2A338-X6007Perifit Care+

User Guide Perifit Care+ - X6 Innovations [email protected] SAS 128 rue la Boetie, 75008 Paris, France PERIFIT CARE+ PMN/Model: Perifit Care+ nRF52 Product Name: Perifit Care+ FCC ID:2A338-X6007 IC:28069-X6007 1. Intended use, intended user description READ ALL INSTRUCTIONS BEFORE USE. Failure to follow the instructions and safety information can lead to injury or damage to the device. 1.1 Intended use Perifit Care+ is a perineometer designed to treat stress, mild-moderate urge and mixed urinary incontinence in women, by strengthening of the pelvic floor muscles through exercise. This device provides biofeedback via smart phone technology. 1.2 Intended Users Perifit Care+ is intended for vaginal use by adults. The body of the probe is meant to be inserted into the user's vagina. The Perifit Care+ is intended for a single user only and is not to be shared. The PATIENT is an intended OPERATOR. 2. Safety Information Perifit Care+ is not intended to diagnose any medical condition. If you are unsure of whether or not you should use Perifit Care+, please consult a qualified healthcare professional. 2.1 Contra-indications Do not use Perifit Care+ if: - you have abnormal vaginal discharge (bleeding or otherwise) including bleeding after sexual intercourse, hematuria (blood in your urine), bleeding from the anus, - you are experiencing back pain severe enough for you to need pain-killers, - you have recently undergone surgery, 3.2 How often and how long should I train? Frequency and duration of use depends on each individual. A recommendation is to start by doing 3 to 5 ten-minute sessions per week. Do not exceed this training time. 3.3 Setting up 1. Download the app on the App Store or Google Play 2. Enable Bluetooth on your phone 3. Open Perifit App 4. Follow the instructions on the screen Ensure the Bluetooth function on your phone is enabled. However do not use your phone’s Bluetooth settings to connect! Connection should be done through the Perifit App. Need Help? Click on "?" in the Perifit App, or reach out to [email protected]. 3.4 Before you begin 3.4.1 Reminder of Contraindications Since purchasing the Perifit Care+, you may have developed a condition for which pelvic flor training is not recommended. Please review Section 2.1 ("Contraindications") before beginning to use your Perifit Care+. If you have any doubt as to whether is suitable for your condition, please consult medical profesionnal before use. 3.4.2 Device Use Life Your Perifit Care+ battery is intended to last for at least 5 years of regular training as detailed in section 3.6 (“Using Perifit Care+”). Once the device stops working after approximately 5 years, you can dispose of the device in accordance with local regulations. Refer to section 5.3 ( “Disposing of Perifit Care+”)." If you wish to dispose of the device, log in to your device account and initiate the account deletion process. Deleting your account will permanently remove all stored data associated with it. A chart showing your cumulative training time can be visualized in the ‘Train’ tab by clicking on the Time Goal section. If, when turning on your Perifit Care+, the green flashing light does not appear, contact customer service. 3.4.3 Inspecting your Perifit Care+ You should inspect your probe before each use. If you see any damage such as a cracked or torn outer surface, visible electronics, stains, discoloration, peeling and cracked seals, corrosion, or any other indication of damage do not use the Perifit Care+ and contact customer service. - you have symptoms of bladder, vaginal, or urinary tract infection are present, - you have a history of urinary retention or symptoms thereof, - you are pregnant, - you have given birth within the last 6 weeks, - you have neurological issues such as difficulties controlling your muscles, numbness, loss of sensitivity, - you have severe pelvic pain or muscle spasms, new pain after menopause, or the appearance of a mass or lump in the pelvis, - you have hypertonic pelvic floor (muscles in the pelvic floor becoming too tense and are unable to relax), vaginismus, - you have moderate to severe prolapse, and you have not yet consulted a medical professional, - you are allergic to medical-grade silicone. Using Perifit Care+ in these situations may affect an underlying condition. Consult a medical professional before using the Perifit Care+ for any of these situations. 2.2 Warnings and risks Please be aware that in rare cases, you may experience the following: - Performing too many pelvic floor contractions may cause muscle fatigue which may result in muscle soreness, and in some rare cases may cause muscle damage. Limit your sessions by the duration and frequency specified in Section 3.2 ("How often and for how long should I train?") - Although Perifit Care+ is made with medical grade silicone, in very rare cases some particularly sensitive users may experience allergic reaction. Please read and carefully follow the instructions in Section 3.5 ("Cleaning Perifit Care") of this User Guide. - If Perifit Care+ causes you a feeling of dryness, burning or itching, please stop using Perifit Care. If the feeling persists, please reach out to a qualified health professional - In rare cases, insertion of an external object such as Perifit Care+ into your vaginal cavity may result in vaginal bleeding. In this case, please stop using your device immediately and reach out to a qualified health professional. - Portable RF communications equipment (including peripherals such as antenna cables and external antennas) should be used no closer than 30 cm (12 inches) to any part of the Perifit Care+. Otherwise, this may impact the performance of the Perifit Care+. 2.3 Precautions In order to avoid risk of contamination or infection: - Wash your hands and your Perifit Care+ before and after every use with warm, soapy water. Read Section 3.5 ("Cleaning Perifit Care") of this User Guide carefully and follow all cleaning instructions. - Do not sh…

Text truncated - open the document above for the full version.

X6 Innovations SAS (2026.01.20) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2A338- X6007) [X6 Innovations SAS] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Camille Guillaume X6 Innovations SAS (2026.01.20) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID:2A338-X6007) [X6 Innovations SAS] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Camille Guillaume

X6 Innovations SAS (2026.01.20) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2A338- X6007) [X6 Innovations SAS] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Camille Guillaume X6 Innovations SAS (2026.01.20) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID:2A338-X6007) [X6 Innovations SAS] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Camille Guillaume

US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process : Company Name: AOGES CO., LIMITED Contact Name: XIAOYAN LAI Address: 1624 Market St., Ste 226, #30327 Denver CO, 80202 US Telephone No: +1 303 623 1940 Email: [email protected] FRN: 0033947847 Applicant: Company name: X6 Innovations SAS Product Description: Perifit Care+ FRN: 0031767254 Grantee code: 2A338 FCC ID: 2A338-X6007 Contact Name: Camille Guillaume Address: 128 Rue la Boétie, 75008 Paris, France Telephone No: 641405663 Email: [email protected] [X6 Innovations SAS] certifies that, as of the date of this filing of the application with the TCB, [AOGES CO., LIMITED] is our designated US agent for service of process for the above referenced FCC ID. [Shenzhen Xingchang Technology Co. Ltd] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [AOGES CO., LIMITED] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Date: 2026.01.09 Applicant’s Name: X6 Innovations SASUS Agent’s Name: AOGES CO., LIMITED Title: V&V Engineer Title: General Manager Signature Camille Guillaume Signature XIAOYAN LAI

X6 Innovations SAS Agent Authorization Company: X6 Innovations SAS Address: 128 Rue la Boétie, 75008 Paris, France Product Name: Perifit Care+ Model Number(s): Perifit Care+ nRF52 Product Description: Perifit Care+ FCC ID: 2A338-X6007 We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2026.01.20 Name: Jiankuai Li Title: PM Company: Shenzhen STS Test Services Co., Ltd.

X6 Innovations SAS Authorization Letter We, (the approval holder) Company name X6 Innovations SAS Addresss 128 Rue la Boétie, 75008 Paris, France declare that the following representative (agent): Name (person) Bovey Yang Company name Shenzhen STS Test Services Co., Ltd. Addresss 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China City Shenzhen Country China to act on our behalf on all matters concerning the application and documents submitted to Nemko for product certification below Product Description Perifit Care+ Type or Model(s) Perifit Care+ nRF52 Brand Name Perifit FCC ID 2A338-X6007 Attestation: Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) China 2026.01.20 Jiankuai Li PM

2026.01.09 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize SHENZHEN STS TEST SERVICES CO.,LTD./ 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China /Jiankuai Li(Name of Agent company name and address, Name of Agent) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. Name: Jiankuai Li Title: PM E-mail:[email protected] This appointment is valid until further until Nov 05, 2026 Sincerely, Signature: Name: Camille Guillaume Title: V&V Engineer E-mail: [email protected] Company: X6 Innovations SAS

X6 Innovations SAS Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2026.01.20 Subject; Request for Confidentiality FCC ID: 2A338-X6007 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description Tune-up Procedure Part List SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Jiankuai Li Title: PM

Page 1 of 3 ReportNo.:STS2510048 APPENDIX-PHOTOGRAPHSOFEUTCONSTRUCTIONALDETAILS Photo1 Photo2 Page 2 of 3 ReportNo.:STS2510048 Photo3 Photo4 Page 3 of 3 ReportNo.:STS2510048 Photo5 Photo6

38mm 38mm The product does not have enough space to place the label, and FCC ID label is reflected in the user manual and package, as below: 1.Package: 2.User Manual:

Page 1 of 6 ReportNo.:STS2510048 APPENDIX-PHOTOGRAPHSOFEUTCONSTRUCTIONALDETAILS Photo1 Photo2 Antenna Page 2 of 6 ReportNo.:STS2510048 Photo3 Photo4 Page 3 of 6 ReportNo.:STS2510048 Photo5 Photo6 Page 4 of 6 ReportNo.:STS2510048 Photo7 Photo8 Page 5 of 6 ReportNo.:STS2510048 Photo9 Photo10 Page 6 of 6 ReportNo.:STS2510048 Photo11

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. MPE Report Report No.:STS2510048H01 Issued for X6 Innovations SAS 128 Rue la Boétie, 75008 Paris, France Product Name: Perifit Care+ Brand Name: Perifit Model Name: Perifit Care+ nRF52 Series Model(s): N/A FCC ID: 2A338-X6007 Test Standards: FCC 47CFR §2.1093 Page 2 of 9 Report No.: STS2510048H01 TEST REPORT Applicant’s Name ................. : X6 Innovations SAS Address .................................. : 128 Rue la Boétie, 75008 Paris, France Manufacturer's Name .......... : X6 Innovations SAS Address .................................. : 128 Rue la Boétie, 75008 Paris, France Product Description Product Name ........................ : Perifit Care+ Brand Name ........................... : Perifit Model Name........................... : Perifit Care+ nRF52 Series Model(s) ...................... : N/A Test Standards ..................... : FCC 47CFR §2.1093 447498 D04 Interim General RF Exposure Guidance v01 The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. Date of Test ............................................ : Date of receipt of test item ...................... : 13 Oct. 2025 Date (s) of performance of tests.............. : 13 Oct. 2025 ~ 30 Oct. 2025 Date of Issue ........................................... : 30 Oct. 2025 Test Result ............................................... : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 9 Report No.: STS2510048H01 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 5 2. FCC 47CFR §2.1093 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 9 Page 4 of 9 Report No.: STS2510048H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 30 Oct. 2025 STS2510048H01 ALL Initial Issue Page 5 of 9 Report No.: STS2510048H01 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name Perifit Care+ Brand Name Perifit Model Name Perifit Care+ nRF52 Series Model(s) N/A Model Difference N/A Product Description The EUT is Perifit Care+ Operation Frequency: 2402~2480 MHz 2402 – 2480 MHz Modulation Type: GFSK BT BR(1Mbps): GFSK BT EDR(2Mbps): π/4-DQPSK Antenna gain: -1.3dBi 1.66dBi Antenna Designation: FPC Ceramic Antenna Power Rating N/A Adapter N/A Battery Model: CR-2032EL Brand: Panasonic Rated Voltage: 3V Capacity: 220mAh Hardware Version S07P08 Software Version 4.134.0 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 6 of 9 Report No.: STS2510048H01 2. FCC 47CFR §2.1093 REQUIREMENT 2.1 TEST STANDARDS Follow the maximum permissible exposure (MPE) limits specified in 447498 D04 Interim General Radio Frequency Exposure Guidelines v01. The gain of the antenna used in the product was extracted from the supplied antenna data sheet and the maximum total power input to the antenna was also measured. Calculate the distance from the product to the MPE limit by the formula. 2.2 LIMIT For single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: (A) The available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption may not be used in conjunction with other exemption criteria other than those in paragraph (b)(3)(ii)(A) of Part 1.1307. Medical implant devices may only use this exemption and that in paragraph (b)(3)(ii)(A); (B) Or the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold Pth (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by: Page 7 of 9 Report No.: STS2510048H01 (C) Or using below table and the minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. For the exemption in Table 1 to apply, R must be at least λ/2π, where λ is the free-space operating wavelength in meters. If the ERP of a single RF source is not easily obtained, then the available maximum time-averaged power may be used in lieu of ERP if the physical dimensions of the radiating structure(s) do not exceed the electrical length of λ/4 or if the antenna gain is less than that of a half-wave dipole (1.64 linear value). RF Source frequency (MHz) Threshold ERP(watts) 0.3-1.34 1,920 R 2 . 1.34-30 3,450 R 2 /f 2 . 30-300 3.83 R 2 . 300-1,500 0.0128 R 2 f. 1,500-100,000 19.2R 2 . Page 8 of 9 Report No.: STS2510048H01 For multiple RF sources: Multiple RF sources are exempt if: (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a radiating structure operating and the nearest portion of any other radiating structure in the same device, except if the sum of multiple sources is less than 1 mW during the time-averaging period, in which case they may be treated as a single source (separation is not required). This exemption may not be used in conjunction with other exemption criteria other than those is paragraph (b)(3)(i)(A) of Part 1.1307. Medical implant devices may only use this exempti…
