2A4M6-007NSurveillance Camera

2 How to mount Fixing the base to the ceiling Connect the camera power cord to 110V-240V AC Align the triangular position of the battery cover with the unlocked position of the bottom cover Turn the camera clockwise to the lock position Three-wire power connection method: Two-wire power connection method: Identify the live wire and neutral wire, The two power wires of the camera can be arbitrarily connected to the neutral wire and the live wire. The two power wires of the camera can be arbitrarily connected to the neutral wire and the live wire. The ground wire does not need to be connected. Note: Supports voltage of 110-240V AC User Manual 1 Model:007N Surveillance Camera * Please select a high-speed memory card; * The product cannot save recorded video without a memory card. * In loop recording mode, the camera automatically save a video per 10 minutes In motion detection mode, the camera records a 2 minutes video after motion detected. How do I turn on the camera ? If you have inserted sd card into camera, the recorded video will automatically be saved in sd card. (Maximum support 256G; the micro sd card is not included with this product) Recorded video is automatically saved to the micro SD card. Press and hold the on/off button for 3 seconds, when seeing the red & blue lights are always on, camera is on and working. After 1 minute, the red and blue indicators will go out and the product will automatically enter recording mode. 5 V S D Note: When using the camera for the first time, remove the battery insulator and the camera turns on automatically How to save the recorded video? 4 3 How can I tell if the camera is on Press the top button once Red light on until off Blue light on until off Camera is switched on and in loop recording mode Camera is switched on and in motion detection mode How do I download the APP ? Method 1: Scan the QR code below to download Download app APP access opening Please select ‘ OK ’ Note: Failure to give APP permission will result in the inability to configure the network. Please authorise APP permissions. Please select ‘Allow While using app’ Please select ‘ Allow ’ Please select ‘ OK ’ Search for and download the "CAMDUCK" app through the app store on your phone. Note: This camera doesn’t support login web page or computer Method 2： 6 your phone's settings first. 2. Open the APP, click " + " to choose ‘Remote Monitor 1. Please connect your (home/office...) WIFI in Setting’. Follow the prompts to complete the network setup. ok Remote Monitor Setting Set InternetConnect the cameraConnect the camera Add successfullyAdd successfully WIFI Name ********** WIFI Password ***** Type your wifi password CAMERA CONTACT USSHOP GIVEAWAY Please select your product Model:Camduck T Model:Camduck T Model:Camduck S Model:Camduck S Model:Camduck 5U Model:Camduck AT Model:Camduck OV Model:Camduck SQ Model:Camduck X Model:Camduck 007 Choose your camera Remote Monitor Setting ok Set InternetConnect the cameraConnect the cameraAdd successfullyAdd successfully Tips Please control the distance between mobile phone, camera and router within 2m when configuring the network OK 2 m Router Cam Phone 2 m 2m CAMDUCK CAMERA CONTACT USSHOP GIVEAWAY CAMDUCK CAMERA CONTACT USSHOP GIVEAWAY Remote Monitor Setting Remote viewing when you are not near the camera Close Range Monitor Setting Only view video when close to camera Maximum Distance in open environment：30m APP Version:1.1.7 High-end Hidden Camera Experts start 5 1. Turn on the Bluetooth on your mobile phone. 2. Power on the camera. 3. Open the app, click "Start," and after about 3 seconds, a dialog for adding devices will appear. Follow the prompts to complete the network setup. Camera Networking Method 1: Bluetooth Configuration CAMDUCK CAMERA CONTACT USSHOP GIVEAWAY APP Version:1.1.7 High-end Hidden Camera Experts Start CAMDUCK News Local file SD File Setting CAMDUCK CAMERA CONTACT USSHOP Aibum ok Tips Please control the distance between mobile phone, camera and router within 2m when configuring the network OK 2 m Router Cam Phone 2 m 2m Bluetooth configuration network Set InternetConnect the cameraConnect the camera Add successfullyAdd successfully NOTE:The Camera does not currently support 5G WIFI Found:2 cameras CAMDUCK Set InternetConnect the camera Adding... Remote Monitor Setting 25% Connecting to WIFI, Please wait... Do not leave this page ok Bluetooth configuration network Set InternetConnect the cameraConnect the camera Add successfullyAdd successfully WIFI Name WIFI Password Some cameras do not support 5G WIFI please refer to the user manual for the details homewifi-2.4G ******** Type your wifi password Complete Camera Networking Method 2: Remote Monitor setting 8 Open the APP, Click the "+" to select the manual networking mode. And then Follow tips to add the camera to the APP list. Camera WIFI name: CAMDUCK-****** "***" is the identification code of your camera. Please check if the camera was plugged in and then there are lights to flash after plugged If blue light flash until off, please tick If blue light on until offflash If blue light on until offstay No indicator light on Set InternetConnect the cameraAdd successfullyAdd successfully Close Range Monitor Setting Tips Please control the distance between mobile phone, camera and router within 2m when configuring the network OK 2 m Router Cam Phone 2 m 2m Manual camera search How to connect mobile phone to the camera without internet? Please check if the camera was plugged in and then there are lights to flash after plugged If blue light flash until off, please tick If blue light on until offflash If blue light on until offstay No indicator light on Remote Monitor Setting Set InternetConnect the cameraAdd successfullyAdd successfully Make sure to keep powering the camera until the light goes off, then move on 7 Please connect the camera signal on your phone's wifi list. The camera signal name is： CAM***-***** Please tick if you have read the above text To connect the c…

Text truncated - open the document above for the full version.

1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: UGK-LVM UNITED INC FRN: 0033476375 Contact Name: Jimmychen Address: 6547NAcademyBlvd#2266,ColoradoSprings,CO80918 Telephone No: 001-323-51 04660 Email: [email protected] Applicant: Company name: Shenzhen Mulan Shijia TechnologyCo., Ltd. Grantee code: 2A4M6 FCC ID: 2A4M6-007N FRN: 0031988504 Contact Name: Carry Pan Address: Dapeng Village Niushenling, Wangmu Community, Dapeng Street, Dapeng New District, Shenzhen, China Telephone: 13530961259 Fax: 13530961259 E-mail: [email protected] [Shenzhen Mulan Shijia TechnologyCo., Ltd.] certifies that, as of the date of this filing of the application with the TCB, [UGK-LVM UNITED INC] is our designated US agent for service of process for the above referenced FCC ID. [Shenzhen Mulan Shijia TechnologyCo., Ltd.] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [UGK-LVM UNITED INC] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2024-06-17 Applicant’s Name: Carry Pan US Agent for Service of Process’s Name: Jimmychen Title: Manager Title: Manager Signature Signature

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Shenzhen Mulan Shijia TechnologyCo., Ltd. Grantee code: 2A4M6 FCC ID: 2A4M6-007N FRN: 0031988504 Contact Name: Carry Pan Address: Dapeng Village Niushenling, Wangmu Community, Dapeng Street, Dapeng New District, Shenzhen, China Telephone: 13530961259 Fax: 13530961259 E-mail: [email protected] i. [Shenzhen Mulan Shijia TechnologyCo., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [Shenzhen Mulan Shijia TechnologyCo., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [Shenzhen Mulan Shijia TechnologyCo., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [ is not] identified on the Covered List as an entity producing “covered”equipment . Date: 2024-06-17 Applicant’s Name: Carry Pan Title: Manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

Shenzhen Mulan Shijia TechnologyCo., Ltd. Product Similarity Declaration Company: Shenzhen Mulan Shijia TechnologyCo., Ltd. Address: Dapeng Village Niushenling, Wangmu Community, Dapeng Street, Dapeng New District, Shenzhen, China Product Name: Surveillance Camera Model Number: 007N, 007, 007P, 007S FCC Identifier: 2A4M6-007N We (Shenzhen Mulan Shijia TechnologyCo., Ltd.) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including product enclosure, materials, etc.,), the only difference is the model name. Client’s signature Name: Carry Pan Date: 2024-06-17 Title: Manager Signature of applicant:

Shenzhen Mulan Shijia TechnologyCo., Ltd. 1/1 Letter of Authorization Company: Shenzhen Mulan Shijia TechnologyCo., Ltd. Address: Dapeng Village Niushenling, Wangmu Community, Dapeng Street, Dapeng New District, Shenzhen, China Product Name: Surveillance Camera Model Number: 007N, 007, 007P, 007S FCC Identifier: 2A4M6-007N We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Carry Pan Date: 2024-06-17 Title: Manager Signature of applicant:

Shenzhen Mulan Shijia TechnologyCo., Ltd. 1/1 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2024-06-17 Subject: Request for Confidentiality FCC ID: 2A4M6-007N To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual No ☐ Internal Photos No ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Carry Pan Title: Manager

Shenzhen DL Testing Technology Co., Ltd. EUT PHOTO(External Photos) Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. ※※※※※ END OF REPORT ※※※※※

Size:12*6mm Mode: 007N FCC ID: 2A4M6-007N Label location

Shenzhen DL Testing Technology Co., Ltd. EUT PHOTO(Internal Photos) Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. ANT Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. ※※※※※ END OF REPORT ※※※※※

FCC ID: 2A4M6-007N RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in KDB 447498 D01 V06 and 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm EIRP=E Meas +20log(d Meas )-104.7 EIRP is the equivalent isotropically radiated power, in dBm E Meas is the field strength of the emission at the measurement distance, in dBμV/m d Meas is the measurement distance, in m Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Test Result of RF Exposure Evaluation wifi 2.4G mode: Channel Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11b 17.671 58.4925 0.02008 1.0 PASS 802.11g 15.974 39.5731 0.01359 1.0 PASS 802.11n HT20 14.912 30.9885 0.01064 1.0 PASS Remark: antenna gain=2.37 dBi

Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-240605001ER Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 1 of 46 FCC Part 15C Test Report FCC ID: 2A4M6-007N Applicant: Shenzhen Mulan Shijia TechnologyCo., Ltd. Address: Dapeng Village Niushenling, Wangmu Community, Dapeng Street, Dapeng New District, Shenzhen, China Manufacturer: Shenzhen Mulan Shijia TechnologyCo., Ltd. Address: Dapeng Village Niushenling, Wangmu Community, Dapeng Street, Dapeng New District, Shenzhen, China EUT: Surveillance Camera Trade Mark: N/A Model Number: 007N, 007, 007P, 007S Date of Receipt: Jun. 05, 2024 Test Date: Jun. 05, 2024 –Jun. 17, 2024 Date of Report: Jun. 17, 2024 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China Applicable Standards: FCC PART 15 C 15.247 ANSI C63.10:2013 Test Result: Pass Report Number: DL-240605001ER Prepared (Test Engineer): Alisa Song Reviewer (Supervisor): Jack Bu Approved (Manager): Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-240605001ER Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 46 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 MEASUREMENT UNCERTAINTY 4 2 . GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 DESCRIPTION OF TEST MODES 6 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 6 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 7 2.5 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 7 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 8 3 . EMC EMISSION TEST 9 3.1 CONDUCTED EMISSION MEASUREMENT 9 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 9 3.1.2 TEST PROCEDURE 9 3.1.3 DEVIATION FROM TEST STANDARD 9 3.1.4 TEST SETUP 10 3.1.5 EUT OPERATING CONDITIONS 10 3.1.6 TEST RESULTS 10 3.2 RADIATED EMISSION MEASUREMENT 15 3.2.1 RADIATED EMISSION LIMITS 15 3.2.2 TEST PROCEDURE 16 3.2.3 DEVIATION FROM TEST STANDARD 16 3.2.4 TEST SETUP 16 3.2.5 EUT OPERATING CONDITIONS 17 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 18 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 19 3.2.8 TEST RESULTS (1GHZ~25GHZ) 23 3.3 RADIATED BAND EMISSION MEASUREMENT 26 3.3.1 TEST REQUIREMENT: 26 3.3.2 TEST PROCEDURE 26 3.3.3 DEVIATION FROM TEST STANDARD 26 3.3.4 TEST SETUP 27 3.3.5 EUT OPERATING CONDITIONS 27 3.4 CONDUCTED BAND EDGE EMISSION&CONDUCTED SPURIOUS EMISSIONS MEASUREMENT 31 3.4.1 APPLICABLE STANDARD 31 3.4.2 TEST PROCEDURE 31 3.4.3 DEVIATION FROM STANDARD 31 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-240605001ER Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 3 of 46 Table of Contents Page 3.4.4 TEST SETUP 31 3.4.5 EUT OPERATION CONDITIONS 31 3.4.6 TEST RESULTS 31 4 . AVERAGE OUTPUT POWER 34 4.1 APPLIED PROCEDURES / LIMIT 34 4.1.1 TEST PROCEDURE 34 4.1.2 DEVIATION FROM STANDARD 34 4.1.3 TEST SETUP 34 4.1.4 EUT OPERATION CONDITIONS 34 4.1.5 TEST RESULTS 35 5 . POWER SPECTRAL DENSITY TEST 38 5.1 APPLIED PROCEDURES / LIMIT 38 5.1.1 TEST PROCEDURE 38 5.1.2 DEVIATION FROM STANDARD 38 5.1.3 TEST SETUP 38 5.1.4 EUT OPERATION CONDITIONS 38 5.1.5 TEST RESULTS 39 6 . 6DB BANDWIDTH TEST 42 6.1 APPLIED PROCEDURES / LIMIT 42 6.1.1 TEST PROCEDURE 42 6.1.2 DEVIATION FROM STANDARD 42 6.1.3 TEST SETUP 42 6.1.4 EUT OPERATION CONDITIONS 42 6.1.5 TEST RESULTS 43 7 . ANTENNA REQUIREMENT 46 7.1 STANDARD REQUIREMENT 46 7.2 EUT ANTENNA 46 8 . TEST SEUUP PHOTO 46 9 . EUT PHOTO 46 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-240605001ER Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 4 of 46 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.205, 15.209, 15.247(d) Radiated Spurious Emission PASS 15.205, 15.247(d) Band Edge Emission& Conducted Spurious Emissions PASS 15.247(b) Average Output Power PASS 15.247(a)(2) 6dB Bandwidth PASS 15.247(e) Power Spectral Density PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Test lab: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China FCC Test Firm Registration Number: 854456 Designation Number: CN1307 IC Registered No.: 27485 CAB ID.: CN0118 1.1 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±2.56dB 2 RF power,conducted ±0.42dB 3 Spurious emissions,conducted ±2.76dB 4 All emissions,radiated(<1G) ±3.65dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% 8 6dB Bandwidth ±0.2MHz Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-240605001ER Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 5 of 46 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product Name: Surveillance Camera Trademark N/A Model No.: 007N, 007, 007P, 007S Test Model: 007N Model Difference: The product's different for model number. Operation Frequency: 2412~2462 MHz for 802.11b/g/nHT20 Channel numbers: 11 Channels for 802.11b/g/n(HT20) Channel separation: 5MHz Modulation technology: 802.11b: DSSS (CCK, DQPSK, DBPSK) 802.11g/n(20): OFDM(QPSK, BPSK, 16-QAM, 64-QAM) Rate of Transmitter 802.11b: 11/5.5/2/1Mbps 802.11g: 54/48/36/24/18/12/9/6Mbps 802.11n: up to 150Mbps Antenna Type: FPC Antenna Antenna gain: 2.37 dBi Power supply: Input:110-240V 60Hz DC …

Text truncated - open the document above for the full version.

ShenzhenQiBingTechnologyCo.,Ltd 5A,5thFloor,BuildingB AnfengIndustrialDistrict,LianrunRoad, TaoyuanCommunity,DalangStreet,LonghuaDistrict,ShenzhenCity,China. AntennaSpecificationfor Approval N0.QBAC20 220210001 CustomerName：LangTong ProductName：WIFIAntenna Productdescriptinon：PCB ，D=1.13mmBlackCableType，L=100mm,IPEX1 PartNO.：WF38B.C113.100B.1 CustomerNO.： Versionnumber：V1.0 IssuedDate：2022-2-10 QIBING R&D Dept BusinessDept ApprovedBy CUSTOMER R&DDept BusinessDept ApprovedBy SpecificationSummary A. ElectricalCharacteristics Frequency2400MHz~2500MHz LogMag<-10 Efficiency>50 % PeakGaindbi Impedance50 Ω PolarizationLine B. Material& MechanicalCharacteristics Materialof RadiatorPCB/CU CableType1.13mmBlack ConnectorTypeIPEXI DimensionAt Attachment C. EnvironmentalCharacteristic StorageTemperature- 30 ̊C ~ + 85 ̊C Heat-durability280 ±5 ̊C，10sec. WeldTemperature320 ±5°C2-3 sec. TestEquipment& Conditions 1． NetworkAnalyzers : Agilent8753D 5071B CommunicationsTestSet: AgilentE5515CCMW500 2． 3D ChamberTestSystem MatchingCricuit ReturnLoss Antennaend Modularend 2.4GGain 2.4GEfficiency 2400Mhz 2450Mhz 2500Mhz AntennaSize： AntennaPicture： ReliabilityTest TestItemTestconditionEquipmentSpecificationResult 1 LowTemp. Storage Test Temperature:-30 °C， Time:48hrs Testcondition:Placingantennain a Low/High TemperatureChamber,keepthe tempis 25 °C and humidityis 65% for one hour,then step-down the temp.to -30 °C in one hour,store antennafor 44 hours;step-uptempto 25 °C,test antennaafter 2 hours. Temp.&Humi. Tester No material deformation is allowed. Electronic Performance is ok . PASS 2 High Temp./High Humid StorageTest Temperature:85 °C Humidity:85%RH Time:48hrs Testcondition:Placingantennain a Low/High TemperatureChamber,keepthe tempis 25 °C and humidityis 65% for one hour,then step-upthe temp.to 80 °C andthehumidityup to 85%in one hour,storeantennafor44 hours; step-downtemp to 25 °C,testantennaafter2 hours. Temp.&Humi. Tester No material deformation is allowed. Electronic Performance is ok . PASS 3 Salt-Spray6 prayTest Placingantennain theSalt-Spray Tester,setthe testcondition，Temp:35 ±2°C Humidity:85% NaClsaltspray:5 ±1 %.PH value:6.5~7.2Test time:24hours Salt-Spray Tester No colorchange No appear rusting PASS

Shenzhen DL Testing Technology Co., Ltd. EUT TEST PHOTO Radiated Measurement Photos Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Conducted Measurement Photos ※※※※※ END OF REPORT ※※※※※
