2A4AE-C21FG002RGBW Smart LED Flood Light

RGBW Smart LED Flood Light User Guide Warranty & Contact 1-year warranty Email: [email protected] Web: www.sansiled.com Mfg. date is printed on the certificate of approval 1 32 54 76 1.3"(33mm) 4"(102mm) 5"(129mm) Dimensions Thanks for purchasing our product, to ensure full understanding of the product and know how to use it properly, please read the user guide thoroughly and keep it for potential use. M6 anchor bolts Mounting surface Hex nut Installation 1. Take the product out of the package. Read the user manual carefully. 2. Prepare the anchor bolts on the mounting surface according to the mounting slots on the bracket. 3. Install the product onto the mounting surface and tighten the hex nuts afterwards. Angle adjustment 1. Loosen the fixing bolts on both sides by turning counter-clockwise. Only loosen the bolts until the mounting bracket could be adjusted. 2. Adjust the light panel to the desired angle, then re-tighten the fixing bolts by turning them clockwise. Fix bolts on both sides Turn clockwise to tighten Product Parameters Warnings 3. Do not look into the operating light. 4. Do not assemple the product under live conditions. 5. The assembly and maintenance can only be performed by a qualified specialist. 6. If the power cord of the outer material is damaged, it must be recorded and repaired by the manufacturer or its authorized serivce center; or replaced by similar qualified specialist. Get the App You can install the Stellar BLE App via below methods: Android： 1. Open Google Play. 2. Search for“Stellar BLE.” 3. Download and install the App. iOS: 1. Open App Store. 2. Search for “Stellar BLE”. 3. Tap “Get”to install the App. 1.Prepare the smart flood light and connect the power cable. 2.Install the Stellar BLE, open the App. 3.Make sure your phone's bluetooth is on and keep your phone close to the light. 4.Tap “+”at the top right of the “Light”interface and select“Add Devices”to start searching for the device. 5.When the device is displayed in the list, select the device you want to add and tap“NEXT”to continue. 6.Wait for the device to be connected and added successfully, tap “OK” to finish . Add device 2 methods to reset the device 1.You can select “Disconnect”on the Light Information interface, then select Remove, reset successfully after the light blinks. 2.You can also complete the reset by quickly switching On and Off for 6 times. Factory reset Model : C21FG002-B0100A40 Enclosure Color : Black Material : PC + Aluminum Input : AC 120V,60Hz Rated Power : 100W Color Temperature : RGB+5000K Controlled by : Mobile App Connection : Bluetooth Beam Angle : 110° Lifespan : 25,000 hrs Dimensions : 4*5*1.3"(102*129*33mm) Net Weight : 460g Working Temperature : 14-104°F Working Humidity : 10%-90% RH IP Rating: IP66 Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 ofthe FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. FCCID：2A4AE-C21FG002 1. Ensure the voltage of the power supply complies with the operating voltage of the product before use. 2. The light source of this product is not replaceable; when the light source reaches its lifecycle, the whole luminaire shall be replaced. Do not attempt to disassemble the product. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

UNITED STATES DESIGNATED AGENT LETTER Date: 06/05/2023 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Applicant U.S. designated agent Company Name: Pujiang Yuansheng Electronic Commerce Co., Ltd. Company Name: SANSI LED Lighting INC Grantee Code: 2A4AE FRN: 0033510850 Contact Name: Miaomiao cao Contact Name: Lili Zhao Address: No.388, Yidianhong Avenue, Xianhua Street, Pujiang County, Address: 30075 AHERN AVE Union City, City/Province/Zip: Zhejiang Province, P.R. China City/Province/Zip: CA 94587 United States Telephone: 13538218145 Telephone: (510)972-0275 Fax: N/A Fax: N/A Email: [email protected] Email: [email protected] Applicable Equipment: FCC ID: 2A4AE-C21FG002 ATTN: Director of Certification: We, Pujiang Yuansheng Electronic Commerce Co., Ltd. and SANSI LED Lighting INC understand and acknowledge the applicants consent and the designated agent’s obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and e- mail of the designated agent listed above. We, Pujiang Yuansheng Electronic Commerce Co., Ltd. and SANSI LED Lighting INC acknowledge the applicant’s acceptance of its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Applicant U.S. designated agent Name (Printed): Miaomiao Cao Name (Printed): Lili Zhao Title: Engineer Title: Sales Signature: Signature:

Applicant Declaration QSF27-14-04 Rev 1.0 Rev. Feb 6, 2023 Page 1 of 1 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name Pujiang Yuansheng Electronic Commerce Co., Ltd. Address No.388, Yidianhong Avenue,Xianhua Street,Pujiang County Zhejiang province, P.R China Grantee Code 2A4AE FCC ID 2A4AE-C21FG002 Authorized Contact Name miaomiao cao Contact Email [email protected] Contact Phone 13538218145 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Link to the Covered List: Covered List Pujiang Yuansheng Electronic Commerce Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Pujiang Yuansheng Electronic Commerce Co., Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered list, established pursuant to §1.50002, as an entity producing “covered” equipment. Applicant Signature: Date: 2023-06-05 Print Name: miaomiao cao Title: Engineer *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

Pujiang Yuansheng Electronic Commerce Co., Ltd. To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: Pujiang Yuansheng Electronic Commerce Co., Ltd. No.388, Yidianhong Avenue, Xianhua Street, Pujiang County, Zhejiang Province, P.R. China Regarding: Confidentiality Request regarding application for FCC ID: 2A4AE-C21FG002 LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, miaomiao cao Engineer Pujiang Yuansheng Electronic Commerce Co., Ltd.

Date: 2023-06-05 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: 2A4AE-C21FG002 To whom it may concern: We, the undersigned, hereby authorize Parlam Zhan to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with Pujiang Yuansheng Electronic Commerce Co., Ltd.. This authorization is valid until further written notice from the applicant. Name (Printed): miaomiao cao Title: Engineer Signature: On behalf of Company: Pujiang Yuansheng Electronic Commerce Co., Ltd. Telephone: 13538218145

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 4 External Photos for SHCR2305001024AT SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 4 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 3 of 4 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 4 of 4

MODEL: C21FG002-B0100A40 AC120V, 60Hz, 100W, 2A FCC ID : 2A4AE-C21FG002 Date: MM.YYY SUITABLE FOR WET LOCATIONS. CONVIENT AUX EMPLACEMENTS MOUILLÉS. Pujiang Yuansheng Electronic Commerce Co., Ltd. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: ( 1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 5 Internal Photos for SHCR2305001024AT SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 5 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 3 of 5 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 4 of 5 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 5 of 5

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230500102402 Page: 1 of 9 Parlam Zhan Laboratory Manager 1 Cover Page RF Exposure Evaluation Report Application No.: FCC ID: SHCR2305001024AT 2A4AE-C21FG002 Applicant: Pujiang Yuansheng Electronic Commerce Co., Ltd. Address of Applicant: No.388, Yidianhong Avenue, Xianhua Street, Pujiang County, Zhejiang Province, P.R. China Manufacturer: Pujiang Yuansheng Electronic Commerce Co., Ltd. Address of Manufacturer: No.388, Yidianhong Avenue, Xianhua Street, Pujiang County, Zhejiang Province, P.R. China Factory: Pujiang Yuansheng Electronic Commerce Co., Ltd. Address of Factory: No.388, Yidianhong Avenue, Xianhua Street, Pujiang County, Zhejiang Province, P.R. China Equipment Under Test (EUT): EUT Name: RGBW Smart LED Flood Light Model No.: C21FG002-B0100A40 Trade Mark: SANSI Standard(s) : FCC Rules 47 CFR §2.1091 KDB 447498 D04 interim General RF Exposure Guidance v01 Date of Receipt: 2023-05-19 Date of Test: 2023-05-20 to 2023-06-02 Date of Issue: 2023-06-15 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230500102402 Page: 2 of 9 Revision Record Version Description Date Remark 00 Original 2023-06-15 / Authorized for issue by: Bill Wu/Project Engineer Parlam Zhan/Reviewer SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230500102402 Page: 3 of 9 2 Contents Page 1 COVER PAGE .................................................................................................................................... 1 2 CONTENTS ........................................................................................................................................ 3 3 GENERAL INFORMATION ................................................................................................................ 4 3.1 GENERAL DESCRIPTION OF E.U.T. ................................................................................................ 4 3.2 DETAILS OF E.U.T. ....................................................................................................................... 4 3.3 SEPARATION DISTANCE ................................................................................................................ 4 3.4 TEST LOCATION ............................................................................................................................ 5 3.5 TEST FACILITY .............................................................................................................................. 5 4 FCC RADIOFREQUENCY RADIATION EXPOSURE LIMITS .......................................................... 6 4.1 BLANKET 1 MW BLANKET EXEMPTION ........................................................................................... 6 4.2 MPE-BASED EXEMPTION .............................................................................................................. 6 4.3 SAR-BASED EXEMPTION ............................................................................................................... 7 5 MEASUREMENT AND CALCULATION ............................................................................................ 9 5.1 MAXIMUM TRANSMIT POWER ......................................................................................................... 9 5.2 RF EXPOSURE CALCULATION ........................................................................................................ 9 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230500102402 Page: 4 of 9 3 General Information 3.1 General Description of E.U.T. Power supply: AC 120V/60Hz 3.2 Details of E.U.T. Operation Frequency: 2402MHz to 2480MHz Modulation Type: GFSK Bluetooth Version: 5.0 LE Date Rate: 2Mb/s,1Mb/s, 500kb/s, 125kb/s Number of Channels: 40 Channel Spacing: 2MHz Antenna Type: PCB Antenna Antenna Gain: 2dBi (Provided by manufacturer) 3.3 Separation Distance Separation distance between the antenna to person (R): ＞20cm Remark: This minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230500102402 Page: 5 of 9 3.4 Test Location All tests were performed at: SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. E&E Lab 588 West Jindu Road, Xinqiao, Songjiang, 201612 Shanghai, China. Tel: +86 21 6191 5666 Fax: +86 21 6191 5678 No tests were sub-contracted. Note: 1. SGS is not responsible for wrong test results due to incorrect information (e.g. max. clock frequency, highest internal frequency, antenna gain, cable loss, etc ) is provided by the applicant. (if applicable). 2. SGS is not responsible for the authenticity, integrity and the validity of the conclusion based on results of the data provided by applicant. (if applicable). 3.5 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • A2LA (Certificate No. 6332.01) SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. is accredited by the American Association for Laboratory Accreditation(A2LA). • FCC (Designation Number: CN1301) SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. has been recognized as an accredited testing laboratory. • ISED (CAB Identifier: CN0020) SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. EMC Laboratory has been recognized by Innovation, Science and Economic Development Canada (ISED) as an accredited testing laboratory. Company Number: 8617A • VCCI (Member No.: 3061) The 3m Semi-anechoic chamber and Shielded Room of SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. has been registered in accordance with the Regulations f…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230500102401 Page: 1 of 78 Parlam Zhan Laboratory Manager TEST REPORT Application No.: FCC ID: SHCR2305001024AT 2A4AE-C21FG002 Applicant: Pujiang Yuansheng Electronic Commerce Co., Ltd. Address of Applicant: No.388, Yidianhong Avenue, Xianhua Street, Pujiang County, Zhejiang Province, P.R. China Manufacturer: Pujiang Yuansheng Electronic Commerce Co., Ltd. Address of Manufacturer: No.388, Yidianhong Avenue, Xianhua Street, Pujiang County, Zhejiang Province, P.R. China Factory: Pujiang Yuansheng Electronic Commerce Co., Ltd. Address of Factory: No.388, Yidianhong Avenue, Xianhua Street, Pujiang County, Zhejiang Province, P.R. China Equipment Under Test (EUT): EUT Name: RGBW Smart LED Flood Light Model No.: C21FG002-B0100A40 Trade Mark: SANSI Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2023-05-19 Date of Test: 2023-05-20 to 2023-06-02 Date of Issue: 2023-06-15 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230500102401 Page: 2 of 78 Revision Record Version Description Date Remark 00 Original 2023-06-15 / Authorized for issue by: Bill Wu/Project Engineer Parlam Zhan / Reviewer SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230500102401 Page: 3 of 78 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2013) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2013) Section 6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Conducted Peak Output Power ANSI C63.10 (2013) Section 11.9.1 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2013) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectrum Density ANSI C63.10 (2013) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2013) Section 11.13.3.2 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2013) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Report No.: SHCR230500102401 Page: 4 of 78 3 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 TEST SUMMARY ....................................................................................................................................... 3 3 CONTENTS ................................................................................................................................................ 4 4 GENERAL INFORMATION ........................................................................................................................ 6 4.1 DETAILS OF E.U.T. ............................................................................................................................... 6 4.2 DESCRIPTION OF SUPPORT UNITS ......................................................................................................... 6 4.3 POWER LEVEL SETTING USING IN TEST ................................................................................................... 6 4.4 MEASUREMENT UNCERTAINTY .............................................................................................................. 7 4.5 TEST LOCATION .................................................................................................................................... 7 4.6 TEST FACILITY ...................................................................................................................................... 8 4.7 DEVIATION FROM STANDARDS ............................................................................................................... 8 4.8 ABNORMALITIES FROM STANDARD CONDITIONS ..................................................................................... 8 5 EQUIPMENT LIST ...................................................................................................................................... 9 6 RADIO SPECTRUM TECHNICAL REQUIREMENT ............................................................................... 11 6.1 ANTENNA REQUIREMENT .................................................................................................................... 11 6.1.1 Test Requirement: ....................................................................................................................... 11 6.1.2 Conclusion ................................................................................................................................... 11 7 RADIO SPECTRUM MATTER TEST RESULTS ..................................................................................... 12 7.1 CONDUCTED EMISSIONS AT AC POWER LINE (150KHZ-30MHZ) ........................................................... 12 7.1.1 E.U.T. Operation .......................................................................................................................... 12 7.1.2 Test Mode Description ................................................................................................................. 12 7.1.3 Test Setup Diagram ...................................................................................................…

Text truncated - open the document above for the full version.

Antenna Specification Specification Description Antenna Manufacturer: Pujiang Yuansheng Electronic Commerce Co., Ltd. Manufacturer Address: No.388 Yidianhong Avenue,Xianhua Street,Pujiang County, Zhejiang Province Antenna Type: PCB Antenna Antenna Gain: 2dBi Antenna Model No.: PCB-MA AntennaRadiationPattern 2.402 G HzGain:2.08dBiEfficiency:69.24% 2.440GHzGain:2.08dBiEfficiency:70.36% 2.480GHzGain:2.04dBiEfficiency:71.15% 2402MHz 2440MHz 2402MHz 2402MHz 2480MHz 2480MHz 2480MHz 2440MHz 2440MHz AntennaReflection Figure 1. Measured Reflection at the Feed Point of the Antenna Figure 1 show that the PCB antenna ensures less than 10 % reflection of the available power for a bandwidth of more than 300 MHz. A large bandwidth makes the antenna less sensitive to detuning due to plastic encapsulation or other objects in the vicinity of the antenna.

SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 1 of 4 Appendix Photographs of Test Setup for SHCR2305001024AT Test Model No.: C21FG002-B0100A40 SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 2 of 4 Test Setup Photo Conducted Emissions at AC Power Line (150kHz-30MHz) Radiated Spurious Emissions Below 1GHz SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 3 of 4 Radiated Spurious Emissions Above 1GHz The EUT Details of Zoom SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd. Page: 4 of 4 RF Conducted
