2A3NS-THORRobotic Lawn Mower

Sveaverken Thor Robotic Lawn Mower User Manual Last edited: October/2025 Cover Page Sveaverken Thor Robotic Lawn Mower Copyright Page Copyright Notice Copyright © 2025 Sveaverken. All rights reserved. No Unlawful Use Permitted No part of this manual may be reproduced, copied, distributed, transmitted, modified, translated, or otherwise exploited in any form or by any means, whether electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Sveaverken. Disclaimer The information contained in this manual is for informational purposes only and is subject to change without notice. Sveaverken makes no representations or warranties, express or implied, regarding the completeness or accuracy of the information contained in this manual. Sveaverken shall not be liable for any damages arising from the use of this manual. Updates This manual is subject to change without notice. Sveaverken reserves the right to update the contents of this manual at any time without providing any prior notice or updates. Trademarks Sveaverken and the Sveaverken logo are trademarks of Sveaverken. All other trademarks mentioned in this manual are the property of their respective owners. Contact Information For more information about Sveaverken or its products, please visit our website at https://www.sveaverken.com/. Versions Version Date Amendments V1.0 January 14 2025 First Version V1.1 July 14 2025 Second Version V1.2 October 27 2025 Third Version Preface • How to Use the Manual: Instructions on how to navigate and use the manual effectively. Introduction The Sveaverken Thor is an advanced robotic lawn mower designed to provide efficient, autonomous lawn care for commercial lawns. This user manual covers the setup, operation, and maintenance of Thor. Effective grounds maintenance requires a solution that balances precision, adaptability, and ease of management. Sveaverken Thor's triple compact cutting deck system, equipped with six pivoting razor blades per deck, is designed to handle a variety of mowing conditions with accuracy and efficiency. Combining autonomous mowing capabilities with a practical fleet management system, Thor helps maintain high standards across properties such as golf courses, sports fields, and public spaces. With an advanced three-layer guidance system—RTK GNSS positioning, computer vision, and a 3D LiDAR sensor—Thor navigates complex environments and adjusts to obstacles while maintaining defined mowing patterns. The cloud-based fleet management platform allows for seamless coordination of multiple units, ensuring smooth integration into your existing operations and providing valuable data insights to support informed decision-making. Key features: Advanced Navigation • Dual RTK GNSS, LiDAR, and vision navigation provide precise mowing in complex terrains, ensuring accurate coverage without boundary wires. • Real-time obstacle detection allows for seamless operation in dense landscaping and irregular layouts. Efficient Cutting Performance • A 730mm cutting width covers more ground in less time, reducing overall mowing duration. • Adjustable cutting height (20–100mm) adapts to different grass types and seasonal changes. • Adaptive fron axel and a floating cutting deck handle slopes up to 20°, ensuring smooth performance on uneven terrain. Smart Energy Management • A 2 kWh Rechargeable Lithium-ion Battery offers extended runtime, fast charging, and improved sustainability. • Optimized path planning enhances efficiency by minimizing redundant passes and reducing operational downtime. Simplified Deployment • Wire-free installation lowers setup costs and makes it easy to deploy across large and dynamic properties. This manual will guide you through the initial installation, setting up the app, operating modes, maintenance procedures, troubleshooting, and technical specifications of the Sveaverken Thor. Follow the instructions carefully to ensure safe and optimal performance of your robotic lawn mower. 1.1 Safety Information 1.1 Safety Definitions Warnings, cautions, and notes are used to highlight particularly important parts of the manual. • WARNING: Indicates a risk of serious injury or death to the operator or bystanders if the instructions in this manual are not followed. Any loss or injury resulting from improper use shall be the responsibility of the user. • CAUTION: Indicates a risk of damage to the product, other materials, or the adjacent area if the instructions in the manual are not followed. • Note: Provides additional information that is necessary in a given situation. 1.2 General Safety Instructions WARNING: Read the following warning instructions carefully before using the product. Never stand, sit, or place objects on the mower or its charging station. Read the Operator’s Manual: Ensure you understand the instructions before using the product. Keep the manual for future reference. Supervision and Instruction: This appliance is not intended for use by children or persons with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety. EU requirements allow this appliance to be used by children aged from 8 years and above and persons with reduced physical, sensory, or mental capabilities or lack of experience and knowledge, if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be done by children without supervision. Operator Reponsibilities: The operator assumes full responsibility for all accidents or hazards that occur to people or property while using this equipment. This responsibility includes proper installation, safe operation, and maintenance of all safety features. The operator must ensure all additional us…

Text truncated - open the document above for the full version.

Sveaverken Svea Agri AB 2025-11-28 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2A3NS-THOR) [Sveaverken Svea Agri AB] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, the equipment does not utilize cyber-security or anti-virus software from Kaspersky Lab, Inc, or any of its successors and assignees, which is also on the “covered list”. Sincerely, River Wang Certified Administrator Sveaverken Svea Agri AB Hˆgmossev‰gen 11, SE-641 39, Katrineholm, Sweden Sveaverken Svea Agri AB 2025-11-28 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID: 2A3NS-THOR) [Sveaverken Svea Agri AB] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, River Wang Certified Administrator Sveaverken Svea Agri AB Hˆgmossev‰gen 11, SE-641 39, Katrineholm, Sweden

Sveaverken Svea Agri AB 2025-11-28 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Guangdong Global Testing Technology Co., Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, River.Wang Certified Administrator Sveaverken Svea Agri AB Hˆgmossev‰gen 11, SE-641 39, Katrineholm, Sweden

Sveaverken Svea Agri AB 2025-11-28 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (EUT Name: Robotic Lawn Mower /Model: Thor /FCC ID: 2A3NS-THOR) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (Block Diagram, Operational Description, Schematics) required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, River.Wang Certified Administrator Sveaverken Svea Agri AB Högmossevägen 11, SE-641 39, Katrineholm, Sweden

External Photographs View of EUT-1 View of EUT-2 Page 2 of 6 View of EUT-3 View of EUT-4 Page 3 of 6 View of EUT-5 View of EUT-6 Page 4 of 6 View of EUT-7 View of EUT-8 Page 5 of 6 View of EUT-9 View of EUT-10 Page 6 of 6 View of EUT-11

1. Label location： 2. Label：

Internal Photographs Internal View of EUT-1 Internal View of EUT-2 Page 2 of 25 Internal View of EUT-3 Internal View of EUT-4 Page 3 of 25 Internal View of EUT-5 Internal View of EUT-6 Page 4 of 25 Internal View of EUT-7 Internal View of EUT-8 Page 5 of 25 Internal View of EUT-9 Internal View of EUT-10 Page 6 of 25 Internal View of EUT-11 Internal View of EUT-12 Page 7 of 25 Internal View of EUT-13 Internal View of EUT-14 Page 8 of 25 Internal View of EUT-15 Internal View of EUT-16 Page 9 of 25 Internal View of EUT-17 Internal View of EUT-18 Page 10 of 25 Internal View of EUT-19 Internal View of EUT-20 Page 11 of 25 Internal View of EUT-21 Internal View of EUT-22 Page 12 of 25 Internal View of EUT-23 Internal View of EUT-24 Page 13 of 25 Internal View of EUT-25 Internal View of EUT-26 2/3/4G Antenna Page 14 of 25 Internal View of EUT-27 Internal View of EUT-28 2/3/4G Antenna BT Antenna Page 15 of 25 Internal View of EUT-29 Internal View of EUT-30 2.4GHz WiFi Antenna Radio station/GNSS Antenna Page 16 of 25 Internal View of EUT-31 Internal View of EUT-32 Page 17 of 25 Internal View of EUT-33 Internal View of EUT-34 Page 18 of 25 Internal View of EUT-35 Internal View of EUT-36 Page 19 of 25 Internal View of EUT-37 Internal View of EUT-38 Page 20 of 25 Internal View of EUT-39 Internal View of EUT-40 Page 21 of 25 Internal View of EUT-41 Internal View of EUT-42 Page 22 of 25 Internal View of EUT-43 Internal View of EUT-44 Page 23 of 25 Internal View of EUT-45 Internal View of EUT-46 Page 24 of 25 Internal View of EUT-47 Internal View of EUT-48 Page 25 of 25 Internal View of EUT-49 Internal View of EUT-50

RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in ß1.1307(b) FCC ID: 2A3NS-THOR EUT Specification EUT Robotic Lawn Mower Frequency band (Operating) BT: 2.402GHz ~ 2.480GHz BLE: 2.402GHz ~ 2.480GHz WIFI: 2.412GHz ~ 2.462GHz WIFI: 5.180GHz ~ 5.240GHz WIFI: 5.260GHz ~ 5.320GHz WIFI: 5.500GHz ~ 5.700GHz WIFI: 5.745GHz ~ 5.825GHz Device category Portable (<20cm separation) Mobile (>20cm separation) Exposure classification Occupational/Controlled exposure (S = 5mW/cm 2 ) General Population/Uncontrolled exposure (S=1mW/cm 2 ) Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power BT DH5: 6.16 dBm 2DH5: 6.95 dBm 3DH5: 7.51 dBm BLE BLE 1M: 6.35 dBm BLE 2M: 6.47 dBm 2.4G WIFI IEEE 802.11b: 16.27 dBm IEEE 802.11g: 16.41 dBm IEEE 802.11n-HT20: 16.40 dBm IEEE 802.11ax HE20: 15.92 dBm Antenna gain (Max) BT: 5.2 dBi BLE: 5.2 dBi 2.4G WIFI: 1.5 dBi 2 / 5 Evaluation applied MPE Evaluation SAR Evaluation Limits for Maximum Permissible Exposure(MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 Friis transmission formula: Pd=(Pout*G)\(4*pi*R2) Where P d = Power density in mW/cm 2 , P out =output power to antenna in mW. G= gain of antenna in linear scale, Pi=3.1416 R= distance between observation point and center of the radiator in cm=20cm P d the limit of MPE, 1mW/cm 2 . If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. For multiple RF sources: Multiple RF sources are exempt if: in the case of fixed RF sources operating in the same time-averaging period, or of multiple mobile or portable RF sources within a device operating in the same time averaging period, if the sum of the fractional contributions to the applicable thresholds is less than or equal to 1 as indicated in the following equation Evaluated k : the maximum reported SAR or MPE of fixed, mobile, or portable RF source k either in the device or at the transmitter site from an existing evaluation at the location of exposure. Exposure Limit k : either the general population/uncontrolled maximum permissible exposure (MPE) or specific Absorption rate (SAR) limit for each fixed, mobile, or portable RF source k. 3 / 5 Measurement Result BT: Mode Max Measured Power (dBm) Tune up tolerance (dBm) Max tune up conducted power(dBm) Output Peak power (mW) Ant. Gain (dBi) Ant. Gain (numeric) Power density at 20cm (mW/ cm 2 ) Power density Limits (mW/ cm 2 ) Results DH5 6.16 6±1 7 5.012 5.2 3.311 0.003302 1 PASS 2DH5 6.95 7±1 8 6.310 5.2 3.311 0.004156 1 PASS 3DH5 7.51 8±1 9 7.943 5.2 3.311 0.005233 1 PASS BLE: Mode Max Measured Power (dBm) Tune up tolerance (dBm) Max tune up conducted power(dBm) Output Peak power (mW) Ant. Gain (dBi) Ant. Gain (numeric) Power density at 20cm (mW/ cm 2 ) Power density Limits (mW/ cm 2 ) Results BLE 1M 6.35 6±1 7 5.012 5.2 3.311 0.003302 1 PASS BLE 2M 6.47 6±1 7 5.012 5.2 3.311 0.003302 1 PASS 2.4G WIFI: Mode Max Measured Power (dBm) Tune up tolerance (dBm) Max tune up conducted power(dBm) Output Peak power (mW) Ant. Gain (dBi) Ant. Gain (numeric) Power density at 20cm (mW/ cm 2 ) Power density Limits (mW/ cm 2 ) Results 802.11b 16.27 16±1 17 50.119 1.5 1.413 0.014084 1 PASS 802.11g 16.41 16±1 17 50.119 1.5 1.413 0.014084 1 PASS 802.11n HT20 16.40 16±1 17 50.119 1.5 1.413 0.014084 1 PASS 802.11ax HE20 15.92 16±1 17 50.119 1.5 1.413 0.014084 1 PASS 4 / 5 Maximum Simultaneous transmission MPE Ratio for Bluetooth & 2.4G WIFI & 2G Maximum MPE ratio (Bluetooth) Maximum MPE ratio (2.4G WIFI) Maximum MPE ratio (2G) ∑ MPE ratios Limit Results 0.005233 0.014084 0.233667 0.233667 1.000 Pass Maximum Simultaneous transmission MPE Ratio for Bluetooth & 2.4G WIFI & 3G Maximum MPE ratio (Bluetooth) Maximum MPE ratio (2.4G WIFI) Maximum MPE ratio (3G) ∑ MPE ratios Limit Results 0.005233 0.014084 0.193502 0.193502 1.000 Pass Maximum Simultaneous transmission MPE Ratio for Bluetooth & 2.4G WIFI & 4G Maximum MPE ratio (Bluetooth) Maximum MPE ratio (2.4G WIFI) Maximum MPE ratio (4G) ∑ MPE ratios Limit Results 0.005233 0.014084 0.337310 0.356627 1.000 Pass Note: 1. 2G & 3G & 4G maximum power of comes from the of the module certified report: HR/2019/1001602. 2. 2G & 3G & 4G not supported transmit simultaneously(declared by client). 3. 2G & 3G & 4G antenna gain: Original antenna gain New antenna gain Operating Band Frequency (MHz) Antenna Gain (dBi) Operating Band Frequency (MHz) Antenna Gain (dBi) GSM850 824.2 2.29 GSM850 824.2 2.10 GSM1900 1850.2 1.59 GSM1900 1850.2 1.20 WCDMA B2 1852.4 1.59 WCDMA B2 1852.4 1.20 WCDMA B4 1712.4 2.00 WCDMA B4 1712.4 1.80 WCDMA B5 826.4 2.29 WCDMA B5 826.4 2.10 LTE B2 1850.7 1.59 LTE B2 1850.7 1.20 LTE B4 1710.7 2.00 LTE B4 1710.7 1.80 LTE B5 824.70 2.29 LTE B5 824.70 2.10 LTE B7 2502.50 3.00 LTE B7 2502.50 2.80 LTE B12 699.70 3.26 LTE B12 699.70 3.00 LTE B13 779.50 4.45 LTE B13 779.50 4.20 LTE B25 1850.7 1.59 LTE B25 1850.7 1.20 5 / 5 LTE B26(814-824) 814.7 2.53 LTE B26(814-824) 814.7 2.10 LTE B26(824-849) 824.7 2.53 LTE B26(824-849) 824.7 2.10 LTE B38 2572.5 2.06 LTE B38 2572.5 2.00 LTE B41 2498.5 3.00 LTE B41 2498.5 2.80 Signature: Shawn Wen Date: 2025-11-21

规格承认书 SPECIFICATION FOR APPROVAL 日期 Date 2025/04/08 编号 File No 25040801 版本 Revision 1.0 客户 CUSTOMER: 丰疆智能 客户料号 CUSTOMER NO: R2119 品名 PARTNAME: 2.4G+5.8G-Episode Antenna L=155mm MHF 供方料号 SUPPLIERNO: YJF01.085.030.301A 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 SUPPLIERNO: YJF01.085.030.301A 送样日期Date: 送样数量Q'TY: 客户确认CUSTOMER APPROVED BY APPROVALCHIEFSUPERVISOR 供方确认SUPPLIER SIGNATURE APPROVALCHECKDESIGN ChenGuoqiangXieLiChenXingyi YJ-RD-F04-A 承认书项目表 NO . 内容 （Contents） 页数 （Number of Page） 页码 （Page Code） 1 承认书封面（Spec Cover） 11 2 承认书项目表（ Spec Item ） 12 3 工程成品图（ Drawing） 13 4 天线规格（ Antenna Specification） 14 5 S参数测试（S Parameter ） 15 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 5 S参数测试（S Parameter ） 15 6 无源测试（Passive Test ） 36 ~ 8 7 方向图（Radiation Pattern ） 79 ~ 15 8 有源测试（Active Test ） 316 ~ 18 9 天线装配图（Antenna Profile） 519 ~ 23 10 材质证明（Material Certificate ） 4024 ~ 63 11 RoHS报告（RoHSTest Report ） **** 12N/AN/AN/A 13--- 天线规格 Antenna Specification Electrical Properties Frequency 2.4-2.5GHz 5.15-5.85GHz Impedance50 Ohm Nominal V.S.W.R 2.0 Max Gain 5.2 dBi@700-960MHz 4.0 dBi@1710-2690MHz RadiationOmni-directional 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 RadiationOmni-directional PolarizationLinear Physical Properties Connector 1代IPEX Cable TypeO.D.1.13mm Cable Length155mm Cable ColorBlack Operating Temp.-40 ~ +85 ̊C Storage Temp / Humidity 25±5 ̊C / <70% Agilent E5071C S 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 S Parameter Test // WiFi Aux Antenna Z Y X Antenna Passive Test 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 Y X Z Passive Test For WiFi Aux Antenna(2.4G) Freq (MHz) Effi (%) Effi (dB) Gain (dBi) 2400 39.3 -4.1 4.8 2410 40.2 -4.0 5.1 2420 39.3 -4.1 5.0 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 2430 38.9 -4.1 5.1 2440 39.7 -4.0 4.8 2450 43.2 -3.7 5.2 2460 42.3 -3.7 4.6 2470 44.6 -3.5 4.9 2480 44.7 -3.5 4.4 2490 46.9 -3.3 4.6 2500 45.3 -3.4 4.1 Passive Test For WiFi Aux Antenna(5.8G) Freq (MHz) Effi (%) Effi (dB) Gain (dBi) 515047.4 -3.2 3.8 520048.5 -3.1 3.7 525049.2 -3.1 4.0 530048.8 -3.1 3.7 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 535048.1 -3.2 3.0 540053.7 -2.7 3.3 545049.9 -3.0 2.1 550045.1 -3.5 1.3 555051.8 -2.9 2.4 560050.1 -3.0 2.0 565044.6 -3.5 1.6 570045.6 -3.4 2.1 575048.3 -3.2 2.7 580049.8 -3.0 3.4 585047.0 -3.3 3.3 Radiation Pattern For WiFi Aux Antenna （ 2400MHz ） 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 Radiation Pattern For WiFi Aux Antenna （ 2450MHz ） 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 Radiation Pattern For WiFi Aux Antenna （ 2500MHz ） 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 Radiation Pattern For WiFi Aux Antenna （ 5150MHz ） 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 Radiation Pattern For WiFi Aux Antenna （ 5500MHz ） 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 Radiation Pattern For WiFi Aux Antenna （ 5850MHz ） 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 Radiation Pattern For WiFi Aux Antenna Phi 0° 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 Phi 90° Theta 90° Antenna Active Test Z Y X 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 Y X Z Active Test For WiFi Antenna BandChannel Data Rate TRP Data Rate TIS WIFI 2.4G 802.11b 1 1Mbps 14.4 1Mbps -92.4 7 14.5 -94.6 13 14.2 -95.8 1 14.4 -85.3 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 11Mbps11Mbps7 14.5 -86.7 13 14.3 -87.3 WIFI 2.4G 802.11g 1 6Mbps 14.3 6Mbps -88.6 7 14.3 -88.6 13 13.9 -85.7 1 54Mbps 14.3 54Mbps -74.7 7 14.4 -74.6 13 14.0 -74.8 Active Test For WiFi Antenna BandChannel Data Rate TRP Data Rate TIS WIFI 2.4G 802.11n 1 MCS0 14.4 MCS0 -86.7 7 14.4 -89.0 13 14.1 -84.6 1 14.4 -73.0 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 MCS7MCS77 14.6 -72.9 13 14.2 -72.0 WIFI 5G 802.11a 48 6Mbps 15.6 6Mbps -87.7 149 17.8 -91.3 157 18.2 -93.3 165 18.3 -91.5 48 54Mbps 15.7 54Mbps -75.8 149 16.7 -77.8 157 17.2 -78.6 165 17.2 -76.1

TRF No.: 04-E001-0B TRF Originator: GTG TRF Date: 2023-12-13 Web: www.gtggroup.com E-mail: [email protected] Tel.: 86-400 755 8988 CFR 47 FCC PART 15 SUBPART C, ISED RSS-247 ISSUE 3 (DSS) TEST REPORT For Robotic Lawn Mower MODEL NUMBER: Thor REPORT NUMBER: E04A25081337F00102 ISSUE DATE: October 30, 2025 FCC ID: 2A3NS-THOR IC: 33682-THOR Prepared for Sveaverken Svea Agri AB Högmossevägen 11, SE-641 39, Katrineholm, Sweden Prepared by Guangdong Global Testing Technology Co., Ltd. Room 101-105, 203-210, Building 1, No.2, Keji 8 Road, Songshan Lake Park, Dongguan city, Guangdong, People’s Republic of China, 523808 This report is based on a single evaluation of the submitted sample(s) of the above mentioned product, it does not imply an assessment of the production of the products. This report shall not be reproduced, except in full, without the written approval of Guangdong Global Testing Technology Co., Ltd. REPORT NO.: E04A25081337F00102 Page 2 of 108 TRF No.: 04-E001-0B Global Testing , Great Quality. Revision History Rev. Issue Date Revisions Revised By V0 October 30, 2025 Initial Issue REPORT NO.: E04A25081337F00102 Page 3 of 108 TRF No.: 04-E001-0B Global Testing , Great Quality. Summary of Test Results Test Item Clause Limit/Requirement Result Antenna Requirement FCC: ANSI C63.10-2020; ISED: ANSI C63.10- 2020+Cor.1-2023+C63.10a- 2024 FCC Part 15.203/15.247 (c) RSS-GEN Clause 6.8 Pass AC Power Line Conducted Emission FCC: ANSI C63.10-2020; ISED: ANSI C63.10- 2020+Cor.1-2023+C63.10a- 2024 FCC Part 15.207 RSS-GEN Clause 8.8 Pass Conducted Output Power FCC: ANSI C63.10-2020; ISED: ANSI C63.10- 2020+Cor.1-2023+C63.10a- 2024 FCC Part 15.247 (b)(3) RSS-247 Clause 5.4 (d) Pass 20 dB Bandwidth and 99% Occupied Bandwidth FCC: ANSI C63.10-2020; ISED: ANSI C63.10- 2020+Cor.1-2023+C63.10a- 2024 FCC Part 15.247 (a)(2) RSS-247 Clause 5.2 (a) ISED RSS-Gen Clause 6.7 Pass Carrier Hopping Channel Separation FCC: ANSI C63.10-2020; ISED: ANSI C63.10- 2020+Cor.1-2023+C63.10a- 2024 FCC Part 15.247 (e) RSS-247 Clause 5.2 (b) Pass Number of Hopping Frequency FCC: ANSI C63.10-2020; ISED: ANSI C63.10- 2020+Cor.1-2023+C63.10a- 2024 FCC Part 15.247(d) RSS-247 Clause 5.5 Pass Time of Occupancy (Dwell Time) FCC: ANSI C63.10-2020; ISED: ANSI C63.10- 2020+Cor.1-2023+C63.10a- 2024 FCC Part 15.247 (d) FCC Part 15.205/15.209 RSS-247 Clause 5.5 RSS-GEN Clause 8.9 Pass Conducted Bandedge and Spurious Emission FCC: ANSI C63.10-2020; ISED: ANSI C63.10- 2020+Cor.1-2023+C63.10a- 2024 None; for reporting purposes only. Pass Radiated Band edge and Spurious Emission FCC: ANSI C63.10-2020; ISED: ANSI C63.10- 2020+Cor.1-2023+C63.10a- 2024 FCC Part 15.203/15.247 (c) RSS-GEN Clause 6.8 Pass Duty Cycle FCC: ANSI C63.10-2020; ISED: ANSI C63.10- 2020+Cor.1-2023+C63.10a- 2024 FCC Part 15.207 RSS-GEN Clause 8.8 Pass *This test report is only published to and used by the applicant, and it is not for evidence purpose in China. *The measurement result for the sample received is <Pass> according to <CFR 47 FCC PART 15 SUBPART C, ISED RSS-247 ISSUE 3 (DSS)> when <Accuracy Method> decision rule is applied. REPORT NO.: E04A25081337F00102 Page 4 of 108 TRF No.: 04-E001-0B Global Testing , Great Quality. CONTENTS 1. ATTESTATION OF TEST RESULTS ..................................................................................... 5 2. TEST METHODOLOGY ......................................................................................................... 6 3. FACILITIES AND ACCREDITATION ..................................................................................... 6 4. CALIBRATION AND UNCERTAINTY ................................................................................... 7 4.1. MEASURING INSTRUMENT CALIBRATION ........................................................... 7 4.2. MEASUREMENT UNCERTAINTY ............................................................................ 7 5. EQUIPMENT UNDER TEST .................................................................................................. 8 5.1. DESCRIPTION OF EUT ........................................................................................... 8 5.2. CHANNEL LIST ........................................................................................................ 8 5.3. MAXIMUM EIRP ....................................................................................................... 9 5.4. TEST CHANNEL CONFIGURATION ........................................................................ 9 5.5. THE WORSE CASE POWER SETTING PARAMETER .......................................... 10 5.6. DESCRIPTION OF AVAILABLE ANTENNAS ......................................................... 10 5.7. EUT ACCESSORY ................................................................................................. 10 5.8. SUPPORT UNITS FOR SYSTEM TEST ................................................................. 11 5.9. SETUP DIAGRAM .................................................................................................. 11 6. MEASURING EQUIPMENT AND SOFTWARE USED......................................................... 12 7. ANTENNA PORT TEST RESULTS ..................................................................................... 14 7.1. Conducted Output Power ........................................................................................ 14 7.2. 20 dB Bandwidth and 99% Occupied Bandwidth..................................................... 15 7.3. Carrier Hopping Channel Separation ...................................................................... 16 7.4. Number of Hopping Frequency ............................................................................... 18 7.5. Time of Occupancy (Dwell Time) ............................................................................ 19 7.6. Conducted Bandedge and Spurious Emission ........................................................ 21 7.7. Duty Cycle .................................................…

Text truncated - open the document above for the full version.

Setup Photographs AC Power Line Conducted Emission Radiated Band edge and Spurious Emission Page 2 of 2
