名称 Awaken Max 英文说明书 8开16页 风折琴 100g铜版纸 四色印刷 工艺 80mmx80mm 尺寸 材质 印刷 Quick Start Guide MISHUAI Wear 1 When wearing the headset, ensure the "L" mark is on the left ear and the "R" mark is on the right ear. Adjust the headband length for a comfortable fit. Before charging, please ensure the USB port is completely dry. Connect the included charging cable to charge the headset， input: 5V 1A. Press the power button for 2 seconds to turn on the headset. The headset automatically enter Bluetooth pairing mode upon first connection. Select "Mishuai Awaken Max" from your device's Bluetooth list to establish a connection. The headset can connect to two devices simultaneously. With one device already connected, double-press the power button to pair with another device. Notes: 1. Incoming calls have the highest priority. 2. To switch music sources, pause the music on the current device and select playback on the second device. RL Charge 2 L R 1H Power on and pair 3 L 1 2 R Press for 2 seconds ON Mishuai Awaken Max Mishuai Awaken Max ON pairing 1S x5 connecting L 1 2 3 R pairing x5 connecting ON Mishuai Awaken Max Mishuai Awaken Max Mishuai Awaken Max double click ON Dual device connection 4 Note: For more personalized settings, open the Mishuai APP. To reduce ambient noise, please switch to noise cancellation via the ANC button (noise cancellation is off by default) and switch to other modes in the Mishuai app. To be aware of your surroundings while listening to music, switch to Transparency Mode using the ANC button and then switch to other modes in the Mishuai app. ·Transparency Mode: Emphasizes vocals within ambient sounds, making them clearer. Enable "One-to-Two" in the Mishuai app to connect two devices simultaneously, and enable LDAC/LHDC for superior sound quality. Note: 1. Only applicable to devices running Android 8.0 or later. 2. Dual devices and LDAC cannot coexist; either must be enabled or disabled. When playing music, use the Mishuai app to select your preferred sound effect mode. Press the (+) and (-) buttons simultaneously for 5 seconds until the LED flashes red and blue three times. Button control 5 Model：M3 Noise reduction 7 Transparency 8 High-quality audio decoding /dual device connection 9 x3 Long Press for 5 seconds 1 2 1 1 2 1 2 23 3EQ mode switching 10 Reset 11 Connect the 3.5mm AUX audio cable to play audio on external devices. Bluetooth mode will automatically turn off when listening via wired connection. A low battery warning tone plays once. ·This indicates the headset battery is low and you need to recharge the headset. No sound from the headset. ·Check if the headset is working. ·Check if the headset volume is appropriate. ·Check if the headset is properly connected to the phone. ·Check if the headset is within its normal operating range. Poor call quality from the headset. ·The headset's effective range is 15 meters. Please ensure the headset is within this range and there are no obstructions between the headset and the phone. ·Check if the microphone is blocked by dust or foreign objects. ·Check if the headset battery is too low; low battery will affect headset performance. Cable listening 6 AUX LR 3.5mm 0.243.24 Frequently Asked Questions 12 Customer Support Lifetime Technical Support Our warranty is a supplement to the legal rights enjoyed by consumers who purchase this product. to turn off ANC (default) Mode switch Single click Ambient sound Wind resistance and noise reduction Deep noise reduction Volume up Single click Power on Press for 2 seconds Press for 5 seconds Power off Pause Single click Play Voice assistant Single click Double click Single click Single click Double click X Answer call Hang up Reject call Next track Long press for 1.5 seconds Volume down Single click Previous track Long press for 1.5 seconds ·For products with lithium batteries, if not used for extended periods, please ensure they are charged at least once every three months. ·Keep the product dry; do not place it in a humid environment to avoid affecting the internal circuitry. ·Do not place the product in direct sunlight or high temperatures. High temperatures can shorten the lifespan of electronic components, damage the battery, and deform some plastic parts. ·Do not place the product in excessively cold environments to avoid damaging the internal circuit board. ·Do not attempt to disassemble the product. This may damage the product if not done by a professional. ·Do not drop, subject to strong vibrations, or impacts from hard objects to avoid damaging the internal circuitry. ·Do not use harsh chemicals or cleaning agents to clean the headphones. ·Do not scratch the product surface with sharp objects to avoid damaging the casing and affecting its appearance. Maintenance and Repair 13 ·Please store the headsets in a cool, dry place at room temperature. Prolonged exposure to sunlight, humidity, sealed environments, and high temperatures will accelerate oxidation and material wear. ·After use, if there are sweat stains, oil stains, or other liquids, wipe them clean with a cotton cloth dampened with diluted alcohol and store them in a ventilated place to prevent the ear tips from staining, deforming, hardening, and decomposing, thus shortening their lifespan. ·When not in use, please place the headsets in the headset case or hang them on a headphone stand to avoid damaging the ear tips. ·Avoid excessive stretching of the ear tips, as this will deform them and affect wearing comfort. ·Please clean them regularly, using a soft cloth or small brush to gently wipe away liquids and dirt from the ear tips. ·Proper maintenance will keep the ear tips in good condition, extend their lifespan, and improve sound quality and comfort. Leather ear tips usage precautions and maintenance methods 14 FCC ID: 2A58W-M3 Scan to activate 2-year warranty Scan the QR code to download the Mishuai APP M3 FCC Caution This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: …
