2A68EJX-UAM027UAM027

Shenzhen Uascent Technology Co., Ltd www.uascent-iot.com 1 Office: 7 / F, Building A2, Chuangzhi Yuncheng Phase 1, Xili Street, Nanshan District, Shenzhen City, CHINA TEL: +86-0755-82571152 E-MAIL: [email protected] Website: www.uascent-iot.com Customer Approval : Company Title Signature Date Uascent UAM027 Wi-Fi Single-band 1T1R 802.11b/g/n Module Datasheet Shenzhen Uascent Technology Co., Ltd Universal Ascent Holdings Limited Shenzhen Uascent Technology Co., Ltd www.uascent-iot.com UAM027-A0 2 Revision History. Version Date Revision Content Draft Approved 1.0 2023/06/15 New version Bella Shenzhen Uascent Technology Co., Ltd www.uascent-iot.com UAM027-A0 3 CONTENTS 1 Overview. ................................................................................................................................ 4 1.1 Introduction. .......................................................................................................................... 4 1.2 Features. ............................................................................................................................... 4 1.3 Recommended Operating Rating. ......................................................................................... 4 1.4 Reference power consumption for conventional continuous operation. ................................ 4 1.5 ESD Specifications ............................................................................................................... 5 2 Module usage precautions. ................................................................................................... 5 3 WiFi Specification. ................................................................................................................. 5 4 Pin Descriptions. .................................................................................................................... 6 4.1 Pin Outline. ........................................................................................................................... 6 4.2 Pin Definition. ........................................................................................................................ 6 5 Dimensions............................................................................................................................. 7 5.1 Module Picture. ..................................................................................................................... 7 5.2 Module Mechanical Dimensions. .......................................................................................... 8 5.3 PCB Layout Reference. ........................................................................................................ 8 6 Antenna Information. ............................................................................................................. 9 6.1 Antenna type. ........................................................................................................................ 9 6.2 Module layout considerations. ............................................................................................... 9 7 Environmental Requirements. .............................................................................................. 9 7.1 Recommended Reflow Profile. .............................................................................................. 9 7.2 Note. ................................................................................................................................... 10 7.3 Humidity sensitive control. .................................................................................................. 11 8 Package style. ...................................................................................................................... 12 8.1 Packaging Detail. ................................................................................................................ 12 9 Transport regulations. ......................................................................................................... 12 10 Disclaimer and copyright notice. ...................................................................................... 12 11 Attention. ............................................................................................................................ 13 12 FCC statements: ................................................................................................................ 13 UAM027-A0 Uascent Technology Co., Ltd 4 www.uascent-iot.com 1 Overview. 1.1 Introduction. UAM027 is a cost-effective WIFI+BLE module developed by Uascent Technology, supporting Bluetooth dual mode 5.1 and IEEE 802.11 b/g/n protocol standards, lightweight TCP/IP protocol stack, STA, AP, and Direct modes, and Matter protocol. Users can use this module to add networking functions to existing devices or build independent network controllers. 1.2 Features.  Operate at ISM frequency bands (2.4GHz).  Standard IEEE 802.11b/g/n.  Support WiFi+Bluetooth 5.1.  Support Wi-Fi and BLE coexist.  Support BLE assists in fast Wi-Fi connection.  Built-in low-power 32-bit MCU speed up to 120 MHz, can be used as an application processor.  Built-in 256KB RAM, 2MB or 4MB internal Flash, 32 bytes eFUSE.  Built-in lightweight TCP/IP stack.  Built-in TR switch, BALUN, LNA, PA, and PCB onboard antenna.  Support remote firmware OTA upgrade, support start upgrade through AT command.  Support STA and AP and Direct working modes.  Support WPS/WEP/WPA/WPA2 Personal/WPA2 Enterprise/WPA3 security protocol. 1.3 Recommended Operating Rating. Description Min Typ Max Unit Ambient Temperature (TA) -40 25 105 deg.C Vcc 3.0 3.3 3.6 V (VOL) Output low voltage VSS / VSS+0.3 V (VOH) Output high voltage VCC-0.3 / VCC V 1.4 Reference power consumption for conventional continuous operation. Parameter Condition / Notes Typ. Unit TX model I RF 11b 11M 270 mA I RF 11g 54M 260 mA UAM027-A0 Uascent Technology Co., Ltd 5 www.uascent-iot.com I …
