2A348SPARKEDGEGuitar Speaker

Spark EDGE User Manual 05 Front Panel 06 A - Preset Selector for Channel 1 Customize up to 8 presets for CH1. Use the knob to switch between presets, and press the knob to choose between the 4 red and 4 green presets. B - Channel 1 Volume Control Controls the overall volume of CH1. C - Preset Selector for Channel 2 Customize up to 8 presets for CH2. Use the knob to switch between presets, and press the knob to choose between the 4 red and 4 green presets. D - Channel 2 Volume Control Controls the overall volume of CH2. E - Channel 3/4 Volume Control Controls the overall volume of CH3/4. Please note that this knob controls the volume of both channels simultaneously and cannot be adjusted separately. F - Music Volume Control Controls the volume of Bluetooth music playback and USB audio. G - Power Indicator Indicates power status. Solid Red when powered on. H - Battery Indicator With Battery Loaded: • Solid Green: Powered on / Battery 50-100% • Solid Yellow: Powered on / Battery 10-50% • Solid Red: Powered on / Battery under 10% • Flashing Green/Yellow/Red: Charging I - Wireless Indicators Indicates the status of the Bluetooth and Wi-Fi connection. • Solid Blue/Green: Connected • Flashing Blue/Green: Pairing Front Panel Rear Panel 07 Rear Panel 08 J - Power Switch Hold to turn on/off Spark EDGE. K - Pair Button Press once to enter Bluetooth® pairing mode when connecting to a new device. Hold to enter pairing mode when connecting to Spark Control X. Press twice to enter TWS pairing mode: - The first speaker to enter TWS mode becomes the L speaker, with a white Bluetooth LED indicator. - The second speaker to enter TWS mode becomes the R speaker, with a red Bluetooth LED indicator. L - USB Audio Port (USB-C®) Connect the supplied USB-C® to USB-A cable to a PC/Mac to use as an audio interface. M - DC Power Input Connect with the supplied Power Adapter to a power outlet. N - Master EQ/Volume Adjust the overall EQ and volume of Spark EDGE. O - Input Channel 1 & 2 (XLR / 1/4" Combo) CH1/2 features a combo socket that supports both standard XLR or 1/4" TS line inputs. Each port supports multiple modes: XLR • Microphone Mode (Factory Default) For standard dynamic microphones • Line In Mode For instruments with an output line level signal, such as keyboards, DI boxes or a line output from an external effects unit 1/4" TS • Standard Instrument Mode (Factory Default) For general electric guitars, acoustic guitars, or basses • Hi-Z Instrument Mode For electric guitars or basses that have high gain/output pickups or a built-in preamp • Line In Mode For instruments with an output line level signal, such as keyboards, DI boxes or a line output from an external effects unit Rear Panel 09 P - Input Channel 3/4 (1/4") CH3/4 has 1 pair of 1/4" sockets. You can connect either a stereo output or 2 mono outputs. Please note that the CH3/4 does not support built-in effects. CH3/4 support multiple modes : • Standard Instrument Mode (Factory Default) For general electric guitars, acoustic guitars, or basses. • Hi-Z Instrument Mode For electric guitars or basses that have high gain/output pickups or a built-in preamp. • Line In Mode For instruments with an output line level signal, such as keyboards, DI boxes or a line output from an external effects unit. Q - Line Output (1/4") Connect to the input of an external device, such as a PA system, audio interface, etc. If you only need 1 output, please use the L/Mono output. R - Headphone Output (1/8") Plug in a pair of headphones with a 1/8" jack. S - MIDI Ports (Standard 5 Pin DIN) Input - Connect a wired MIDI controller to control built-in effects and other features. • To pair a new device, press the Pair button on the Rear Panel of Spark EDGE, turn Bluetooth® on in the settings of your mobile device, and select “Spark EDGE Audio" from the list of scanned devices. • Spark EDGE will automatically pair with the last device it connected to. If the last device is not available, Spark EDGE will automatically connect to a device that has been previously paired. 10 To play music via Bluetooth® Spark EDGE is only compatible with Spark Battery (sold separately). Spark Battery has up to 10 hours of play time and automatically starts charging when Spark EDGE is plugged in via DC. Please be aware that using a third party battery can damage your Spark EDGE. 14 Installing Battery • Make sure Spark EDGE is off and unplug the power cord. • Open the battery cover on the back and lift it up • Insert Spark Battery with the sticker facing above. • Put back the cover. • You can now turn on Spark EDGE using battery power. 19 Factory Reset Follow the steps below to perform a factory reset. This process will reset all the presets stored on the Spark EDGE as well as its Bluetooth pairing information, Power Saving Setting. 1. Turn off your Spark EDGE. 2. Hold the Power Button and Preset Knob, then release the buttons when the Power Indicator turns into white color. 3. Hold the Power Button, until all four preset LEDs blink, then release the button. 4. Spark EDGE will be turned off automatically when the factory reset is completed, turn it back on to start playing. *After the step 2, if you’re not ready to perform factory reset, or tends to do it later, you can cancel the process by tapping the Power Button. Force Shutdown & Restart If Spark EDGE runs into an issue where the knobs/buttons doesn't respond anymore or freezes, or emits an unusual noise, follow the steps below to force shutdown and restart Spark EDGE. 1. Hold the Power button over 10 seconds. 2. Release the Power button, and hold it again to turn Spark EDGE on.

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 1 of 5 Appendix External Photos for GZCR2408000889AT SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 2 of 5 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 3 of 5 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 4 of 5 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 5 of 5 - End of the Appendix -

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 1 of 17 Appendix Internal Photos for GZCR2408000889AT SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 2 of 17 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 3 of 17 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 4 of 17 BT ANT 2.4G Wi-Fi ANT SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 5 of 17 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 6 of 17 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 7 of 17 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 8 of 17 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 9 of 17 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 10 of 17 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 11 of 17 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 12 of 17 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 13 of 17 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 14 of 17 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 15 of 17 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 16 of 17 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 17 of 17 - End of the Appendix -

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR240800088904 Page: 1 of 9 FCC ID: 2A348SPARKEDGE Ricky Liu Manager RF EXPOSURE EVALUATION REPORT Application No.: GZCR2408000889AT Applicant:Positive LLC Address of Applicant:2820 S Alma School Rd Suite 18 PMB 2011 Chandler, AZ 85286, USA Manufacturer:Jia Ge Digital Technology Co. Ltd Address of Manufacturer:11F, No. 176, Changchun Rd., Zhongshan Dist., Taipei City 104082, Taiwan, China Product Name:Guitar Speaker Model No.: Spark EDGE Trade Mark:Positive Grid Standard(s) : KDB447498D01 General RF Exposure Guidance v06 47 CFR Part 1.1310 Date of Receipt: 2024-08-02 Date of Evaluation: 2024-08-15 to 2024-08-28 Date of Issue: 2024-09-13 Evaluation Result: Pass* * In the configuration evaluated, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR240800088904 Page: 2 of 9 Revision Record VersionReport No.DateRemark 01GZCR2408000889042024-09-13Original Authorized for issue by: Luke Lin/Project Engineer Vico Cui/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR240800088904 Page: 3 of 9 2Evaluation Summary ItemStandardMethodRequirementResult RF Exposure KDB447498D01 General RF Exposure Guidance v06 KDB447498D01 General RF Exposure Guidance v06 47 CFR Part 1.1310Pass Note: E.U.T./EUT means Equipment Under Test. Pass means the test result passed the test standard requirement, please find the detailed decision rule in the report relative section. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR240800088904 Page: 4 of 9 3Contents Page 1Cover Page...............................................................................................................................................1 2Evaluation Summary................................................................................................................................3 3Contents....................................................................................................................................................4 4General Information.................................................................................................................................5 4.1Details of E.U.T.................................................................................................................................5 4.2Evaluating Location...........................................................................................................................5 4.3Facility...............................................................................................................................................6 4.4Deviation from Standards..................................................................................................................6 4.5Abnormalities from Standard Conditions...........................................................................................6 5Technical Requirements Specification..................................................................................................7 5.1General Description of Applied Standards........................................................................................7 5.2RF Exposure Evaluation....................................................................................................................7 5.2.1Limit & Test Method......................................................................................................................7 5.2.2Conclusion....................................................................................................................................8 6EUT Constructional Details (EUT Photos).............................................................................................9 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR240800088904 Page: 5 of 9 4General Information 4.1Details of E.U.T. Power supply:Option 1: Powered by AC/DC adapter as below: Model: MS-Z3250R200-060B0-E INPUT: 100-240V~, 50/60Hz 1.5A Max OUTPUT: 65.0W DC 20.0V 3.25A Option 2: Powered by Rechargeable Li-on Battery as below: Model: Spark Battery Rated: DC 14.4 V, 6000mAh, 86.4Wh Cable(s):USB-C port*1pcs XLR port*2pcs AUX IN port*1pcs TRS*6.5mm port*4pcs USB-C port cable with magnetic ring 1.5m*1pcs MIDI port*1pcs RF characters: Refer to report GZCR240800088902 for BLE/2.4G Wi-Fi detail. Refer to report GZCR240800088903 for BT classic detail. Remark: The information in this section is provided by the applicant or manufacturer, SGS is not liable to the accuracy, suitability, reliability or/and integrity of the information. 4.2Evaluating Location All tests were performed at: SGS-CSTC Standards Technical Services Co., Ltd., Guangzhou Branch EMC Laboratory, No.198, Kezhu Road, Science City, Economic & Technological Development Area, Guangzhou, Guangdong, China 510663 Tel: +86 20 82155555 No tests were sub-contracted. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR240800088904 Page: 6 of 9 4.3Facility The facility is recognized, certified, or accredited by the following organizations: ● ACMA SGS-CSTC Standards Technical Services Co., Ltd., EMC Laboratory can also perform testing for the Australian/New Zealand Regulatory Compliance Mark (RCM). ● SGS UK(Certificate No.: 32), SGS-TUV SAARLAND and SGS-FIMKO Have approved SGS-CSTC Standards Technical Services Co., Ltd., EMC Laboratory as a supplier of EMC TESTING SERVICES and SAFETY TESTING SERVICES. ● FCC Recognized Accredited Test Firm(Registration No.: 486818) SGS-CSTC Standards Technical Services Co., Ltd., EMC Laboratory has been accredited and fully described in a report filed with the (FCC) Federal Communications Commission. The acceptance letter from the FCC is maintain…

Text truncated - open the document above for the full version.

QR/RD-P01-06B SPECIFICATION 深圳市大显科技有限公司 ShenzhenDaxianTechnologyCo.,Ltd. 国光Spark-EDGEBT天线组件 GGECSpark-EDGEBTAntennaassembly 产品规格书 ProductSpecification 客户 connection 国光 GGEC 频段 frequencyrange 2400~2500MHz 项目名称 entryname Spark-EDGE 版本 edition V1.0 物料编号 MaterialNo 2S-PARK-054 颜色 Color 黑色 Black 客户料号 CustomerItem Number EAN00404 RF设计 RFDesign 沈川 Chuan.Shen 结构设计 StructuralDesign 周锐斌 Ruibin.Zhou 品质经理 QualityManager 杨进 Jin.Yang 技术总监 TechnicalDirector 张磊 Lei.Zhang 日期 Date 2024-6-21 深圳市大显科技有限公司 ShenzhenDaXianTechnologyCo.,Ltd. 深圳市龙岗区布吉镇吉华路513号上水径村（国防培训基地 对面）达成工业园综合楼7楼 TEL:0755-28576002 FAX:0755-84276383 上海分部：上海市张江高科技园区集成电路产业区龙东大道 3000号8号楼201室 TEL:021-61630552 FAX:755-84276383 BujiTown,LonggangDistrict,Shenzhen,ChinaJihuaRoad513, ShangshuijingVillage(oppositethenationaldefense trainingbase)DachengIndustrialPark,Building7。 TEL:0755-28576002 FAX:0755-84276383 Room201,Building8,LongDongRoad3000#,SemiconductorIndustry Park,ZhangJiangHitechZone,ShangHai TEL:021-61630552 FAX:755-84276383 客户确认： Customerconfirmation: 装配是否符合贵司要求：□OK□NG Whethertheassemblymeetsyourcompany'srequirements：□OK□NG ConfidentialInformation www.Topant.com.cn Confidentialityrequirements ShenzhenDaxianTechnologyCo.,Ltd.alreadypossessestheinformationprovidedbytheproprietarytechnology,which shouldbestrictlyconfidentialandnotallowedtobedisclosedtoanypersonorcompanywithoutthepriorwrittenconsentof ShenzhenDaxianTechnologyCo.,Ltd Page2 变更履历 Revisionhistory 版本号 Versionnumber 变更内容 Changecontent 变更理由 Reasonforchange 发起变更方 Originating Party 日期 Date 修改人 Modifiedby V1.0 创建 found 2024-6-21 V1.1 ConfidentialInformation www.Topant.com.cn Confidentialityrequirements ShenzhenDaxianTechnologyCo.,Ltd.alreadypossessestheinformationprovidedbytheproprietarytechnology,which shouldbestrictlyconfidentialandnotallowedtobedisclosedtoanypersonorcompanywithoutthepriorwrittenconsentof ShenzhenDaxianTechnologyCo.,Ltd Page3 索引 Indexes 一、项目说明ProjectDescription...................................................................................................................4 二、BT天线antenna..............................................................................................................4 1、规格specifications.................................................................................................4 1.1电气规格标准Electricalspecificationsandstandards........................................................5 1.1.1电性能指标Electricalperformanceindex................................................................5 1.1.2天线位置布局AntennaLocationLayout.................................................................5 1.2结构规格标准Structuralspecificationsandstandards...................................................6 1.2.1天线组成Antennacomposition.............................................................................6 2、测试环境testingenvironment............................................................................................6 3、测试test.....................................................................................................................7 3.1驻波(VSWR)的测试Testofstandingwave(VSWR)........................................................7 3.1.1测试连接Testconnection.......................................................................................7 3.2效率、功率（TRP）、灵敏度（TIS）的测试Testingofefficiency,power(TRP),sensitivity(TIS)..................7 3.2.1测试的场地Testsite..............................................................................................7 3.2.2测试的仪表TestedInstruments..............................................................................7 3.2.3测试数据testdata..............................................................................................7-8 4、VSWR参数图Parameterdiagram.....................................................................................................9 5、无源场型图Passivefieldpatterndiagram..........................................................................................10 6、有源效率场型图Activeefficiencyfieldpatterndiagram.................................................................11 7、户外拉距测试OutdoorPulldistancetest............................................................................................12 8、结论conclusion.......................................................................................................................................12 三、工程图scheduledrawing.................................................................................................13 ConfidentialInformation www.Topant.com.cn Confidentialityrequirements ShenzhenDaxianTechnologyCo.,Ltd.alreadypossessestheinformationprovidedbytheproprietarytechnology,which shouldbestrictlyconfidentialandnotallowedtobedisclosedtoanypersonorcompanywithoutthepriorwrittenconsentof ShenzhenDaxianTechnologyCo.,Ltd Page4 一项目说明ProjectDescription 客户名： CustomerName： 国光 GGEC 整机类型： Typeofcomplete machine： 音箱 loudspeakerbox 天线频段： Antennaband： 2400~2500MHz 天线形式： Antennaform： FPC+同轴线+线材海绵 FPC+coaxialline+wiresponge 馈电形式： Feedform： 焊接 weld 硬件版本： Hardwareversion： / 二BT天线组件Antennaassembly 1规格specifications 本报告主要提供 Spark-EDGE 项目天线的各项电气和结构性能参数的测试状况。下图为大 显设计的天线图片。 Thisreportmainlyprovidesthetestingstatusofvariouselectricalandstructuralperformance parametersoftheantennafortheSpark-EDGEproject.Thefollowingimageshowsanantennawith alargedisplaydesign. 整机外观图天线外观图 Wholemachineappearancechartantennaappearingdiagram ConfidentialInformation www.Topant.com.cn Confidentialityrequirements ShenzhenDaxianTechnologyCo.,Ltd.alreadypossessestheinformationprovidedbytheproprietarytechnology,which shouldbestrictlyconfidentialandnotallowedtobedisclosedtoanypersonorcompanywithoutthepriorwrittenconsentof ShenzhenDaxianTechnologyCo.,Ltd Page5 1.1电气规格标准Electricalspecificationsandstandards 1.1.1电性能指标Electricalperformanceindex 天线工作频段在2400~2500MHz。下表是大显设计和量产天线的电性能的指标. Theoperatingfrequencybandoftheantennaisbetween2400and2500MHz.Thefollowingtable showstheelectricalperformanceindicatorsoflargedisplaydesignandmassproductionantennas. FrequencyRangeFrequency(MHz)VSWR BT2400~2500≤2 1.1.3天线位置布局AntennaLoc…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240800088902 Page: 1 of 138 FCC ID: 2A348SPARKEDGE Ricky Liu Manager TEST REPORT Application No.: GZCR2408000889AT Applicant: Positive LLC Address of Applicant: 2820 S Alma School Rd Suite 18 PMB 2011 Chandler, AZ 85286, USA Manufacturer: Jia Ge Digital Technology Co. Ltd Address of Manufacturer: 11F, No. 176, Changchun Rd., Zhongshan Dist., Taipei City 104082, Taiwan, China Product Name: Guitar Speaker Model No.: Spark EDGE Trade Mark: Positive Grid Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2024-08-02 Date of Test: 2024-08-15 to 2024-08-28 Date of Issue: 2024-09-13 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240800088902 Page: 2 of 138 Revision Record Version Report No. Date Remark 01 GZCR240800088902 2024-09-13 Original Authorized for issue by: Luke Lin/Project Engineer Vico Cui/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240800088902 Page: 3 of 138 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2013) Section 11.12 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2013) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2013) Section 6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Conducted Peak Output Power ANSI C63.10 (2013) Section 11.9.1 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2013) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectrum Density ANSI C63.10 (2013) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2013) Section 11.13.3.2 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2013) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Note: E.U.T./EUT means Equipment Under Test. Pass means the test result passed the test standard requirement, please find the detailed decision rule in the report relative section. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240800088902 Page: 4 of 138 3 Contents Page 1 Cover Page .............................................................................................................................................. 1 2 Test Summary ......................................................................................................................................... 3 3 Contents .................................................................................................................................................. 4 4 General Information................................................................................................................................ 6 4.1 Details of E.U.T. ............................................................................................................................... 6 4.2 Description of Support Units ............................................................................................................. 7 4.3 Measurement Uncertainty ................................................................................................................ 7 4.4 Test Location.................................................................................................................................... 7 4.5 Test Facility ...................................................................................................................................... 8 4.6 Deviation from Standards ................................................................................................................. 8 4.7 Abnormalities from Standard Conditions .......................................................................................... 8 5 Equipment List........................................................................................................................................ 9 6 Radio Spectrum Technical Requirement ............................................................................................ 12 6.1 Antenna Requirement .................................................................................................................... 12 6.1.1 Test Requirement: ..................................................................................................................... 12 6.1.2 Conclusion ................................................................................................................................. 12 7 Radio Spectrum Matter Test Results................................................................................................... 13 7.1 Conducted Emissions at AC Power Line (150kHz-30MHz)............................................................. 13 7.1.1 E.U.T. Operation ........................................................................................................................ 13 7.1.2 Test Mode Description ............................................................................................................... 13 7.1.3 Test Setup Diagram ................................................................................................................... 14 7.1.4 Measurement Procedure and Data .........................................…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240800088902 Page: 96 of 138 5.2.2 CSE and Band Edges 1M_LCH_2402MHz_Ant1_NTNV 1M_LCH_2402MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240800088902 Page: 97 of 138 1M_MCH_2440MHz_Ant1_NTNV 1M_HCH_2480MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240800088902 Page: 98 of 138 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240800088902 Page: 99 of 138 2M_LCH_2402MHz_Ant1_NTNV 2M_MCH_2440MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240800088902 Page: 100 of 138 2M_HCH_2480MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240800088902 Page: 101 of 138 For 2.4GHz Wi-Fi 1. Duty Cycle 1.1 Test Result 1.1.1 Ant1 Ant1 Mode TX Type Frequency (MHz) T_on (ms) Period (ms) Duty Cycle (%) Duty Cycle Correction Factor (dB) Max. DC Variation (%) 802.11b SISO 2412 32.950 32.980 99.91 0.00 0.01 2437 32.954 32.984 99.91 0.00 0.01 2462 32.950 32.980 99.91 0.00 0.00 802.11g SISO 2412 5.484 5.510 99.53 0.02 0.00 2437 5.484 5.510 99.53 0.02 0.00 2462 5.484 5.510 99.53 0.02 0.00 802.11n (HT20) SISO 2412 5.080 5.107 99.47 0.02 0.04 2437 5.079 5.105 99.49 0.02 0.00 2462 5.080 5.107 99.47 0.02 0.04 802.11n (HT40) SISO 2422 2.468 2.494 98.96 0.05 0.03 2437 2.468 2.493 99.00 0.04 0.00 2452 2.468 2.494 98.96 0.05 0.03 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240800088902 Page: 102 of 138 1.2 Test Graph 1.2.1 Ant1 802.11b_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11b_MCH_2437MHz_Ant1 (SISO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240800088902 Page: 103 of 138 802.11b_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11g_LCH_2412MHz_Ant1 (SISO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240800088902 Page: 104 of 138 802.11g_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11g_HCH_2462MHz_Ant1 (SISO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240800088902 Page: 105 of 138 802.11n(HT20)_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11n(HT20)_MCH_2437MHz_Ant1 (SISO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240800088902 Page: 106 of 138 802.11n(HT20)_HCH_2462MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_LCH_2422MHz_Ant1 (SISO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240800088902 Page: 107 of 138 802.11n(HT40)_MCH_2437MHz_Ant1 (SISO)_NTNV 802.11n(HT40)_HCH_2452MHz_Ant1 (SISO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240800088902 Page: 108 of 138 2. Bandwidth 2.1 Test Result 2.1.2 6dB BW Mode TX Type Frequency (MHz) ANT 6dB Bandwidth (MHz) Verdict Result Limit 802.11b SISO 2412 1 10.017 >=0.5 Pass 2437 1 9.568 >=0.5 Pass 2462 1 10.064 >=0.5 Pass 802.11g SISO 2412 1 16.378 >=0.5 Pass 2437 1 16.383 >=0.5 Pass 2462 1 16.354 >=0.5 Pass 802.11n (HT20) SISO 2412 1 16.917 >=0.5 Pass 2437 1 16.867 >=0.5 Pass 2462 1 16.838 >=0.5 Pass 802.11n (HT40) SISO 2422 1 34.811 >=0.5 Pass 2437 1 35.134 >=0.5 Pass 2452 1 35.100 >=0.5 Pass SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240800088902 Page: 109 of 138 2.2 Test Graph 2.2.1 6dB BW 802.11b_LCH_2412MHz_Ant1 (SISO)_NTNV 802.11b_MCH_2437MHz_Ant1 (SISO)_NTNV SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240800088902 Page: 110 of 138 802.11b_HCH_2462…

Text truncated - open the document above for the full version.
