2A3TL-15501Betline TOT

15301-ML001 REV02 ECN 6113 15501 BETMAKERS TOT KIOSK USER SERVICE MANUAL 15501-ML001 REV02 ECN 6113 Page 2 Version History Dec. 2021 V 0.1 Release Version ISSUE NUMBER DATE ECN COMMENTS APPROVED 01 22-02-2023 6113 DRAFT FORMAT DOCUMENT ISSUED TO FOR CUSTOMER REVIEW ONLY. N/A. 02 28-02-2023 6113 FINAL FORMAT DOCUMENT FOR FCC SUBMISSION. L.D 15501-ML001 REV02 ECN 6113 Page 3 Who Should Use This Manual This guide is intended for those responsible for the installation and use of the Kiosk. It contains information on: • Installation and set-up instructions • Operational requirements • Kiosk Hardware Component Overview Notices 4 1. Safety Information 4 Danger Notices 5 Caution Notices 6 Electronic Emission & Safety Notices 6 Electrostatic Discharge (ESD) 6 2. Product Description 7 2.1 Physical Specifications, Operating Environment 7 2.1.1 Mechanical 7 2.1.2 Environmental 7 2.1.3 Electrical 7 2.1.4 Communications 7 3. Kiosk Exploded view _______________________________8 4. Location of marking _______________________________9 5. Power Connection / Cable Access _____ 10 6. Replacing the Printer Module 11 7. Relocating the Printer _____________________________12 8. Replacing the Printer Paper Roll _____________________14 9. Replacing Teller 15.6” LCD Screen 16 10. Replacing Teller 7” LCD Screen 18 11. Replacing Betslip Reader 20 Contents 15501-ML001 REV02 ECN 6113 Page 4 Notices Note: For any safety-related incident that occurs related to this machine, the field personnel involved must immediately follow regular Safety Incident Reporting and contact the following department: Neo Products Pty Ltd. 62-66 Pacific Drive Keysborough, VIC 3173 Phone (03) 9701 1511 The System Services Representative (SSR) should check the following: 1. Ensure that the Kiosk is plugged into a properly grounded outlet. 2. Ensure that the ground wires are properly secured at each end and not pinched. Neo Products believes the information provided below is accurate, but except the extent required by law, makes no commitment, affirmation, or certification with respect to any of the information. Rather, Neo Products provides all such information “AS IS”, without any express or implied warranty of any kind. Neo Products reserves the right to make improvements and/or changes in the product and/or programme described in this publication without advance notice if Neo Products believes it is appropriate to do so. Changes will be incorporated in new editions of the publication and replaces all previous releases. Neo Products may use or distribute any of the information you supply in any way it believes appropriate without incurring any obligation to you. Any references in this information to non-Neo Products Web sites are provided for convenience only and do not in any manner serve as an endorsement of those Web sites. The materials at those Web sites are not part of the materials for this product and use of those Web sites is at your own risk. SAVE THESE INSTRUCTIONS Read the following information before operating the equipment. Definitions of Hazard Levels: The word DANGER indicates the presence of a hazard that has the potential of causing death or serious personal injury. The word CAUTION indicates the presence of a hazard that has the potential of causing moderate or minor personal injury. Chapter 1 - Safety Information – READ THIS FIRST 15501-ML001 REV02 ECN 6113 Page 5 Danger Notices DANGER: To prevent a possible shock from touching two surfaces with different protective ground (earth), use one hand, when possible, to connect or disconnect signal cables. DANGER: Overloading a branch circuit is potentially a fire hazard and a shock hazard under certain conditions. To avoid these hazards, ensure that your system electrical requirements do not exceed branch circuit protection requirements. Refer to the information that is provided with your device or the power rating label for electrical specifications. DANGER: An electrical outlet that is not correctly wired could place hazardous voltage on the metal parts of the system or the devices that attach to the system. It is the responsibility of the customer to ensure that the outlet is correctly wired and grounded to prevent an electrical shock. DANGER: When working on or around the system, observe the following precautions: Electrical voltage and current from power, telephone, and communication cables are hazardous. To avoid a shock hazard: • If Neo Products supplied a power cord, connect power to this unit only with the Neo Products provided power cord. Do not use the Neo Products provided power cord for any other product. • Do not open or service any power supply assembly. • Do not connect or disconnect any cables or perform installation, maintenance, or reconfiguration of this product during an electrical storm. • The product might be equipped with multiple power cords. To remove all hazardous voltages, disconnect all power cords. • Connect all power cords to a properly wired and grounded electrical outlet. Ensure that the outlet supplies proper voltage and phase rotation according to the system rating plate. • Connect any equipment that will be attached to this product to properly wired outlets. • When possible, use one hand only to connect or disconnect signal cables. • Never turn ON any equipment when there is evidence of fire, water, or structural damage. • Sharp edges, corners and joints may be present in and around the system. Use care when handling equipment to avoid cuts, scrapes and pinching. • Route all cords away from sharp edges, corners and points, moving parts and heated surfaces, to prevent damage to the cable insulation. Never route cables through openings that do not have smooth well-rounded surfaces or with bushings. • Protect all cords against physical damage. Never allow objects to be placed on or against the cords, or on surfaces that contact the cords. Ensure cords are positioned not to be stepped on, tripped over, or subjected to damage or stress. • Inspect…

Text truncated - open the document above for the full version.

Rev 1/26/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 03-08-2023 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2A3TL-15501 FRN: 0031690670 Neoproducts PTY LTD (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Lex Dickson Rev 1/26/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 03-08-2023 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2A3TL-15501 FRN: 0031690670 Neoproducts PTY LTD (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Lex Dickson

Rev 11/20/07 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: (2A3TL-15501). Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Schematics Block Diagrams Operational description (theory of operation) 15501 Schem1,2,6,8 15501 BlkDia 15501-OpDes The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below for 180 days: Exhibit Type File Name External photos Test set-up photos Internal photos User Manual 15501 ExtPho1-7 15501 Tsup 15501 IntPho1-4 15501 UserMan Sincerely, Lex Dickson PRODUCTION AND QUALITY ENGINEER

Label location (Rear of device – cover lifted) Label location (Rear of device – behind cover)

NeoProducts Pty Ltd ACN 007 152 374 ABN 76 007 152 374, 62-66 Pacific Drive, Keysborough, Vic, 3173 Telephone 03 9701 1511 www.neoproductsgroup.com Page 1 of 1 15501 – Betline TOT NeoProducts - RF Exposure FCC ID#: 2A3TL-15501

Betline TOT - test set-up photos: Betline TOT - test set-up photos: Betline TOT - test set-up photos:
