2A33X-HC6Handheld data collection terminal

HC6 QuickStartManual 1.AppearanceDescription OKkey FNkey Systemandcharging light PowerkeyBackspacekey Aakey FrontView 1 Arrowkey Returnkey APPkey Bluetoothlight Backcamera Flash Mountingbracketholes Batterycoverscrews TYPE-C Rearview 2 Horn KeyDescription： OKkey:Confirmationkey FNkey： PressFN+numberkeyssimultaneouslytotogglethecharacternext tothenumber Long-anFNkey+shortpressthedirectionupanddownkeysto adjustthevolumelevel Bluetoothlight:thetransmissiondataisalwayson,Bluetooth lightisonwhentheBluetoothconfigurationissuccessful Powerbutton:longpressthepowerbuttontodisplayshutdown, airplanemode,reboot,screenshot Aakey:Switchbetweenupperandlowercase,thesystemdefaultis small.Clicktoopenuppercaseinput,andthenclicktocancel uppercaseinput Returnkey:systemreturn Arrowkeys:up,down,leftandrightdirectionselection Systemandcharginglight:poweronstatebatterycapacity> 70%greenlightisalwayson,20%-70%greenlightflashes, lessthan20%redlightisalwayson,poweroffchargingstate, chargingredlightisalwayson,fullgreenlightisalwayson Backspacekey:Deletekey HC6isthelatestAndroid10.0ruggedsmarthandbookproduct launchedbySolidHoyi,itshigh-definitionandlargescreen, highreliabilityandotherfeaturesmakeitanexcellent handbookproduct.Itcanmeettheuser'smeasurementandmapping andotherapplicationfields 2、BatteryCharging Chargingwithtravelcharger PlugthesmallendoftheUSBcableintothehost'sTYPE-Cconnector, plugthelargeendoftheUSBcableintothetravelchargingplug,and thenplugthetravelchargingplugintoanelectricaloutletforcharging ChargingwithUSBdatacable PlugthesmallendoftheUSBcableintotheTYPE-Cportofthehost computer,andplugthelargeendintothe USBportforcharging . 3、InstallSIMcard,memorycard, battery BeforeinstallingorremovingtheSIMcard,memorycardorbattery, turnoffthepowertothemainunit. Turnthemainunittothebackandliftupthebackcoverinthe directionindicatedinFigure1toremovethebatterycompartmentcover InstalltheSIMcardandTFcardaccordingtothebatterycompartment labelinstructionsasshowninFigure1. F igure 1 3 4 F igure 2F igure 3 PushtheSIMcardmetalcontactfacedowncompletelyintotheslot,paying attentiontothedirectionofthecutcorner.(Figure2) PushthemicroSDmemorycardmetalcontactsintotheslotfacingdownward,paying attentiontothetangentdirection.(Figure3) Alignthecopperpartofthebatterywiththecoppercontactendofthebattery compartmentandgentlyinsertthebattery. Afterthebatteryinstallationiscompleteputthebatterycompartmentcoverin place,pushthebackcoversnaptothelockingpositiontolockthebattery compartmentcover Translatedwithwww.DeepL.com/Translator(freeversion) 4、Switchonandoff Toturnonthephone,pressandholdthepowerbuttononthebottomrightside untilthepoweronscreenappears. Toturnoffthephone,pressandholdthePowerbuttontobringuptheoptions menu,includingshutdown,flightmode,reboot,screenshot,etc.Selectthe shutdownoptiontoturnoffthephone. Inthebootstate,clickthe[powerbutton]toturnoffthescreenandenter sleepmode;clickthe[powerbutton]againtowakeupthescreen,slidethe screenupwardonthescreen,thenunlockthescreen;thehostwill automaticallyturnoffthescreenafteraperiodofinactivityandentersleep mode 5 5、Homescreenoperation TheHomescreenallowsyoutoviewthestatusofyourdeviceandaccessapplications. TheHomescreenhasmultiplepanels,swipeleftorrightonthescreentovieweach panel.ThisisshowninFigure4. Figure4 Thisenvironmentalprotectionuseperiodmeansthatunderthenormaluse conditionsdescribedinthisguide,theterminal(excludingthebattery) anditsaccessoryproductscontainharmfulsubstancesorelementswillnot leakout,andtheuserofelectronicinformationproductsproductwill notcauseseriouspollutiontotheenvironment orseriousdamagetotheirpersonalorproperty6+Thetermofthe product.Translatedwithwww.DeepL.com/Translator(freeversion) FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This Handheld data collection terminal meets the government's requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. Thestandards include a substantial safety margin designed to assure the safety of all persons regardless of age or health. The SAR limit of USA (FCC) is 1.6 W/kg/4.0 W/kg averaged over one gram of tissue. Device types: HC6 (FCC ID: 2A33X-HC6) has also been tested against this SAR limit. The highest SAR value reported under this standard during product certification for when properly worn on the body is 0.484W/kg and Limbs is 0.720 W/kg(10g). This device was tested for typical body-worn operations with the back of the handset kept 10mm from the bod…
