Designed by Kemimoto Group Web: www. kemimoto. com Complete journey of dreams 1 of 4B0117-00101BK Installation Tips SKUB0117-00101BK IMPORTANT SAFETY PRECAUTIONS · Do not operate mobile equipment while driving a motorized vehicle – safe driving and safety consideration of others should always be your highest priority. · In the event you should notice smoke, strange noises or odor from this product, or any other abnormal signs, immediately turn off the power and consult your dealer. Using this product in this condition may result in permanent damage to the system. · Set your volume control at a low setting, then slowly increase the sound until you can hear it comfortably without distortion, or ear discomfort. · Be sure to observe the following guidelines: Do not turn up the volume so high, otherwise you can’t hear what’s around you. Use caution or temporarily discontinue use in potentially hazardous situations. INSTALLATION PRECAUTIONS · Do not attempt to service this product by yourself. Installation or servicing of this product by persons without professional training and experience in electronic equipment and motorized vehicle accessories may be dangerous and could expose you to the risk of electric shock, injury or other hazards. · When wiring directly to the vehicles battery, be sure to disconnect the batteries negative terminal wire before starting any wiring procedures. · The speaker has a weather resistant design, it should not be under any circumstances submerged in, or under water. · Use only the supplied installation parts provided with the speaker. · Wipe a mild detergent and lukewarm water using a clean sponge or a soft cloth. PRODUCT INFORMATION: INSTALLATION TIPS: 21 3 4 5 (M6*35mm) I. The base of the bracket. II. The cover of the bracket, is fixed by 2 mounting screws. Mounting hole dimension Min: 1.65'' (4.2cm)Max: 2'' (5cm) II I · As shown in pictures, W / L is DC 12V power. · As shown in pictures, connect the Positive Pole and the Negative Pole respectively of two speakers (R to R), (B to B). + - BATTERY 12V + - WIRE DIAGRAM BLUETOOTH OPERATION 1 2 3 W (white) W W (white) L (blue) L (blue) R (red) connect connect connect connect R (red) B (black) B (black) 2 of 4B0117-00101BK L R B Pairing & discovering a new bluetooth connection 1) Power on the speaker, a tone will be heard, signalling that the speaker is now ready for Bluetooth pairing. The speaker is now ready for Bluetooth pairing. 2) The speaker is now in pairing mode: ANDROID users: a. Go into the Settings Menu of your device. b. Enter the Bluetooth Menu. c. TURN ON Bluetooth and press SCAN. d. “KEMIMOTO” will now be displayed under available devices. e. If prompted, enter passcode: “0000”. iOS users: a. Go into the Settings Menu of your iOS device. b. Enter the Bluetooth Menu. c. TURN ON Bluetooth. d. “KEMIMOTO” will now be displayed. e. If prompted, enter passcode: “0000”. 3) If KEMIMOTO is not seen, repeat the above steps to refresh the “Device List”. 4) When the connection is successful a tone will be heard. Note: · Using this product without running the engine can drain the battery. · To avoid battery exhaustion, be sure to occasionally run the vehicles engine while using this product. Reconnection 1) Power on the speaker and your last paired device Bluetooth. 2) Ensure you are within range of the speaker, the unit will now automatically reconnect. 3) If the device is out of range from the speaker, it will disconnect automatically. 4) If your device was previously paired with the speaker, but it wasn’t the last paired device: a. Ensure no other devices are currently paired. b. Enter the Bluetooth Menu on your device being paired. c. “KEMIMOTO” will display under available devices. d. Choose the “KEMIMOTO” to reconnect. NOTE: Some devices may require a manual Bluetooth reconnection once the devices Bluetooth is powered OFF / ON and/or back in range. CAUTION Don‘t connect the speaker to a 24v power supply, the product is only suitable for 12v power. Don‘t clean in hot sun or on very hot days. Don‘t use abrasive or highly alkaline cleaners on the main body. Don‘t scrape the main body with razor blades, or other sharp instruments. Don‘t ever use gasoline, acetone or carbon tetra chloride. Don‘t ever use a pressure washer aimed at the speakers. COMMON SOLUTIONS SPECIFICATIONS Technical Specications: BluetoothVersion: 4.1 Waterproof : IP-65 Roll Cage Support Size: Up to 1.65''-2 ''(5cm) Tweeter Type: 1” Titanium Dome Frequency Response: 100hz-20kHz Impedance: 4 Ohms Magnet: 10 Oz Sensitivity: 90 dB Construction Material: Engineered ABS Speaker Housing Dimensions (L x W x H): 5.4'' x 5.4'' x 7.0'' inches Maximum Output Power: 300 Watts 3 of 4B0117-00101BK ProblemWhat to do No power Speaker won't pair with mobile device No sound Poor sound quality • Reconnect the wires according to the instructions and make sure the color of the wire harness is correct • Connect to other 12v power supply. • On your mobile device, turn the Bluetooth feature off and then on. • Remove “KEMIMOTO” from the Bluetooth list on your mobile device. Pair your mobile device again. • On your mobile device, turn the Bluetooth feature off and then on. • Remove “KEMIMOTO” from the Bluetooth list on your mobile device. Pair your mobile device again. • Increase the volume on your mobile device and music source. • Use a different music source. • Pair a different mobile device. • If two mobile devices are connected, pause your other mobile device first. • Use a different music source. • Pair a different mobile device. • Increase the volume on your mobile device and music source. FCC Caution: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance …

Text truncated - open the document above for the full version.

GUANGZHOU ISSYZONE TECHNOLOGY CO.,LTD 2023.08.17 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for FCC ID: 2A449-DBS4063B GUANGZHOU ISSYZONE TECHNOLOGY CO.,LTD certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Applicant signature: Applicant printed name: Typing Yang / Vic GM GUANGZHOU ISSYZONE TECHNOLOGY CO.,LTD 2023.08.17 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for FCC ID: 2A449-DBS4063B GUANGZHOU ISSYZONE TECHNOLOGY CO.,LTD certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Applicant signature: Applicant printed name: Typing Yang / Vic GM

GUANGZHOU ISSYZONE TECHNOLOGY CO.,LTD 2023.08.17 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: CONFIDENTIALITY REQUEST FOR EUT NAME: Bluetooth speaker Trademark: KEMIMOTO MODEL : DBS4063B FCC ID: 2A449-DBS4063B To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Client’s signature: Client’s name / title: Typing Yang / Vic GM Contact information / address: 3Floor, Tairong Business center C10, No.63 Xizeng Road, Liwan District, Guangzhou, China

GUANGZHOU ISSYZONE TECHNOLOGY CO.,LTD 2023.08.17 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen BCTC Testing Co., Ltd to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s signature: Client’s name / title: Typing Yang / Vic GM Contact information / address: 3Floor, Tairong Business center C10, No.63 Xizeng Road, Liwan District, Guangzhou, China

External Photos

50*30mm Label Location FCC ID: 2A449-DBS4063B This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesire d operation.

Internal Photos Antenna

FCC ID: 2A449-DBS4063B Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V06 The 1-g SAR and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[√f(GHZ)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f(GHZ) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. BT Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion GFSK 2.480 4.65 2.92 4±1 5.00 3.16 <5 0.99599 3.00 YES π /4DQPSK 2.480 3.06 2.02 3±1 4.00 2.51 <5 0.79114 3.00 YES 8DPSK 2.480 3.45 2.21 3±1 4.00 2.51 <5 0.79114 3.00 YES Conclusion: For the max result : 0.99599＜3, the SAR testing is not required.

No.：BCTC/RF-EMC-007 Page: 1 of 77 Edition：B.0 TEST REPORT Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2307569322E Applicant: GUANGZHOU ISSYZONE TECHNOLOGY CO.,LTD Product Name: Bluetooth speaker Model/Type reference: DBS4063B Tested Date: 2023-07-19 to 2023-07-28 Issued Date: 2023-07-31 Report No.: BCTC2307569322E No.：BCTC/RF-EMC-007 Page: 2 of 77 Edition：B.0 FCC ID: 2A449-DBS4063B The test report is effective only with both signature and specialized stamp.This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen BCTC Testing Co., Ltd, this report can’t be reproduced except in full.The tested sample(s) and the sample information are provided by the client. Product Name: Bluetooth speaker Trademark: KEMIMOTO Model/Type Reference: DBS4063B Prepared For: GUANGZHOU ISSYZONE TECHNOLOGY CO.,LTD Address: 3rd Foor, Tairong Business Center C10, No.63 Xizeng Road, Liwan District, Guangzhou, China Manufacturer: GUANGZHOU ISSYZONE TECHNOLOGY CO.,LTD Address: 3rd Foor, Tairong Business Center C10, No.63 Xizeng Road, Liwan District, Guangzhou, China Prepared By: Shenzhen BCTC Testing Co., Ltd. Address: 1-2/F., Building B, Pengzhou Industrial Park, No.158, Fuyuan 1st Road, Zhancheng, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: 2023-07-18 Sample tested Date: 2023-07-19 to 2023-07-28 Issue Date: 2023-07-31 Report No.: BCTC2307569322E Test Standards: FCC Part15.247 ANSI C63.10-2013 Test Results: PASS Remark: This is Bluetooth Classic radio test report. Tested by: Approved by: Eric Yang/Project Handler Zero Zhou/Reviewer Report No.: BCTC2307569322E No.：BCTC/RF-EMC-007 Page: 3 of 77 Edition：B.0 Table Of Content Test Report Declaration Page 1. Version .................................................................................................................. 5 2. Test Summary ....................................................................................................... 6 3. Measurement Uncertainty ..................................................................................... 7 4. Product Information And Test Setup ..................................................................... 8 4.1 Product Information ............................................................................................... 8 4.2 Test Setup Configuration ...................................................................................... 9 4.3 Support Equipment ............................................................................................... 9 4.4 Channel List ........................................................................................................ 10 4.5 Test Mode ........................................................................................................... 10 4.6 Table Of Parameters Of Text Software Setting ................................................... 10 5. Test Facility And Test Instrument Used ............................................................... 11 5.1 Test Facility ......................................................................................................... 11 5.2 Test Instrument Used .......................................................................................... 11 6. Conducted Emissions .......................................................................................... 13 6.1 Block Diagram Of Test Setup .............................................................................. 13 6.2 Limit .................................................................................................................... 13 6.3 Test procedure .................................................................................................... 13 6.4 EUT operating Conditions ................................................................................... 13 6.5 Test Result .......................................................................................................... 13 7. Radiated emissions ............................................................................................. 14 7.1 Block Diagram Of Test Setup .............................................................................. 14 7.2 Limit .................................................................................................................... 15 7.3 Test procedure .................................................................................................... 16 7.4 EUT operating Conditions ................................................................................... 17 7.5 Test Result .......................................................................................................... 18 8. Radiated Band Emission Measurement And Restricted Bands Of Operation ..... 22 8.1 Block Diagram Of Test Setup .............................................................................. 22 8.2 Limit .................................................................................................................... 22 8.3 Test procedure .................................................................................................... 23 8.4 EUT operating Conditions ................................................................................... 23 8.5 Test Result .......................................................................................................... 24 9. Spurious RF Conducted Emissions ..................................................................... 25 9.1 Block Diagram Of Test Setup .............................................................................. 25 9.2 Limit .................................................................................................................... 25 9.3 Test procedure .................................................................................................... 25 9.4 Test Result .............................................................................…

Text truncated - open the document above for the full version.

Report No.: BL-SZ2380292-901 Tel: +86-755-66850100 E-mail: [email protected] Page No. 1 / 13 Web: www.titcgroup.com Template No.: TRP-Passive-EN (2022-09-07) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China TEST REPORT Applicant: GUANGZHOU ISSYZONE TECHNOLOGY CO., LTD Address: 3rd Foor, Tairong Business Center C10, No.63 Xizeng Road, Liwan District, Guangzhou, China Equipment Type: Bluetooth speaker Model Name: DBS4063B Brand Name: N/A Test Standard: IEEE Std 149-2021 Sample Arrival Date: Aug. 07, 2023 Test Date: Aug. 08, 2023 Date of Issue: Aug. 15, 2023 ISSUED BY: Shenzhen BALUN Technology Co., Ltd. Tested by: Mai Jintian Checked by: Zou Liu Approved by: Tolan Tu (Testing Director) _______________ _______________ _______________ Report No.: BL-SZ2380292-901 Tel: +86-755-66850100 E-mail: [email protected] Page No. 2 / 13 Web: www.titcgroup.com Template No.: TRP-Passive-EN (2022-09-07) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China Revision History Version Issue Date Revisions Rev. 01 Aug. 15, 2023 Initial Issue TABLE OF CONTENTS 1 GENERAL INFORMATION ........................................................................................................ 3 1.1 Test Laboratory ................................................................................................................... 3 1.2 Test Location ....................................................................................................................... 3 2 PRODUCT INFORMATION ....................................................................................................... 4 2.1 Applicant Information ........................................................................................................... 4 2.2 Manufacturer Information .................................................................................................... 4 2.3 General Description for Equipment under Test (EUT) ......................................................... 4 2.4 Ancillary Equipment ............................................................................................................. 4 2.5 Technical Information .......................................................................................................... 4 3 SUMMARY OF TEST RESULTS ............................................................................................... 5 3.1 Test Standards .................................................................................................................... 5 3.2 Test Verdict ......................................................................................................................... 5 3.3 Test Uncertainty .................................................................................................................. 5 4 GENERAL TEST CONFIGURATIONS ...................................................................................... 6 4.1 Test Condition ..................................................................................................................... 6 4.2 Test Equipment List ............................................................................................................. 6 4.3 Test Setup ........................................................................................................................... 7 ANNEX A TEST RESULTS ........................................................................................................... 8 A.1 Gain and Efficiency ............................................................................................................. 8 A.2 VSWR ................................................................................................................................. 8 ANNEX B RADIATION PATTERN ................................................................................................ 9 ANNEX C TEST SETUP PHOTOS ............................................................................................. 12 ANNEX D EUT PHOTO .............................................................................................................. 12 Report No.: BL-SZ2380292-901 Tel: +86-755-66850100 E-mail: [email protected] Page No. 3 / 13 Web: www.titcgroup.com Template No.: TRP-Passive-EN (2022-09-07) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China 1 GENERAL INFORMATION 1.1 Test Laboratory Name Shenzhen BALUN Technology Co., Ltd. Address Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China Phone Number +86 755 6685 0100 1.2 Test Location Name Shenzhen BALUN Technology Co., Ltd. Location Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China 1/F, Building B, Ganghongji High-tech Intelligent Industrial Park, No. 1008, Songbai Road, Yangguang Community, Xili Sub-district, Nanshan District, Shenzhen, Guangdong Province, P. R. China Report No.: BL-SZ2380292-901 Tel: +86-755-66850100 E-mail: [email protected] Page No. 4 / 13 Web: www.titcgroup.com Template No.: TRP-Passive-EN (2022-09-07) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China 2 PRODUCT INFORMATION 2.1 Applicant Information Applicant GUANGZHOU ISSYZONE TECHNOLOGY CO., LTD Address 3rd Foor, Tairong Business Center C10, No.63 Xizeng Road, Liwan District, Guangzhou, China 2.2 Manufacturer Information Manufacturer GUANGZHOU ISSYZONE TECHNOLOGY CO., LTD Address 3rd Foor, Tairong Business Center C10, No.63 Xizeng Road, Liwan District, Guangzhou, China 2.3 General Description for Equipment under Test (EUT) EUT Name Bluetooth speaker Model Name Under Test DBS4063B Antenna Type PCB Antenna Dimensions 12*4mm 2.4 An…
