2A59C-A102Bluetooth Headset

Bluetooth Headset User Manual A102 Contents Product Overview Basic Operation Bluetooth Pairing and Connection Connection with Two devices LED Indicator Charging Product Specification Attention and Q & A 1. 2. 3. 4. 5. 6. 7. 8. 2 3 4 5 6 7 8 9 1 - EN 1.Product Overview A.Bluetooth Headset A102 X 1 B.Micro USB charging cable x 1 C.User manual x 1 Package Contents: Volume - / Previous Song Volume + /Next Song LED Indicator Multi-Function Button (MFB) ABC Microphone Micro-USB Charge Port 2 - EN A102 Mono Bluetooth Headset User Manual A102 2.Basic Operation Button Function Operation Button Volume + Volume - Power OnIn off status,Long press MFB for 3 seconds to power on. Power OffIn on status,Long press MFB for 5 seconds to power off. Enter Pairing Mode In off status,long press MFB for 5 seconds to enter pairing mode. Play/PauseShort press when play music. Redial A CallIn connected status,double press MFB to dial the last call. Answer A CallWhen a call incoming,short press to answer Volume UpShort press. Volume Down Short press. Next SongLong press for 1 second. Previous Song Long press for 1 second. Reject A CallWhen a call incoming, long press for 1 second to reject a call. Microphone Mute When during a call, double press to mute, double press again to cancel Hang Up A Call When during a call, short press to hang up Voice Dialing In connected status, long press MFB for 3 second then release. Audio Switch When during a call, long press for 1 second MFB then release. 3 - EN 3.Bluetooth Pairing and Connection In off status, long press MFB for 5 seconds to enter pairing mode with Blue & Red LED flash alternately. Search and click to connect”A102" on your phone Bluetooth lists, LED change to Blue slow flash once every 10 seconds after connected, now you can play music from phone to headphone. You can press MFB / volume+ / volume- on the Bluetooth headset to control the answer/hang up a call and play/pause of the music, next and previous song, volume up and down. In off status, long press MFB for 5 seconds to enter pairing mode with Blue & Red LED flash alternately. A. B. C. 1 Pairing Search and click to connect “A102”On your phone Bluetooth lists, LED change to Blue slow flash once every 10 seconds after connected. 2 Connection Search and Connect 4 - EN 4.Connection with Two devices Follow part 3 to connect with first phone, then turn off the Bluetooth function of first phone. Turn off the headset then long press MFB for 5 seconds to enter pairing mode again with Red & Blue LED flash alternately. Tum on the Bluetooth function of second phone to search and connect “A102", LED change to Blue flash once every 10 seconds. Turn on Bluetooth function of second phone, click to reconnect “A102" on Bluetooth lists. LED change to Blue slow flash after connected. Turn on Bluetooth function of first phone, click to reconnect “A102" on Bluetooth lists. Headset is connected with two phones now. Notes : Music only can be played from one phone under two connections, when you want to play music from another phone, you need to pause or turn off the music of the previous phone. The same operation during talking status. A. B. C. D. 5 - EN 5.LED Indicator ModeLED Indicator Power on Power off Blue LED flash 3 times Red LED is on for 1 second Pairing mode Red & Blue LED flash alternately Reconnect mode Blue LED flash twice every 5 seconds Connected standby mode LED Blue flash once every 10 seconds Playing Music LED Blue flash twice every 10 seconds Talking LED Blue flash twice every 10 seconds Charging Solid Red LED Full charged Solid Blue LED Low batteryRed LED flash 6 - EN 6.Charging Charging with ChargerCharging with PC Notes : Please charge the A102 at least one time every 2 months when don't use it. Plug charging cable for charging when power on, will reset the headset and power off. 1. 2. Please charge the A102 at once when the Red LED flash. Charging time is about 2 hours. Red LED turn off and blue LED turn on when full charged. Charge Connections Please connect to the A102 charging port through the Micro USB end of Micro USB charging cable, the USB end to the charger as car charger, travel charger, computer USB, etc. 7 - EN 7.Product Specification Bluetooth Version Bluetooth Chipset V5.1 QCC3020 Operation Range 10 meters Battery Capacity 180mAh/3.7V Charging Time About 2 hours Standby Time About 160 hours Music Time About 13 hours Talking Time About 11 hours Working Temperature -10- 55°C Notes : Actual use time will differ from environment and music* 8 - EN 8.Attentions and Q & A A. How to reconnect and operation when failed to reconnect? When A102 connected with your mobile phone successfully at the first time, it will search and reconnect the paired device automatically when power on, If failed, please pair and connect again. B. How to delete paired records? In power on status, long press the Volume - and Volume + for 5 seconds to clear the pairing record. Blue and Red LED flash once at the same time that means the pairing record has been cleared, and the A102 will not connect the connected device. When there are various connection problem, try clearing the pairing record firstly. C. What devices could charge for the headphone? Any car charger, power bank, PC etc which meet DC 5V , charging current more than 500mA could be charge for this item. D. How to do if can not power on or dead? Please try charging reset: Plug the charging cable when power on, it will reset the headset and power off. 9 - EN Inhaltsangabe Produktübersicht Grundlegende Bedienung Bluetooth-Kopplung und Verbindung Gleichzeitiges Verbinden mit zwei Geräten LED-Anzeige Aufladen Produktspezifikation Hinweis und F&A 1. 2. 3. 4. 5. 6. 7. 8. 11 12 13 14 15 16 17 17 10 - DE 1.Produktübersicht A. Bluetooth Kopfhörer A102 x1 B. Micro-USB-Ladekabel x1 C. Bedienungsanleitung x1 Paketumfang: Lautstärke - / Vorheriger Titel Lautstärke + / Nächster Titel LED-Anzeige Multifunktionstaste (MFB) ABC Mikrofon Micro-USB Ladeschnittstellle 11 - DE A102 Mono Bl…

Text truncated - open the document above for the full version.

5.Indicador LED ModoIndicador LED Encendido Apagado LED azul parpadea 3 veces El LED rojo está encendido durante 1 segundo Modo de emparejamiento LED rojo y azul parpadean alternativamente Modo de reconexión El LED azul parpadea dos veces cada 5 segundos Modo de espera conectado El LED azul parpadea una vez cada 10 segundos Tocando musica LED azul parpadea dos veces cada 10 segundos Hablando LED azul parpadea dos veces cada 10 segundos Cargando LED rojo fijo Cargado por completo LED azul fijo Batería bajaFlash LED rojo 24 - SP 6.Carga Cargando con Cargador Carga con ordenador personal Notas: Cargue el A102 al menos una vez cada 2 meses cuando no lo use. Enchufe el cable de carga para cargar cuando se enciende, reiniciará el auricular y se apagará. 1. 2. Cargue el A102 inmediatamente cuando el LED rojo parpadee. El tiempo de carga es de aproximadamente 2 horas. El LED rojo se apaga y el LED azul se enciende cuando está completamente cargado. Conexiones de carga Conéctelo al puerto de carga A102 a través del extremo Micro USB del cable de carga Micro USB, el extremo USB al cargador como cargador de automóvil, cargador de viaje, USB de computadora, etc. 25 - SP 7.Especificación del producto Versión de Bluetooth Chipset de Bluetooth V5.1 QCC3020 Rango de operación 10 metros Capacidad de la batería 180 mAh / 3,7 V Tiempo de carga Alrededor de 2 horas Tiempo de espera Aproximadamente 160 horas Tiempo de música Aproximadamente 13 horas Tiempo hablando Aproximadamente 11 horas Temperatura de trabajo -10- 55°C Notas: El tiempo de uso real diferirá del entorno y la música.* 26 - SP 8.Atenciones y preguntas y respuestas A. ¿Cómo volver a conectar y operar cuando no se pudo volver a conectar? Cuando A102 se conectó correctamente con su teléfono móvil por primera vez, buscará y volverá a conectar el dispositivo emparejado automáticamente cuando se encienda. Si falla, empareje y vuelva a conectar. B. ¿Cómo eliminar registros emparejados? En el estado de encendido, mantenga presionado Volumen - y Volumen + durante 5 segundos para borrar el registro de emparejamiento. Los LED azul y rojo parpadean una vez al mismo tiempo, lo que significa que el registro de emparejamiento se ha borrado y el A102 no conectará el dispositivo conectado. Cuando haya varios problemas de conexión, primero intente borrar el registro de emparejamiento. C. ¿Qué dispositivos podrían cobrar por los auriculares? Cualquier cargador de automóvil, banco de energía, PC, etc.que cumpla con DC 5V, corriente de carga superior a 500mA podría cargarse por este artículo. D. ¿Cómo se hace si no se enciende o se apaga? Intente reiniciar la carga: conecte el cable de carga cuando se encienda, reiniciará el auricular y se apagará. 27 - SP Contenuti Panoramica del Prodotto Operazione base Associazione e connessione Bluetooth Connessione con due dispositivi Indicatore LED In carica Specifiche di prodotto Attenzione e domande e risposte 1. 2. 3. 4. 5. 6. 7. 8. 29 30 31 32 33 34 35 36 28 - IT 1.Panoramica del prodotto Volume - /Canzone precedente Volume + /Prossima canzone Indicatore LED Pulsante multifunzione (MFB) ABC Microfono Porta di ricarica micro-USB 29 - IT A102 Mono Bluetooth Headset User Manual A102 A. Auricolare Bluetooth A102 X 1 B. Cavo di ricarica micro USB x 1 C. Manuale dell'utente x 1 Contenuto del pacco: 30 - IT 2.Operazione di base Pulsante FunzioneOperazione Pulsante Volume + Volume - AccensioneIn stato spento, premere a lungo MFB per 3 secondi per accendere. SpegniIn stato acceso, premere a lungo MFB per 5 secondi per spegnere. Entra in abbinamento Modalità In stato spento, premere a lungo MFB per 5 secondi per accedere all'associazione modalità. Play pausaPremere brevemente quando si riproduce la musica. Ricomponi una chiamata In stato connesso, premere due volte MFB per comporre l'ultima chiamata. Rispondi a una chiamata Quando una chiamata in arrivo, premere brevemente per rispondere Volume su Pressione breve. Volume bassoPressione breve. Prossima canzone Premere a lungo per 1 secondo. Canzone precedente Premere a lungo per 1 secondo. Rifiuta una chiamata Quando una chiamata in arrivo, premere a lungo per 1 secondo per rifiutare a chiamata. Microfono Muto Durante una chiamata, premere due volte per disattivare l'audio, premere due volte di nuovo per annullare Riaggancia A Chiamata Durante una chiamata, premere brevemente per riagganciare La composizione vocale In stato connesso, premere a lungo MFB per 3 secondi, quindi pubblicazione. Interruttore audio Durante una chiamata, premere a lungo per 1 secondo MFB quindi pubblicazione. 31 - IT 3.Associazione e connessione Bluetooth In stato spento, premere a lungo MFB per 5 secondi per accedere alla modalità di associazione con il LED blu e rosso che lampeggia alternativamente. Cerca e fai clic per connettere "A102" sugli elenchi Bluetooth del tuo telefono, il LED cambia in blu lampeggiante lento una volta ogni 10 secondi dopo la connessione, ora puoi riprodurre musica dal telefono alle cuffie. Voi puoi premere MFB / volume + / volume- sull'auricolare Bluetooth per controllare la risposta / riagganciare una chiamata e riprodurre / mettere in pausa la musica, il brano successivo e precedente, il volume su e giù. In stato spento, premere a lungo MFB per 5 secondi per accedere alla modalità di associazione con il LED blu e rosso che lampeggia alternativamente. A. B. C. 1 Accoppiamento Cerca e fai clic per connettere "A102" Negli elenchi Bluetooth del telefono, il LED cambia in blu lampeggia lentamente una volta ogni 10 secondi dopo la connessione. 2 Connessione Cerca e connetti 4. Connessione con due dispositivi Segui la parte 3 per connetterti con il primo telefono, quindi disattiva la funzione Bluetooth del primo telefono. Spegnere l'auricolare, quindi premere a lungo MFB per 5 secondi per accedere nuovamente alla modalità di associazione con i LED rosso e blu che lampeggiano alternativamente. Attivare la funzione Bluetooth del secondo telefono per cercare e collegare "A102", il LED…

Text truncated - open the document above for the full version.

Guangzhou H & F Electronics Technology Co., Ltd. Agent Authorization Company: Guangzhou H & F Electronics Technology Co., Ltd. Address: Room 101, Building 5, No.481, Tainan Road, Nansha District, Guangzhou, China Product Name: Bluetooth Headset Trade Mark: N/A Model Number(s): A102, DT628 FCC ID: 2A59C-A102 We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2022-04-25 Name: David Xi Title: sales Company: Guangzhou H & F Electronics Technology Co., Ltd.

Guangzhou H & F Electronics Technology Co., Ltd. Address: Room 101, Building 5, No.481, Tainan Road, Nansha District, Guangzhou, China Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Dear Sir/Madam, We, Guangzhou H & F Electronics Technology Co., Ltd. Hereby declares the following statement: PCB board, structure and internal of these model(s) are the same, Only models name is different for these models: Product Name: Bluetooth Headset Trade Mark: N/A Model Number(s): A102, DT628 FCC ID: 2A59C-A102 Signature: Date: 2022-04-25 Name: David Xi Title: sales Company: Guangzhou H & F Electronics Technology Co., Ltd.

Guangzhou H & F Electronics Technology Co., Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2022-04-25 Subject; Request for Confidentiality FCC ID: 2A59C-A102 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: David Xi Title: sales

Page 1 of 3 FCC ID: 2A59C-A102 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity External Photos of the EUT Fig. 1 Fig. 2 Page 2 of 3 FCC ID: 2A59C-A102 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 3 FCC ID: 2A59C-A102 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6

Page 1 of 1 FCC ID: 2A59C-A102 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity LABEL AND LOCATION (Size: L1.5cm x 1.0cm) Label Location Bluetooth Headset Model: A102 FCC ID: 2A59C-A102

Page 1 of 2 FCC ID: 2A59C-A102 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Internal Photos of the EUT Fig. 1 Fig. 2 Page 2 of 2 FCC ID: 2A59C-A102 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 BT ANT

Page 1 of 4 FCC ID: 2A59C-A102 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC RF Exposure Evaluation 1. Product Information FCC ID : 2A59C-A102 Product name : Bluetooth Headset Test Model : A102 Additional Model : DT628 Model Declaration : PCB board, structure and internal of these model(s) are the same, So no additional models were tested Power Supply : Input: DC 5V DC 3.7V by Rechargeable Li-ion Battery, 180mAh Hardware Version : V1.0 Software Version : V003 Bluetooth : 2402MHz ~ 2480MHz Channel Number : 79 channels for Bluetooth V5.1 (DSS) 40 channels for Bluetooth V5.1 (DTS) Channel Spacing : 1MHz for Bluetooth V5.1(DSS) 2MHz for Bluetooth V5.1(DTS) Modulation Type : GFSK , π/4-DQPSK, 8-DPSK for Bluetooth V5.1 (DSS) GFSK for Bluetooth V5.1 (DTS) Bluetooth Version : V5.1 Antenna Type : Ceramics Antenna Antenna Gain : 3.5dBi Exposure category : General population/uncontrolled environment EUT Type : Production Unit Device Type : Portable Device 2. Evaluation method and Limit According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before Page 2 of 4 FCC ID: 2A59C-A102 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.“ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to f) in section 4.1 is applied to determine SAR test exclusion. When one of the following test exclusion conditions is satisfied for all combinations of simultaneous transmission configurations, further equipment approval is not required to incorporate transmitter modules in host devices that operate in the mixed mobile and portable host platform exposure conditions. The grantee is responsible for documenting this according to Class I permissive change requirements. Antennas that qualify for standalone SAR test exclusion must apply the estimated standalone SAR to determine simultaneous transmission test exclusion. a) The [∑ of (the highest measured or estimated SAR for each standalone antenna configuration, adjusted for maximum tune-up tolerance) / 1.6 W/kg] + [∑ of MPE ratios] is ≤ 1.0. b)The SAR to peak location separation ratios of all simultaneously transmitting antenna pairs operating in portable device exposure conditions are all ≤ 0.04, and the [∑ of MPE ratios] is ≤ 1.0. 3. Refer Evaluation Method ANSI C95.1–1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. FCC KDB publication 447498 D01 General RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1093: Radiofrequency radiation exposure evaluation: portable devices Page 3 of 4 FCC ID: 2A59C-A102 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 4. Conducted Power Results <BT> Mode Channel Frequency (MHz) Peak Conducted Output Power (dBm) GFSK 0 2402 -0.6 39 2441 0.31 78 2480 0.3 π/4…

Text truncated - open the document above for the full version.

Page 1 of 52 FCC ID: 2A59C-A102 Report No.: LCS220407046AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Appendix A RF Test Data for BT (Conducted Measurement) Product Name: Bluetooth Headset Test Model: A102 Environmental Conditions Temperature: 23.5  C Relative Humidity: 52.2% ATM Pressure: 100.0 kPa Test Engineer: Jack Cheng Supervised by: Li huan Page 2 of 52 FCC ID: 2A59C-A102 Report No.: LCS220407046AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity A.1 20dB Emission Bandwidth Test Result TestMode Antenna Channel 20db EBW[MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict DH5 Ant 2402 1.038 2401.463 2402.501 No Limit Pass 2441 1.020 2440.478 2441.498 No Limit Pass 2480 1.041 2479.457 2480.498 No Limit Pass 2DH5 Ant 2402 1.299 2401.355 2402.654 No Limit Pass 2441 1.320 2440.334 2441.654 No Limit Pass 2480 1.287 2479.361 2480.648 No Limit Pass 3DH5 Ant 2402 1.287 2401.349 2402.636 No Limit Pass 2441 1.305 2440.343 2441.648 No Limit Pass 2480 1.287 2479.349 2480.636 No Limit Pass Page 3 of 52 FCC ID: 2A59C-A102 Report No.: LCS220407046AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Test Graphs DH5_Ant_2402 DH5_Ant_2441 DH5_Ant_2480 Page 4 of 52 FCC ID: 2A59C-A102 Report No.: LCS220407046AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 2DH5_Ant_2402 2DH5_Ant_2441 Page 5 of 52 FCC ID: 2A59C-A102 Report No.: LCS220407046AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 2DH5_Ant_2480 3DH5_Ant_2402 Page 6 of 52 FCC ID: 2A59C-A102 Report No.: LCS220407046AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 3DH5_Ant_2441 3DH5_Ant_2480 Page 7 of 52 FCC ID: 2A59C-A102 Report No.: LCS220407046AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 8 of 52 FCC ID: 2A59C-A102 Report No.: LCS220407046AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity A.2 Maximum conducted output power Test Result TestMode Antenna Channel Result[dBm] Limit[dBm] Verdict DH5 Ant 2402 -0.6 ≤20.97 PASS 2441 0.31 ≤20.97 PASS 2480 0.3 ≤20.97 PASS 2DH5 Ant 2402 -0.37 ≤20.97 PASS 2441 0.1 ≤20.97 PASS 2480 0.14 ≤20.97 PASS 3DH5 Ant 2402 -0.22 ≤20.97 PASS 2441 0.29 ≤20.97 PASS 2480 0.26 ≤20.97 PASS Page 9 of 52 FCC ID: 2A59C-A102 Report No.: LCS220407046AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Test Graphs DH5_Ant_2402 DH5_Ant_2441 DH5_Ant_2480 Page 10 of 52 FCC ID: 2A59C-A102 Report No.: LCS220407046AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 2DH5_Ant_2402 2DH5_Ant_2441 Page 11 of 52 FCC ID: 2A59C-A102 Report No.: LCS220407046AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 2DH5_Ant_2480 3DH5_Ant_2402 Page 12 of 52 FCC ID: 2A59C-A102 Report No.: LCS220407046AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 3DH5_Ant_2441 3DH5_Ant_2480 Page 13 of 52 FCC ID: 2A59C-A102 Report No.: LCS220407046AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 14 of 52 FCC ID: 2A59C-A102 Report No.: LCS220407046AEA Shenzhen LCS…

Text truncated - open the document above for the full version.

Page 1 of 36 FCC ID: 2A59C-A102 Report No.: LCS220407046AEA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC TEST REPORT FOR Guangzhou H & F Electronics Technology Co., Ltd. Bluetooth Headset Test Model: A102 Additional Model No.: DT628 Prepared for : Guangzhou H & F Ele…
