USER MANUAL Wifi Hub Model: WG03 Thank You! Need Help? : [email protected] 1. Product Appearance 1 Packing List 1Water Timer*1 21/2"inlet adapter*1 3Threaded connector*1 4Thread Seal Tape*1 5Instruction*1 Filter Hose Faucet Connection LED Light Control Button LED Light ON/OFF Button Outlet fitting 3/4” 3/4" inlet adapter 2.Product Specifications 3.Important Tips 1. Please do not use Carbon-zinc or rechargable batteries. 2. Do not use your timer when the air temperature is below 3°C(37°F), the timers should be removed from the hose faucet and stored indoors to avoid potential frozen damage. 3. When replacing the power unit, please make sure that the water timer is dry. 4. Filter can trap dirt particles, please clean filter regularly and replace if worn to prevent blockage. 5. The valve will shut down automatically when the voltage is lower than 4.3V. 6. The range of connection and control is within 60m of the open area. 7. Do not put the water valve in underground water valve box or in the place where the signal may be blocked. 8. Make sure the device is connected to 2.4GHz Wifi frequency. Water Timer: WT-07W 1. Working Water Pressure: 0.5bar-8bar (7.25 psi-116.03 psi 2. Working Temperature: 3°C-50°C (37°F-122°F) 3. Waterproof Level: IP54 4. Power Supply: 4 x AA batteries WiFi hub: WG03 1Wi-Fi Band: 2.4 GHz only. 2WiFi hub: up to 196 feet(60m). 3Input voltage110V-220V, frequen- cy: 433.92MHZ 2 4. Mode Of Operation Download"HOMGAR" app and register. 1 Pairing hub 2-1. Connect hub to powersource, press and hold for 5-10 sec until blue light flashes to enter pairing mode. 2-2. Hub matching method 1: Smart pairing Matching order: "+" (Home) "socket hub" set WIFI information with correct WIFI password make sure the hub is powered on, press and hold the hub button until the light flashes quickly set the device name. Note: If the network pairing fails within 120 seconds, check the settings and retry, or switch the pairing method into the AP pairing. 2 3 IOSAndroid home Adding a valve 3-1. Put batteries in the valve and connect it to water pipe, press and hold the button on the valve for 5-10 sec until red light flashes to enter pairing mode. Note: make sure the water value is closed 3-2.Pairing steps“+”to enter main page select “1-zone water timer””Next"Pair your device complete. 3 2-3. Hub matching method 2: AP networking Matching order: "+" (Home) "socket hub" Set WIFI information with correct WIFI password When the device is in smart pairing mode, press the button to enter AP pairing Switch the pairing mode Connect the phone to HomGar_xxx Hotspot Set the device name. 4 Operating Interface 4-1. Watering schedule (1)Misting mode Set start time(0000-2359)Total misting length(1min-12h)Misting duration(5s-60min)Misting inverval (5s-60min)Watering program frequen- cy(Everyday, Odd days, Even days, Custom) 4 5 Setting When there is no watering schedule, the screen displays: No current watering schedule When there is a watering schedule, the screen displays: remaining watering hours/next run �me Watering schdule Rain delay Start watering immediatel y Mist 6 (2) Irrigation mode Set start time(0000-2359)Total irrigation length(1min-12h)Irrigation frequency(Everyday, Odd days, Even days, Custom) Total mis�ng length One day Start �me ... ... Total irriga�on length One day Start �me Irrigation 7 (3) Schedule Calender Able to check watering schedule for current month, the little dot under the date represents watering times for current date. 4-2. Rain delay Set up Rain delay duration (24H, 48H, 72H), remaining watering time will be displayed, it will stop automatically when time's up, or shut down manually before time's up. 4-3. Manual Watering Set up manual watering duration (1 min- 12h), remaining watering time will be displayed, it will stop automatically when time's up, or shut down manually before time's up. Note: Up to 6 watering schedules can be set at the same time. when preset program is in conflict with other zones, turning on water valve will lower water flow. Note: After turning on "rain delay" or "Manuel watering", the Auto watering program will stop, after stopping manual watering, the program will resume but the remain watering duration for the relap period of the program will not be executed. HMin 8 4-4. Setting (1) Zone Setting Click Zone1 to change Zone name and default watering time. (2)Custom interface Change into your preferable background picture and font. Amazon Alexa Open the Alexa app on your phone, log in successfully and select "Skills&Games" on the “MORE” page. -Search for "Homgar Intelligence" and select it. -Click "Enable to use" to enable the skill. -Enter your HOMGAR APP account & password, then click "Sign In" to bind your HOMGAR APP account and activate your device. Voice commands. Alexaopen "zone name " Alexaclose "zone name " Google Assistant Open the Google Home app on your phone, sign in, click the "+" symbol in the upper left corner, then click the "Set up device" option, and select "Use Google" . Enter your account password via "HomgarSmart" to bind your app account and allow it to access your Google account Voice commands. okGoogleopen "zone name " okGoogleclose "zone name " 5. FAQ 9 Q1: Why doesn't the water timer opened/closed within the preset time? The program is incorrect The water pressure is too low. There are particles of dirt or debris inside the valve. There are overlapped plan in the multiple set start times. Q2: Why does the network connection fail? Please check if the icon is selected correctly in the app. If the device is already connected to another cell phone, please disconnect first. Turn off the WLAN connection of your phone and turn it on again. Make sure there is sufficient battery power and place the water valve as close as possible to the gateway. There are too many devices connected to the router and the WLAN signal is unstable. Pairing is only to be performed on 2.4G WLAN networks. It is not possible to connect the gateway and water valv…
