WWW.RADIOMASTERRC.COM Quick start guide Boxer Introduction Thank you for purchasing the RadioMaster Boxer 2.4g remote control system. The system is versatile and can be used by beginners and professionals. In order to ensure the correct and safe use of this product, please read this manual carefully before use. Due to constant improvements in software and hardware this manual may change over time. The information contained in this manual is subject to change without notice. Visit our website for the most up to date information. Boxer remote control is suitable for all types of fixed-wing aircraft, gliders, helicopters, cars, boats, robotics, multi-rotor aircraft and anything else you might create, if you can build it RadioMaster can control it. The Boxer uses a powerful operating system called EdgeTX, for more information visit the links below. -The RadioMaster team. Many remote-control models are equipped with powerful motors and sharp propellers. When using or maintaining models, proceed with caution. When performing assembly or maintenance, make sure to disconnect the power to the model and remove the propellers. Do not operate the Boxer remote control system under the following conditions: • In severe weather or strong windy conditions, such as rain, hail, snow, storms or electromagnetic environ- ments. • In any situation where visibility is limited. • In areas where people, property, high-voltage power lines, public roads, vehicles or animals may be present. • If you feel tired or unwell, or under the influence of drugs or alcohol. • If the remote control or model seems to be damaged or not working properly. • In areas with high 2.4GHz interference or where 2.4GHz radio is prohibited. • When the radios battery voltage is too low to be used. • In areas where local regulations prohibit the use of aviation models. Safety Information Manual and firmware download Boxer is pre-installed with factory approved EdgeTX firmware. To download the latest software manual, please visit the RadioMaster website: https://www.radiomasterrc.com To download the latest firmware for your Boxer remote control, please visit the EdgeTX website: https://www.Edge-tx.org Important ANTENNA: Install the provided antenna in the top of the radio BEFORE installing batteries and turning on the radio. DO NOT operate the radio without the antenna installed and the internal RF module powered on. Doing so will damage the internal RF module and will not be covered under warranty. FIRMWARE: The Boxer is pre-installed with the most stable firmware at the factory at time of release. please only attempt to update the firmware if you are confident in the process. Incorrect firmware updates may cause the remote control to become inoperable. 1 Remote control overview Batteries and charging 2 Boxer has a built-in USB-C charging function for 3.7V lithium batteries. The charging circuit is only designed to charge 2x 3.7V Li-ion 18650 or 2x 3.7V Li-Poly batteries (2s 7.4v Lipo battery pack), the nominal battery voltage is 3.7V, the charged voltage is 4.2V/Cell. Do not use LiFE battery packs or 18650 lithium-ion batteries with a nominal voltage of 3.6v with a fully charged voltage of 4.10V. Charging the incorrect type of battery may damage the charger or cause a fire. If using Li-ion, ensure the cells are not protected and are button-top cells. Please check the voltage and condition of the battery regularly and never charge unattended. Always charge in a safe area away from combustible materials. Refrain from charging if the remote control gets wet or damaged in any way. Do not charge with the polarity reversed RadioMaster does not assume any responsibility for any adverse consequences caused by the use or misuse of this product. Antenna Type-C Data Port 6 Pos Buttons Trainer Port LCD Screen Headphone Jack SF Momentary switch S1 DialS2 Dial SE Latching switch SB 3 Position SA 2 PositionSD 2 Position SC 3 Position Speaker Right Gimbal Left Gimbal Power Button Lanyard Loop MDL Button SYS Button RTN Button PAGE> Button PAGE< Button TELE Button Scroll wheel TYPE-C Charger Port Trim Buttons Model and protocol selection (multi-protocol module) Notes 3 Model selection and protocol selection (ELRS version) The Boxer comes with 4in1 or CC2500 multi-protocol internal RF module, which is compatible with several different protocols. To view the latest list of all compatible protocols, please visit https://www.- multi-module.org/ Please note that new protocols will be constantly updated and added to the latest firmware. Some new protocols may require firmware upgrades. Boxer ELRS units are equipped with an internal ELRS module, capable of providing 25mW-1000mW RF output. In non-extreme circumstances, 100mW output at 500Hz update rate is recommended, as higher RF output and update rates may significantly reduce battery life and generate excessive heat. Bind instructions 1Turn off the transmitter 2Cycle power to the receiver 3 times, the receiver LED will flash twice- indicating bind mode. 3Turn on the transmitter, long press the SYS button and choose the ExpressLRS LUA under the TOOLS menu. Scroll down to [Bind] and press enter. 4The LED on the receiver should now be solid, indicating successful bind. • Long press the MDL button to enter the model settings, select MULTI in the SETUP page, and select the protocol to be used in the sub-options. The system will automatically turn on the corresponding RF module according to the RF protocol you selected. • Bind [BND] is used to start the binding process. • Range [RNG] button can reduce the power to 1/30 to facilitate testing of remote-control distance. EdgeTX software is very powerful, and has a large number of programming and mixing functions. Please download the comprehensive software installation guide from the link below for more detailed instructions: https://www.Edge-tx.org or https://www.radiomasterrc.com Specifications Size: 235*178*77mm Weight: 532.5g Frequency: 2.400GHz-2.480GHz Internal RF O…
