FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Specific Absorption Rate (SAR) information: This Smart Phone meets the government's requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health. FCC RF Exposure Information and Statement the SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types: Smart Phone has also been tested against this SAR limit. This device was tested for typical body-worn operations with the back of the phone kept 10mm from the body. To maintain compliance with FCC RF exposure requirements, use accessories that maintain an 10mm separation distance between the user's body and the back of the phone. The use of belt clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided.

Page 1 of 9 Report No.: STS2601345 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: HPPL61B Photo 1 Photo 2 Page 2 of 9 Report No.: STS2601345 Photo 3 Photo 4 2G/3G/4G TX Antenna 2G/3G/4G RX Antenna Page 3 of 9 Report No.: STS2601345 Photo 5 Photo 6 Page 4 of 9 Report No.: STS2601345 Photo 7 Photo 8 BT/WIFI Antenna Page 5 of 9 Report No.: STS2601345 Photo 9 Photo 10 Page 6 of 9 Report No.: STS2601345 Photo 11 Photo 12 Page 7 of 9 Report No.: STS2601345 Photo 13 Photo14 Page 8 of 9 Report No.: STS2601345 Photo15 Photo16 Page 9 of 9 Report No.: STS2601345 Photo17 Photo18

SARSetupphotosforFCCID:2A33N-L61B RightTouch RightTilt LeftTouch LeftTilt BodyFrontside(separationdistanceis10mm) BodyBackside(separationdistanceis10mm) BodyLeftside(separationdistanceis10mm) BodyRightside(separationdistanceis10mm) BodyBottomside(separationdistanceis10mm) BodyTopside(separationdistanceis10mm)

Page 1 of 2 FCC ID: 2A33N-L61B Setup photo AC Conduction RF Conduction Page 2 of 2 FCC ID: 2A33N-L61B RE (Below 1GHz) RE (Above 1GHz)

天 线 测 试 报 告 客户名称：小辣椒 项目名称：A61A 第2页- Matching circuit Main Antenna Element Value C140 0Ω L123 NC R129 0Ω C113 12NH R113 0Ω C112 NC C111 0Ω C116 0Ω C 位号 匹配值 RF1 R134 NC DCS1800/1900+W2/4+FDD2/4/25/41/66TRX RF2 R135 0 欧姆 GSM850/900+W5+FDD5/26TRX RF3 R136 15NH B12/17TRX RF4 R137 33NH FDD71 第3页- G/W/B G/W/B Antenna Element Value C2906 NC R2902 0Ω C2905 NC DIV 第4页- DIV Antenna Element Value R3903 0 欧姆 C3905 1PF R3990 3.9NH C3906 10NH C3925 33PF L3918 2.7NH Antenna passive testing data 3.1 S11 Description of the test method Test the equipment：Vector network analyzer (Agilent E5071C) Test methodology：Use a 50 ohm CABLE cable to export from the instrument test port, use the calibration piece to calibrate and connect the SMA connector of the test fixture, and record the return loss and standing wave ratio corresponding to the relevant frequency point. Below is a schematic picture of the test： VNA 第5页- MAIN VSWR Antenna tuner works in RF1 channel Antenna tuner works in RF2 channel Antenna tuner works in RF3 channel Antenna tuner works in RF4 channel 第6页- DIV VSWR GWB VSWR 第7页- Antenna gain Band Frequency Gain Band Frequency Gain (dBi) (dBi) GSM850 TX:824-849MHz -1.12 LTE B5 TX:824-849MHz -1.12 RX:869-894MHz RX:869-894MHz GSM900 TX:880-915MHz -1.13 LTE B12 TX:700-716MHz -1.28 RX:925-960MHz RX:729-746MHz DCS1800 TX:1710-1785MHz 0.15 LTE B25 TX:1850-1915MHz 0.44 RX:1850-1880MHz RX:1930-1995MHz PCS1900 TX:1850-1910MHz 0.31 LTE B26 TX:814-844MHz 1.13 RX:1930-1990MHz RX:864-889MHz WCDMA B2 TX:1845-1915MHz 0.31 LTE B41 TX:2496-2690MHz -1.25 RX:1925-1995MHz RX:2496-2690MHz WCDMA B4 TX:1710-1785MHz 0.58 LTE B66 TX:1710-1785MHz 0.58 RX:2110-2155MHz RX:2110-2155MHz WCDMA B5 TX:824-849MHz -1.12 LTE B71 TX:617-656MHz -1.57 RX:869-894MHz RX:663-698MHz LTE B2 TX:1845-1915MHz 0.31 RX:1925-1995MHz LTE B4 TX:1710-1785MHz 0.58 RX:2110-2155MHz Band Frequency Gain (dBi) wifi2.4G/BT 2.4GHz-2.4835GHz 1.11 WIFI5G 5.150GHz-5.350GHz 1.21 5.725GHz-5.850GHz GPS 1.57542GHz 1.14 第8页- Radiation pattern 第9页- 第10页- 第11页- OTA Active test data Measurement Band Total Measurement Band Total TRP GSM850 26.62 TRP FDD_B2(10MHz) 16.66 TRP GSM850 26.68 TRP FDD_B2(10MHz) 16.62 TRP GSM850 26.66 TRP FDD_B2(10MHz) 16.66 TIS(RSSI) GSM850 -100.29 TIS(RSSI) FDD_B2(10MHz) -90.77 TRP GSM900 26.85 TRP FDD_B4(10MHz) 17.85 TRP GSM900 24.96 TRP FDD_B4(10MHz) 17.88 TRP GSM900 23.07 TRP FDD_B4(10MHz) 17.85 TIS(RSSI) GSM900 -96.91 TIS(RSSI) FDD_B4(10MHz) -91.11 TRP DCS1800 23.23 TRP FDD_B5(10MHz) 16.66 TRP DCS1800 23.11 TRP FDD_B5(10MHz) 16.68 TRP DCS1800 23.35 TRP FDD_B5(10MHz) 16.86 TIS(RSSI) DCS1800 -101.23 TIS(RSSI) FDD_B5(10MHz) -92.23 TRP PCS1900 23.35 TRP FDD_B25(10MHz 16.11 TRP PCS1900 24.11 TRP FDD_B25(10MHz 16.23 TRP PCS1900 24.223 TRP FDD_B25(10MHz 16.01 TIS(RSSI) PCS1900 -102.25 TIS(RSSI) FDD_B26(10MHz -88.01 TRP WCDMA_B2 16.7 TRP FDD_B26(10MHz 16.05 TRP WCDMA_B2 17.2 TRP FDD_B26(10MHz 17.01 TRP WCDMA_B2 17.2 TRP FDD_B26(10MHz 16.66 TIS(RSSI) WCDMA_B2 -103.28 TIS(RSSI) FDD_B26(10MHz -94.25 TRP WCDMA_B4 17.93 TRP FDD_B12(10MHz) 15.62 TRP WCDMA_B4 17.52 TRP FDD_B12(10MHz) 16.66 TRP WCDMA_B4 17.69 TRP FDD_B12(10MHz) 16.62 TIS(RSSI) WCDMA_B4 -104.11 TIS(RSSI) FDD_B12(10MHz) -91.23 TRP WCDMA_B5 15.62 TRP FDD_B66(10MHz) 17.23 TRP WCDMA_B5 15.25 TRP FDD_B66(10MHz) 17.89 TRP WCDMA_B5 16.11 TRP FDD_B66(10MHz) 17.74 TIS(RSSI) WCDMA_B5 -103.23 TIS(RSSI) FDD_B66(10MHz) -93.48 TRP FDD_B41(20MHz) 14.69 TRP FDD_B71(5MHz) 17.11 TRP FDD_B41(20MHz) 15.11 TRP FDD_B71(5MHz) 17.23 TRP FDD_B41(10MHz) 14.52 TRP FDD_B71(5MHz) 16.62 TIS(RSSI) FDD_B41(20MHz) -89.23 TIS(RSSI) FDD_B71(5MHz) -90.23 第12页- Measurement Band Channel Total Measurement Band Channel Total TRP WIFI_B (11M) 1 10.23 TRP WIFI_A (54M) 36 8.23 TRP WIFI_B (11M) 6 10.11 TRP WIFI_A (54M) 149 9.22 TRP WIFI_B (11M) 11 10.23 TRP WIFI_A (54M) 165 9.35 TIS(EIRP) WIFI_B (11M) 1 -78.28 TIS(EIRP) WIFI_A (54M) 165 -69.98 TIS(EIRP) WIFI_B (11M) 6 -79.11 TIS(EIRP) WIFI_A (54M) 36 -70.24 TIS(EIRP) WIFI_B (11M) 11 -78.85 TIS(EIRP) WIFI_A (54M) 149 -70.11 Engineering drawings MAIN ANT: 第13页- DIV ANT: 第14页- GWB ANT:

Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 Duty Cycle Condition Mode Frequency (MHz) On Time (ms) Period (ms) Duty Cycle (%) Correction Factor (dB) 1/T (kHz) Max Variation (%) NVNT a 5745 0.192 0.239 80.33 0.95 5.21 0.25 NVNT a 5785 0.192 0.239 80.33 0.95 5.21 0.27 NVNT a 5825 0.193 0.24 80.42 0.95 5.19 0.32 NVNT n20 5745 0.212 0.26 81.54 0.89 4.72 0.22 NVNT n20 5785 0.213 0.26 81.92 0.87 4.71 0.24 NVNT n20 5825 0.212 0.259 81.85 0.87 4.72 0.28 NVNT n40 5755 0.2 0.248 80.65 0.93 5 0.28 NVNT n40 5795 0.201 0.248 81.05 0.91 4.99 0.25 NVNT ac20 5745 0.205 0.253 81.03 0.91 4.89 0.18 NVNT ac20 5785 0.204 0.252 80.95 0.92 4.9 0.22 NVNT ac20 5825 0.203 0.252 80.56 0.94 4.9 0.20 NVNT ac40 5755 0.184 0.232 79.31 1.01 5.43 0.23 NVNT ac40 5795 0.184 0.232 79.31 1.01 5.43 0.20 NVNT ac80 5775 0.177 0.225 78.67 1.04 5.67 0.25 Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 Test Graphs Duty Cycle NVNT a 5745MHz Duty Cycle NVNT a 5785MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 Duty Cycle NVNT a 5825MHz Duty Cycle NVNT n20 5745MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 Duty Cycle NVNT n20 5785MHz Duty Cycle NVNT n20 5825MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 Duty Cycle NVNT n40 5755MHz Duty Cycle NVNT n40 5795MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 Duty Cycle NVNT ac20 5745MHz Duty Cycle NVNT ac20 5785MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 Duty Cycle NVNT ac20 5825MHz Duty Cycle NVNT ac40 5755MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 Duty Cycle NVNT ac40 5795MHz Duty Cycle NVNT ac80 5775MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 Maximum Conducted Output Power Condition Mode Frequency (MHz) Conducted Power (dBm) Duty Factor (dB) Total Power (dBm) Limit (dBm) Verdict NVNT a 5745 11.48 0.95 12.43 <=30 Pass NVNT a 5785 11.96 0.95 12.91 <=30 Pass NVNT a 5825 12.13 0.95 13.08 <=30 Pass NVNT n20 5745 12.38 0.89 13.27 <=30 Pass NVNT n20 5785 12.94 0.87 13.81 <=30 Pass NVNT n20 5825 13.11 0.87 13.98 <=30 Pass NVNT n40 5755 11.81 0.93 12.74 <=30 Pass NVNT n40 5795 12.39 0.91 13.3 <=30 Pass NVNT ac20 5745 11.46 0.91 12.37 <=30 Pass NVNT ac20 5785 11.97 0.92 12.89 <=30 Pass NVNT ac20 5825 12.19 0.94 13.13 <=30 Pass NVNT ac40 5755 11.68 1.01 12.69 <=30 Pass NVNT ac40 5795 12.21 1.01 13.22 <=30 Pass NVNT ac80 5775 12.36 1.04 13.4 <=30 Pass Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 Test Graphs Power NVNT a 5745MHz Power NVNT a 5785MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 Power NVNT a 5825MHz Power NVNT n20 5745MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 Power NVNT n20 5785MHz Power NVNT n20 5825MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 Power NVNT n40 5755MHz Power NVNT n40 5795MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 Power NVNT ac20 5745MHz Power NVNT ac20 5785MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 Power NVNT ac20 5825MHz Power NVNT ac40 5755MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 Power NVNT ac40 5795MHz Power NVNT ac80 5775MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 -6dB Bandwidth Condition Mode Frequency (MHz) -6 dB Bandwidth (MHz) Limit -6 dB Bandwidth (MHz) Verdict NVNT a 5745 15.09 >=0.5 Pass NVNT a 5785 15.13 >=0.5 Pass NVNT a 5825 15.14 >=0.5 Pass NVNT n20 5745 15.13 >=0.5 Pass NVNT n20 5785 15.14 >=0.5 Pass NVNT n20 5825 15.13 >=0.5 Pass NVNT n40 5755 35.1 >=0.5 Pass NVNT n40 5795 35.02 >=0.5 Pass NVNT ac20 5745 15.12 >=0.5 Pass NVNT ac20 5785 15.14 >=0.5 Pass NVNT ac20 5825 15.08 >=0.5 Pass NVNT ac40 5755 35.08 >=0.5 Pass NVNT ac40 5795 35.11 >=0.5 Pass NVNT ac80 5775 75.02 >=0.5 Pass Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 Test Graphs -6dB Bandwidth NVNT a 5745MHz -6dB Bandwidth NVNT a 5785MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 -6dB Bandwidth NVNT a 5825MHz -6dB Bandwidth NVNT n20 5745MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 -6dB Bandwidth NVNT n20 5785MHz -6dB Bandwidth NVNT n20 5825MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 -6dB Bandwidth NVNT n40 5755MHz -6dB Bandwidth NVNT n40 5795MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 -6dB Bandwidth NVNT ac20 5745MHz -6dB Bandwidth NVNT ac20 5785MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 -6dB Bandwidth NVNT ac20 5825MHz -6dB Bandwidth NVNT ac40 5755MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 -6dB Bandwidth NVNT ac40 5795MHz -6dB Bandwidth NVNT ac80 5775MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 Occupied Channel Bandwidth Condition Mode Frequency (MHz) 99% OBW (MHz) NVNT a 5745 16.507 NVNT a 5785 16.599 NVNT a 5825 16.575 NVNT n20 5745 17.636 NVNT n20 5785 17.671 NVNT n20 5825 17.652 NVNT n40 5755 36.142 NVNT n40 5795 36.087 NVNT ac20 5745 17.618 NVNT ac20 5785 17.634 NVNT ac20 5825 17.678 NVNT ac40 5755 36.089 NVNT ac40 5795 36.066 NVNT ac80 5775 75.069 Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 Test Graphs OBW NVNT a 5745MHz OBW NVNT a 5785MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 OBW NVNT a 5825MHz OBW NVNT n20 5745MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 OBW NVNT n20 5785MHz OBW NVNT n20 5825MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 OBW NVNT n40 5755MHz OBW NVNT n40 5795MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 OBW NVNT ac20 5745MHz OBW NVNT ac20 5785MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 OBW NVNT ac20 5825MHz OBW NVNT ac40 5755MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 OBW NVNT ac40 5795MHz OBW NVNT ac80 5775MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-3 Maximum Power Spectral Density Level Conditio n Mod e Frequenc y (MHz) Conducted PSD (dBm/510kHz ) Duty Facto r (dB) Total PSD (dBm/510kHz ) Total PSD (dBm/500kHz ) Limit (dBm/500kHz ) Verdic t NVNT a 5745 -0.954 0.95 -0.004 -0.09 <=30 Pass NVNT a 5785 -0.548 0.95 0.402 0.32 <=30 Pass NVNT a 5825 -0.331 0.95 0.619 0.53 <=30 Pass NVNT n20 5745 -0.139 0.89 0.751 0.66 <=30 Pass NVNT n20 5785 0.169 0.87 1.039 0.95 <=30…

Text truncated - open the document above for the full version.

Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 Duty Cycle Condition Mode Frequency (MHz) On Time (ms) Period (ms) Duty Cycle (%) Correction Factor (dB) 1/T (kHz) Max Variation (%) NVNT a 5180 0.192 0.241 79.67 0.99 5.19 0.23 NVNT a 5200 0.192 0.24 80 0.97 5.19 0.26 NVNT a 5240 0.193 0.241 80.08 0.96 5.19 0.33 NVNT n20 5180 0.213 0.26 81.92 0.87 4.71 0.24 NVNT n20 5200 0.213 0.26 81.92 0.87 4.71 0.23 NVNT n20 5240 0.212 0.259 81.85 0.87 4.71 0.25 NVNT n40 5190 0.201 0.248 81.05 0.91 4.99 0.26 NVNT n40 5230 0.2 0.248 80.65 0.93 4.99 0.26 NVNT ac20 5180 0.204 0.251 81.27 0.9 4.89 0.17 NVNT ac20 5200 0.205 0.252 81.35 0.9 4.89 0.22 NVNT ac20 5240 0.205 0.252 81.35 0.9 4.89 0.19 NVNT ac40 5190 0.185 0.233 79.4 1 5.42 0.23 NVNT ac40 5230 0.184 0.233 78.97 1.03 5.42 0.21 NVNT ac80 5210 0.176 0.226 77.88 1.09 5.67 0.26 Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 Test Graphs Duty Cycle NVNT a 5180MHz Duty Cycle NVNT a 5200MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 Duty Cycle NVNT a 5240MHz Duty Cycle NVNT n20 5180MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 Duty Cycle NVNT n20 5200MHz Duty Cycle NVNT n20 5240MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 Duty Cycle NVNT n40 5190MHz Duty Cycle NVNT n40 5230MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 Duty Cycle NVNT ac20 5180MHz Duty Cycle NVNT ac20 5200MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 Duty Cycle NVNT ac20 5240MHz Duty Cycle NVNT ac40 5190MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 Duty Cycle NVNT ac40 5230MHz Duty Cycle NVNT ac80 5210MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 Maximum Conducted Output Power Condition Mode Frequency (MHz) Conducted Power (dBm) Duty Factor (dB) Total Power (dBm) Limit (dBm) Verdict NVNT a 5180 11.14 0.99 12.13 <=24 Pass NVNT a 5200 11.57 0.97 12.54 <=24 Pass NVNT a 5240 12.32 0.96 13.28 <=24 Pass NVNT n20 5180 12.13 0.87 13 <=24 Pass NVNT n20 5200 12.53 0.87 13.4 <=24 Pass NVNT n20 5240 13.29 0.87 14.16 <=24 Pass NVNT n40 5190 11.82 0.91 12.73 <=24 Pass NVNT n40 5230 12.65 0.93 13.58 <=24 Pass NVNT ac20 5180 11.17 0.9 12.07 <=24 Pass NVNT ac20 5200 11.58 0.9 12.48 <=24 Pass NVNT ac20 5240 12.33 0.9 13.23 <=24 Pass NVNT ac40 5190 11.77 1 12.77 <=24 Pass NVNT ac40 5230 12.59 1.03 13.62 <=24 Pass NVNT ac80 5210 12.25 1.09 13.34 <=24 Pass Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 Test Graphs Power NVNT a 5180MHz Power NVNT a 5200MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 Power NVNT a 5240MHz Power NVNT n20 5180MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 Power NVNT n20 5200MHz Power NVNT n20 5240MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 Power NVNT n40 5190MHz Power NVNT n40 5230MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 Power NVNT ac20 5180MHz Power NVNT ac20 5200MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 Power NVNT ac20 5240MHz Power NVNT ac40 5190MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 Power NVNT ac40 5230MHz Power NVNT ac80 5210MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 -26dB Bandwidth Condition Mode Frequency (MHz) -26 dB Bandwidth (MHz) Verdict NVNT a 5180 23.89 Pass NVNT a 5200 23.68 Pass NVNT a 5240 23.39 Pass NVNT n20 5180 23.64 Pass NVNT n20 5200 24.06 Pass NVNT n20 5240 23.59 Pass NVNT n40 5190 44.35 Pass NVNT n40 5230 43.04 Pass NVNT ac20 5180 23.75 Pass NVNT ac20 5200 23.8 Pass NVNT ac20 5240 23.43 Pass NVNT ac40 5190 44.59 Pass NVNT ac40 5230 42.42 Pass NVNT ac80 5210 84.07 Pass Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 Test Graphs -26dB Bandwidth NVNT a 5180MHz -26dB Bandwidth NVNT a 5200MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 -26dB Bandwidth NVNT a 5240MHz -26dB Bandwidth NVNT n20 5180MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 -26dB Bandwidth NVNT n20 5200MHz -26dB Bandwidth NVNT n20 5240MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 -26dB Bandwidth NVNT n40 5190MHz -26dB Bandwidth NVNT n40 5230MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 -26dB Bandwidth NVNT ac20 5180MHz -26dB Bandwidth NVNT ac20 5200MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 -26dB Bandwidth NVNT ac20 5240MHz -26dB Bandwidth NVNT ac40 5190MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 -26dB Bandwidth NVNT ac40 5230MHz -26dB Bandwidth NVNT ac80 5210MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 Occupied Channel Bandwidth Condition Mode Frequency (MHz) 99% OBW (MHz) NVNT a 5180 16.518 NVNT a 5200 16.557 NVNT a 5240 16.509 NVNT n20 5180 17.674 NVNT n20 5200 17.658 NVNT n20 5240 17.63 NVNT n40 5190 36.082 NVNT n40 5230 35.959 NVNT ac20 5180 17.642 NVNT ac20 5200 17.655 NVNT ac20 5240 17.626 NVNT ac40 5190 36.078 NVNT ac40 5230 35.976 NVNT ac80 5210 75.007 Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 Test Graphs OBW NVNT a 5180MHz OBW NVNT a 5200MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 OBW NVNT a 5240MHz OBW NVNT n20 5180MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 OBW NVNT n20 5200MHz OBW NVNT n20 5240MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 OBW NVNT n40 5190MHz OBW NVNT n40 5230MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 OBW NVNT ac20 5180MHz OBW NVNT ac20 5200MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 OBW NVNT ac20 5240MHz OBW NVNT ac40 5190MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 OBW NVNT ac40 5230MHz OBW NVNT ac80 5210MHz Report No.: STS2603145W04_Appendix 5G RLAN U-NII-1 Maximum Power Spectral Density Level Condition Mode Frequency (MHz) Conducted PSD (dBm) Duty Factor (dB) Total PSD (dBm) Limit (dBm) Verdict NVNT a 5180 1.504 0.99 2.494 <=11 Pass NVNT a 5200 2.086 0.97 3.056 <=11 Pass NVNT a 5240 2.889 0.96 3.849 <=11 Pass NVNT n20 5180 2.29 0.87 3.16 <=11 Pass NVNT n20 5200 2.599 0.87 3.469 <=11 Pass NVNT n20 5240 3.456 0.87 4.326 <=11 Pass NVNT n40 5190 -1.184 0.91 -0.274 <=11 Pass NVNT n40 5230 -0.458 0.93 0.472 <=11 Pass NVNT ac20 5180 1.381 0.9 2.281 <=11 Pass NVNT ac20 5200 1.679 0.…

Text truncated - open the document above for the full version.

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Radio Test Report Report No.: STS2603145W04 Issued for Hot Pepper Mobile Inc. 350 10th Ave 1000 Ste San Diego California Unite States 92101-8705 Product Name: Smart Phone Brand Name: Hotpepper Model Name: HPPL61B Series Model(s): N/A FCC ID: 2A33N-L61B Test Standards: FCC Part15.407 Page 2 of 52 Report No.: STS2603145W04 TEST REPORT Applicant’s Name ................. : Hot Pepper Mobile Inc. Address .................................. : 350 10th Ave 1000 Ste San Diego California Unite States 92101-8705 Manufacturer's Name ........... : Hot Pepper Mobile Inc. Address .................................. : 350 10th Ave 1000 Ste San Diego California Unite States 92101-8705 Product Description Product Name ........................ : Smart Phone Brand Name ........................... : Hotpepper Model Name ........................... : HPPL61B Series Model(s) .................... : N/A Test Standards ..................... : FCC Part15.407 Test Procedure ............................... : ANSI C63.10-2020 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Date of Test............................................ : Date of receipt of test item ...................... : 18 Mar 2026 Date (s) of performance of tests ............. : 18 Mar 2026 ~ 25 Mar 2026 Date of Issue .......................................... : 25 Mar 2026 Test Result .............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 52 Report No.: STS2603145W04 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF TEST MODES 10 2.3 TEST SOFTWARE AND POWER LEVEL 11 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 13 2.6 EQUIPMENTS LIST 14 3. EMC EMISSION TEST 15 3.1 CONDUCTED EMISSION MEASUREMENT 15 3.2 RADIATED EMISSION AND MEASUREMENT 19 4. POWER SPECTRAL DENSITY TEST 43 4.1 LIMIT 43 4.2 TEST PROCEDURE 43 4.3 DEVIATION FROM STANDARD 44 4.4 TEST SETUP 44 4.5 EUT OPERATION CONDITIONS 44 4.6 TEST RESULTS 44 5. DUTY CYCLE 45 5.1 TEST STANDARD 45 5.2 TEST PROCEDURE 45 5.3 DEVIATION FROM STANDARD 45 5.4 TEST SETUP 45 5.5 EUT OPERATION CONDITIONS 45 5.6 TEST RESULTS 45 6. BANDWIDTH MEASUREMENT 46 6.1 EMISSION BANDWIDTH (EBW) 26 BANDWID PROCEDURES / LIMIT 46 6.2 OCCUPIED BANDWIDTH ( 99%) TEST APPLIED PROCEDURES / LIMIT 47 6.3 MINIMUM EMISSION BANDWIDTH(6 DB) PROCEDURES / LIMIT 48 7. MAXIMUM OUTPUT POWER 49 7.1 LIMIT 49 7.2 TEST PROCEDURE 49 7.3 DEVIATION FROM STANDARD 49 Page 4 of 52 Report No.: STS2603145W04 Table of Contents Page 7.4 TEST SETUP 49 7.5 EUT OPERATION CONDITIONS 49 7.6 TEST RESULTS 49 8. AUTOMATICALLY DISCONTINUE TRANSMISSION 50 8.1 LIMIT OF AUTOMATICALLY DISCONTINUE TRANSMISSION 50 8.2 TEST RESULT OF AUTOMATICALLY DISCONTINUE TRANSMISSION 50 9. ANTENNA REQUIREMENT 51 9.1 STANDARD REQUIREMENT 51 9.2 EUT ANTENNA 51 APPENDIX - PHOTOS OF TEST SETUP 52 Page 5 of 52 Report No.: STS2603145W04 Revision History Rev. Issue Date Report No. Effect Page Contents 00 25 Mar 2026 STS2603145W04 ALL Initial Issue Page 6 of 52 Report No.: STS2603145W04 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: § 15.407,KDB 789033 D02 General U-NII Test Procedures New Rules v02r01 FCC Part 15.407 FCC standard Test Item Results 15.207 AC Conducted Emission PASS 15.407 (a) /15.407 (e) 26dB/6dB &99% Bandwidth PASS 15.407(a) Maximum Conducted Output Power PASS 15.407(b)/15.209 Radiated Emission And (bandedge Emissions) Measurement PASS 15.407(a) Power Spectral Density PASS 15.407(c) Automatically Discontinue Transmission PASS 15.203 Antenna Requirement PASS Note: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020. Page 7 of 52 Report No.: STS2603145W04 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add.: 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.751dB 2 Unwanted Emissions, conducted ±2.888dB 3 All emissions, radiated 9K-30MHz ±2.48dB 4 All emissions, radiated 30M-1GHz ±2.52dB 5 All emissions, radiated 1G-18GHz ±3.48dB 6 All emissions, radiated>18GHz ±4.18dB 7 Conducted Emission (9KHz-150KHz) ±2.48dB 8 Conducted Emission (150KHz-30MHz) ±2.52dB 9 Occupied Channel Bandwidth ±3.6% 10 Power Spectral Density, conducted ±1.214dB 11 Duty Cycle ±3.2% Page 8 of 52 Report No.: STS2603145W04 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name Smart Phone Brand Name Hotpepper Model Name HPPL61B Series Model(s) N/A Model Difference N/A Product Description The EUT is Smart Phone Operation Frequency: IEEE 802.11a/ n(HT20)/ac(VHT20): 5.180GHz-5.240GHz IEEE 802.11n(HT40)/ac(VHT40): 5.190GHz-5.230GHz IEEE 802.11ac(VHT80) : 5.210GHz IEEE 802.11a/ n(HT20)/ac(VHT20): 5.745GHz-5.825GHz IEEE 802.11a/ n(HT40)/ac(VH…

Text truncated - open the document above for the full version.

Page: 1/11 SHENZHEN STS TEST SE RVICES CO., LTD. 1/F, BUILDING 2, ZHUOKE SCI ENCE PARK, 190 CHONGQI NG ROAD FUYONG , BAO’ AN DISTRICT, SHENZHEN,CHINA MVG COMOSAR DOSIMETRIC E - FIELD PROBE SER I AL NO.: SN 08/21 EPGO352 Calibrated at MVG Z.I. de la poin te du diable Technopôle Brest Iroise – 295 avenue Alexis de Rochon 29280 PLOUZANE - FRANCE Cal ibration date: 09/15/2025 Acc reditations #2-6789 Sc ope available on www.cofrac.fr The use of the Cofrac brand and the accreditation references is prohibited from any reproduction. Summary: This document presents the method and results from an accredited COMOSAR Dosimetric E- Field Pro be calibration performed at MVG, using the CALIPROBE test bench, for use with a MVG COMO SA R system only. The test results covered by accreditation are traceable to the International System of Units (SI). COMOSAR E-Field Probe Cal ibration Report Ref : ACR.95.19.25.BES.A Docusign Envelope ID: 711C3E09-7054-43A0-BF16-C536091746C4 COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref : A C R.95.19.25.BES.A Page: 2/11 Temp late_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vM Th is document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. Name Function Date Signature Prepared by : Pedro Ruiz Measure ment Responsibl e 9/16/2025 C h ecked & approved by: Jérôme L uc Technica l M anager 9/16/2025 Authorized by: Labora tory Di rector Customer Name Distribution : Shenzhen STS Test Services Co., Ltd. Issue Name Date Modifications A Pedro Ruiz 9/16/2025 Initial r elease Docusign Envelope ID: 711C3E09-7054-43A0-BF16-C536091746C4 Geraldine Toutain 9/16/2025 COMOSAR E-FIELD PROBE CALIBRATION REPORT Page: 3/11 Temp late_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vM Th is document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. TABLE OF CONTEN T S 1 Device Under Test ..................................................................................................... 4 2 Product Description ................................................................................................... 4 2.1 General Information _______________________________________________________ 4 3 Measurement Method ................................................................................................ 4 3.1 Sensitivity _______________________________________________________________ 4 3.2 Linearity ________________________________________________________________ 5 3.3 Isotropy _________________________________________________________________ 5 3.4 Boundary Effect __________________________________________________________ 5 3.5 Probe Modulation Response _________________________________________________ 6 4 Measurement Uncertainty .......................................................................................... 6 5 Calibration Results ..................................................................................................... 6 5.1 Calibration in air __________________________________________________________ 6 5.2 Calibration in liquid _______________________________________________________ 7 6 Verification Results ................................................................................................... 8 7 List of Equipment ...................................................................................................... 9 Docusign Envelope ID: 711C3E09-7054-43A0-BF16-C536091746C4 Ref : A C R.95.19.25.BES.A COMOSAR E-FIELD PROBE CALIBRATION REPORT Page: 4/11 Temp late_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vM Th is document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 1 DEVICE UNDER TEST Device Under Test De vice Type COMO SAR DO SIMETRIC E FIELD PROBE Manufa ctur er MVG Model SSE2 S…
