Shenzhen Uascent Technology Co., Ltd www.uascent- 1 Shenzhen Uascent Technology Co., Ltd Universal Ascent Holdings Limited UAM087-Matter Wi-Fi Single-band 1T1R 802.11b/g/n Module Datasheet Office: 2101, Zhongxing Hotel , No. 19, Xinghua 1st Road, Xin'an Street, Bao'an District, Shenzhen, China. TEL: +86-0755-82571152 E-MAIL: [email protected] Website: www.uascent-iot.com Customer Approval : Company Title Signature Date Shenzhen Uascent Technology Co., Ltd www.uascent- 2 UAM087-Matter Revision History. Version Date Revision Content Draft Approved 1.0 2024/04/25 New version Bella Shenzhen Uascent Technology Co., Ltd www.uascent- 3 UAM087-Matter CONTENTS 1 Overview. ................................................................................................................................................ 4 1.1 Introduction .......................................................................................................................................... 4 1.2 Features ............................................................................................................................................... 4 1.3 Recommended Operating Rating. .................................................................................................... 4 1.4 Reference power consumption for conventional continuous operation ..................................... 4 1.5 Low-power consumption .................................................................................................................... 5 1.6 ESD Specifications ............................................................................................................................. 5 2 Module use precautions ..................................................................................................................... 5 3 WiFi Specification ................................................................................................................................ 5 4 Bluetooth Specification ...................................................................................................................... 6 5 Pin Descriptions ................................................................................................................................... 6 5.1 Pin Outline ............................................................................................................................................ 6 5.2 Pin Definition ........................................................................................................................................ 6 6 Dimensions ............................................................................................................................................ 7 6.1 Module Picture ..................................................................................................................................... 7 6.2 Module Mechanical Dimensions ....................................................................................................... 8 7 Antenna Information ........................................................................................................................... 9 7.1 Antenna type ........................................................................................................................................ 9 7.2 Module layout considerations............................................................................................................ 9 8 Environmental Requirements ........................................................................................................... 9 8.1 Recommended Reflow Profile. ......................................................................................................... 9 8.2 Note .....................................................................................................................................................10 8.3 Humidity sensitive control ................................................................................................................11 9 Package. ...............................................................................................................................................12 9.1 Packaging Detail ...............................................................................................................................12 10 Transport regulations. ....................................................................................................................12 11 Disclaimer and copyright notice ..................................................................................................12 12 Attention .............................................................................................................................................13 UAM087-Matter www.uascent- Uascent Technology Co., 4 1 Overview. 1.1 Introduction. UAM087 is a cost-effective WIFI+BLE module developed by Uascent Technology, supporting Bluetooth dual mode 5.2 and IEEE 802.11 b/g/n protocol standards, lightweight TCP/IP protocol stack, STA, AP, and Direct modes, and Matter protocol. Users can use this module to add networking functions to existing devices or build independent network controllers. 1.2 Features.  Supports 20 MHz channel.  Standard IEEE 802.11b/g/n.  Support WiFi+Bluetooth 5.2.  Support STBC.  Built-in low-power 32-bit MCU speed up to 160MHz, can be used as an application processor.  Support STA and AP and Direct working modes.  Support BLE 1 Mbps. 1.3 Recommended Operating Rating. Description Min Typ Max Unit Ambient Temperature (TA) -40 25 85 deg.C Vcc 3.0 3.3 3.6 V (VOL) Output low voltage VSS VSS+0.3 V (VOH) Output high voltage VCC-0.3 VCC V 1.4 Reference power consumption for conventional continuous operation. Parameter Condition / Notes Typ. Unit TX Mode I RF 11b 11M 270 mA I RF 11g 54M 240 mA I RF 11n HT20 MCS7 230 mA RX Mode I RF 11b 11M 80 mA I RF 11g 54M 80 mA I RF 11n HT20 MCS7 80 mA UA…
