2A3CE-NP08EPoE NVR

LongVision App    Related tools and documents are available at https://longplus.com Cloud Service Light USB Port Power Input Power Switch USB Port LAN Port PoE Interface HD-OUT Port VGA Port HDD Light Network Light Power Light Audio Out LAN Port PoE Interface VGA Port Cloud Service Light USB Port HDD Light Network Light Power Light Power Input Power Switch USB Port HD-OUT Port Audio Out Step1: Connect the LAN port of the NVR to the router via an ethernet cable, and connect the mouse to the USB port of the NVR. Step2: Connect the NVR to the monitor with a HDMI or VGA cable. The VGA cable is not included. Step3: Connect cameras to PoE ports on the NVR. Step4: Connect the NVR to a power outlet and turn on power switch. You can use the provided screws and expansion screws to mount the camera on a flat wall surface. The wall surface must have enough strength to secure the camera (the camera shown in the illustration is for instructional purposes only). Bullet Camera Select the appropriate position and stick the position- ing sticker on the wall. Drill holes according to the installation hole template. Install the mount base with the mounting screws included in the package. By rotating the round joint and bracket to achieve the longitudinal and axial adjustment of the camera Turn the knob clockwise to fix the camera angle and complete the installation. Quick installation of Conch camera Drill holes according to the mounting hole template and screw the mounting plate to the mounting holes on the ceiling. Conch Camera Once the camera is installed, you may rotate the camera body manually to adjust the camera’s surveillance angle. 3 Note： For installation on a wooden wall, the bracket can be mounted directly on the wall by screws. For installation on masonry walls (brick, concrete or others), expansion screws need to be installed first. Push the camera upward onto the mounting bracket and then move it to the right to lock the camera in place. Quickly remove the conch camera Use your fingers to push up on the mounting bracket protrusion, then hold the camera and move it to the left. Step1: Thread the Ethernet cable through the top cover and then the waterproof connector.Put the rubber seal ring around the Ethernet cable between the top cover and the waterproof connector. When mounting your PoE camera outdoors, you are suggested to install the waterproof lid for it. You may follow the steps below for installation. Step2: Put on the rubber O-ring to the Ethernet port of the camera and plug the Ethernet cable into the Ethernet port. Top Cover 1 Waterproof Connector Rubber Seal Ring Ethernet PortRubber O-Ring 2 Step3: Align the waterproof connector with the Ethernet port, then twist it clockwise to tighten the two parts. Waterproof Connector 3 Step4: Push the rubber seal ring into the waterproof connector, then screw the top cover and lock it into position firmly to finish installation. 4 5 Rubber Seal Ring Note: The rubber seal ring provided has been cut. If not, you may manually cut it. 1. Please ensure that the access voltage meets the device requirements and that the device power cord is in good contact. 2. Please ensure the monitor is connected to the video output interface of the device before power on. 3. After the device powers on, the power indicator will be red and the power-on image will appear on the monitor screen. After the device powers on, users can quickly configure the device through the "Wizard", System Languages -> Administrator Password -> Security Question -> Security Email -> Network Param- eters -> System Time. Power On Startup Wizard After installing the hard drive for the first time, the hard drive must be formatted in the Setup->Video->Hard Drive interface(Preinstalled HDD does not need to be formatted). Note: Please access the NVR with the following web browsers: Microsoft EdgeApple SafariMozilla Firefox and Google Chrome. Steps 1. Enter the IP address of the device in the browser http://IP (eghttp://192.168.1.88). If you have changed the http port, please enter http://IP:HTTP Port (eghttp://192.168.1.88:89). 2.Enter the username and password on the login interface. 3.Click login. After logging in, please follow the system prompts to download and install the Web plug-in. Otherwise, some functions will not be available. Note: App Operation 1. Scan the QR code below to download and install the LongVision App. 2. Download and install the LongVision App in the App Store or Google Play. Please install the device in a well-ventilated place and do not block the vents of the device. Please keep the device installed horizontally, or in a stable place, and pay attention to prevent the product from falling. Please store and use the device within the allowable humidity and moisture range. Please use the device within the rated input and output range. Do not drip or spill liquids on the device and ensure that items containing liquids are not placed on the device to prevent liquids from flowing into the device. Dust on the circuit board will cause a short circuit after moisture. In order to make the NVR work properly for a long time, please regularly use a brush to dust the circuit board, connec- tors, case, etc. When cleaning the device, please do not use volatile solvents such as: alcohol, benzene or thinner, which will damage the surface coating. When cleaning the device, please unplug the power cord and completely cut off the power. The installation and construction of the device must comply with the specifications, which can refer to the relevant national or local standards. If the equipment smokes, smells or is noisy, cut off the power immediately and unplug the power plug cable. Do not point the camera lens at cold, such as air conditioning vents, ice, etc. Do not place the camera in a shaded area, as this may result in poor image quality. To ensure the best image quality, please place it towards a well-lit area, the lighting condi- tions …

Text truncated - open the document above for the full version.

(Longse Technology Limited) (2025/11/6) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2A3CE-NP08E) [Longse Technology Limited] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, the equipment does not utilize cyber-security or anti-virus software from Kaspersky Lab, Inc, or any of its successors and assignees, which is also on the “covered list”. Sincerely, (Applicant signature) (Applicant printed name) HE HAIEN (Longse Technology Limited) (2025/11/6) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID: 2A3CE-NP08E) [Longse Technology Limited] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) HE HAIEN

Longse Technology Limited 2025/12/23 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen STS Test Services Co., Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s signature: Client’s name / title : HE HAIEN / Manager Contact information / address: No.18, Dongming 3rd road, Huangpu District, Guangzhou, Guangdong, China

Longse Technology Limited 2025/12/23 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: CONFIDENTIALITY REQUEST FOR EUT NAME: PoE NVR Trademark: N/A MODEL: NP08E NP08C, NP08D, NP08F, NP08G, NP08K, NP08L, NP08N, NP08P, NP08C, NP08D, NP08F, NP08G, NP08K, NP08L, NP08N, NP08P, LP8ME84D1, LP8ME84B1, LP8ME88D1, LP8ME88B1, LP8ME84D2, LP8MC84B2, LP8MC88D2, LP8MC88B2 FCC ID: 2A3CE-NP08E To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Client’s signature: Client’s name / title : HE HAIEN / Manager Contact information / address: No.18, Dongming 3rd road, Huangpu District, Guangzhou, Guangdong, China

Longse Technology Limited Model Difference 2025/12/23 EUT NAME: PoE NVR Trademark: N/A MODEL: NP08E NP08C, NP08D, NP08F, NP08G, NP08K, NP08L, NP08N, NP08P, LP8ME84D1, LP8ME84B1, LP8ME88D1, LP8ME88B1, LP8ME84D2, LP8MC84B2, LP8MC88D2, LP8MC88B2 FCC ID: 2A3CE-NP08E All the models are the same circuit and RF module, except model names and appearance of the color. Regards Sincerely Client’s signature: Client’s name / title : HE HAIEN / Manager Contact information / address: No.18, Dongming 3rd road, Huangpu District, Guangzhou, Guangdong, China

Page 1 of 13 FCC ID: 2A3CE-NP08E External Photos Page 2 of 13 FCC ID: 2A3CE-NP08E Page 3 of 13 FCC ID: 2A3CE-NP08E Page 4 of 13 FCC ID: 2A3CE-NP08E Page 5 of 13 FCC ID: 2A3CE-NP08E Page 6 of 13 FCC ID: 2A3CE-NP08E

Location： Label FCC ID: 2A3CE-NP08E This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation

Page 7 of 13 FCC ID: 2A3CE-NP08E Internal Photos Antenna Page 8 of 13 FCC ID: 2A3CE-NP08E Page 9 of 13 FCC ID: 2A3CE-NP08E Page 10 of 13 FCC ID: 2A3CE-NP08E Page 11 of 13 FCC ID: 2A3CE-NP08E Page 12 of 13 FCC ID: 2A3CE-NP08E Page 13 of 13 FCC ID: 2A3CE-NP08E

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. MPE Report Report No.: STS2601310H01 Issued for Longse Technology Limited No.18, Dongming 3rd, Huangpu District, Guangzhou, Guangdong, China Product Name: PoE NVR Brand Name: N/A Model Name: NP08E Series Model(s): NP08C, NP08D, NP08F, NP08G, NP08K, NP08L, NP08N, NP08P, LP8ME84D1, LP8ME84B1, LP8ME88D1, LP8ME88B1, LP8ME84D2, LP8MC84B2, LP8MC88D2, LP8MC88B2 FCC ID: 2A3CE-NP08E Test Standard: FCC 47CFR §2.1091 Page 2 of 7 Report No.: STS2601310H01 TEST REPORT Applicant’s Name ................. : Longse Technology Limited Address ................................. : No.18, Dongming 3rd, Huangpu District, Guangzhou, Guangdong, China Manufacturer's Name ........... : Longse Technology Limited Address ................................. : No.18, Dongming 3rd, Huangpu District, Guangzhou, Guangdong, China Product Description Product Name ........................ : PoE NVR Brand Name .......................... : N/A Model Name .......................... : NP08E Series Model(s) ...................... : NP08C, NP08D, NP08F, NP08G, NP08K, NP08L, NP08N, NP08P, LP8ME84D1, LP8ME84B1, LP8ME88D1, LP8ME88B1, LP8ME84D2, LP8MC84B2, LP8MC88D2, LP8MC88B2 Test Standards ..................... : FCC 47CFR §2.1091 447498 D01 Interim General RF Exposure Guidance v06 The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ...................... : 23 Dec. 2025 Date (s) of performance of tests ............. : 23 Dec. 2025 to 14 Jan. 2026 Date of Issue .......................................... : 14 Jan. 2026 Test Result .............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 7 Report No.: STS2601310H01 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 5 2. FCC 47CFR §2.1091 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 7 Page 4 of 7 Report No.: STS2601310H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 14 Jan. 2026 STS2601310H01 ALL Initial Issue Page 5 of 7 Report No.: STS2601310H01 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name PoE NVR Brand Name N/A Model Name NP08E Series Model(s) NP08C, NP08D, NP08F, NP08G, NP08K, NP08L, NP08N, NP08P, LP8ME84D1, LP8ME84B1, LP8ME88D1, LP8ME88B1, LP8ME84D2, LP8MC84B2, LP8MC88D2, LP8MC88B2 Model Difference All the model are the same circuit and RF module, except model names and appearance of the color, the test model is NP08E. Product Description The EUT is a PoE NVR Operation Frequency: 2402~2480 MHz Modulation Type: GFSK Radio Technology: BLE Bluetooth Configuration: LE(Support 1M PHY, 2M PHY) Number Of Channel: 40 Antenna Type: Internal antenna Antenna Gain (dBi) 2.11 Power Rating AC 100-240V, 50/60Hz Adapter Model: SA0691-4801360D Input: 100-240V~, 50/60Hz, 1.5A Max Output: DC 48V, 1.36A, 65.28W Battery N/A Hardware Version N/A Software Version N/A 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 6 of 7 Report No.: STS2601310H01 2. FCC 47CFR §2.1091 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of the human exposure to radio-frequency (RF) radiation as specified in 1.1307 (b) Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm²) Limits for Occupational / controlled Exposures 300 - 1500 -- -- F/300 3.0-30 1842/f 4.89/f *(900/f²) 1500 – 100000 -- -- 5.0 Limits for General population / Uncontrolled Exposure 300 - 1500 -- -- F/1500 1.34-30 824/f 2.19/f *(180f²) 1500 – 100000 -- -- 1.0 F= Frequency in MHz Friss Formula Friss Transmission Formula: Pd = (Pout * G) / (4*pi*r²) Where Pd = power density in mW/cm² Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = Distance between observation point and the center of radiator in cm If we know the maximum gain of the antenna and the total output power to the antenna, through calculation, we will know MPE value at distance 20cm. Page 7 of 7 Report No.: STS2601310H01 2.3 TEST RESULT Tune up Mode Detector Tune up Power GFSK Peak 2±1dBm Note: 1. The Maxinum power is less than the limit, complies with the exemption requirements. 2. ERP = EIRP - 2.15 ※※※※※END OF THE REPORT※※※※※ Protocol Fre. (GHz) Separati on distance (cm) Max Tune up power (dBm) ANT Gain (dBi) Max EIRP (dBm) Max EIRP (mW) Power Density (mW/cm²) Limit (mW/ cm²) Ratio Result GFSK 2.480 20 3 2.11 5.11 3.243 0.0006 1 0.0006 Pass

地址：东莞市塘厦镇清湖头建隆科创园4栋6楼第 1 页共 10 页 SPECIFICATIONFORAPPROVAL CUSTOMERNAME: CUSTOMERP/N: PRODUCTP/N:Z1C190F3D37A PRODUCTNAME:2.4GHz-5.8GHzAntenna Description: Z1C190F3D37A/2.4GHz-5.8GHzBuiltinFPC antenna/1.13blackwireL=190mm+domesticIPEX (firstgeneration) REV:A Factoryseal S I G N APPROVEDBYCHECKEDBYDRAMN Customersignature S I G N QER&DPE 地址：东莞市塘厦镇清湖头建隆科创园4栋6楼第 2 页共 10 页 Contents ltemDescription 一、--------------------------------------------------ChangeHistory 二、-----------------------------------------------SpecificationSheet 三、------------------------------------------------Productdrawing 四、-------------------------------------------------------TestReport 五、---------------------------------------------------Productimage 地址：东莞市塘厦镇清湖头建隆科创园4栋6楼第 3 页共 10 页 一、（RevisionHistory）： Reversi on Revisi onpage Change date Revised by Reasonandcontentfor revision Remarks A-2025.11.03EVIENFirstEdition Instructions: Thisspecificationisgenerallyvalidfor1year; Ifeitherpartyneedstomakemodifications,itmustbeagreed uponbybothpartiesthroughconsultationbefore implementation; Ifneitherpartyrequestsanymodificationsafterthe expirationofthisspecification,thevalidityperiodofthis specificationshallbeextendedbyoneyear. 地址：东莞市塘厦镇清湖头建隆科创园4栋6楼第 4 页共 10 页 二、SpecificationSheet： Maintechnicalspecifications FrequencyRange (MHZ) 2400-2500/5150-5850 Impedance(Ω)50 Gain(dBi) 1.5~5 VSWR ≤2.0 Polarizationvertical RadiationOmni-directional PhysicalProperties AntennaMaterialFPCB ConnectorTypeThefirstgenerationIPEX Totallength190mm Exposedlength190mm OperatingTemp-20°C~+70°C StorageTemp-20°C~+60°C 地址：东莞市塘厦镇清湖头建隆科创园4栋6楼第 5 页共 10 页 三、Productdrawing： 地址：东莞市塘厦镇清湖头建隆科创园4栋6楼第 6 页共 10 页 四、Testreport： 4.1：NetworkAnalyzerTestReport 地址：东莞市塘厦镇清湖头建隆科创园4栋6楼第 7 页共 10 页 4.2：Darkroom2D、3DRaditationPattern 2400MHz 2450MHz 2500MHz 地址：东莞市塘厦镇清湖头建隆科创园4栋6楼第 8 页共 10 页 5150MHz 5500MHz 5850MHz 地址：东莞市塘厦镇清湖头建隆科创园4栋6楼第 9 页共 10 页 2400/5800MHZ-Phi0 2400/5800MHz-Phi90 2400/5800MHz-Theta90 地址：东莞市塘厦镇清湖头建隆科创园4栋6楼第 10 页共 10 页 4.3：Gainandefficiencyofantenna 五、Productimage ANT Frequency（MHZ）Gain（dBi）Efficiency（%） 24001.8253.57 24501.8555.29 25002.1152.34 51505.1557.34 55003.2759.26 58502.7552.63

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Radio Test Report Report No.: STS2601310W01 Issued for Longse Technology Limited No.18, Dongming 3rd, Huangpu District, Guangzhou, Guangdong, China Product Name: PoE NVR Brand Name: N/A Model Name: NP08E Series Model(s): NP08C, NP08D, NP08F, NP08G, NP08K, NP08L, NP08N, NP08P, LP8ME84D1, LP8ME84B1, LP8ME88D1, LP8ME88B1, LP8ME84D2, LP8MC84B2, LP8MC88D2, LP8MC88B2 FCC ID: 2A3CE-NP08E Test Standards: FCC Part15.247 Page 2 of 70 Report No.: STS2601310W01 TEST REPORT Applicant’s Name ................. : Longse Technology Limited Address ................................. : No.18, Dongming 3rd, Huangpu District, Guangzhou, Guangdong, China Manufacturer's Name .......... : Longse Technology Limited Address ................................. : No.18, Dongming 3rd, Huangpu District, Guangzhou, Guangdong, China Product Description Product Name ....................... : PoE NVR Brand Name .......................... : N/A Model Name .......................... : ... : NP08E Series Model(s) .................... : NP08C, NP08D, NP08F, NP08G, NP08K, NP08L, NP08N, NP08P, LP8ME84D1, LP8ME84B1, LP8ME88D1, LP8ME88B1, LP8ME84D2, LP8MC84B2, LP8MC88D2, LP8MC88B2 Test Standards ..................... : FCC Part15.247 Test Procedure ...................... : ANSI C63.10-2020 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the IC requirements. And it is applicable only to the tested sample identified in the report. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ..................... : 23 Dec. 2025 Date (s) of performance of tests ............. : 23 Dec. 2025 to 14 Jan. 2026 Date of Issue .......................................... : 14 Jan. 2026 Test Result.............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 70 Report No.: STS2601310W01 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 TEST SOFTWARE AND POWER LEVEL 10 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 11 2.6 EQUIPMENTS LIST 12 3. EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.2 TEST PROCEDURE 14 3.3 TEST SETUP 14 3.4 EUT OPERATING CONDITIONS 14 3.5 TEST RESULTS 15 4. RADIATED EMISSION MEASUREMENT 17 4.1 RADIATED EMISSION LIMITS 17 4.2 TEST PROCEDURE 19 4.3 TEST SETUP 20 4.4 EUT OPERATING CONDITIONS 20 4.5 FIELD STRENGTH CALCULATION 21 4.6 TEST RESULTS 22 5. CONDUCTED SPURIOUS & BAND EDGE EMISSION 37 5.1 LIMIT 37 5.2 TEST PROCEDURE 37 5.3 TEST SETUP 37 5.4 EUT OPERATION CONDITIONS 37 5.5 TEST RESULTS 37 6. POWER SPECTRAL DENSITY TEST 38 6.1 LIMIT 38 Page 4 of 70 Report No.: STS2601310W01 Table of Contents Page 6.2 TEST PROCEDURE 38 6.3 TEST SETUP 38 6.4 EUT OPERATION CONDITIONS 38 6.5 TEST RESULTS 38 7. BANDWIDTH TEST 39 7.1 LIMIT 39 7.2 TEST PROCEDURE 39 7.3 TEST SETUP 39 7.4 EUT OPERATION CONDITIONS 39 7.5 TEST RESULTS 39 8. PEAK OUTPUT POWER TEST 40 8.1 LIMIT 40 8.2 TEST PROCEDURE 40 8.3 TEST SETUP 40 8.4 EUT OPERATION CONDITIONS 40 8.5 TEST RESULTS 40 9. ANTENNA REQUIREMENT 41 9.1 STANDARD REQUIREMENT 41 9.2 EUT ANTENNA 41 APPENDIX 1-TEST DATA 42 DUTY CYCLE 42 MAXIMUM CONDUCTED OUTPUT POWER 46 -6DB BANDWIDTH 50 MAXIMUM POWER SPECTRAL DENSITY LEVEL 54 BAND EDGE 58 CONDUCTED RF SPURIOUS EMISSION 63 APPENDIX 2- EUT TEST PHOTO 70 Page 5 of 70 Report No.: STS2601310W01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 14 Jan. 2026 STS2601310W01 ALL Initial Issue Page 6 of 70 Report No.: STS2601310W01 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted bands of operation PASS -- Part 15.247(d)/ Part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- Note: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020. Page 7 of 70 Report No.: STS2601310W01 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.751dB 2 Unwanted Emissions, conducted ±2.888dB 3 All emissions, radiated 9K-30MHz ±2.48dB 4 All emissions, radiated 30M-1GHz ±2.52dB 5 All emissions, radiated 1G-18GHz ±3.48dB 6 All emissions, radiated>18GHz ±4.18dB 7 Conducted Emission (9KHz-150KHz) ±2.48dB 8 Conducted Emission (150KHz-30MHz) ±2.52dB 9 Occupied Channel Bandwidth ±3.6% 10 Power Spectral Density, conducted ±1.214dB 11 Duty Cycle ±3.2% Page 8 of 70 Report No.: STS2601310W01 2. GENERAL INFORMATION 2.1 GEN…

Text truncated - open the document above for the full version.

Page 1 of 2 FCC ID: 2A3CE-NP08E Conducted emissions 30MHz-1GHz Page 2 of 2 FCC ID: 2A3CE-NP08E Spurious emissions
