2A33N-AP32Tablet

FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of following measures:  -Reorient or relocate the receiving antenna.  -Increase the separation between the equipment and receiver.  -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  -Consult the dealer or an experienced radio/TV technician for help. Specific Absorption Rate (SAR) information: This Tablet meets the government's requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health. FCC RF Exposure Information and Statement The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types: AP32 (FCC ID: 2A33N-AP32) has also been tested against this SAR limit. The highest SAR value reported under this standard during product certification for when properly worn on the body is 1.277 W/kg. This device was tested for typical body-worn operations with the back of the Tablet kept 0mm from the body. To maintain compliance with FCC RF exposure requirements, use accessories that maintain a 0cm separation distance between the user's body and the back of the Tablet. The use of belt clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided. Body-worn Operation This device was tested for typical body-worn operations. To comply with RF exposure requirements, a minimum separation distance of 1cm must be maintained between the user’s body and the Tablet, including the antenna. Third-party belt-clips, holsters, and similar accessories used by this device should not contain any metallic components. Body-worn accessories that do not meet these requirements may not comply with RF exposure requirements and should be avoided. Use only the supplied or an approved antenna. requirements, a minimum separation distance of 0cm

Hot Pepper Mobile Inc. Covered Equipment Certification Attestation Letter 6/28/2023 ATTN.: Reviewing Engineer FCC ID: 2A33N-AP32 Hot Pepper Mobile Inc. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Hot Pepper Mobile Inc. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: Shawn Sun Title: CEO Company Name: Hot Pepper Mobile Inc. Date: 6/28/2023

Hot Pepper Mobile Inc. * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter 6/28/2023 ATTN.: Reviewing Engineer FCC ID: 2A33N-AP32 Per section 2.911(d)(7) of the FCC rules, Hot Pepper Mobile Inc. (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. agent* for service of process: Company Name: Hot Pepper Mobile Inc. Physical U.S. Company Address: 350 10th Ave 1000 Ste San Diego California United States 92101-8705 Agent contact name/Title : Shawn Sun/CEO Agent Email Address: [email protected] Tel No.: 619-341-9501 FRN No.: 0031763733 The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Agent Signed (if different to Applicant): Signed: Signed: Printed name: Shawn Sun Printed name: Shawn Sun Title: CEO Title: CEO Company Name: Hot Pepper Mobile Inc. Company Name: Hot Pepper Mobile Inc. Date: 6/28/2023 Date: 6/28/2023

Hot Pepper Mobile Inc. Agent Authorization Company: Hot Pepper Mobile Inc. Address: 350 10th Ave 1000 Ste San Diego California United States 92101-8705 Product Name: Tablet Model Number(s): AP32 Product Description: Tablet We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2023.06.28 Name: Jiankuai Li Title: PM Company: SHENZHEN STS TEST SERVICES CO.,LTD.

2023.03.03 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize SHENZHEN STS TEST SERVICES CO.,LTD./ A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District,Bao’an District, Shenzhen, Guang Dong, China/Jiankuai Li(Name of Agent company name and address, Name of Agent) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. Name: Jiankuai Li Title: PM E-mail:[email protected] This appointment is valid until further until December 31, 2023 Sincerely, Name: Shawn Sun Title: CEO E-mail: [email protected] Company: Hot Pepper Mobile Inc.

Hot Pepper Mobile Inc. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2023.06.28 Subject; Request for Confidentiality FCC ID: 2A33N-AP32 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description Tune-up Procedure Part List SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Hot Pepper Mobile Inc. Signature: Date: 2023.06.28 Name: Jiankuai Li Title: PM Company: SHENZHEN STS TEST SERVICES CO.,LTD.

Page 1 of 5 Report No.: STS2306300 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: AP32 Photo 1 Photo 2 Page 2 of 5 Report No.: STS2306300 Photo 3 Photo 4 Page 3 of 5 Report No.: STS2306300 Photo 5 Photo 6 Page 4 of 5 Report No.: STS2306300 Photo 7 Photo 8 Page 5 of 5 Report No.: STS2306300 Photo 9 Photo 10

FCC Label W:15mm L:30mm Note:The label is silk-screen on the sample Tablet Model name: AP32 FCC ID: 2A33N-AP32

Page 1 of 5 Report No.: STS2306300 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: AP32 Photo 1 Photo 2 WIFI/BT Antenna 2G/3G/4G Antenna GPS Antenna Page 2 of 5 Report No.: STS2306300 Photo 3 Photo 4 Page 3 of 5 Report No.: STS2306300 Photo 5 Photo 6 Page 4 of 5 Report No.: STS2306300 Photo 7 Photo 8 Page 5 of 5 Report No.: STS2306300 Photo 9

Page: 1/10 Ref : ACR.60.17.23.MVGB.A SHENZHEN STS TEST SERVICES CO., LTD. 1/F, BUILDING 2, ZHUOKE SCIENCE PARK, CHONGQING ROAD FUYONG, BAO’ AN DISTRICT, SHENZHEN,CHINA MVG COMOSAR DOSIMETRIC E-FIELD PROBE SERIAL NO.: SN 07/21 EPGO352 Calibrated at MVG Z.I. de la pointe du diable Technopôle Brest Iroise – 295 avenue Alexis de Rochon 29280 PLOUZANE - FRANCE Calibration date: 02/24/2023 Accreditations #2-6789 and #2-6814 Scope available on www.cofrac.fr Summary: This document presents the method and results from an accredited COMOSAR E-Field Probe calibration performed at MVG, using the CALIPROBE test bench, for use with a MVG COMOSAR system only. The test results covered by accreditation are traceable to the International System of Units (SI). COMOSAR E-Field Probe Calibration Report COMOSAR E-FIELD PROBE CALIBRATION REPORT Page: 3/10 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vH This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. TABLE OF CONTENTS 1 Device Under Test ..................................................................................................... 4 2 Product Description ................................................................................................... 4 2.1 General Information _______________________________________________________ 4 3 Measurement Method ................................................................................................ 4 3.1 Linearity ________________________________________________________________ 4 3.2 Sensitivity _______________________________________________________________ 5 3.3 Lower Detection Limit _____________________________________________________ 5 3.4 Isotropy _________________________________________________________________ 5 3.1 Boundary Effect __________________________________________________________ 5 4 Measurement Uncertainty .......................................................................................... 6 5 Calibration Measurement Results .............................................................................. 6 5.1 Sensitivity in air __________________________________________________________ 6 5.2 Linearity ________________________________________________________________ 7 5.3 Sensitivity in liquid ________________________________________________________ 8 5.4 Isotropy _________________________________________________________________ 9 6 List of Equipment .................................................................................................... 10 Ref: ACR.60.17.23.MVGB.A COMOSAR E-FIELD PROBE CALIBRATION REPORT Page: 4/10 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vH This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 1 DEVICE UNDER TEST Device Under Test Device Type COMOSAR DOSIMETRIC E FIELD PROBE Manufacturer MVG Model SSE2 Serial Number SN 07/21 EPGO352 Product Condition (new / used) Used Frequency Range of Probe 0.15 GHz-6GHz Resistance of Three Dipoles at Connector Dipole 1: R1=0.227 M Dipole 2: R2=0.203 M Dipole 3: R3=0.195 M 2 PRODUCT DESCRIPTION 2.1 GENERAL INFORMATION MVG’s COMOSAR E field Probes are built in accordance to the IEEE 1528, FCC KDB865664 D01, CENELEC EN62209 and CEI/IEC 62209 standards. Figure 1 – MVG COMOSAR Dosimetric E field Dipole Probe Length 330 mm Length of Individual Dipoles 2 mm Maximum external diameter 8 mm Probe Tip External Diameter 2.5 mm Distance between dipoles / probe extremity 1 mm 3 MEASUREMENT METHOD The IEEE 1528, FCC KDB865664 D01, CENELEC EN62209 and CEI/IEC 62209 standards provide recommended practices for the probe calibrations, including the performance characteristics of interest and methods by which to assess their affect. All calibrations / measurements performed meet the fore mentioned standards. 3.1 LINEARITY The evaluation of the linearity was done in free space using the waveguide, performing a power sweep to cover the SAR range 0.01W/kg to 100W/kg. Ref: ACR.60.17.23.MVGB.A COMOSAR E-FIELD PROBE CALIBRATION REPORT Page: 5/10 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vH This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 3.2 SENSITIVITY The sensitivity factors of the three dipoles were determined using a two step calibration method (air and tissue simulating liquid) using waveguides as outlined in the standards. 3.3 LOWER DETECTION LIMIT The lower detection limit was assessed using the same measurement set up as used for the linearity measurement. The required lower detection limit is 10 mW/kg. 3.4 ISOTROPY The axial isotropy was evaluated by exposing the probe to a reference wave from a standard dipole with the dipole mounted under the flat phantom in the test configuration suggested for system validations and checks. The probe was rotated along its main axis from 0 to 360 degrees in 15- degree steps. The hemispherical isotropy is determined by inserting the probe in a thin plastic box filled with tissue-equivalent liquid, with the plastic box illuminated with the fields from a half wave dipole. The dipole is rotated about its axis (0°–180°) in 15° increments. At each step the probe is rotated about its axis (0°–360°). 3.1 BOUNDARY EFFECT The boundary effect is defined as the deviation between the SAR measured data and the expected exponential decay in the liquid when the probe is oriented normal to the interface. To evaluate this effect, the liquid …

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. ShenZhen STS Test Services Co.,Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC SAR TEST REPORT Report No.: STS2306300H01 Issued for Hot Pepper Mobile Inc. 350 10th Ave 1000 Ste San Diego California United States 92101-8705 Product Name: Tablet Brand Name: Hot Pepper Model Name: AP32 Series Model: N/A FCC ID: 2A33N-AP32 Test Standard: ANSI/IEEE Std. C95.1 FCC 47 CFR Part 2 ( 2.1093) IEC/IEEE 62209-1528 Max. Report SAR (1g): Body: 1.277 W/kg S T L A B S Page 2 of 107 Report No.: STS2306300H01 Test Report Certification Applicant’s name ............... : Hot Pepper Mobile Inc. Address ............................... : 350 10th Ave 1000 Ste San Diego California United States 92101- 8705 Manufacturer's Name ........ : Shenzhen Mediafly Technology CO.,LTD Address ............................... : 1/F, Building A, WeiXing Science And Technology Park, No. 268- 3, BaoShi East Rd, ShuiTian Community, ShiYan Street, BaoAn Di strict, ShenZhen, China Product description Product name ...................... : Tablet Brand name ....................... : Hot Pepper Model name ....................... : AP32 Series Model ........................ : N/A Standards ........................... : ANSI/IEEE Std. C95.1-1992 FCC 47 CFR Part 2 ( 2.1093) IEC/IEEE 62209-1528 The device was tested by Shenzhen STS Test Services Co., Ltd. in accordance with the measurement methods and procedures specified in KDB 865664 The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Date of Test:.............................. Date (s) of performance of tests:...... 05 Jun. 2023 ~ 19 Jun. 2023 Date of Issue:.............................. 21 Jun. 2023 Test Result:................................. Pass Testing Engineer : (Shifan. Long) Technical Manager : (Sean she) Authorized Signatory : (Bovey Yang) Page 3 of 107 Report No.: STS2306300H01 Table of Contents 1. General Information 5 1.1 EUT Description 5 1.2 Test Environment 7 1.3 Test Factory 7 2. Test Standards and Limits 8 3. SAR Measurement System 9 3.1 Definition of Specific Absorption Rate (SAR) 9 3.2 SAR System 9 4. Tissue Simulating Liquids 12 4.1 Simulating Liquids Parameter Check 12 5. SAR System Validation 16 5.1 Validation System 16 5.2 Validation Result 16 6. SAR Evaluation Procedures 17 7. EUT Antenna Location Sketch 18 7.1 SAR test exclusion consider table 19 8. EUT Test Position 25 8.1 Body-worn Position Conditions 25 9. Uncertainty 26 9.1 Measurement Uncertainty 26 10. Conducted Power Measurement 27 10.1 Test Result 27 11. EUT and Test Setup Photo 58 11.1 EUT Photo 58 11.2 Setup Photo 61 12. SAR Result Summary 64 12.1 Body-worn and Hotspot SAR 64 13. Equipment List 72 Appendix A. System Validation Plots 73 Appendix B. SAR Test Plots 89 Appendix C. Probe Calibration and Dipole Calibration Report 107 Page 4 of 107 Report No.: STS2306300H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 21 Jun. 2023 STS2306300H01 ALL Initial Issue Page 5 of 107 Report No.: STS2306300H01 1. General Information Environmental evaluation measurements of specific absorption rate (SAR) distributions in emulated human head and body tissues exposed to radio frequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 1.1 EUT Description Product Name Tablet Brand Name Hot Pepper Model Name AP32 Series Model N/A Model Difference N/A Battery Rated Voltage: 3.8V Charge Limit Voltage: 5.0V Capacity: 5000mAh Device Category Portable Product stage Production unit RF Exposure Environment General Population / Uncontrolled IMEI IMEI: 123460000000538/78 Hardware Version M863YAR310-VB44CF Software Version HPP-AP32-A-V1_20230525 Frequency Range GSM 850: 824 MHz ~ 849 MHz PCS1900: 1850 MHz ~ 1910 MHz WCDMA Band II: 1850 MHz ~ 1910 MHz WCDMA Band IV:1710 MHz ~ 1755 MHz WCDMA Band V: 824 MHz ~ 849 MHz LTE Band 2: 1850 MHz ~ 1910 MHz LTE Band 4: 1710 MHz ~ 1755 MHz LTE Band 5: 824 MHz ~ 849 MHz LTE Band 12: 699 MHz ~ 716 MHz LTE Band 25: 1850 MHz ~ 1915 MHz LTE Band 26: 814 MHz ~ 824 MHz / 824 MHz ~ 849 MHz LTE Band 41: 2496 MHz ~ 2690 MHz LTE Band 66: 1710 MHz ~ 1780 MHz LTE Band 71: 663 MHz ~ 698 MHz WLAN802.11b/g/n20: 2412 MHz ~ 2462 MHz WLAN 802.11n40: 2422 MHz ~ 2452 MHz WLAN 802.11a/n20/n40/ac20/ac40/ac80: 5150 ~ 5250 MHz WLAN 802.11a/n20/n40/ac20/ac40/ac80: 5725 ~ 5850 MHz Bluetooth: 2402 MHz to 2480 MHz Page 6 of 107 Report No.: STS2306300H01 Max. Reported SAR(1g): (Limit:1.6W/kg) Band Mode Body (W/kg) PCB GSM 850 1.220 PCB GSM 1900 0.733 PCB WCDMA Band 2 1.277 PCB WCDMA Band 4 0.343 PCB WCDMA Band 5 0.893 PCB LTE Band 2 1.258 PCB LTE Band 4 0.651 PCB LTE Band 5 0.935 PCB LTE Band 12 0.430 PCB LTE Band 25 0.464 PCB LTE Band 26 0.875 PCB LTE Band 41 0.916 PCB LTE Band 66 0.624 PCB LTE Band 71 0.744 DTS 2.4G WLAN 0.076 DSS BT 0.036 NII 5.2G WLAN 0.224 NII 5.8G WLAN 0.237 1-g Sum SAR 1.514 FCC Equipment Class PCS Licensed Transmitter (PCB) Part 15 Spread Spectrum Transmitter (DSS) Digital Transmission System (DTS) Unlicensed National Information Infrastructure TX(NII) Operating Mode: GSM: GPRS/EGPRS Class 12 WCDMA: RMC, HSDPA, HSUPA Release 6 LTE: QPSK, 16QAM 2.4G WLAN : 802.11b(DSSS):CCK,DQPSK,DBPSK 802.11g(OFDM):BPSK,QPSK,16-QAM,64-QAM 802.11n(OFDM):BPSK,QPSK,16-QAM,64-QAM 5G WLAN: 802.11a(OFDM):BPSK,QPSK,16-QAM,64-QAM 802.11n(OFDM):BPSK,QPSK,16-QAM,64-QAM 802.11ac(OFDM):BPSK,QPSK,16-QAM,64-QAM,256-QAM Bluetooth: GFSK +π/4DQPSK+8DPSK BL…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, all test data presented in this report is only applicable to presented test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No.:STS2306300W03 Issued for Hot Pepper Mobile Inc. 350 10th Ave 1000 Ste San Diego California United States 92101-8705 Product Name: Tablet Brand: Hot Pepper Model Number: AP32 Series Model(s): N/A FCC ID: 2A33N-AP32 Test Standard: FCC Part 15.247 S T L A B S Page 2 of 74 Report No.: STS2306300W03 TEST RESULT CERTIFICATION Applicant’s Name ................. : Hot Pepper Mobile Inc. Address .................................. : 350 10th Ave 1000 Ste San Diego California United States 92101-8705 Manufacturer's Name ........... : Shenzhen Mediafly Technology CO.,LTD Address .................................. : 1/F, Building A, WeiXing Science And Technology Park, No. 268-3, BaoShi East Rd, ShuiTian Community, ShiYan Street, BaoAn District, ShenZhen, China Product Description Product Name ........................ : Tablet Brand .................................... : Hot Pepper Model Number ....................... : ... : AP32 Series Model(s) ...................... : N/A Test Standards ..................... : FCC Part15.247 Test Procedure ....................... : ANSI C63.10-2013 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ........................................... : Date of receipt of test item...................... : 02 June 2023 Date (s) of performance of tests ............. : 02 June 2023 ~ 10 June 2023 Date of Issue .......................................... : 10 June 2023 Test Result .............................................. : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory : (Bovey Yang) Page 3 of 74 Report No.: STS2306300W03 Table of Contents 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 TEST SOFTWARE AND POWER LEVEL 10 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 12 2.6 EQUIPMENTS LIST 13 3. EMC EMISSION TEST 14 3.1 CONDUCTED EMISSION MEASUREMENT 14 3.2 TEST PROCEDURE 15 3.3 TEST SETUP 15 3.4 EUT OPERATING CONDITIONS 15 3.5 TEST RESULTS 16 4. RADIATED EMISSION MEASUREMENT 18 4.1 RADIATED EMISSION LIMITS 18 4.2 TEST PROCEDURE 20 4.3 TEST SETUP 21 4.4 EUT OPERATING CONDITIONS 21 4.5 FIELD STRENGTH CALCULATION 22 4.6 TEST RESULTS 23 5. CONDUCTED SPURIOUS & BAND EDGE EMISSION 36 5.1 LIMIT 36 5.2 TEST PROCEDURE 36 5.3 TEST SETUP 36 5.4 EUT OPERATION CONDITIONS 36 5.5 TEST RESULTS 36 6. POWER SPECTRAL DENSITY TEST 37 6.1 LIMIT 37 6.2 TEST PROCEDURE 37 Page 4 of 74 Report No.: STS2306300W03 Table of Contents 6.3 TEST SETUP 37 6.4 EUT OPERATION CONDITIONS 37 6.5 TEST RESULTS 37 7. BANDWIDTH TEST 38 7.1 LIMIT 38 7.2 TEST PROCEDURE 38 7.3 TEST SETUP 38 7.4 EUT OPERATION CONDITIONS 38 7.5 TEST RESULTS 38 8. PEAK OUTPUT POWER TEST 39 8.1 LIMIT 39 8.2 TEST PROCEDURE 39 8.3 TEST SETUP 40 8.4 EUT OPERATION CONDITIONS 40 8.5 TEST RESULTS 40 9. ANTENNA REQUIREMENT 41 9.1 STANDARD REQUIREMENT 41 9.2 EUT ANTENNA 41 APPENDIX 1-TEST DATA 42 1. DUTY CYCLE 42 2. MAXIMUM AVERAGE CONDUCTED OUTPUT POWER 46 3. MAXIMUM PEAK CONDUCTED OUTPUT POWER 50 4. -6DB BANDWIDTH 54 5. MAXIMUM POWER SPECTRAL DENSITY LEVEL 58 6. BAND EDGE 62 7. CONDUCTED RF SPURIOUS EMISSION 67 APPENDIX 2- EUT TEST PHOTO 74 Page 5 of 74 Report No.: STS2306300W03 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 10 June 2023 STS2306300W03 ALL Initial Issue Page 6 of 74 Report No.: STS2306300W03 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted bands of operation PASS -- Part 15.247(d)/ Part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2013. Page 7 of 74 Report No.: STS2306300W03 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±1.197dB 2 Unwanted Emissions, conducted ±2.896dB 3 All emissions, radiated 9K-30MHz ±3.84dB 4 All emissions, radiated 30M-1GHz ±3.94dB 5 All emissions, radiated 1G-6GHz ±4.59dB 6 All emissions, radiated>6G ±5.22dB 7 Conducted Emission (9KHz-150KHz) ±2.14dB 8 Conducted Emission (150KHz-30MHz) ±2.…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, all test data presented in this report is only applicable to presented test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No.:STS2306300W04 Issued for Hot Pepper Mobile Inc. 350 10th Ave 1000 Ste San Diego California United States 92101-8705 Product Name: Tablet Brand: Hot Pepper Model Number: AP32 Series Model(s): N/A FCC ID: 2A33N-AP32 Test Standard: FCC Part 15.247 S T L A B S Page 2 of 87 Report No.:STS2306300W04 TEST RESULT CERTIFICATION Applicant’s Name ................. : Hot Pepper Mobile Inc. Address .................................. : 350 10th Ave 1000 Ste San Diego California United States 92101-8705 Manufacturer's Name ........... : Shenzhen Mediafly Technology CO.,LTD Address .................................. : 1/F, Building A, WeiXing Science And Technology Park, No. 268-3, B aoShi East Rd, ShuiTian Community, ShiYan Street, BaoAn District, ShenZhen, China Product Description Product Name ........................ : Tablet Brand .................................... : Hot Pepper Model Number ....................... : ... : AP32 Series Model(s) ...................... : N/A Test Standards ..................... : FCC Part 15.247 Test Procedure........................: ANSI C63.10-2013 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document only be altered or revised by STS, personal only, and shall be noted in the revision of the…
