2A5UQ-OMNIAC20WSmart Access Control Terminal

Product Name and Model Number User Manual Page | 1 User Manual OmniAC20 Date: June 2023 Doc Version: 1.6 English OmniAC20 User Manual Page | 1 Copyright©2023 ARMATURA LLC. All rights reserved. Copyright © 2023 ARMATURA LLC. All rights reserved. Without the prior written consent of ARMATURA LLC, no portion of this manual can be copied or forwarded in any way or form. All parts of this manual belong to ARMATURA LLC and its subsidiaries (hereinafter the "Company" or "Armatura"). Trademark is a registered trademark of ARMATURA LLC. Other trademarks involved in this manual are owned by their respective owners. Disclaimer This manual contains information on the operation and maintenance of the Armatura equipment. The copyright in all the documents, drawings, etc. in relation to the Armatura supplied equipment vests in and is the property of Armatura. The contents hereof should not be used or shared by the receiver with any third party without express written permission of Armatura. The contents of this manual must be read as a whole before starting the operation and maintenance of the supplied equipment. If any of the content(s) of the manual seems unclear or incomplete, please contact Armatura before starting the operation and maintenance of the said equipment. It is an essential pre-requisite for the satisfactory operation and maintenance that the operating and maintenance personnel are fully familiar with the design and that the said personnel have received thorough training in operating and maintaining the machine/unit/ equipment. It is further essential for the safe operation of the machine/unit/ equipment that personnel has read, understood and followed the safety instructions contained in the manual. In case of any conflict between terms and conditions of this manual and the contract specifications, drawings, instruction sheets or any other contract-related documents, the contract conditions/documents shall prevail. The contract specific conditions/documents shall apply in priority. Armatura offers no warranty, guarantee or representation regarding the completeness of any information contained in this manual or any of the amendments made thereto. Armatura does not extend the warranty of any kind, including, without limitation, any warranty of design, merchantability or fitness for a particular purpose. Armatura does not assume responsibility for any errors or omissions in the information or documents which are referenced by or linked to this manual. The entire risk as to the results and performance obtained from using the information is assumed by the user. OmniAC20 User Manual Page | 2 Copyright©2023 ARMATURA LLC. All rights reserved. Armatura in no event shall be liable to the user or any third party for any incidental, consequential, indirect, special, or exemplary damages, including, without limitation, loss of business, loss of profits, business interruption, loss of business information or any pecuniary loss, arising out of, in connection with, or relating to the use of the information contained in or referenced by this manual, even if Armatura has been advised of the possibility of such damages. This manual and the information contained therein may include technical, other inaccuracies or typographical errors. Armatura periodically changes the information herein which will be incorporated into new additions/amendments to the manual. Armatura reserves the right to add, delete, amend or modify the information contained in the manual from time to time in the form of circulars, letters, notes, etc. for better operation and safety of the machine/unit/ equipment. The said additions or amendments are meant for improvement /better operations of the machine/unit/equipment and such amendments shall not give any right to claim any compensation or damages under any circumstances. Armatura shall in no way be responsible (i) in case the machine/unit/equipment malfunctions due to any non-compliance of the instructions contained in this manual (ii) in case of operation of the machine/unit/equipment beyond the rate limits (iii) in case of operation of the machine and equipment in conditions different from the prescribed conditions of the manual. The product will be updated from time to time without prior notice. The latest operation procedures and relevant documents are available on http://www.armatura.us. If there is any issue related to the product, please contact us. Armatura LLC. Co., Ltd. Address: 190 Bluegrass Valley Parkway Alpharetta, GA 30005 USA Phone: +1-650-4556863 For business related queries, please write to us at: [email protected]. To know more about our global branches, visit www.armatura.us. About the Manual This manual introduces the operations of OmniAC20. All figures displayed are for illustration purposes only. Figures in this manual may not be exactly consistent with the actual products. OmniAC20 User Manual Page | 3 Copyright©2023 ARMATURA LLC. All rights reserved. Table of Contents DATA SECURITY STATEMENT ..................................................................... 6 SAFETY MEASURES ...................................................................................... 6 E LECTRICAL SAFETY ..................................................................................... 8 O PERATION SAFETY ..................................................................................... 9 1 INSTRUCTION FOR USE .....................................................................11 P ALM REGISTRATION ...........................................................................11 1.1 S TANDING POSITION, FACIAL EXPRESSION AND STANDING POSTURE .......12 1.2 F ACE REGISTRATION ...........................................................................13 1.3 S TANDBY INTERFACE ...........................................................................15 1.4 V IRTUAL KEYBOARD ............................................................................17 1.5 V ERIFICATION MODE .....…

Text truncated - open the document above for the full version.

Page 1 of 7 FCC ID: 2A5UQ-OMNIAC20W Intertek Testing Services Shanghai Address: Building 86, No. 1198 Qinzhou Road(North), Shanghai 200233, P.R. China Tel: +86 21 61278200 Fax: +86 21 54262353 APPENDIX II: PHOTOGRAPH OF EQUIPMENT UNDER TEST EUT External Photos EUT Photo EUT Photo Page 2 of 7 FCC ID: 2A5UQ-OMNIAC20W Intertek Testing Services Shanghai Address: Building 86, No. 1198 Qinzhou Road(North), Shanghai 200233, P.R. China Tel: +86 21 61278200 Fax: +86 21 54262353 EUT Photo EUT Photo Page 3 of 7 FCC ID: 2A5UQ-OMNIAC20W Intertek Testing Services Shanghai Address: Building 86, No. 1198 Qinzhou Road(North), Shanghai 200233, P.R. China Tel: +86 21 61278200 Fax: +86 21 54262353 EUT Photo EUT Photo Page 4 of 7 FCC ID: 2A5UQ-OMNIAC20W Intertek Testing Services Shanghai Address: Building 86, No. 1198 Qinzhou Road(North), Shanghai 200233, P.R. China Tel: +86 21 61278200 Fax: +86 21 54262353 EUT Photo EUT Photo Page 5 of 7 FCC ID: 2A5UQ-OMNIAC20W Intertek Testing Services Shanghai Address: Building 86, No. 1198 Qinzhou Road(North), Shanghai 200233, P.R. China Tel: +86 21 61278200 Fax: +86 21 54262353 EUT Photo EUT Photo Page 6 of 7 FCC ID: 2A5UQ-OMNIAC20W Intertek Testing Services Shanghai Address: Building 86, No. 1198 Qinzhou Road(North), Shanghai 200233, P.R. China Tel: +86 21 61278200 Fax: +86 21 54262353 EUT Photo EUT Photo Page 7 of 7 FCC ID: 2A5UQ-OMNIAC20W Intertek Testing Services Shanghai Address: Building 86, No. 1198 Qinzhou Road(North), Shanghai 200233, P.R. China Tel: +86 21 61278200 Fax: +86 21 54262353 EUT Photo

Label Location

Page 1 of 8 FCC ID: 2A5UQ-OMNIAC20W Intertek Testing Services Shanghai Address: Building 86, No. 1198 Qinzhou Road(North), Shanghai 200233, P.R. China Tel: +86 21 61278200 Fax: +86 21 54262353 APPENDIX II: PHOTOGRAPH OF EQUIPMENT UNDER TEST EUT Internal Photos EUT Photo EUT Photo Page 2 of 8 FCC ID: 2A5UQ-OMNIAC20W Intertek Testing Services Shanghai Address: Building 86, No. 1198 Qinzhou Road(North), Shanghai 200233, P.R. China Tel: +86 21 61278200 Fax: +86 21 54262353 EUT Photo EUT Photo Wi-Fi Module 125kHz & 13.56MHz Module Page 3 of 8 FCC ID: 2A5UQ-OMNIAC20W Intertek Testing Services Shanghai Address: Building 86, No. 1198 Qinzhou Road(North), Shanghai 200233, P.R. China Tel: +86 21 61278200 Fax: +86 21 54262353 EUT Photo EUT Photo Page 4 of 8 FCC ID: 2A5UQ-OMNIAC20W Intertek Testing Services Shanghai Address: Building 86, No. 1198 Qinzhou Road(North), Shanghai 200233, P.R. China Tel: +86 21 61278200 Fax: +86 21 54262353 EUT Photo EUT Photo Page 5 of 8 FCC ID: 2A5UQ-OMNIAC20W Intertek Testing Services Shanghai Address: Building 86, No. 1198 Qinzhou Road(North), Shanghai 200233, P.R. China Tel: +86 21 61278200 Fax: +86 21 54262353 EUT Photo EUT Photo Page 6 of 8 FCC ID: 2A5UQ-OMNIAC20W Intertek Testing Services Shanghai Address: Building 86, No. 1198 Qinzhou Road(North), Shanghai 200233, P.R. China Tel: +86 21 61278200 Fax: +86 21 54262353 EUT Photo EUT Photo Page 7 of 8 FCC ID: 2A5UQ-OMNIAC20W Intertek Testing Services Shanghai Address: Building 86, No. 1198 Qinzhou Road(North), Shanghai 200233, P.R. China Tel: +86 21 61278200 Fax: +86 21 54262353 EUT Photo EUT Photo Page 8 of 8 FCC ID: 2A5UQ-OMNIAC20W Intertek Testing Services Shanghai Address: Building 86, No. 1198 Qinzhou Road(North), Shanghai 200233, P.R. China Tel: +86 21 61278200 Fax: +86 21 54262353 EUT Photo EUT Photo 125kHz & 13.56MHz Antenna Wi-Fi Antenna

Armatura LLC MPE ASSESSMENT REPORT Report Type: FCC MPE assessment report Model: OmniAC20 REPORT NUMBER: 230402194SHA-006 ISSUE DATE: July 5, 2023 DOCUMENT CONTROL NUMBER: TTRFFCCMPE-01_V1 © 2018 Intertek Intertek Testing Services Shanghai Building No.86, 1198 Qinzhou Road (North) Caohejing Development Zone Shanghai 200233, China Telephone: 86 21 6127 8200 www.intertek.com TEST REPORT This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. TTRFFCCMPE-01_V1© 2018 Intertek Page 2 of 14 Report no.: 230402194SHA-006 Applicant: Armatura LLC 190 Bluegrass Valley Parkway Alpharetta, GA 30005 Manufacturer: Armatura LLC 190 Bluegrass Valley Parkway Alpharetta, GA 30005 FCC ID: 2A5UQ-OMNIAC20W SUMMARY: The equipment complies with the requirements according to the following standard(s) or Specification: KDB447498 D01 General RF Exposure Guidance v06 FCC Part2.1091, FCC Part2.1093 FCC Part1.1307(b) PREPARED BY: REVIEWED BY: Project Engineer Damon Ding Reviewer Erick Liu Report No.: 230402194SHA-006 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 3 of 14 Revision History Report No. Version Description Issued Date 230402194SHA-006 Rev. 01 Initial issue of report July 5, 2023 Report No.: 230402194SHA-006 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 4 of 14 1 GENERAL INFORMATION 1.1 Description of Equipment Under Test (EUT) Product name: Smart Access Control Terminal Type/Model: OmniAC20 Description of EUT: Smart Access Control Terminal Rating: Powered from adapter DC12V, 3.0A Category of EUT: Class B EUT type: Table top Floor standing Software Version: Not provided Hardware Version: Not provided Sample received date: March 8, 2023 Date of test: April 03, 2023 to June 07, 2023 1.2 Technical Specification For 2.4 GHz ISM Band of Wi-Fi Frequency band: 2400MHz ~ 2483.5MHz Frequency Range: 2412MHz ~ 2462MHz Support Standards: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n-HT20, IEEE 802.11n-HT40 Type of Modulation: IEEE 802.11b: DSSS(CCK, DQPSK, DBPSK) IEEE 802.11g: OFDM(64-QAM, 16-QAM, QPSK, BPSK) IEEE 802.11n-HT20: OFDM(64-QAM, 16-QAM, QPSK, BPSK) IEEE 802.11n-HT40: OFDM(64-QAM, 16-QAM, QPSK, BPSK) Channel Number: IEEE 802.11b: 11 IEEE 802.11g: 11 IEEE 802.11n-HT20: 11 IEEE 802.11n-HT40: 9 Data Rate: IEEE 802.11b: Up to 11 Mbps IEEE 802.11g: Up to 54 Mbps IEEE 802.11n-HT20: Up to MCS7 IEEE 802.11n-HT40: Up to MCS7 Channel Separation: 5 MHz Antenna Information: FPCB antenna: 3.2 dBi Report No.: 230402194SHA-006 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 5 of 14 For 5 GHz U-NII Bands of Wi-Fi Frequency Range: 5150 MHz to 5250 MHz (U-NII-1) 5250 MHz to 5350 MHz (U-NII-2A) 5470 MHz to 5725 MHz (U-NII-2C) 5 725 MHz to 5 850 MHz (U-NII-3) Support Standards: IEEE 802.11a/n Type of Modulation: IEEE 802.11a: OFDM(64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n: OFDM(64QAM, 16QAM, QPSK, BPSK) IEEE 802.11a/n-HT20: 20 MHz IEEE 802.11n-HT40: 40 MHz Channel Number: 5150 MHz to 5250 MHz: 4 for IEEE 802.11a/n-HT20 2 for IEEE 802.11n-HT40 5250 MHz to 5350 MHz: 4 for IEEE 802.11a/n-HT20 2 for IEEE 802.11n-HT40 5470 MHz to 5725 MHz: 12 for IEEE 802.11a/n-HT20 6 for IEEE 802.11n-HT40 5725 MHz to 5850 MHz: 5 for IEEE 802.11a/n-HT20 2 for IEEE 802.11n-HT40 Data Rate: IEEE 802.11a: Up to 54 Mbps IEEE 802.11n-HT20: Up to MCS7 IEEE 802.11n-HT40: Up to MCS7 Channel Separation: IEEE 802.11a/n-HT20: 20 MHz IEEE 802.11n-HT40: 40 MHz Antenna Information: FPCB antenna 5150-5350MHz 3.7dBi 5470-5725MHz 4.6dBi 5725-5850MHz 4.2dBi Report No.: 230402194SHA-006 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 6 of 14 For RFID 13.56 MHz Frequency Range: 13.56 MHz ~ 13.56 MHz Nominal Operating Frequency: 13.56 MHz Max. Data Rates: 106 Kbps Number of Channels: 1 Work in Modes: ☐ Card Emulation, ☐ Peer-to-Peer, ☒ Reader/Writer NFC Type: ☒ NFC A Type, ☒ NFC B Type, ☐ NFC F Type, ☐ NFC V Type Modulation: ASK Antenna: induction coil antenna For RFID 125 kHz Frequency Range: 119 kHz ~ 140 kHz Nominal Operating Frequency: 125kHz Number of Channels: 1 Modulation: ASK Antenna: induction coil antenna Report No.: 230402194SHA-006 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 7 of 14 1.3 Description of Test Facility Name: Intertek Testing Services Shanghai Address: Building 86, No. 1198 Qinzhou Road(North), Shanghai 200233, P.R. China Telephone: 86 21 61278200 Telefax: 86 21 54262353 The test facility is recognized, certified, or accredited by these organizations: CNAS Accreditation Lab Registration No. CNAS L0139 FCC Accredited Lab Designation Number: CN1175 IC Registration Lab Registration code No.: 2042B-1 VCCI Registration Lab Registration No.: R-4243, G-845, C-4723, T-2252 NVLAP Accreditation Lab NVLAP LAB CODE: 200849-0 A2LA Accreditation Lab Certificate Number: 3309.02 Report No.: 230402194SHA-006 TEST REPORT TTRFFCCMPE-01_V1© 2018 Intertek Page 8 of 14 2 MPE Assessment Test result: Pass 2.1 MPE Assessment Limit Mobile device exposure for standalone operations: Frequency range E-field strength (V/m) H-field strength (A/m) B-field (uT) Equivalent plane wave power density S eq (W/m 2 ) 0-1 Hz - 3,2 × 10 4 4 × 10 4 - 1-8 Hz 10 000 3,2 × 10 4 /f 2 4 × 10 4 /f 2 - 8-25 Hz 10 000 4 000/f 5 000/f - 0,025-0,8 kHz 250/f 4…

Text truncated - open the document above for the full version.

Armatura LLC RF TEST REPORT Report Type: FCC Part 15.247 RF report Model: OmniAC20 REPORT NUMBER: 230402194SHA-002 ISSUE DATE: July 5, 2023 DOCUMENT CONTROL NUMBER: TTRF15.247-03_V1 © 2018 Intertek Intertek Testing Services Shanghai Building No.86, 1198 Qinzhou Road (North) Caohejing Development Zone Shanghai 200233, China Telephone: 86 21 6127 8200 www.intertek.com TEST REPORT This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. TTRF15.247-03_V1 © 2018 Intertek Page 2 of 33 Report no.: 230402194SHA-002 Applicant: Armatura LLC Address of Applicant: 190 Bluegrass Valley Parkway Alpharetta, GA 30005 Manufacturer: Armatura LLC Address of Manufacturer: 190 Bluegrass Valley Parkway Alpharetta, GA 30005 FCC ID: 2A5UQ-OMNIAC20W SUMMARY: The equipment complies with the requirements according to the following standard(s) or Specification: 47CFR Part 15 (2021): Radio Frequency Devices (Subpart C) ANSI C63.10 (2013): American National Standard of Procedures for Compliance Testing of Unlicensed Wireless Devices PREPARED BY: REVIEWED BY: Project Engineer Damon Ding Reviewer Erick Liu Report No.: 230402194SHA-002 TEST REPORT TTRF15.247-03_V1 © 2018 Intertek Page 3 of 33 Content REVISION HISTORY................................................................................................................................................ 5 MEASUREMENT RESULT SUMMARY ..................................................................................................................... 6 1 GENERAL INFORMATION ............................................................................................................................. 7 1.1 DESCRIPTION OF EQUIPMENT UNDER TEST (EUT) ..................................................................................................... 7 1.2 TECHNICAL SPECIFICATION .................................................................................................................................... 7 1.3 ANTENNA INFORMATION....................................................................................................................................... 8 1.4 DESCRIPTION OF TEST FACILITY .............................................................................................................................. 8 2 TEST SPECIFICATIONS ................................................................................................................................. 10 2.1 STANDARDS OR SPECIFICATION ............................................................................................................................. 10 2.2 MODE OF OPERATION DURING THE TEST ................................................................................................................. 10 2.3 TEST SOFTWARE LIST .......................................................................................................................................... 10 2.4 TEST PERIPHERALS LIST ....................................................................................................................................... 11 2.5 SUPPORT CABLE LIST .......................................................................................................................................... 11 2.6 TEST ENVIRONMENT CONDITION: .......................................................................................................................... 11 2.7 INSTRUMENT LIST .............................................................................................................................................. 12 2.8 MEASUREMENT UNCERTAINTY ............................................................................................................................. 13 2.9 DUTY CYCLE .................................................................................................................................................. 14 3 MINIMUM 6DB BANDWIDTH ..................................................................................................................... 17 3.1 LIMIT .............................................................................................................................................................. 17 3.2 MEASUREMENT PROCEDURE ............................................................................................................................... 17 3.3 TEST CONFIGURATION ........................................................................................................................................ 17 3.4 TEST RESULTS OF MINIMUM 6DB BANDWIDTH ....................................................................................................... 17 4 MAXIMUM CONDUCTED OUTPUT POWER ................................................................................................ 18 4.1 LIMIT .............................................................................................................................................................. 18 4.2 MEASUREMENT PROCEDURE ............................................................................................................................... 18 4.3 TE…

Text truncated - open the document above for the full version.

深圳市盛邦尔科技有限公司 ShenzhenSurbanerTechnologyCO.LTD Address:2/F,BuildingB25,Hengfengindustrialcity,Hezhoucommunity,XixiangStreet,BaoanDistrict,ShenzhenCity.TEL：0755-82790675FAX： 0755-82809726 SBRCommunicationhaspossessionofproprietaryinformationprovidedinthisreportandthisproprietaryinformationshallbekeptinstrictconfidenceandnot disclosedtoanypersonorfirmwithoutthepriorwrittenconsentofSBRCommunicationTechnology. www.surbaner.com.cn 目录/Catalogue 序号 No. 项目 Item 页码 PageNo. 1 图纸或实物图片 DrawingorProductImage 3 2 技术参数 TechnicalParameter 4 3 射频性能测试报告 RFPerformanceTestReport 5-12 4 包装文件 PackageDocument 13 5 尺寸测量报告 DimensionsTestReport 14 6 可靠性测试报告 ReliabilityTestReport 15 7 环境有害物质管控一览表 RoHSControllistforSample 16 深圳市盛邦尔科技有限公司 ShenzhenSurbanerTechnologyCO.LTD Address:2/F,BuildingB25,Hengfengindustrialcity,Hezhoucommunity,XixiangStreet,BaoanDistrict,ShenzhenCity.TEL：0755-82790675FAX： 0755-82809726 SBRCommunicationhaspossessionofproprietaryinformationprovidedinthisreportandthisproprietaryinformationshallbekeptinstrictconfidenceandnot disclosedtoanypersonorfirmwithoutthepriorwrittenconsentofSBRCommunicationTechnology. www.surbaner.com.cn 产品图纸或实物图片 DrawingorProductImage 深圳市盛邦尔科技有限公司 ShenzhenSurbanerTechnologyCO.LTD Address:2/F,BuildingB25,Hengfengindustrialcity,Hezhoucommunity,XixiangStreet,BaoanDistrict,ShenzhenCity.TEL：0755-82790675FAX： 0755-82809726 SBRCommunicationhaspossessionofproprietaryinformationprovidedinthisreportandthisproprietaryinformationshallbekeptinstrictconfidenceandnot disclosedtoanypersonorfirmwithoutthepriorwrittenconsentofSBRCommunicationTechnology. www.surbaner.com.cn 二.TechnicalParameter/技术参数 1.Antenna/天线 No/序号PartName/项目SPEC/规格 1 FrequencyRange/ 频率范围 2400-2500MHz&5150-5850MHz 2 Impendence/ 阻抗50ohmnominal 3 Maximumpeakgain/最大 峰值增益 2400MHz-2483.5MHz:3.2dBi 5150MHz-5250MHz:3.7dBi 5250MHz-5350MHz:3.7dBi 5470MHz-5725MHz:4.6dBi 5725MHz-5850MHz:4.2dBi 4 Polarization/ 极化Vertical/horizontal 5 VSWR/驻波比 ≤2.5 6 Efficiency/效率 ≥35% 7 RFCable/射频连接线1.13blackline95mm 8 RFConnector/连接器CCTGeneration1terminal 2.EnvironmentalCharacteristics/环境特性 No/ 序号 PartName/ 项目 SPEC/ 规格 1 OperationHumidity /工作湿度 5~95% 2 OperatingTemperature/ 工作温度 -20~+60°C 3 StoreTemperatuer/ 储存温度 -30~+70°C 深圳市盛邦尔科技有限公司 ShenzhenSurbanerTechnologyCO.LTD Address:2/F,BuildingB25,Hengfengindustrialcity,Hezhoucommunity,XixiangStreet,BaoanDistrict,ShenzhenCity.TEL：0755-82790675FAX： 0755-82809726 SBRCommunicationhaspossessionofproprietaryinformationprovidedinthisreportandthisproprietaryinformationshallbekeptinstrictconfidenceandnot disclosedtoanypersonorfirmwithoutthepriorwrittenconsentofSBRCommunicationTechnology. www.surbaner.com.cn 射频性能测量报告 RFPerformanceTestReport 客户名称 Customer Name 熵基 项目名称 ProjectName V3L 盛邦尔料号 SurbanerP/N 3160-170-00409-V01 频段 Band 2400-2500MHz& 5150-5850MHz 测试日期 TestDate 2023/04/23 测试人 Inspector 林德友 天线测试设备简介 AntennaTestEquipmentIntroduction 测试天线输入特性使用AgilentE5071CandAgilent5062A矢量网络分析仪；辐射特性利 用Satimo三维近场暗室进行测试，并分别使用8960E5515和AgilentE4438C进行了分析。暗房 的测试坐标如下: TestofantennainputcharacteristicsusingAgilentE5071CandAgilent5062Avectornetwork analyzer;TheradiationpatternoftheantennaaretestedusingtheSatimostarlab3DnearfieldAnechoic Chamber,andtheinstrumentisusedtoagilent8960E5515andAgilentE4438C.Thetestcoordinatesofthe darkroomareasfollows: 1.S11参数测量/ S11Parameter-VSWR 使用一根50Ω同轴电缆连接到天线，然后该电缆连接到网络分析仪测量S11参数，被测量产品远离金属至 少20厘米。 MeasuringMethodisa50Ωcoaxialcableisconnectedtotheantenna.Thenthiscableisconnectedtoanetwork analyzertomeasuretheS11parameter,Keepingthisfixtureawayfrommetalatleast20cm. 深圳市盛邦尔科技有限公司 ShenzhenSurbanerTechnologyCO.LTD Address:2/F,BuildingB25,Hengfengindustrialcity,Hezhoucommunity,XixiangStreet,BaoanDistrict,ShenzhenCity.TEL：0755-82790675FAX： 0755-82809726 SBRCommunicationhaspossessionofproprietaryinformationprovidedinthisreportandthisproprietaryinformationshallbekeptinstrictconfidenceandnot disclosedtoanypersonorfirmwithoutthepriorwrittenconsentofSBRCommunicationTechnology. www.surbaner.com.cn TestSystem S11Parameter-VSWR 2. 天线匹配网络 /AntennaMatchingNetwork 深圳市盛邦尔科技有限公司 ShenzhenSurbanerTechnologyCO.LTD Address:2/F,BuildingB25,Hengfengindustrialcity,Hezhoucommunity,XixiangStreet,BaoanDistrict,ShenzhenCity.TEL：0755-82790675FAX： 0755-82809726 SBRCommunicationhaspossessionofproprietaryinformationprovidedinthisreportandthisproprietaryinformationshallbekeptinstrictconfidenceandnot disclosedtoanypersonorfirmwithoutthepriorwrittenconsentofSBRCommunicationTechnology. www.surbaner.com.cn 3.Gain&Efficiency 2DPattern-2.4GHzBand 深圳市盛邦尔科技有限公司 ShenzhenSurbanerTechnologyCO.LTD Address:2/F,BuildingB25,Hengfengindustrialcity,Hezhoucommunity,XixiangStreet,BaoanDistrict,ShenzhenCity.TEL：0755-82790675FAX： 0755-82809726 SBRCommunicationhaspossessionofproprietaryinformationprovidedinthisreportandthisproprietaryinformationshallbekeptinstrictconfidenceandnot disclosedtoanypersonorfirmwithoutthepriorwrittenconsentofSBRCommunicationTechnology. www.surbaner.com.cn Phi=0Phi=90 Theta=903D 2DPattern-5GHz(5150-5350MHz) 深圳市盛邦尔科技有限公司 ShenzhenSurbanerTechnologyCO.LTD Address:2/F,BuildingB25,Hengfengindustrialcity,Hezhoucommunity,XixiangStreet,BaoanDistrict,ShenzhenCity.TEL：0755-82790675FAX： 0755-82809726 SBRCommunicationhaspossessionofproprietaryinformationprovidedinthisreportandthisproprietaryinformationshallbekeptinstrictconfidenceandnot disclosedtoanypersonorfirmwithoutthepriorwrittenconsentofSBRCommunicationTechnology. www.surbaner.com.cn Phi=0Phi=90 Theta=903D 2DPattern-5GHz(5470-5725Mhz) 深圳市盛邦尔科技有限公司 ShenzhenSurbanerTechnologyCO.LTD Address:2/F,BuildingB25,Hengfengindustrialcity,Hezhoucommunity,XixiangStreet,BaoanDistrict,ShenzhenCity.TEL：0755-82790675FAX： 0755-82809726 SBRCommunicationhaspossessionofproprietaryinformationprovidedinthisreportandthisproprietaryinformationshallbekeptinstrictconfidenceandnot disclosedtoanypersonorfirmwithoutthepriorwrittenconsentofSBRCommunicationTechnology. www.surbaner.com.cn Phi=0Phi=90 Theta=903D 2DPattern-5.8GHz(5745-5850MHz) 深圳市盛邦尔科技有限公司 ShenzhenSurbanerTechnologyCO.LTD Address:2/F,BuildingB25,Hengfengindus…

Text truncated - open the document above for the full version.

Report No.: 230402194SHA-002 TEST REPORT TTRF15.247-03_V1 © 2018 Intertek Page 1 of 27 Appendix A Test Results of Minimum 6dB bandwidth: Mode Channel/ Frequency (MHz) 6 dB Bandwidth (MHz) 6 dB Bandwidth Limit Pass / Fail IEEE 802.11b 1(2412) 10.09 > 500 kHz Pass 6(2437) 10.08 > 500 kHz Pass 11(2462) 10.08 > 500 kHz Pass IEEE 802.11g 1(2412) 16.39 > 500 kHz Pass 6(2437) 16.39 > 500 kHz Pass 11(2462) 16.39 > 500 kHz Pass IEEE 802.11n-HT20 1(2412) 17.64 > 500 kHz Pass 6(2437) 17.65 > 500 kHz Pass 11(2462) 17.65 > 500 kHz Pass IEEE 802.11n-HT40 3(2422) 36.38 > 500 kHz Pass 6(2437) 36.38 > 500 kHz Pass 9(2452) 36.38 > 500 kHz Pass Report No.: 230402194SHA-002 TEST REPORT TTRF15.247-03_V1 © 2018 Intertek Page 2 of 27 The test plots as follows: IEEE 802.11b IEEE 802.11g Channel 1 Channel 6 Channel 11 Report No.: 230402194SHA-002 TEST REPORT TTRF15.247-03_V1 © 2018 Intertek Page 3 of 27 IEEE 802.11n-HT20 IEEE 802.11n-HT40 Channel 1 Channel 3 Channel 6 Channel 6 Channel 11 Channel 9 Report No.: 230402194SHA-002 TEST REPORT TTRF15.247-03_V1 © 2018 Intertek Page 4 of 27 Appendix B Test Results of Maximum conducted output power Mode Channel/ Frequency (MHz) Maximum Conducted Peak Power (dBm) Maximum Conducted Average Power (dBm) Limit (dBm) Pass / Fail Measured Value Corrected Value IEEE 802.11b 1(2412) 14.27 12.65 12.65 30 Pass 6(2437) 14.30 12.67 12.67 30 Pass 11(2462) 14.36 12.69 12.69 30 Pass IEEE 802.11g 1(2412) 20.75 10.77 11.01 30 Pass 6(2437) 20.84 10.78 11.02 30 Pass 11(2462) 20.96 10.90 11.14 30 Pass IEEE 802.11n- HT20 1(2412) 20.05 9.74 9.74 30 Pass 6(2437) 20.14 9.77 9.77 30 Pass 11(2462) 20.31 9.85 9.85 30 Pass IEEE 802.11n- HT40 3(2422) 20.71 10.22 10.36 30 Pass 6(2437) 20.82 10.25 10.39 30 Pass 9(2452) 20.86 10.29 10.43 30 Pass Report No.: 230402194SHA-002 TEST REPORT TTRF15.247-03_V1 © 2018 Intertek Page 5 of 27 Appendix C Test Results of Power spectrum density Mode Channel/ Frequency (MHz) PSD (dBm/3kHz) PSD Limit (dBm/3kHz) Pass / Fail IEEE 802.11b 1(2412) -13.131 8 Pass 6(2437) -14.034 8 Pass 11(2462) -14.072 8 Pass IEEE 802.11g 1(2412) -16.988 8 Pass 6(2437) -16.757 8 Pass 11(2462) -15.917 8 Pass IEEE 802.11n-HT20 1(2412) -17.180 8 Pass 6(2437) -17.306 8 Pass 11(2462) -17.563 8 Pass IEEE 802.11n-HT40 3(2422) -19.270 8 Pass 6(2437) -19.620 8 Pass 9(2452) -20.027 8 Pass Report No.: 230402194SHA-002 TEST REPORT TTRF15.247-03_V1 © 2018 Intertek Page 6 of 27 The test plots as follows: IEEE 802.11b IEEE 802.11g Channel 1 Channel 6 Channel 11 Report No.: 230402194SHA-002 TEST REPORT TTRF15.247-03_V1 © 2018 Intertek Page 7 of 27 IEEE 802.11n-H…
