightness and CCT under white light mode. 2.Under color light mode, you could change to any RGB mixed color and adjust the brightness and saturability. 4.Music modes 3.Scene: 1)Recommended scene: various modes available for options, you can choose your preferable modes freely. The APP interface, please subject to the latest version. 1.Use the power adapter with DC5V of output voltage only. 2. Install the controller correctly, use 3M tape to fix it. 3.Please unfold the LED strip to avoid the overheat issues. Please connect the cables of LED strip with the right position on the controller. Test the APP to check if it can control the LED strip correctly. If everything goes well, go to next step. 4. Check and ensure the power supply, controller and LED strip are connected correctly. Model No. SCBMC6-12 SCBMC6-14 CCT Color Input voltage DC 5V RGB+W Power Max.5W DC 5V Max.5W Color light mode White light mode Adjust CCT Switch Switch brightness Adjust brightness Adjust Custom scene Adjust Color 5.0 10.0 Music+IR remote controller manual Product introduction: 8-key infrared remote control can remotely realize the functions of dimming, color adjustment, mode, and music.5 modes of remote control music directly as external microphone. Remote control operation introduction: When using, first remove the tail PVC sheet, When the controller is under the pairing process,the remote controller can't work. Function NameFunction Description Press once, light on Press once, it will be white light 100% brightness Short press, every time the brigntness will increase 20% brightness, from 1%-20%-40%-60%-80%-100% brightness adjustment. Long press, stepless adjusting from current brightness. Short press, every time the brigntness will decrease 20% brightness, from 1%-20%-40%-60%-80%-100% brightness adjustment. Long press, stepless adjusting from current brightness. Every press will change to a scene. The default scenes are good night / work / read / leisure / soft / routious / colorful / multicoloured 1. Every shortly press will change a color, the order is " red, orange, yellow, green, cyan, blue, purple" 2. Long press is color stepless adjustment. "H" value. Regulating rule is 0-360-0-360. 3. For single CCT and CCT version light, this button is ineffective. Press once, light off Press once the light will be at a given brightness and color temperature. Brightness is 5%, color temperature is 0%. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Statement: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help.
CLEANLIFE ENERGY LLC Agent Authorization Company: CLEANLIFE ENERGY LLC Address: 7620 Hub Parkway Valley View Ohio 44125 USA Product Name: USB SMART BEACON TAPE LIGHT Model Number(s): TC-SMRT-TLK-USB-RGB30-BC-2M-01, TC-SMRT-TLK-USB-2765- BC-2M-01, TC-SMRT-TLK-USB-XXXXXXX-WW-LM-00, XXXXXXX - Can be RGB only, RGB with any 4 digit number or 2 digit number, or any 4 digit number or 2 digit number.WW - any 2 or 3 letter format , LM - Can be any number from 0-99 ending in the letter, 00 - Can be any number from 0-99 Product Description: USB SMART BEACON TAPE LIGHT We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. i s allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of o ur own. Date: Jan. 03, 2023 Signature: Name: Danny DiCioccio Title: manager Company: CLEANLIFE ENERGY LLC
CLEANLIFE ENERGY LLC Date: Jan. 03, 2023 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Subject; Request for Confidentiality FCC ID: 2A2YF-CLTLKUSB5V To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Danny DiCioccio Title: manager
CleanLife Energy LLC Model Confirmation Letter We, CleanLife Energy LLC, certify the product: USB SMART BEACON TAPE LIGHT , Model No.: TC-SMRT-TLK-USB-RGB30-BC-2M-01, TC-SMRT-TLK-USB-2765-BC-2M-01, TC-SMRT-TLK-USB-XXXXXXX-WW- LM-00 (XXXXXXX - Can be RGB only, RGB with any 4 digit number or 2 digit number, or any 4 digit number or 2 digit number. WW - any 2 or 3 letter format , LM - Can be any number from 0-99 ending in the letter, 00 - Can be any number from 0-99) All models have the same functionality, software and electronics, only the names may differ. Test sample model: TC-SMRT-TLK-USB-RGB30-BC-2M-01 Signiture: Grantee Contact: Danny DiCioccio Company Name: CleanLife Energy LLC Date: Jan. 03, 2022 FCC ID: 2A2YF-CLTLKUSB5V
Project No.: ZKT-221115L8511 FCC ID: 2A2YF-CLTLKUSB5V Project No.: ZKT-221115L8511 FCC ID: 2A2YF-CLTLKUSB5V Project No.: ZKT-221115L8511 FCC ID: 2A2YF-CLTLKUSB5V Project No.: ZKT-221115L8511 FCC ID: 2A2YF-CLTLKUSB5V
Project No.: ZKT-221115L8511 FCC ID: 2A2YF-CLTLKUSB5V Label place SIZE: 30*6mm USB SMART BEA CON TAPE LIGHT FCC ID: 2A2YF-CLTLKUSB5V
Project No.: ZKT-221115L8511 FCC ID: 2A2YF-CLTLKUSB5V Project No.: ZKT-221115L8511 FCC ID: 2A2YF-CLTLKUSB5V ANT
FCC ID: 2A2YF-CLTLKUSB5V RF Exposure Evaluation According to KDB 447498 and part 2.1093,Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f (GHz) ] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where f (GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Here, BLE-worst mode and channel Mode Channel Max Power (dBm) Tune up tolerance (dBm) Maximum tune-up (dBm) (mW) BLE Middle 4.79 5±1 63.981 Mode Maxtune-up Power (dBm) Max tune-up Power (mW) Frequency (MHz) Min. distance (mm) Calc. thresholds limit 63.981 2440< 5mm 1.2443.0 BLE So a SAR test is not required
