2A5RP-NX16LAPTOP

Hardware Configuration Precautions For Use CPU RAM Storage Display Input Wi-Fi os Language Intel Alder Lake-N95 16GB DDR4 3200 512GB M.2 SATA 2280 16 inch 16:10 LCD 12V 3A 802.11a/b/g/n/ac Bluetooth Charging 4.2 Red/Green Windows 11 Pro Multi-Language * Computers are precision electronic instruments, please do not disassemble by yourself. * Avoid using device in high temperature, low temperature, humidity, dust,strong magnetic field and long time exposure to sunlight. * Check for any frayed or damaged cords or plugs . *Please use original battery, charger and other accessories. The use of any othertype of accessories will violate the warranty and may cause the equipment tomalfunction. * Do not use harsh of chemical solvent , cleaning products , we recommendusing a soft cloth to wipe . * Dispose of waste machinery and accessories in accordance with local environmental regulations. * Please keep plastic packaging bags out of reach of infants and children to prevent the risk of suffocation . * Use this product at temperatures ranging from 0C to 35C and store it at temperatures ranging from -10C to +45C. * The power plug serves as a disconnecting device, and for pluggable devices, the power outlet should be mounted near the product and should be easy to operate When the device is not used for a long period of time, disconnect the power adapter from the device and unplug the power adapter from the power outlet. * Use of unapproved or incompatible power supplies, power adapters or batteries may cause fire, explosion or other hazards. * Risk of fire or explosion if the battery is replaced with an incorrect model Do not expose the battery to high temperatures or around heat-generating products, such as sunlight, heaters, microwaves, ovens, or water heaters. Overheating of the battery may cause an explosion. * Do not throw the battery into a fire as this may cause the battery to catch fire and explode. * Do not drop, crush or puncture the battery. Avoid subjecting the battery to large external pressures that could cause internal short circuiting and overheating. * Do not disassemble or modify the battery, insert foreign objects, or immerse it in water or other liquids, as this may cause the battery to leak, overheat, catch fire, or explode. * Do not cover ventilation holes, and this product is not intended to be used on soft supports (e.g., bedding, blankets, etc.). * This device utilizes a non-removable internal battery, do not replace the battery yourself as this may result in the device not functioning properly or the battery being damaged. * To prevent data loss, we recommend that you back up your device during daily use, before upgrading it, or before sending it in for repair. Do not use the power adapter in wet locations (such as near an allied sink, bathtub, or shower room), and do not plug or unplug the power adapter with wet hands. * Keep the device and its accessories dry. Do not use external heating devices such as microwave ovens or hair dryers to dry them. * Do not subject the appliance and its ac . Warning Camera Fingerprint Power Touchpad USB DC HDMI Display Screen Keyboard Headphone SD card Type - C 1 2 3 System Information LAPTOP User Manual Manuel de l'utilisateur Benutzerhandbuch Manuale d'uso Manual del usuario ユーザーマニュアル Руководство пользователя ليلد مدختسملا Product Description Configuration du matériel Précautions d'emploi CPU RAM Stockage Affichage Entrée Wi-Fi os Langue Intel Alder Lake-N95 16GB DDR4 3200 512GB M.2 SATA 2280 16 inch 16:10 LCD 12V 3A 802.11a/b/g/n/ac Bluetooth Chargement 4.2 Rouge/vert Windows 11 Pro Multi-langues * Les ordinateurs sont des instruments électroniques de précision, ne les démontez pas vous-même. * Évitez d'utiliser l'appareil à des températures élevées ou basses, à l'humidité, à la poussière, à un champ magnétique puissant et à une exposition prolongée à la lumière du soleil. champ magnétique fort et une exposition prolongée à la lumière du soleil. * Vérifiez que les cordons et les fiches ne sont pas effilochés ou endommagés. *Veuillez utiliser la batterie, le chargeur et les autres accessoires d'origine. L'utilisation de tout autre type d'accessoires L'utilisation de tout autre type d'accessoires enfreint la garantie et peut entraîner le dysfonctionnement de l'appareil. * N'utilisez pas de solvants chimiques agressifs, de produits de nettoyage, nous vous recommandons d'utiliser un chiffon doux pour essuyer. Nous recommandons d'utiliser un chiffon doux pour essuyer. * Eliminez les déchets de l'appareil et des accessoires conformément aux réglementations locales en matière d'environnement. de l'environnement. * Les sacs d'emballage en plastique doivent être conservés hors de portée des enfants et des nourrissons afin d'éviter tout risque de suffocation. le risque de suffocation. * Utilisez ce produit à des températures comprises entre 0C et 35C et stockez-le à des températures comprises entre -10C et +45C. * Lorsque l'appareil n'est pas utilisé pendant une longue période, déconnectez l'adaptateur d'alimentation de l'appareil et débran- chez l'adaptateur d'alimentation de la prise de courant. * L'utilisation de blocs d'alimentation, d'adaptateurs d'alimentation ou de batteries non approuvés ou incompatibles peut provoquer un incendie, une explosion ou d'autres dangers. * Risque d'incendie ou d'explosion si la batterie est remplacée par un modèle incorrect N'exposez pas la batterie à des températures élevées ou à proximité de produits générant de la chaleur, tels que le soleil, les radiateurs, les micro-ondes, les fours ou les chauffe-eau. La surchauffe de la batterie peut provoquer une explosion. * Ne jetez pas la batterie dans le feu, car elle pourrait s'enflammer et exploser. * Ne faites pas tomber, n'écrasez pas et ne perforez pas la batterie. Évitez de soumettre la batterie à des pressions externes impor- tantes qui pourraient provoquer un court-circuit interne et une surchauffe. * Ne démontez pas ou ne modifiez pas la batterie, n'y insérez…

Text truncated - open the document above for the full version.

Covered Equipment Identification Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(5)(ii) of the Commission’s Rules (47 C.F.R.) we attest as follows: We, applicant Company Name: Shenzhen Borui Zhitong Technology Co., LTD Address: Room 501, Building 1, Nanling Science Park, No.7 jianmin Road, Nanwan Street, Longgang District, Shenzhen, China Phone: +86-13538218145 certify that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. FCC ID: 2A5RP-NX16 If you have any questions, please feel free to contact us at the address shown below. Sincerely, Signature Date:2024-07-04 Name / Title: JINBO HU / General Manager Company: Shenzhen Borui Zhitong Technology Co., LTD Address: Room 501, Building 1, Nanling Science Park, No.7 jianmin Road, Nanwan Street, Longgang District, Shenzhen, China Phone: +86-13538218145 Fax: N/A E-Mail: [email protected]

Covered Equipment Attestation Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(5)(i)-(ii) of the Commission’s Rules (47 C.F.R.) we attest as follows for the product listed below: FCC ID Model name 2A5RP-NX16 NX16 We, applicant Company Name: Shenzhen Borui Zhitong Technology Co., LTD Address: Room 501, Building 1, Nanling Science Park, No.7 jianmin Road, Nanwan Street, Longgang District, Shenzhen, China Phone: +86-13538218145 certify that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If you have any questions, please feel free to contact us at the address shown below. Sincerely, Signature Date:2024-07-04 Name / Title: JINBO HU / General Manager Company: Shenzhen Borui Zhitong Technology Co., LTD Address: Room 501, Building 1, Nanling Science Park, No.7 jianmin Road, Nanwan Street, Longgang District, Shenzhen, China Phone: +86-13538218145 Fax: N/A E-Mail: [email protected]

Confidentiality Request Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we request confidentiality for the documentation of the following products: FCC ID Model name 2A5RP-NX16 NX16 For the products listed above, we request permanent confidentiality for all applicable exhibits as there are: • the Operational Description • the Block Diagram • the Schematics • the Part List • the Tune up Information The above listed exhibits contain trade secrets and proprietary information that could be of benefit to our competitors. If you have any questions, please feel free to contact us at the address shown below. Sincerely, Signature Date:2024-07-04 Name / Title: JINBO HU / General Manager Company: Shenzhen Borui Zhitong Technology Co., LTD Address: Room 501, Building 1, Nanling Science Park, No.7 jianmin Road, Nanwan Street, Longgang District, Shenzhen, China Phone: +86-13538218145 Fax: N/A E-Mail: [email protected]

Page 1 of 1 Rev.2.0 Shenzhen Borui Zhitong Technology Co., LTD WIFI Channel 12 and 13 Declaration Letter We declare the equipment identified below with regards to Channel 12 and 13 capabilities for FCC ID: 2A5RP-NX16 Declaration Product hardware does not have the capability to operate on Channel 12 and 13. Product hardware has the capability to operate on Channel 12 and 13. However, these two channels will be disabled via software and will not be accessible to user. Product hardware has the capability to operate on Channel 12 and 13. However, all the operated channels can’t be changed in the RF parameter via software. All channels have complied with all of the requirements sets out in FCC Part 15.247. Product hardware has the capability to operate on WiFi Channel 12 and 13, and meets the requirements of KDB 594280 D01 v02r01. Please note: 1.) By default, this device operates in a mode that is compliant with the U.S. requirements. 2.) This device will also use supplemental information such as geo- location data to determine that it is operating outside the U.S., if necessary, to change its power. Such supplemental data will be derived from the following: Global Navigation Satellite System (GNSS)7 sensors in the device Mobile Country Code (MCC),8 or MCC with a Mobile Network code (MNC), received from a CMRS9 carrier and received directly by a receiver on the device Country information derived from multiple adjacent access points (for example using IEEE Std 802.11d provisions) may be permitted on case-by-case basis Other suitable geo-location data based on IP addresses or other reliable source. Name / Title: JINBO HU / General Manager Signature: Phone: +86-13538218145 Email: [email protected] Date: 2024-07-04

FCC ID: 2A5RP-NX16 Fig. 1 Fig. 2 FCC ID: 2A5RP-NX16 Fig. 3 Fig. 4 FCC ID: 2A5RP-NX16 Fig. 5 Fig. 6 FCC ID: 2A5RP-NX16 Fig. 7 Fig. 8 FCC ID: 2A5RP-NX16 Fig. 9 Fig. 10 FCC ID: 2A5RP-NX16 Fig. 11 Fig. 12

_____________________________________________________________________________________________________ LABEL AND LOCATION (Size: L5.0cm x 3.0cm) Label Location

FCC ID: 2A5RP-NX16 Fig. 1 Fig. 2 FCC ID: 2A5RP-NX16 Fig. 3 Fig. 4 FCC ID: 2A5RP-NX16 Fig. 5 Fig. 6 FCC ID: 2A5RP-NX16 Fig. 7 Fig. 8 FCC ID: 2A5RP-NX16 Fig. 9 Fig. 10 FCC ID: 2A5RP-NX16 Fig. 11 Fig. 12 FCC ID: 2A5RP-NX16 Fig. 13 Fig. 14 FCC ID: 2A5RP-NX16 Fig. 15 Fig. 16 FCC ID: 2A5RP-NX16 Fig. 17 Fig. 18 2.4GWLAN Antenna BT&5GWLAN Antenna

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‟an District, Shenzhen, China RF Exposure evaluation Report Reference No. .................... : FCC ID. ............................................ : CTA24050902505 2A5RP-NX16 Compiled by ( position+printed name+signature) .. : File administrators Jinghua Xiao Supervised by ( position+printed name+signature) .. : Test Engineer Lushan Kong Approved by ( position+printed name+signature) .. : Manager Eric Wang Date of issue ..................................... : May.21, 2024 Representative Laboratory Name : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................. : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao„an District, Shenzhen, China Applicant’s name ............................ : Shenzhen Borui Zhitong Technology Co., LTD Address ............................................. : Room 501, Building 1, Nanling Science Park, No.7 jianmin Road, Nanwan Street, Longgang District, Shenzhen, China Test specification .......................... : Standard ........................................... : 47CFR §1.1310 47CFR §2.1093 KDB447498 D01 General RF Exposure Guidance v06 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ....................................... : Dated 2014-12 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : LAPTOP Trade Mark ....................................... : N/A Manufacturer ..................................... : Shenzhen Borui Zhitong Technology Co., LTD Model/Type reference ....................... : NX16 Listed Models ................................... : N/A Exposure category ............................ : General population/uncontrolled environment EUT Type .......................................... : Portable Hardware Version ............................ : N/A Software Version .............................. : N/A Rating ............................................... : DC 12.0V/3.0A by Adapter Result ................................................ : PASS Report No.: CTA24050902505 Page 2 of 13 T E S T R E P O R T Test Report No. : CTA24050902505 May. 21, 2024 ______________________________________________________________________________________________ Date of issue Equipment under Test : LAPTOP Model /Type : NX16 Listed model : N/A Applicant : Shenzhen Borui Zhitong Technology Co., LTD Address : Room 501, Building 1, Nanling Science Park, No.7 jianmin Road, Nanwan Street, Longgang District, Shenzhen, China Manufacturer : Shenzhen Borui Zhitong Technology Co., LTD Address : Room 501, Building 1, Nanling Science Park, No.7 jianmin Road, Nanwan Street, Longgang District, Shenzhen, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA24050902505 Page 3 of 13 Contents 1. S U M M A R Y .................................................................................. 4 1.1. Product Description .................................................................................................................................... 4 2. T E S T E N V I R O N M E N T ................................................................... 5 2.1. Address of the test laboratory ................................................................................................................... 5 2.2. Test Facility .................................................................................................................................................. 5 2.3. Environmental conditions .......................................................................................................................... 5 2.4. Statement of the measurement uncertainty ............................................................................................. 5 3 . M E T H O D O F M E A S U R EM E N T ......................................................... 6 3.1. Applicable Standard .................................................................................................................................... 6 3.2. Evaluation Method and Limit...................................................................................................................... 6 4. C O N D U C T E D P O W E R R E S U L T S ...................................................... 7 5. M A N U F A C T U R I N G T O L E R ANCE ...................................................... 9 6 . E V A L U A T I O N R E S U L TS ............................................................... 11 6.1. Standalone Evaluation .............................................................................................................................. 11 6.2 Simultaneous Transmission MPE ............................................................................................................. 12 7. C O N C L U S I O N ............................................................................ 13 Report No.: CTA24050902505 Page 4 of 13 1. S U M M A R Y 1.1. Product Description Product Name: LAPTOP Trade Mark: N/A Model/Type reference: NX16 List Model: N/A Model Declaration N/A Power supply: DC 12.0V/3.0A by Adapter Hardware Version N/A Software Version N/A Sample ID CTA240509025-S0001-1# & CTA240509025-S0001-2# Bluetooth Frequency Range 2402MHz ~ 2480M…

Text truncated - open the document above for the full version.

深圳市亿圣邦科技有限公司第 1 页 深圳卓创智能科技有限公司 供应商名称：深圳市亿圣邦科技有限公司 卓创机型：ANB12 卓创料号： 物料型号：WIFIMAIN:SLK-ZC-T3010A-L-140IV-B WIFIAUX:SLK-ZC-T3010A-L-150IV-G 送样日期：2023-11-21 备注： 承认书一式三份签字盖章（封面 + 骑缝章） 2023 年 02 版 卓创确认 单位结构研发项目 NPI 备注 签章 卓创意见 供应商确认 单位业务结构研发电子研发品质盖章 签章 样品承认 深圳市亿圣邦科技有限公司第 2 页 深圳市亿圣邦科技有限公司 样 品 承 认 书 SPECIFICATIONFORAPPROVAL 公司名称（客户填写）：深圳卓创智能科技有限公司 物料代码（客户填写）： 规格型号（客户填写）：ANB12 承认日期（客户填写）： 供应商 名 称（SLK填写）：深圳市亿圣邦科技有限公司 供 应 商 规 格 型 号（SLK填写）：WIFIMAIN:SLK-ZC-T3010A-L-140IV-B WIFIAUX:SLK-ZC-T3010A-L-150IV-G Shenzhen Yi Sheng Bang technology Co., LTD 101, Building C, Shenzhen Qianwan Hard Science and Technology Industrial Park, Bao 'an District, Shenzhen 电话： 18025305599电话： 18666299104 承认签章 供 应 商 承 认（SLK填写栏）深圳卓创智能科技有限公司 工 程 师审 核批 准工 程 师审 核批 准 陈仕联黄震林美财 盖章签署盖章签署 日期 202 3-11-21 日期 批示：□接受□有条件接受 备注（客户填写）： 深圳市亿圣邦科技有限公司第 3 页 WIFIMAINAntenna(T3010A) 1.ExplanationofProductnumber: SLK-ZC-T3010A-L-140IV-B 12345 ProductCode: (1)Customer: ZC:卓创 (2)Project: T3010A:SLK-ZC-T3010A(WIFIMAINantenna) (3)WeldingPosition L:Left (4)CableLength: 140:140IV*1.13MM四代端子 (5)CableColor B:Black 2.Features *Stableandreliableinperformances *Compactsize *RoHScompliance 3.Applications *IEEE802.11(a/b/g/n) *Hand-helddeviceswhenWIFI(802.11a/b/g/n)functionsareneeded 深圳市亿圣邦科技有限公司第 4 页 4.Description Holybond’sFPCantennaseriesarespeciallydesignedforWIFI(802.11 a/b/g/n)applications.BasedonHolybond’sproprietarydesignandprocesses, thisFPCantennahasexcellentstabilityandsensitivitytoconsistentlyprovide highsignalreceptionefficiency. 5.ElectricalSpecifications 5-1 CharacteristicsSpecificationsUnit OutlineDimensions 30*10.95*5.2T=0.4 mm CenterFrequency 2.4-2.5-5.15-5.85GHz Bandwidth(under-10dBreturnloss) 130minMHz VSWR 3max 5-2 ． VSWRS11 深圳市亿圣邦科技有限公司第 5 页 5-3.WIFI+BTAntennaGain/Efficiency/RadiationPatternof3D Frequency(MHz)Efficiency(dBi)Gain(dBi)Efficiency(%) 2400.0-4.053.1039.31 2410.0-4.322.6436.97 2420.0-3.933.0240.42 2430.0-3.673.4243.00 2440.0-3.663.2543.01 2450.0-3.523.6044.47 2460.0-3.353.9746.20 2470.0-3.523.9044.47 2480.0-3.454.0145.15 2490.0-3.633.8743.32 2500.0-3.953.4940.28 5150.0-5.332.4629.31 5350.0-4.792.1833.17 5550.0-4.232.8037.80 5750.0-4.812.3633.02 5850.0-5.122.9030.73 深圳市亿圣邦科技有限公司第 6 页 深圳市亿圣邦科技有限公司第 7 页 6.AntennaDimensions(unit:mm)

FCC ID: 2A5RP-NX16 1 Case No. : CTA24050902502 Ambient Condition: 23 °C, 49 %RH According Standard: ■Part15C Test Date: 2024.3.19 Test Engineer: Evan ouyang Appendix B.1: DTS Bandwidth Test Result TestMode Antenna Freq(MHz) DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict BLE Ant1 2402 0.720 2401.628 2402.348 0.5 PASS 2440 0.720 2439.636 2440.356 0.5 PASS 2480 0.672 2479.656 2480.328 0.5 PASS FCC ID: 2A5RP-NX16 2 Test Graphs BLE_Ant1_2402 BLE_Ant1_2440 BLE_Ant1_2480 FCC ID: 2A5RP-NX16 3 FCC ID: 2A5RP-NX16 4 Appendix B.2: Occupied Channel Bandwidth Test Result TestMode Antenna Freq(MHz) OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict BLE Ant1 2402 1.0461 2401.4838 2402.5299 --- --- 2440 1.0516 2439.4804 2440.5320 --- --- 2480 1.0488 2479.4811 2480.5299 --- --- FCC ID: 2A5RP-NX16 5 Test Graphs BLE_Ant1_2402 BLE_Ant1_2440 BLE_Ant1_2480 FCC ID: 2A5RP-NX16 6 FCC ID: 2A5RP-NX16 7 Appendix B.3: Maximum conducted output power Test Result Peak TestMode Antenna Freq(MHz) Conducted Peak Powert[dBm] Conducted Limit[dBm] Verdict BLE Ant1 2402 3.05 ≤30 PASS 2440 3.59 ≤30 PASS 2480 3.25 ≤30 PASS FCC ID: 2A5RP-NX16 8 Appendix B.4: Maximum power spectral density Test Result TestMode Antenna Freq(MHz) Result[dBm/3kHz] Limit[dBm/3kHz] Verdict BLE Ant1 2402 -10.75 ≤8.00 PASS 2440 -11.28 ≤8.00 PASS 2480 -10.92 ≤8.00 PASS Note： 1. The Duty Cycle Factor and RBW Factor is compensated in the graph. FCC ID: 2A5RP-NX16 9 Test Graphs BLE_Ant1_2402 BLE_Ant1_2440 BLE_Ant1_2480 FCC ID: 2A5RP-NX16 10 FCC ID: 2A5RP-NX16 11 Appendix B.5: Band edge measurements Test Result TestMode Antenna ChName Freq(MHz) RefLevel[dBm] Result[dBm] Limit[dBm] Verdict BLE Ant1 Low 2402 3.24 -43.26 ≤-16.76 PASS High 2480 3.66 -46.71 ≤-16.34 PASS FCC ID: 2A5RP-NX16 12 Test Graphs BLE_Ant1_Low_2402 BLE_Ant1_High_2480 FCC ID: 2A5RP-NX16 13 Appendix B.6: Conducted Spurious Emission Test Result TestMode Antenna Freq(MHz) FreqRange [MHz] RefLevel [dBm] Result[dBm] Limit[dBm] Verdict BLE Ant1 2402 Reference 3.03 3.03 --- PASS 30~1000 3.03 -60.44 ≤-16.97 PASS 1000~26500 3.03 -47.79 ≤-16.97 PASS 2440 Reference 2.38 2.38 --- PASS 30~1000 2.38 -60.26 ≤-17.62 PASS 1000~26500 2.38 -46.85 ≤-17.62 PASS 2480 Reference 3.28 3.28 --- PASS 30~1000 3.28 -60.28 ≤-16.72 PASS 1000~26500 3.28 -47.27 ≤-16.72 PASS FCC ID: 2A5RP-NX16 14 Test Graphs BLE_Ant1_2402_0~Reference BLE_Ant1_2402_30~1000 BLE_Ant1_2402_1000~26500 FCC ID: 2A5RP-NX16 15 BLE_Ant1_2440_0~Reference BLE_Ant1_2440_30~1000 FCC ID: 2A5RP-NX16 16 BLE_Ant1_2440_1000~26500 BLE_Ant1_2480_0~Reference BLE_Ant1_2480_30~1000 FCC ID: 2A5RP-NX16 17 BLE_Ant1_2480_1000~26500 FCC ID: 2A5RP-NX16 18 Appendix B.7: Emissions in Restricted Bands Test Result TestMode Antenna ChName Freq(MHz ) Detector Freq [MHz] Result [dBm] Limit [dBm] Result [dBuV/m] Limit [dBuV/m] Verdict BLE Ant1 Low 2402 AV 2310.000 -49.31 ≤-41.20 45.89 ≤54 PASS AV 2389.985 -48.92 ≤-41.20 46.28 ≤54 PASS AV 2390.000 -48.92 ≤-41.20 46.28 ≤54 PASS Peak 2310.000 -41.4 ≤-21.20 53.80 ≤74 PASS Peak 2389.565 -38.19 ≤-21.20 57.01 ≤74 PASS Peak 2390.000 -40.64 ≤-21.20 54.56 ≤74 PASS High 2480 AV 2483.500 -46.27 ≤-41.20 48.93 ≤54 PASS AV 2484.800 -45.54 ≤-41.20 49.66 ≤54 PASS AV 2500.000 -48.63 ≤-41.20 46.57 ≤54 PASS Peak 2483.500 -40.71 ≤-21.20 54.49 ≤74 PASS Peak 2484.320 -36.65 ≤-21.20 58.55 ≤74 PASS Peak 2500.000 -40.66 ≤-21.20 54.54 ≤74 PASS Note： 1. The Antenna Gain is compensated in the graph. 2. The Duty Cycle Factor and RBW Factor is compensated in the graph. 3. The limit in dBm for average detector is conversion from 54dBuV/m, according to 15.209(a). The limit in dBm for peak detector is 20dB above the limit of average detector in dBm. FCC ID: 2A5RP-NX16 19 Test Graphs BLE_Ant1_Low_2402_AV BLE_Ant1_Low_2402_Peak BLE_Ant1_High_2480_AV FCC ID: 2A5RP-NX16 20 BLE_Ant1_High_2480_Peak

FCC ID: 2A5RP-NX16 1 Case No. : CTA24050902503 Ambient Condition: 23 °C, 49 %RH, Test Date: 2024.3.19 Test Engineer: Evan ouyang Appendix C.1: DTS Bandwidth Test Result TestMode Antenna Frequency[MHz] DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant0 2412 10.080 2406.960 2417.040 0.5 PASS 2437 10.080 2431.960 2442.040 0.5 PASS 2462 10.080 2456.960 2467.040 0.5 PASS 11G Ant0 2412 16.520 2403.760 2420.280 0.5 PASS 2437 16.520 2428.760 2445.280 0.5 PASS 2462 16.560 2453.720 2470.280 0.5 PASS 11N20SISO Ant0 2412 17.800 2403.080 2420.880 0.5 PASS 2437 17.760 2428.120 2445.880 0.5 PASS 2462 17.760 2453.120 2470.880 0.5 PASS 11N40SISO Ant0 2422 36.480 2403.760 2440.240 0.5 PASS 2437 36.480 2418.760 2455.240 0.5 PASS 2452 36.480 2433.760 2470.240 0.5 PASS FCC ID: 2A5RP-NX16 2 Test Graphs 11B_Ant0_2412 11B_Ant0_2437 11B_Ant0_2462 FCC ID: 2A5RP-NX16 3 11G_Ant0_2412 11G_Ant0_2437 FCC ID: 2A5RP-NX16 4 11G_Ant0_2462 11N20SISO_Ant0_2412 11N20SISO_Ant0_2437 FCC ID: 2A5RP-NX16 5 11N20SISO_Ant0_2462 11N40SISO_Ant0_2422 FCC ID: 2A5RP-NX16 6 11N40SISO_Ant0_2437 11N40SISO_Ant0_2452 FCC ID: 2A5RP-NX16 7 Appendix C.2: Occupied Channel Bandwidth Test Result TestMode Antenna Channel Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] 11B Ant0 2412 15.294 2404.3675 2419.6615 2437 15.378 2429.3641 2444.7421 2462 15.330 2454.3135 2469.6435 11G Ant0 2412 17.316 2403.2749 2420.5909 2437 17.279 2428.3606 2445.6396 2462 17.440 2453.1263 2470.5663 11N20SISO Ant0 2412 18.456 2402.8039 2421.2599 2437 18.313 2427.8729 2446.1859 2462 18.329 2452.8076 2471.1366 11N40SISO Ant0 2422 37.391 2403.4561 2440.8471 2437 37.110 2418.5733 2455.6833 2452 37.188 2433.4123 2470.6003 FCC ID: 2A5RP-NX16 8 Test Graphs 11B_Ant0_2412 11B_Ant0_2437 11B_Ant0_2462 FCC ID: 2A5RP-NX16 9 11G_Ant0_2412 11G_Ant0_2437 FCC ID: 2A5RP-NX16 10 11G_Ant0_2462 11N20SISO_Ant0_2412 11N20SISO_Ant0_2437 FCC ID: 2A5RP-NX16 11 11N20SISO_Ant0_2462 11N40SISO_Ant0_2422 FCC ID: 2A5RP-NX16 12 11N40SISO_Ant0_2437 11N40SISO_Ant0_2452 FCC ID: 2A5RP-NX16 13 Appendix C.3: Maximum conducted output power Test Result -CHP Test Mode Antenna Frequency[MHz] Result [dBm] Limit [dBm] Verdict 11B Ant0 2412 8.40 ≤30.00 PASS 2437 8.74 ≤30.00 PASS 2462 8.75 ≤30.00 PASS 11G Ant0 2412 7.08 ≤30.00 PASS 2437 8.10 ≤30.00 PASS 2462 8.60 ≤30.00 PASS 11N20SISO Ant0 2412 8.62 ≤30.00 PASS 2437 8.98 ≤30.00 PASS 2462 8.65 ≤30.00 PASS 11N40SISO Ant0 2422 8.11 ≤30.00 PASS 2437 8.40 ≤30.00 PASS 2452 8.83 ≤30.00 PASS Note： 1.The Duty Cycle Factor and RBW Factor is compensated in the data. FCC ID: 2A5RP-NX16 14 Appendix C.4: Maximum power spectral density Test Result TestMode Antenna Frequency[MHz] Result[dBm/3-100kHz] Limit[dBm/3kHz] Verdict 11B Ant0 2412 -25.06 ≤8.00 PASS 2437 -23.65 ≤8.00 PASS 2462 -23.23 ≤8.00 PASS 11G Ant0 2412 -24.55 ≤8.00 PASS 2437 -26.04 ≤8.00 PASS 2462 -25.46 ≤8.00 PASS 11N20SISO Ant0 2412 -26.22 ≤8.00 PASS 2437 -25.00 ≤8.00 PASS 2462 -25.52 ≤8.00 PASS 11N40SISO Ant0 2422 -25.95 ≤8.00 PASS 2437 -27.65 ≤8.00 PASS 2452 -27.89 ≤8.00 PASS Note： 1. The Duty Cycle Factor and RBW Factor is compensated in the graph. FCC ID: 2A5RP-NX16 15 Test Graphs 11B_Ant0_2412 11B_Ant0_2437 11B_Ant0_2462 FCC ID: 2A5RP-NX16 16 11G_Ant0_2412 11G_Ant0_2437 FCC ID: 2A5RP-NX16 17 11G_Ant0_2462 11N20SISO_Ant0_2412 11N20SISO_Ant0_2437 FCC ID: 2A5RP-NX16 18 11N20SISO_Ant0_2462 11N40SISO_Ant0_2422 FCC ID: 2A5RP-NX16 19 11N40SISO_Ant0_2437 11N40SISO_Ant0_2452 FCC ID: 2A5RP-NX16 20 Appendix C.5: Band edge measurements Test Result TestMode Antenna ChName Frequency[MHz] RefLevel[dBm] Result[dBm] Limit[dBm] Verdict 11B Ant0 Low 2412 -4.99 -43.86 ≤-24.99 PASS High 2462 -3.11 -49.61 ≤-23.11 PASS 11G Ant0 Low 2412 -10.21 -42 ≤-30.21 PASS High 2462 -11.40 -49.16 ≤-31.4 PASS 11N20SISO Ant0 Low 2412 -12.93 -43.28 ≤-32.93 PASS High 2462 -11.08 -49.46 ≤-31.08 PASS 11N40SISO Ant0 Low 2422 -15.73 -44.94 ≤-35.73 PASS High 2452 -14.59 -49.03 ≤-34.59 PASS FCC ID: 2A5RP-NX16 21 Test Graphs 11B_Ant0_Low_2412 11B_Ant0_High_2462 11G_Ant0_Low_2412 FCC ID: 2A5RP-NX16 22 11G_Ant0_High_2462 11N20SISO_Ant0_Low_2412 FCC ID: 2A5RP-NX16 23 11N20SISO_Ant0_High_2462 11N40SISO_Ant0_Low_2422 11N40SISO_Ant0_High_2452 FCC ID: 2A5RP-NX16 24 FCC ID: 2A5RP-NX16 25 Appendix C.6: Conducted Spurious Emission Test Result TestMode Antenna Frequency[MHz] FreqRange [Mhz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict 11B Ant0 2412 Reference -5.20 -5.20 --- PASS 30~1000 -5.20 -60.87 ≤-25.2 PASS 1000~26500 -5.20 -47.79 ≤-25.2 PASS 2437 Reference -4.01 -4.01 --- PASS 30~1000 -4.01 -61.08 ≤-24.01 PASS 1000~26500 -4.01 -47.39 ≤-24.01 PASS 2462 Reference -3.57 -3.57 --- PASS 30~1000 -3.57 -60.35 ≤-23.57 PASS 1000~26500 -3.57 -47.88 ≤-23.57 PASS 11G Ant0 2412 Reference -11.10 -11.10 --- PASS 30~1000 -11.10 -61 ≤-31.1 PASS 1000~26500 -11.10 -48.5 ≤-31.1 PASS 2437 Reference -12.82 -12.82 --- PASS 30~1000 -12.82 -60.48 ≤-32.82 PASS 1000~26500 -12.82 -48.09 ≤-32.82 PASS 2462 Reference -11.65 -11.65 --- PASS 30~1000 -11.65 -60.92 ≤-31.65 PASS 1000~26500 -11.65 -47.77 ≤-31.65 PASS 11N20SISO Ant0 2412 Reference -13.22 -13.22 --- PASS 30~1000 -13.22 -61.22 ≤-33.22 PASS 1000~26500 -13.22 -46.21 ≤-33.22 PASS 2437 Reference -12.22 -12.22 --- PASS 30~1000 -12.22 -60.48 ≤-32.22 PASS 1000~26500 -12.22 -47.74 ≤-32.22 PASS 2462 Reference -12.36 -12.36 --- PASS 30~1000 -12.36 -60.61 ≤-32.36 PASS 1000~26500 -12.36 -48.42 ≤-32.36 PASS 11N40SISO Ant0 2422 Reference -15.62 -15.62 --- PASS 30~1000 -15.62 -60.47 ≤-35.62 PASS 1000~26500 -15.62 -47.87 ≤-35.62 PASS 2437 Reference -15.31 -15.31 --- PASS 30~1000 -15.31 -60.7 ≤-35.31 PASS 1000~26500 -15.31 -46.74 ≤-35.31 PASS 2452 Reference -14.98 -14.98 --- PASS 30~1000 -14.98 -60.62 ≤-34.98 PASS 1000~26500 -14.98 -48.13 ≤-34.98 PASS FCC ID: 2A5RP-NX16 26 Test Graphs 11B_Ant0_2412_0~Reference 11B_Ant0_2412_30~1000 11B_Ant0_2412_1000~26500 FCC ID: 2A5RP-NX16 27 11B_Ant0_2437_0~Reference 11B_Ant0_2437_30~1000 FCC ID: 2A5RP-NX16 28 11B_Ant0_2437_1000~26500 11B_Ant0_2462_0~Reference 11B_Ant0_2462_30~1000 FCC ID: 2A5RP-NX16 29 11B_Ant0_2462_10…
