2A34K-ESA2High Precision Smart Antenna

eSA2 Quick Start Guide Copyright © Shanghai eSurvey GNSS Co., Ltd. 2022. All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Shanghai eSurvey GNSS Co., Ltd. Trademarks and Permissions and other eSurvey trademarks are trademarks of Shanghai eSurvey GNSS Co., Ltd. All other trademarks and trade names mentioned in this document are the property of their respective holders. Notice The purchased products, services and features are stipulated by the contract made between eSurvey and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. The information in this document is subject to change without notice. Every effort has been made in the preparation of this document to ensure accuracy of the contents, but all statements, information, and recommendations in this document do not constitute a warranty of any kind, express or implied. Before You Start Dear customers, Thank you for purchasing the eSurvey eSA2. Before starting your work, please carefully read the following: • This user guide is for your product only. If the actual situation does not match with the situation in the user guide, the actual situation shall prevail. • Improper use of the product can lead to death or injury to persons, damage to property and/or malfunction of the product. For safety and instructions on how to use this product, please carefully read the precautions for safe operation, disclaimers and instructions in the user guide and at all times comply with the same. Remember that YOU are the key to safety. • The information in this user guide is subject to change without notice. We reserve the right to change or improve the product as well the content in the user guide without any obligation to notify you. For any questions, please contact us. Precautions for Safe Operation Caution Precautions can be divided into the following types according to the degree of loss or injury in case of negligence or omission: The following outlines the cautions that you should avoid when operating the eSA2 and any of its components: Storage Transportation Indicates a potentially hazardous situation that, if not avoided, may result in INJURY OR PROPORTY DAMAGE OR IRRETRIEVABLE DATA LOSS. • To reduce the self-discharge of the battery, please strictly follow the temperature requirements, and keep the instrument dry. • When transporting, please make sure the instrument and its accessories are reasonably placed in a professional case to prevent direct damage to the instrument from impact and vibration. • Please recharge the instrument before use after storage. • When transporting, please try your best to lighten libration on the instrument. • The eSA2 has a built-in lithium-ion battery. When transporting, please comply with relevant national and international regulations. Indicates a potentially hazardous situation that, if not avoided, could result in SERIOUS INJURY OR EVEN DEATH. Clean and Drying Safety • Please clean the surface of the instrument with a clean, soft and lint- free cloth. If necessary, please wipe the instrument with clean water or alcohol. • Please do not touch the instrument with wet hand. Otherwise, electric shock may occur. • Please always open the instrument box in a warm and dry place in all kinds of weather conditions, after the back of field operation. • Please put the instrument firmly on the pole. • Please make sure that all connectors are clean and dry all the time. • To avoid accidental damage, please only use original supplied parts. Otherwise, damage to the instrument may occur. • Please do not arbitrarily stand or seat on the carrying case, or turn over it. Otherwise, the instrument may be damaged. Warning The following outlines the warnings that you should avoid when operating the eSA2 and any of its components: • Please do not disassemble the instrument. Otherwise, fire or electric shock may occur. Only e-Survey authorized distributors can disassemble or rebuild the instrument. • Please do not cover the charger when charging. Otherwise, fire or explosion may occur. • Please do not use wet charger, defective power cable, socket or plug, and power cable not specified by e-Survey. Otherwise, fire or electric shock may occur. • Please do not put the instrument close to burning gas or liquid, and do not put it in the fire or high temperature condition. Otherwise explosion may occur. • Please avoid short circuit of the battery. Otherwise, fire may occur. • Please avoid disturbance of severe electrostatic discharge. Otherwise, the instrument may have some degradation of performance like switching on/off automatically, etc. Disclaimer It is your responsibility to exercise common sense and navigational judgment while using the eSA2. We assume no responsibility or liability for any damages to property (including direct or indirect damage), personal injuries or death caused by the following conditions: • A faulty or intentional usage or misuse. • Any disasters, such as earthquakes, storms, floods etc. • A change of data, loss of data, an interruption of business etc. • Wrong transport. • Use of non-original parts. • Usage not explained in the user guide. Appearance eSA2 at a Glance The eSA2 main body is as follows: The eSurvey eSA2 is an easy-to-use, wearable, portable smart antenna that provides professional-level positioning data to any Android instruments. And with the designated app support, the eSA2 can be paired with iOS instruments as you wish. Indicator Light Power Button Type C Port Battery status • Off: powered off. • Red: Bluetooth status • Off: no Bluetooth. • Green: Bluetooth connected. • Flashing green: Bluetooth disconnected. Datalink status • Off: no receiving differential signal. • Flashing green: datalink is transmitting data normally. Satellite status • Off: no receiving satellites. • Green: fixed or float solution. • Fl…

Text truncated - open the document above for the full version.

December 19, 2022 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2A34K-ESA2 Product Name: High Precision Smart Antenna Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics Long-term confidential  Block diagram Long-term confidential  Operation description Long-term confidential  Parts lists (BOM) Long-term confidential These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Signature: Name Reinhard Lyu Position Purchase Supervisor Company Name Shanghai eSurvey GNSS Co., Ltd. Address Lianhang Rd, Pujiang Town, Minhang District, Shanghai, China Tel 021-54467149 Fax / Email [email protected]

FCC ID: 2A34K-ESA2 FCC ID: 2A34K-ESA2 FCC ID: 2A34K-ESA2 FCC ID: 2A34K-ESA2 FCC ID: 2A34K-ESA2

4.5cm 2.5cm Label Location FCC ID: 2A34K-ESA2 Shanghai eSurvey GNSS Co., Ltd. Product name: High Precision Smart Antenna Model No.: eSA2 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2A34K-ESA2 FCC ID: 2A34K-ESA2 BT ANT FCC ID: 2A34K-ESA2 FCC ID: 2A34K-ESA2 FCC ID: 2A34K-ESA2 FCC ID: 2A34K-ESA2 FCC ID: 2A34K-ESA2

FCC ID: 2A34K-ESA2 RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v06 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz. Power and distance are rounded to the nearest mW and mm before calculation. The result is rounded to one decimal place for comparison. Worse case is as below: 2402 MHz -3.298 dBm（0.33 mW）output power (0.33mW /5mm)·[√2.402(GHz)]= 0.1 < 3.0 for 1-g SAR So， SAR evaluation is not required.

ALPHA's reports is using a digital certificate that is trusted on Adobe's official server. If there is no digital certificate or the digital certificate shows damaged in your report. Please do not accept the report. E-mail: [email protected] Tel: 4008-3008-95 Website: http://www.a-lab.cn FCC TEST REPORT FCC ID: 2A34K-ESA2 On Behalf of Shanghai eSurvey GNSS Co., Ltd. High Precision Smart Antenna Model No.: eSA2 Prepared for : Shanghai eSurvey GNSS Co., Ltd. Address : Lianhang Rd, Pujiang Town, Minhang District, Shanghai, China Prepared By : Shenzhen Alpha Product Testing Co., Ltd. Address : Building i, No.2, Lixin Road, Fuyong Street, Bao'an District, 518103, Shenzhen, Guangdong, China Report Number : A2209200-C01-R07 Date of Receipt : October 9, 2022 Date of Test : October 9, 2022- December 12, 2022 Date of Report : December 12, 2022 Version Number : V0 Page 2 of 37 Report No.: A2209200-C01-R07 TABLE OF CONTENTS Description Page 1. Summary Of Standards And Results -------------------------------------------------------------------------------- 5 1.1. Description of Standards and Results ------------------------------------------------------------------------ 5 2. General Information ------------------------------------------------------------------------------------------------------ 6 2.1. Description of Device (EUT) ------------------------------------------------------------------------------------ 6 2.2. Accessories of Device (EUT) ----------------------------------------------------------------------------------- 7 2.3. Tested Supporting System Details----------------------------------------------------------------------------- 7 2.4. Block Diagram of connection between EUT and simulators -------------------------------------------- 7 2.5. Test Mode Description -------------------------------------------------------------------------------------------- 7 2.6. Test Conditions ----------------------------------------------------------------------------------------------------- 7 2.7. Test Facility ---------------------------------------------------------------------------------------------------------- 8 2.8. Measurement Uncertainty --------------------------------------------------------------------------------------- 8 2.9. Test Equipment List ----------------------------------------------------------------------------------------------- 9 3. Spurious Emission ------------------------------------------------------------------------------------------------------- 11 3.1. Test Limits ---------------------------------------------------------------------------------------------------------- 11 3.2. Test Procedure ---------------------------------------------------------------------------------------------------- 12 3.3. Test Setup ---------------------------------------------------------------------------------------------------------- 12 3.4. Test Results -------------------------------------------------------------------------------------------------------- 14 4. Power Line Conducted Emission ----------------------------------------------------------------------------------- 20 4.1. Test Limits ---------------------------------------------------------------------------------------------------------- 20 4.2. Test Procedure ---------------------------------------------------------------------------------------------------- 20 4.3. Test Setup ---------------------------------------------------------------------------------------------------------- 20 4.4. Test Results -------------------------------------------------------------------------------------------------------- 21 5. Conducted Maximum Output Power ------------------------------------------------------------------------------- 23 5.1. Test limits ----------------------------------------------------------------------------------------------------------- 23 5.2. Test Procedure ---------------------------------------------------------------------------------------------------- 23 5.3. Test Setup ---------------------------------------------------------------------------------------------------------- 23 5.4. Test Results -------------------------------------------------------------------------------------------------------- 23 6. Peak Power Spectral Density ----------------------------------------------------------------------------------------- 24 6.1. Test limits ----------------------------------------------------------------------------------------------------------- 24 6.2. Test Procedure ---------------------------------------------------------------------------------------------------- 24 6.3. Test Setup ---------------------------------------------------------------------------------------------------------- 24 6.4. Test Results -------------------------------------------------------------------------------------------------------- 24 7. Bandwidth ------------------------------------------------------------------------------------------------------------------ 27 7.1. Test limits ----------------------------------------------------------------------------------------------------------- 27 7.2. Test Procedure ---------------------------------------------------------------------------------------------------- 27 7.3. Test Setup ---------------------------------------------------------------------------------------------------------- 27 7.4. Test Results -------------------------------------------------------------------------------------------------------- 27 8. Band Edge Check -------------------------------------------------------------------------------------------------------- 31 8.1. Test limits ----------------------------------------------------------------------------------------------------------- 31 8.2. Test Procedure ---------------------------------------------------------------------------------------------------- 31 8.3. Test Setup ---------------------------------------------------------------------------------…

Text truncated - open the document above for the full version.

Page 1 Version: 1.0 Issue Date: 2022-08-16 东莞市辉益电子有限公司 DongGuan HuiYi Electronics Co., LTD 客户/Customer： 客户料号/Customer P/N： 规 格 书 Specification 编制/ Signed by： 广东省东莞市长安镇新岗路23号编制日期/ Date： No. 23, XinGang Road, Chang An, Dongguan City, Guangdong Province Page 2 Version: 1.0 Issue Date: 2022-08-16 东莞市辉益电子有限公司 DongGuan HuiYi Electronics Co., LTD Index: 1. Specification / Page 3 2. Characteristics and Reliability Test / Page 4 3. Antenna - S Parameter Test Data / Page 5 4. Antenna - Radiation Pattern Test Data / Page 6 5. Antenna Test method / Page 7 Page 3 Version: 1.0 Issue Date: 2022-08-16 东莞市辉益电子有限公司 DongGuan HuiYi Electronics Co., LTD 1.Specification Sample Photo A. Electrical Characteristics Frequency 2400 ~ 2500 MHz S.W.R. <= 2.0 Efficiency > 50% Polarization Linear Impedance 50 Ohm Antenna Type PIFA B. Material & Mechanical Characteristics Material of Radiator PCB Cable Type O.D. 1.13 mm (Black) 95mm Connector Type Mini1 Connector for O.D. 1.13 mm Coaxial Cable Pull Test >= 1.0 Kg C. Environmental Operation Temperature -40 ̊C ~ + 65 ̊C Storage Temperature -40 ̊C ~ + 80 ̊C Model Number:NB1807-113G-095BX Product NameBT Antenna Page 4 Version: 1.0 Issue Date: 2022-08-16 东莞市辉益电子有限公司 DongGuan HuiYi Electronics Co., LTD 2.Characteristics and Reliability Test Test Items Test Condition and Procedure Requirements C1 S.W.R. Set DUT on Network Analyzer; make individual calibration to test Directive DUT specification C2 Antenna Gain Set DUT on Antenna Chamber; make individual calibration to test Directive DUT specification M1 Vibration MIL-STD-202G, 201A Amplitude: 0.03 inch (0.76mm); Freq: 10 to 55 Hz 3 directions; 2 hours for each direction 1. No Visual Damage 2. Frequency Tol.<= 5% M2 Random Drop Height: 1.5 Meter; 3 directions; 1 time for each direction 1. No parts separated 2. Frequency Tol.<= 5% M3 Solderability MIL-STD-202G, 210F, cond. A Solder iron: 350±10°C; Duration: 5 seconds 1. Mounted on PCB 2. No Visual Damage M4 Terminal- Pull Test MIL-STD-202G, 211A, cond. A Holding with individual specification; force applied to axis of terminal 1. Directive DUT specification 2. Frequency Tol.<= 5% M5 Dimension Inspection of dimension, color, material, package, surface process Directive DUT specification E1 Salt Spray MIL-STD-202G, 101E, cond. B Temp: 35°C; RH: >= 95%; NaCl solution: >= 5%; Time: 48 hours After 2 Hours Recovery 1. No Visual Damage 2. Frequency Tol.<= 5% E2 Humidity MIL-STD-202G, 103B, cond. B Temp: 40°C; RH: >= 95%; Time: 48 hours After 2 Hours Recovery 1. No Visual Damage 2. Frequency Tol.<= 5% E3 Thermal Shock 1 Cycle: - 40°C (30 minutes) to + 80°C (30 minutes) Cycles: 24 After 2 Hours Recovery 1. No Visual Damage 2. Frequency Tol.<= 5% E4 Life (High Temp.) MIL-STD-202G, 108A, cond. A Temp: 85°C; Time: 96 hours After 2 Hours Recovery 1. No Visual Damage 2. Frequency Tol.<= 5% Page 5 Version: 1.0 Issue Date: 2022-08-16 东莞市辉益电子有限公司 DongGuan HuiYi Electronics Co., LTD 3.Antenna - S Parameter Test Data Remark： Test data is based on casing matching test, it’s different from the single product test data. Page 6 Version: 1.0 Issue Date: 2022-08-16 东莞市辉益电子有限公司 DongGuan HuiYi Electronics Co., LTD 4.Antenna - Radiation Pattern Test Data See attached files Testing Equipment Specification: Antenna Anechoic Chamber Dimension: 8 x 4 x 4 m Quite Zone: 600mm @1 GHz Isolation: >100dB @ 1 MHz ~ 10 GHz Testing Equipment: Agilent 5071B Received Antenna: 0.7 ~ 6.0 GHz for Gain Calibration Double Ridged Horn Antenna Page 7 Version: 1.0 Issue Date: 2022-08-16 东莞市辉益电子有限公司 DongGuan HuiYi Electronics Co., LTD 5.Antenna Test method Technical parameters reference range： Page 8 Version: 1.0 Issue Date: 2022-08-16 东莞市辉益电子有限公司 DongGuan HuiYi Electronics Co., LTD Frequency 驻波比（V.S.W.R）范围 2.4GHz <2.0 2.45GHz <2.0 2.5GHz <2.5

FCC ID: 2A34K-ESA2 Radiated Emission FCC ID: 2A34K-ESA2 Conducted Emission
