2A55Q-DU4L-WAAutomatic Pet Feeder

Button Description Product Image Front view Button to open cover Food Tank Lid Food Tank Food Outlet Body Control panel Bottom View Speaker Battery Compartment Tpye-C Interface Food Bowl PUSH Press and hold the detachable grain bucket on both sides simultaneously. Indicator light color Indicator light signal Device status White Red flash Slow flashing light's on twinkle flash Twice flashing in 1s, WIFI fast connection distribution mode 3S flashing once, AP hotspot distribution mode Network connection successful Abnormal detection (motor not rotating) Unlock/Lock Status Packing list After opening the product package, please confirm whether the machine is in good condition. Please check the list to confirm whether the accessories are complete. Cleaning and Maintenance Usage Guidelines PUSH Low Power Description 1. When the feeder is not connected to a power source, it will change to battery power supply. If you need to use it without plugging it in, please ensure that the battery is installed as required. 2. When the feeder battery is powered, in order to ensure normal feeding and long-term battery life, remote control of the app is not supported, only feeding records and battery level are reported. 3. If you need to use the app function, please connect the power cord and use it after successful network distribution. Automatic Pet Feeder Smart Type Operation Guide Please Read the Manual Carefully Before Using the Product Safety Instruction 1.Children must be accompanied by adults to use it. 2.Do not use the feeder for pets which cannot reach the food tray or have physical disabilities. 3.Do not immerse the base part in water, which will damage electronic components such as control panel. 4.Do not put any foreign objects into the pet feeder. 5. Do not put canned or wet food into the feeder. 6.Do not disassemble the equipment by yourself. 7.Do not modify the pet feeder. 8.If there is a malfunction or damaged accessory on this device, please do not attempt to repair the pet feeder yourself. Please contact the dealer immediately and resolve the issue 9.Please make sure the the feeder is unplug and power off when not using or cleaning it. 10.lf the plug is damp, please turn off the socket rather than trying to unplug the power. Notice 1.Please purchase hard plastic protector from hardware store to protect plugs and power cord then prevent your pet from damaging the accessories. 2.The ambient temperature for normal operation of this feeder is between 0 ° C and 40 ° C. Do not place the feeder in a place that is exposed to sunlight or does not match the ambient temperature. 3.Please use alkaline Size D battery for power supply. Do not use rechargeable batteries. 4.Check the battery regularly. Please replace the battery before having a trip. 5.Do not lift the pet feeder directly with the cover, food bucket and food tray. Hold the base with both hands to lift and carry, while keeping the device in an upright position. 6.Only applicable to dry food with a diameter of 3-10mm. Larger food may get stuck or block the food outlet. 7.Please read all the notices on the packing and manuals carefully. Feeding button: Press once to manually feed once, and when there is a recording, it will play once.Long press for 6 seconds, the red indicator light flashes twice to lock the machine, and long press again for 6 seconds, the red indicator light flashes twice to unlock.In the locked state, you can press and hold the setting button to restore the factory settings. In the locked state, you cannot press the recording and feeding buttons. Recording: Press and hold for 3 second to make a "di" sound to start recording, and release to make two "di" sounds to end recording. The recording duration can be up to 10 seconds. Reset: Press and hold for 6 seconds to make a three beep sound. After restoring the factory settings, the device will automatically restart (the white light flashes quickly for 7-10 seconds and then restarts. If the white light remains on, it needs to be re wired). The Feeder×1The power adapter×1 Power Cord×1 Product Manual×1 For the health of your pet, it is recommended to regularly clean the feeder. When it starts to get dirty and there is a lot of loose food in the food bin, you can remove the food cover for cleaning. Use a soft cloth to clean the feeder base including the control panel. Do not wet the equipment. Clean with running water. Do not put the product in the dishwasher, as it may be permanently damaged! Specification Food Tank Capacity:4L Screen: LCD screen Power supply: DC 5V/1A power adapter; 3pcs alkaline D Size batteries Power adapter: AC110-240V input, DC5V output N.G: 1.52KG Size: 23*16.4*30.7cm BC-041-D 1. Download the App, register a dedicated account and log in Smart Life APP specific operations 3S 6S 6S 08 丨 Fault alarm 3. First open your phone Bluetooth and allow permissions. After entering the interface, wait for the device to be discovered 4. Enter a WiFi password (the name cannot be used in Chinese, the password cannot be used for special symbols) Instructions 01 丨 Installation ◎ Remove the feeder from the box. ◎ Place the feeder in the suitable location. ◎ Combine the food tray with the base of the feeder. 02 丨 Connect the power supply ◎ Plug the 5V/1A power adapter into the wall socket and connect the device. ◎ Open the battery compartment at the bottom of the feeder and install 3 pcs D size batteries (not necessary) to prevent power failure ◎ The LED light is turn on to indicate that the feeder is powered on. Note: Does not including battery . Before turning on the power, make sure that all parts are clean and completely dry. 03 丨 Put pet food into food tank ◎Fill the food tank with dry pet food then close the lid. Note: Do not place canned, wet or moist pet food. The recommended pet food size range is 3-10 mm. 04 丨 Recording ◎ Long press for 3s until you hear "di" and start recording.The recording time does not exceed 10s, After you release your hand, you will hear "didi" to…

Text truncated - open the document above for the full version.

Huizhou Dudu Pet Products Co., ltd Address:Floor 2/3/ 4, Building 2 District D Qiaosheng Industrial Park, Lilin Town,Huicheng District, Huizhou, China Tel.:18124747060 E-mail:[email protected] CFR 47 §2.911(d)(5)(i) Attestation Letter Attestation Letter Date: 2023-09-21 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(5)(i) Filing FCC ID:2A55Q-DU4L-WA Huizhou Dudu Pet Products Co., ltd certifies that the equipment for which authorization is sought, is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Signature Contact Person:ANN HU Title:Human Resources Specialist

Huizhou Dudu Pet Products Co., ltd Address: Floor 2/3/ 4, Building 2 District D Qiaosheng Industrial Park, Lilin Town, Huicheng District, Huizhou, China Tel.: 18124747060 E-mail: [email protected] CFR 47 §2.911 (d)(5)(ii) Attestation Letter Attestation Letter Date: 21/09/2023 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(5)(ii) Filing FCC ID: 2A55Q-DU4L-WA Huizhou Dudu Pet Products Co., ltd certifies that as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Signature ANN HU Human Resources Specialist

U.S. AGENT LETTER OF ATTESTATION Date: 2023-09-21 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(7) Filing FCC ID: 2A55Q-DU4L-WA Huizhou Dudu Pet Products Co., ltd certifies that, as of the date of the filing of the application, Baihetian Innovative Solutions is our designated U.S. agent for service of process for the above referenced FCC ID. Huizhou Dudu Pet Products Co., ltd accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Baihetian Innovative Solutions accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Name: Baihetian Innovative Solutions Address: 6837 Chase Rd, Dearborn, MI 48126 FRN: 0033401605 Tel.: 313-395-3113 Email: [email protected] Signed by (printed name): Kenneth Young Signature: Applicant: Huizhou Dudu Pet Products Co., ltd Address: Floor 2/3/ 4, Building 2 District D Qiaosheng Industrial Park, Lilin Town, Huicheng District, Huizhou, China FRN: 0032188674 Tel: 18124747060 Email: [email protected] Signed by (printed name): ANN HU Signature:

Huizhou Dudu Pet Products Co., ltd Address: Floor 2/3/ 4, Building 2 District D Qiaosheng Industrial Park, Lilin Town, Huicheng District, Huizhou, China Tel.: 18124747060 E-mail: [email protected] QA-FR-170-B FCC Authorization Date: 2023-09-21 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We, Huizhou Dudu Pet Products Co., ltd hereby authorize China Certification ICT Co., Ltd (Dongguan) to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Shenzhen Accurate Technology Co., Ltd. on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Signature: ANN HU Human Resources Specialist

Huizhou Dudu Pet Products Co., ltd Address:Floor 2/3/ 4, Building 2 District D Qiaosheng Industrial Park, Lilin Town,Huicheng District, Huizhou, China Tel.:18124747060 E-mail:[email protected] FCC Confidential Authorization Date: 2023-09-21 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: 2A55Q-DU4L-WA In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, Huizhou Dudu Pet Products Co., ltd, hereby requests long-term confidential treatment of information accompanying this application as outlined below: • Block Diagram • Schematics • Operation Description • Parts List The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely Yours, Signature ANN HU Human Resources Specialist

Huizhou Dudu Pet Products Co., ltd Address:Floor 2/3/ 4, Building 2 District D Qiaosheng Industrial Park, Lilin Town,Huicheng District, Huizhou, China Tel.:18124747060 E-mail:[email protected] Date: 2023-09-21 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Attestation letter Dear Sir or Madam, Our product Automatic Pet Feeder, model: DU4L-WA, DU4L-WA-01, DU4L-KA, DU-F01K, DU-F01W, DU-F01V, FCC ID: 2A55Q-DU4L-WA, for marketing purpose, this product only supports BLE 1M, 2.4G Wi-Fi(2412-2462MHz, 802.11b/g/n20 modes).The other functions, bands and modes was disabled to use by manufacturer in the software, the end user has no capability to activate it. Sincerely, Signature ANN HU Human Resources Specialist

Huizhou Dudu Pet Products Co., ltd Address: Floor 2/3/ 4, Building 2 District D Qiaosheng Industrial Park, Lilin Town, Huicheng District, Huizhou, China Tel.: 18124747060 E-mail: [email protected] Product Similarity Declaration Date: 2023-09-21 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir or Madam, We Huizhou Dudu Pet Products Co., ltd hereby declare that we have a product named Automatic Pet Feeder (Model number:DU4L-WA) was tested by China Certification ICT Co., Ltd (Dongguan), Meanwhile, for our marketing purpose, we would like to list a series models (DU4L-WA-01, DU4L-KA, DU-F01K, DU-F01W, DU-F01V) on reports and certificate. All of the models are electrically identical, but the difference among them is model name. We confirm that all information above is true, and we’ll be responsible for all the consequences. Please contact with me if you have any question. Signature ANN HU Human Resources Specialis

China Certification ICT Co., Ltd (Dongguan) Report No.: CR230739372-EXP Page 1 of 6 EUT EXTERNAL PHOTOGRAPHS China Certification ICT Co., Ltd (Dongguan) Report No.: CR230739372-EXP Page 2 of 6 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230739372-EXP Page 3 of 6 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230739372-EXP Page 4 of 6 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230739372-EXP Page 5 of 6 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230739372-EXP Page 6 of 6

Label Location

China Certification ICT Co., Ltd (Dongguan) Report No.: CR230739372-INP EUT INTERNAL PHOTOGRAPHS China Certification ICT Co., Ltd (Dongguan) Report No.: CR230739372-INP China Certification ICT Co., Ltd (Dongguan) Report No.: CR230739372-INP China Certification ICT Co., Ltd (Dongguan) Report No.: CR230739372-INP China Certification ICT Co., Ltd (Dongguan) Report No.: CR230739372-INP China Certification ICT Co., Ltd (Dongguan) Report No.: CR230739372-INP China Certification ICT Co., Ltd (Dongguan) Report No.: CR230739372-INP China Certification ICT Co., Ltd (Dongguan) Report No.: CR230739372-INP ANT China Certification ICT Co., Ltd (Dongguan) Report No.: CR230739372-INP

China Certification ICT Co., Ltd (Dongguan) Report No.: CR230739372-00B Page 53 of 57 5. RF EXPOSURE EVALUATION 5.1 Simultaneous Transmission with both MPE-based 5.1.1 Applicable Standard According to §1.1307(b)(3)(i) (C) Or using Table 1 and the minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. For the exemption in Table 1 to apply, R must be at least λ/2π, where λ is the free-space operating wavelength in meters. If the ERP of a single RF source is not easily obtained, then the available maximum time-averaged power may be used in lieu of ERP if the physical dimensions of the radiating structure(s) do not exceed the electrical length of λ/4 or if the antenna gain is less than that of a half-wave dipole (1.64 linear value). Table 1 to § 1.1307(b)(3)(i)(C) - Single RF Sources Subject to Routine Environmental Evaluation RF Source frequency (MHz) Threshold ERP (watts) 0.3-1.34 1,920 R 2 . 1.34-30 3,450 R 2 /f 2 . 30-300 3.83 R 2 . 300-1,500 0.0128 R 2 f. 1,500-100,000 19.2R 2 . China Certification ICT Co., Ltd (Dongguan) Report No.: CR230739372-00B Page 54 of 57 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230739372-00B Page 55 of 57 5.1.2 Measurement Result Radio Frequency (MHz) λ/2 Π (mm) Distance (mm) Exemption ERP (mW) Maximum Conducted Power including Tune-up Tolerance (dBm) Antenna Gain (dBi) ERP dBmmW BLE 2402-2480 19.88 200 768 3.5 2.54 3.89 2.45 2.4G WLAN 2412-2462 19.80 200 768 15.5 2.54 15.89 38.82 Note: The Maximum Conducted Power including Tune-up Tolerance was declared by manufacturer. The 2.4G WLAN and BLE can transmit simultaneously. =P BLE / P th + P 2.4G WLAN / P th = 2.45/768 + 38.82/768 =0.054 < 1.0 Result: The device compliant the MPE-Based Exemption at 20cm distances.

AntennaSpecification Manufacture：TUYA ProductName：WBR3Antenna AntennaType：PCB TestDate：2021.05.20 Testedby：LongWang Approvedby：Licco Content 1.GeneralDescription.................................................................................1 2.TestConfigurations...................................................................................2 2.1TestEnvironment............................................................................2 2.2TestEquipment...............................................................................2 2.3TestPrinciple...................................................................................2 3.TestResults..............................................................................................3 3.1GainandEfficiency..........................................................................3 3.2RadiationPattern............................................................................4 4.AntennaDimensions................................................................................6 5.EUTPhoto................................................................................................6 6.TestSetupPhoto......................................................................................7 1 1.GeneralDescription ManufacturerHangzhouTuyaInformationTechnologyCo.,Ltd Address Room701,Building3,MoreCenter,No.87GuDunRoad, Hangzhou,Zhejiang,China TestLocation Room106,Building3,LetongSciencePark,No.500, QiuyiRoad,BinjiangDistrict,Hangzhou ProductNameWBR3Antenna Productmodel WBR3 AntennaType PCBAntenna TestItems Gain;Efficiency;RadiationPattern TestFrequency 2400-2500MHz TestStandard ANSI/IEEEStd149-1979 2 2.TestConfigurations 2.1TestEnvironment Temperature(°C)25 Humidity(%RH)60 AtmosphericPressure(kPa)100.5 2.2TestEquipment TestSystemTEM24Multi-probeMicrowaveChamber TestInstrumentAgilentE5071B 2.3TestPrinciple 3 3.TestResults 3.1GainandEfficiency Frequency(MHz)PeakGain(dBi)Efficiency(%) 2400 1.6252.29 2410 1.7152.17 2420 1.9353.14 2430 1.9854.16 2440 2.0057.62 2450 2.1759.64 2460 2.4561.55 2470 2.3860.64 2480 2.5462.86 2490 2.3059.85 2500 2.4960.41 4 3.2RadiationPattern Phi02D Phi902D 5 Theta902D 2480MHz3D 6 4.AntennaDimensions 5.EUTPhoto 7 6.TestSetupPhoto

TEST REPORT Applicant: Huizhou Dudu Pet Products Co., ltd Address: Floor 2/3/ 4, Building 2 District D Qiaosheng Industrial Park, Lilin Town,Huicheng District, Huizhou, China FCC ID: 2A55Q-DU4L-WA Product Name: Automatic Pet Feeder Standard(s): 47 CFR Part 15, Subpart C(15.247) ANSI C63.10-2013 KDB 558074 D01 15.247 Meas Guidance v05r02 The above equipment has been tested and found compliant with the requirement of the relative standards by China Certification ICT Co., Ltd (Dongguan) Report Number: CR230739372-00A Date Of Issue: 2023/9/4 Reviewed By: Calvin Chen Title: RF Engineer Approved By: Sun Zhong Title: Manager Test Laboratory: China Certification ICT Co., Ltd (Dongguan) No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China Tel: +86-769-82016888 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230739372-00A Page 2 of 46 Test Facility The Test site used by China Certification ICT Co., Ltd (Dongguan) to collect test data is located on the No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China. The lab has been recognized as the FCC accredited lab under the KDB 974614 D01 and is listed in the FCC Public Access Link (PAL) database, FCC Registration No. : 442868, the FCC Designation No. : CN1314. The lab has been recognized by Innovation, Science and Economic Development Canada to test to Canadian radio equipment requirements, the CAB identifier: CN0123. Declarations China Certification ICT Co., Ltd (Dongguan) is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with a triangle symbol “▲”. Customer model name, addresses, names, trademarks etc. are not considered data. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report cannot be reproduced except in full, without prior written approval of the Company. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report may contain data that are not covered by the accreditation scope and shall be marked with an asterisk “★”. China Certification ICT Co., Ltd (Dongguan) Report No.: CR230739372-00A Page 3 of 46 CONTENTS T EST FACILITY .......................................................................................................................................... 2 DECLARATIONS .......................................................................................................................................... 2 DOCUMENT REVISION HISTORY .......................................................................................... 5 1. GENERAL INFORMATION .................................................................................................... 6 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ....................................................... 6 1.2 DESCRIPTION OF TEST CONFIGURATION ........................................................................................... 7 1.2.1 EUT Operation Condition: ............................................................................................................................. 7 1.2.2 Support Equipment List and Details .............................................................................................................. 7 1.2.3 Support Cable List and Details ...................................................................................................................... 7 1.2.4 Block Diagram of Test Setup ......................................................................................................................... 8 1.3 MEASUREMENT UNCERTAINTY .......................................................................................................... 9 2. SUMMARY OF TEST RESULTS .......................................................................................... 10 3. REQUIREMENTS AND TEST PROCEDURES .................................................................. 11 3.1 AC LINE CONDUCTED EMISSIONS .................................................................................................... 11 3.1.1 Applicable Standard ..................................................................................................................................... 11 3.1.2 EUT Setup.................................................................................................................................................... 12 3.1.3 EMI Test Receiver Setup ............................................................................................................................. 12 3.1.4 Test Procedure ............................................................................................................................................. 13 3.1.5 Corrected Amplitude & Margin Calculation ................................................................................................ 13 3.2 RADIATION SPURIOUS EMISSIONS .................................................................................................... 14 3.2.1 Applicable Standard ..................................................................................................................................... 14 3.2.2 EUT Setup.................................................................................................................................................... 14 3.2.3 EMI Test Receiver & Spectrum Analyzer Setup ......................................................................................... 15 3.2.4 Test Procedure ............................................................................................................................................. 15 3.2.5 Corrected Amplitude & Margin Calculation ................................................................................................ 15 3.3 MINIMUM 6 DB BANDWIDTH .....................................…

Text truncated - open the document above for the full version.

TEST REPORT Applicant: Huizhou Dudu Pet Products Co., ltd Address: Floor 2/3/ 4, Building 2 District D Qiaosheng Industrial Park, Lilin Town,Huicheng District, Huizhou, China FCC ID: 2A55Q-DU4L-WA Product Name: Automatic Pet Feeder Standard(s): 47 CFR Part 15, Subpart C(15.247) ANSI C63.10-2013 KDB 558074 D01 15.247 Meas Guidance v05r02 The above equipment has been tested and found compliant with the requirement of the relative standards by China Certification ICT Co., Ltd (Dongguan) Report Number: CR230739372-00B Date Of Issue: 2023/9/4 Reviewed By: Calvin Chen Title: RF Engineer Approved By: Sun Zhong Title: Manager Test Laboratory: China Certification ICT Co., Ltd (Dongguan) No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China Tel: +86-769-82016888 China Certification ICT Co., Ltd (Dongguan) Report No.: CR230739372-00B Page 2 of 57 Test Facility The Test site used by China Certification ICT Co., Ltd (Dongguan) to collect test data is located on the No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China. The lab has been recognized as the FCC accredited lab under the KDB 974614 D01 and is listed in the FCC Public Access Link (PAL) database, FCC Registration No. : 442868, the FCC Designation No. : CN1314. The lab has been recognized by Innovation, Science and Economic Development Canada to test to Canadian radio equipment requirements, the CAB identifier: CN0123. Declarations China Certification ICT Co., Ltd (Dongguan) is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with a triangle symbol “▲”. Customer model name, addresses, names, trademarks etc. are not considered data. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report cannot be reproduced except in full, without prior written approval of the Company. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report may contain data that are not covered by the accreditation scope and shall be marked with an asterisk “★”. China Certification ICT Co., Ltd (Dongguan) Report No.: CR230739372-00B Page 3 of 57 CONTENTS T EST FACILITY .......................................................................................................................................... 2 DECLARATIONS .......................................................................................................................................... 2 DOCUMENT REVISION HISTORY .......................................................................................... 5 1. GENERAL INFORMATION .................................................................................................... 6 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ....................................................... 6 1.2 DESCRIPTION OF TEST CONFIGURATION ........................................................................................... 7 1.2.1 EUT Operation Condition: ............................................................................................................................. 7 1.2.2 Support Equipment List and Details .............................................................................................................. 7 1.2.3 Support Cable List and Details ...................................................................................................................... 7 1.2.4 Block Diagram of Test Setup ......................................................................................................................... 8 1.3 MEASUREMENT UNCERTAINTY .......................................................................................................... 9 2. SUMMARY OF TEST RESULTS .......................................................................................... 10 3. REQUIREMENTS AND TEST PROCEDURES .................................................................. 11 3.1 AC LINE CONDUCTED EMISSIONS .................................................................................................... 11 3.1.1 Applicable Standard ..................................................................................................................................... 11 3.1.2 EUT Setup.................................................................................................................................................... 12 3.1.3 EMI Test Receiver Setup ............................................................................................................................. 12 3.1.4 Test Procedure ............................................................................................................................................. 13 3.1.5 Corrected Amplitude & Margin Calculation ................................................................................................ 13 3.2 RADIATION SPURIOUS EMISSIONS .................................................................................................... 14 3.2.1 Applicable Standard ..................................................................................................................................... 14 3.2.2 EUT Setup.................................................................................................................................................... 14 3.2.3 EMI Test Receiver & Spectrum Analyzer Setup ......................................................................................... 15 3.2.4 Test Procedure ............................................................................................................................................. 15 3.2.5 Corrected Amplitude & Margin Calculation ........…

Text truncated - open the document above for the full version.
