2A542-AIR96Keyboard

FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. IC Warning This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. Cet appareil est conforme aux CNR exemptes de licence d'Industrie Canada . Son fonctionnement est soumis aux deux conditions suivantes : ( 1 ) Ce dispositif ne peut causer d'interférences ; et ( 2 ) Ce dispositif doit accepter toute interférence , y compris les interférences qui peuvent causer un mauvais fonctionnement de l'appareil. Le dispositif a été conçu pour répondre à la demande générale de radioexposition.

SHENZHEN REOSTUDIO TECHNOLOGY CO.,LTD Covered Equipment Certification Attestation Letter 5/5/2023 ATTN.: Reviewing Engineer FCC ID: 2A542-AIR96 SHENZHEN REOSTUDIO TECHNOLOGY CO.,LTD (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. SHENZHEN REOSTUDIO TECHNOLOGY CO.,LTD (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: Huang zhuang hui Title: Manager Company Name: SHENZHEN REOSTUDIO TECHNOLOGY CO.,LTD Date: 5/5/2023

JOC Australia Inc * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter 5/5/2023 ATTN.: Reviewing Engineer Per section 2.911(d)(7) of the FCC rules, SHENZHEN REOSTUDIO TECHNOLOGY CO.,LTD (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. agent* for service of process: Company Name: JOC Australia Inc Physical U.S. Company Address: 18351 Colima Road Ste 585 Rowland Heights,California,91748 United States of America Agent contact name/Title : Benjamin.Smith/Vice President Agent Email Address: [email protected]/[email protected] Tel No.: +1(626) 217 47788 FRN No.: 0033379421 The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Agent Signed (if different to Applicant): Signed: Signed: Printed name: Huang zhuang hui Printed name: Benjamin. Smith Title: Manager Title: Vice President Company Name: SHENZHEN REOSTUDIO Company Name: JOC Australia Inc TECHNOLOGY CO.,LTD Date: 5/12/2023 Date: 5/5/2023

SHENZHEN REOSTUDIO TECHNOLOGY CO.,LTD Agent Authorization Company: SHENZHEN REOSTUDIO TECHNOLOGY CO.,LTD Address: Room 213-214, Internet of Things Demonstration Park, No. 6 Minhuan Road, Longhua District, Shenzhen, China Product Name: Keyboard Model Number(s): Air96 Product Description: Keyboard We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2023.05.05 Name: Jiankuai Li Title: PM Company: SHENZHEN STS TEST SERVICES CO.,LTD.

SHENZHEN REOSTUDIO TECHNOLOGY CO.,LTD Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2023.05.05 Subject; Request for Confidentiality FCC ID: 2A542-AIR96 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Date: 2023.05.05 Name: Jiankuai Li Title: PM Company: Shenzhen STS Test Services Co., Ltd.

Page 1 of 4 Report No.: STS2303086 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: Air96 Photo 1 Photo 2 Page 2 of 4 Report No.: STS2303086 Photo 3 Photo 4 Page 3 of 4 Report No.: STS2303086 Photo 5 Photo 6 Page 4 of 4 Report No.: STS2303086 Photo 7 Photo 8

Label Keyboard Nuphy Model: Air96 FCC ID: 2A542-AIR96 IC: 29557-AIR96 Input: DC 5V SHENZHEN ARBITER TECHNOLOGY CO.,LTD 30mm 5mm 15mm

Page 1 of 3 Report No.: STS2303086 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: Air96 Photo 1 Photo 2 Page 2 of 3 Report No.: STS2303086 Photo 3 Photo 4 2.4G/BLE Antenna Page 3 of 3 Report No.: STS2303086 Photo 5

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, all test data presented in this report is only applicable to presented test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No: STS2303086H02 Issued for SHENZHEN REOSTUDIO TECHNOLOGY CO.,LTD Room 213-214, Internet of Things Demonstration Park, No. 6 Minhuan Road, Longhua District, Shenzhen, China Product Name: Keyboard Brand: Nuphy Model Number: Air96 Series Model(s): N/A FCC ID: 2A542-AIR96 Test Standard: FCC 47CFR §2.1093 S T L A B S Page 2 of 9 Report No.: STS2303086H02 Test Report Certification Applicant’s Name .................. : SHENZHEN REOSTUDIO TECHNOLOGY CO.,LTD Address ................................... : Room 213-214, Internet of Things Demonstration Park, No. 6 Minhuan Road, Longhua District, Shenzhen, China Manufacturer's Name ........... : SHENZHEN ARBITER TECHNOLOGY CO.,LTD Address ................................... : Floor 2, 3 and 4, Bldg. A, Meisheng Industrial Park, Chongqing Rd., Fuhai St., Baoan Dist.,Shenzhen, Guangdong, China Product Description Product Name ......................... : Keyboard Brand ..................................... : Nuphy Model Number ........................ : ...: Air96 Series Model(s) ....................... : N/A Standards .............................. : FCC 47CFR §2.1093 447498 D04 Interim General RF Exposure Guidance v01 This report shall not be reproduced except in full, without the written approval of STS, this document only be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test .............................................. : Date of receipt of test item ....................... : 24 Mar. 2023 Date (s) of performance of tests .............. : 24 Mar. 2023 ~ 30 Mar. 2023 Date of Issue............................................. : 30 Mar. 2023 Test Result ................................................. : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory : (Bovey Yang) Page 3 of 9 Report No.: STS2303086H02 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 5 2. FCC 47CFR §2.1093 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 9 Page 4 of 9 Report No.: STS2303086H02 Revision History Rev. Issue Date Report No. Effect Page Contents 00 30 Mar. 2023 STS2303086H02 ALL Initial Issue Page 5 of 9 Report No.: STS2303086H02 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name Keyboard Brand Nuphy Model Number Air96 Series Model(s) N/A Model Difference N/A Product Description The EUT is Keyboard. Operation Frequency: BLE: 2402-2480 MHz 2.4G: 2403-2480 MHz Modulation Type: GFSK Antenna gain: 2.34dBi Antenna Designation: PCB Rating Input: Wired: DC 5V; Wireless: DC 3.7V Battery Rated Voltage:3.8V Charge Limit Voltage:4.2V Capacity: 4000mAh Hardware version number F3-BT818 VER1.0 Software version number V0110 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 6 of 9 Report No.: STS2303086H02 2. FCC 47CFR §2.1093 REQUIREMENT 2.1 TEST STANDARDS Follow the maximum permissible exposure (MPE) limits specified in 447498 D04 Interim General Radio Frequency Exposure Guidelines v01. The gain of the antenna used in the product was extracted from the supplied antenna data sheet and the maximum total power input to the antenna was also measured. Calculate the distance from the product to the MPE limit by the formula. 2.2 LIMIT For single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: (A) The available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption may not be used in conjunction with other exemption criteria other than those in paragraph (b)(3)(ii)(A) of Part 1.1307. Medical implant devices may only use this exemption and that in paragraph (b)(3)(ii)(A); (B) Or the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold Pth (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by: Page 7 of 9 Report No.: STS2303086H02 (C) Or using below table and the minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. For the exemption in Table 1 to apply, R must be at least λ/2π, where λ is the free-space operating wavelength in meters. If the ERP of a single RF source is not easily obtained, then the available maximum time-averaged power may be used in lieu of ERP if the physical dimensions of the radiating structure(s) do not exceed the electrical length of λ/4 or if the antenna gain is less than that of a half-wave dipole (1.64 linear value). RF Source frequency (MHz) Threshold ERP(watts) 0.3-1.34 1,920 R 2 . 1.34-30 3,450 R 2 /f 2 . 30-300 3.83 R 2 . 300-1,500 0.0128 R 2 f. 1,500-100,000 19.2R 2 . Page 8 of 9 Report No.: STS2303086H02 For multiple RF sources: Multiple RF sources are exempt if: (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two cent…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, all test data presented in this report is only applicable to presented test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No.:STS2303086W03 Issued for SHENZHEN REOSTUDIO TECHNOLOGY CO.,LTD Room 213-214, Internet of Things Demonstration Park, No. 6 Minhuan Road, Longhua District, Shenzhen, China Product Name: Keyboard Brand: Nuphy Model Number: Air96 Series Model(s): N/A FCC ID: 2A542-AIR96 Test Standard: FCC Part 15.247 S T L A B S Page 2 of 58 Report No.: STS2303086W03 TEST RESULT CERTIFICATION Applicant’s Name .................. : SHENZHEN REOSTUDIO TECHNOLOGY CO.,LTD Address ................................... : Room 213-214, Internet of Things Demonstration Park, No. 6 Minhuan Road, Longhua District, Shenzhen, China Manufacturer's Name ........... : SHENZHEN ARBITER TECHNOLOGY CO.,LTD Address ................................... : Floor 2, 3 and 4, Bldg. A, Meisheng Industrial Park, Chongqing Rd., Fuhai St., Baoan Dist.,Shenzhen, Guangdong, China Product Description Product Name ......................... : Keyboard Brand ..................................... : Nuphy Model Number ........................ : ...: Air96 Series Model(s) ....................... : N/A Test Standards ...................... : FCC Part15.247 Test Procedure ........................ : ANSI C63.10-2013 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test .............................................. : Date of receipt of test item ....................... : 24 Mar. 2023 Date (s) of performance of tests .............. : 24 Mar. 2023 ~ 30 Mar. 2023 Date of Issue ............................................. : 30 Mar. 2023 Test Result ................................................. : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory : (Bovey Yang) Page 3 of 58 Report No.: STS2303086W03 Table of Contents 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 TEST SOFTWARE AND POWER LEVEL 10 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 12 2.6 EQUIPMENTS LIST 13 3. EMC EMISSION TEST 14 3.1 CONDUCTED EMISSION MEASUREMENT 14 3.2 TEST PROCEDURE 15 3.3 TEST SETUP 15 3.4 EUT OPERATING CONDITIONS 15 3.5 TEST RESULTS 16 4. RADIATED EMISSION MEASUREMENT 18 4.1 RADIATED EMISSION LIMITS 18 4.2 TEST PROCEDURE 20 4.3 TEST SETUP 21 4.4 EUT OPERATING CONDITIONS 21 4.5 FIELD STRENGTH CALCULATION 22 4.6 TEST RESULTS 23 5. CONDUCTED SPURIOUS & BAND EDGE EMISSION 30 5.1 LIMIT 30 5.2 TEST PROCEDURE 30 5.3 TEST SETUP 30 5.4 EUT OPERATION CONDITIONS 30 5.5 TEST RESULTS 30 6. POWER SPECTRAL DENSITY TEST 31 6.1 LIMIT 31 6.2 TEST PROCEDURE 31 6.3 TEST SETUP 31 Page 4 of 58 Report No.: STS2303086W03 Table of Contents 6.4 EUT OPERATION CONDITIONS 31 6.5 TEST RESULTS 31 7. BANDWIDTH TEST 32 7.1 LIMIT 32 7.2 TEST PROCEDURE 32 7.3 TEST SETUP 32 7.4 EUT OPERATION CONDITIONS 32 7.5 TEST RESULTS 32 8. PEAK OUTPUT POWER TEST 33 8.1 LIMIT 33 8.2 TEST PROCEDURE 33 8.3 TEST SETUP 34 8.4 EUT OPERATION CONDITIONS 34 8.5 TEST RESULTS 34 9. ANTENNA REQUIREMENT 35 9.1 STANDARD REQUIREMENT 35 9.2 EUT ANTENNA 35 APPENDIX 1-TEST DATA 36 1. DUTY CYCLE 36 2. MAXIMUM AVERAGE CONDUCTED OUTPUT POWER 39 3. MAXIMUM PEAK CONDUCTED OUTPUT POWER 42 4. -6DB BANDWIDTH 45 5. MAXIMUM POWER SPECTRAL DENSITY LEVEL 48 6. BAND EDGE 51 7. CONDUCTED RF SPURIOUS EMISSION 54 APPENDIX 2- EUT TEST PHOTO 58 Page 5 of 58 Report No.: STS2303086W03 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 30 Mar. 2023 STS2303086W03 ALL Initial Issue Page 6 of 58 Report No.: STS2303086W03 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted bands of operation PASS -- Part 15.247(d)/ Part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2013. Page 7 of 58 Report No.: STS2303086W03 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±1.197dB 2 Unwanted Emissions, conducted ±2.896dB 3 All emissions, radiated 9K-30MHz ±3.84dB 4 All emissions, radiated 30M-1GHz ±3.94dB 5 All emissions, radiated 1G-6GHz ±4.59dB 6 All emissions, radiated…

Text truncated - open the document above for the full version.

Antenna Specification Specifications Summary ITEMSPEC. Model NameIBM 2.4 GHz Center Frequency 2402 MHz 2441 MHz 2480 MHz 2.34 dBi 2.07dBi 1.45 dBi MAX. GAIN2.34 dBi PolarizationHorizontal Azimuth Beam Pattern Omni-directional Impedance50Ω Antenna Length Antenna Photo & Length (mm) Test Address 16 Tzu Chiang Road, Hsinchu Industrial District Hsinchu Hsien 303, Taiwan Test Date2009-04-14 Test Instrument vector network analyzer - R&S ZVB20 36.0mm 1. Main antenna : 2402 MHz 1.1 Horizontal Frequency(MHZ):2402Antenna Polarity:Horizontal Maximum Gain(dBi): 2.34 Average Gain(dBi):-2.48 Minim um Gain(dBi):-55.18 1.2 Vertical Frequency(MHZ):2402Antenna Polarity:Vertical Maximum Gain(dBi): -4.51 AverageGain(dBi) :-8.98 Minimum Gain(dBi):-62.3 2. Main antenna : 2441 MHz 2.1 Horizontal Frequency(MHZ):2441Antenna Polarity:Horizontal Maximum Gain(dBi): 2.07 Average Gain(dBi) : -2.54 Minimum Gain(dBi): -66.98 2.2 Vertical Frequency(MHZ):2441Antenna Polarity:Vertical Maximum Gain(dBi): -4.29 AverageGain(dBi) :-8.81 Minimum Gain(dBi):-51.4 2. Main antenna : 2480 MHz 2.1 Horizontal Frequency(MHZ): 2480AntennaPolarity:Horizontal Maximum Gain(dBi):1.45 AverageG ain(dBi) : -3.34 Minimum Gain(dBi): -53.4 2.2 Vertical Frequency(MHZ):2480Antenna Polarity:Vertical Maximum Gain(dBi): -4.95 AverageGain(dBi) :-9.06 Minimum Gain(dBi):-60.00

Page 1 of 2 FCC ID: 2A542-AIR96 DTSDXX Setup photo Model Number: Air96 DTS&DXX conduction DTS&DXX radiation L Page 2 of 2 FCC ID: 2A542-AIR96 DTS&DXX radiation H
