2A69E-RGHHDPBK-01HAND+

1 HAND+ August 2023 USER MANUAL 2 HAND+ USER MANUAL Scan the QR code with your phone to download the Rad Mobile App or go to https://radgolf.com/pages/download-the-rad-golf-app. DOWNLOAD THE RAD MOBILE APP USER MANUAL TABLE OF CONTENTS POWER ON YOUR HAND+ 4 HAND+ HOME SCREEN 4 STARTING A ROUND OF GOLF 4 PLAYING A ROUND OF GOLF 5 GOLF ROUND SCREENS 6 HAZARD ICON LIST 6 CONTROLLING YOUR RAD SPEAKERS 7 ENTERING YOUR SCORE 7 CHANGING HOLES 8 MAIN HAND+ SETTINGS 9 UPDATING YOUR HAND+ 10 RESETTING YOUR HAND+ 11 3 POWER ON YOUR HAND+ •To star t your Hand+, hold down the red side button for 3 seconds. •“Welcome” will be followed by your startup screen for 3-5 seconds as your Hand+ boots up HAND+ HOME SCREEN •Once your Hand+ boots up it will change to the Home screen which shows 2 main buttons. One to Play Golf and one to access Settings. •As you would expect, you can select the Play Golf button to start a round of golf and you can select Settings to open the Settings section of the Hand+. STARTING A ROUND OF GOLF •To initiate a round of golf simply select Play Golf. •Your Hand+ will begin looking for a GPS signal. For quickest results: •Make sure that you are outside and not inside a building when trying to acquire a GPS signal •Don’t move and hold the device with the screen facing upwards •Once your Hand+ has successfully fixed your GPS position, you will see a list of courses ordered from closest to your current location to furthest from your current location. •Swipe Up or Down to find your course and then tap the screen to choose. 4 HAND+ USER MANUAL •Once you select your course you need to choose your view. Swipe Right and Left to toggle between the Green View and the Classic View and hit select. •Green View will provide you with a projection of the shape of the green, as well as front, center, and back distances. •Classic View will provide you with front, center (in red), and back distances •Once you select your view, your round will begin. PLAYING A ROUND OF GOLF •After selecting a view, your round will start. In an active round, you will see: •Front, Center and Back Distance •Hole number •Par for the Hole •Track Shot - Touch to start tracking your shot distance •Tap the Shot text at the beginning of your shot, at which point the Hand+ will begin measuring your starting position to your shot landing position. Tap the number displayed to close the measurement, and tap again to begin a new measurement. 5 HAND+ USER MANUAL Green View Simple View GOLF ROUND SCREENS •While playing a round you can swipe up and down to cycle through different screens. •Home Screen - Shows the distances, Hole Number, Par and Shot •Scoring Screen - If you swipe down, then you will be able to enter your score for the hole. Swipe down again and it brings up the Green View screen. •Hazard View - Swipe Down again to view the Hazard Screen. This shows any major hazards. Arrows indicate which direction the hazard is from the tee box. •A list of possible icons and their meaning is shown below. •Speaker Controls - If you are connected to a Rad speaker, then the Speaker Controls screen will show when you swipe up from the Home Screen. •If you are not connected to a Rad speaker, then this screen will not appear. •You can continue to swipe up or down to cycle through all screens. •Pressing the side button brings you back to the Home Screen. HAZARD ICON LIST •To the right is the list of possible hazards and their meaning. •The 3 primary icons are for Bunkers, Water and the End of the Fairway. •Arrows indicate which direction from the middle of the fairway that the hazard is located. •Carry shows the distance needed to hit past the hazard. •Front shows the distance to the beginning of the hazard. 6 HAND+ USER MANUAL Swipe Up/Down CONTROLLING YOUR RAD SPEAKERS •If you own a Rad Sound or Sound+ you are able to control it from your Rad Hand+. Speaker control options include: •Volume Up •Volume Down •Rewind •Play/Pause •Fast Forward •Announce •By selecting announce, the front, center, and back distances from your Hand+ will be played through your speaker. ENTERING YOUR SCORE •You are able to quickly save your score after each hole by swiping down from the Home Screen and choosing the correct number for shots taken. •In the Settings there is a Preferences option and you can choose if you want to track putts and clubs. If you select to track putts, then you will be able to enter number of putts on the Enter Score screen as well. •After you leave the green on the 1st hole the Enter Score screen should automatically appear for you to enter your score. If you would prefer not to have this automatically happen after each hole, then you can press the side button or hit the menu icon in the top left of the screen to pull up the Settings screen and choose Preference, then toggle the Score Prompt option Off. 7 HAND+ USER MANUAL Putt Tracking Off Putt Tracking On CHANGING HOLES •The Hand+ uses GPS to automatically go to the hole that you are on, however if you want or need to change holes then just swipe left or right from the Golf Home Screen. • Scores entered on the Hand+ for holes that you are not currently on will transfer to the Rad Golf application, so ensure that your Hand+ is set to the hole you’re on. GOLF MENU •Pressing the side button or the menu icon in the top left while in an active round of golf will pull up the Golf Settings Menu. In the Golf menu you have multiple different options: • End Round - Allows you to end the round. • If you are connected to your Rad App it will also end the round on the app. • Preferences - Allows you to choose between the Green View and Simple View. You can also turn Score Prompt, Putt Tracking and Club Tracking on and off. • Edit Shot - This allows you to change the club you used on a shot or delete a shot altogether. • Brightness - Choose between High, Normal and Low screen brightness. The higher the brightness the less battery life you will have. • Power Save - This will dim the screen after 5 s…

Text truncated - open the document above for the full version.

Federal Communica/ons Commission Authoriza/on and Evalua/on Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 01-11- 2024 Ref: AKesta/on Statements Part 2.911(d)(7) Filing FCC ID or Grantee Code: 2A69E Rad Golf, Inc. cer/fies that, as of the date of the filing of the applica/on, we designate ourselves as the U.S. agent for service of process. Designated U.S. Agent Informa/on: FRN: 0032495640 Name: Rad Golf, Inc. Address: 4026 N. Miller road Suite 102, ScoKsdale, Arizona 85251, US Contact Person: Peter Johnson Tel.: (480) 747-3622 Email: [email protected] Sincerely, Rad Golf, Inc. Peter Johnson

Applicant Declaration QSF27-14-04 Rev 1.1 Jan 17, 2024 Page 1 of 1 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name Rad Golf, Inc. Address 4026 N. Miller road Suite 102, Scottsdale, Arizona 85251, US FRN 0032495640 Grantee Code 2A69E FCC ID 2A69E-RGHHDPBK-01 Authorized Contact Name Peter Johnson Contact Email [email protected] Contact Phone (480) 747-3622 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Link to the Covered List: Covered List Rad Golf, Inc. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Rad Golf, Inc. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered list, established pursuant to §1.50002, as an entity producing “covered” equipment. Applicant Signature: Date: 2024/01/11 Print Name: Peter Johnson Title: Certification Manager *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

RF_160, Issue 04 Rad Golf, Inc. Declaration of Authorization We Name: Rad Golf, Inc. Address: 4026 N. Miller road Suite 102, Scottsdale, Arizona 85251, US City: Scottsdale Country: America Declare that: Name Representative of agent: Well Wei Agent Company name: SGS-CSTC Standards Technical Services (Suzhou) Co., Ltd Address: South of No. 6 Plant, No. 1, Runsheng Road, Suzhou Industrial Park, Suzhou Area, China (Jiangsu) Pilot Free Trade Zone City: Suzhou Country China is authorized to apply for Certification of the following product(s): Product description: HAND+ Type designation: RGHHDPBK-01 Trademark: Rad Golf FCC ID: 2A69E-RGHHDPBK-01 on our behalf. Date: ............2024/01/11.................... City: ............ Scottsdale ................. Name: ............ Peter Johnson ......... Email: [email protected]....... Signature: ......... ...................

Rad Golf, Inc. 4026 N. Miller road Suite 102, Scottsdale, Arizona 85251, US Date: 2024/1/11 Federal Communications C ommission Office of Engineeri ng and Technology Laboratory Division 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Request for Confidentiality FCC ID: 2A69E-RGHHDPBK-01 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission’s rules (47C FR§§0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure indefinitely. lSchematic Diagram lBlock Diagram lOperational Description Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’ s policy, in order to comply with the marketing regulations in 47 CFT §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachment(s) for 180 days after the grant as outlined in Public Notice DA 04-1705. lExternal Photos lInternal Photos lTest Setup Photos lUser Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards, Date: ............2024/01/11.................... City: ............ Scottsdale ................. Name: ............ Peter Johnson ......... Email: [email protected]....... Signature: ............................

Compliance Certification Services (Kunshan) Inc. Page: 1 of 4 External Photos for KSCR2312002274AT Test Model No.: RGHHDPBK-01 Compliance Certification Services (Kunshan) Inc. Page: 2 of 4 EUT Constructional Details (EUT Photos) Compliance Certification Services (Kunshan) Inc. Page: 3 of 4 Compliance Certification Services (Kunshan) Inc. Page: 4 of 4

PVT1圖面 供試模用途 Hand+ Rad Golf Lasering 本材料不應該違反RoHS&WEEE裡指令的任何禁/限用物質 This part should not contain any substances which are Specified in RoHS&WEEE’s Directive. ERP Number Printing Model Number Unit / mmScale / 1:1 Dimensions Drawing NO. Material 料 號 型 號 圖 號 印 刷 尺 寸 材 質 SPECIFICATION PC+TPU L1 Hand Rad Golf GSMORADHAND02_PVT1 L5PCHAND00B100 Description 敘 述 廠 商Factory 產品工業設計中心 0.15mm + - 注意事項： 1. 須能通過酒精測試與百格測試 (進貨需附上備品供品保再次驗證可通過酒精測試方可驗收) 2. 位置公差 3. 字體須平行與垂直不能有錯位歪斜情況發生 4. 同一批不能有含兩種以上不同顏色色差 5. 字體與圖樣須能清晰辨識不能模糊不清 6. 不能有破裂、破損，等情況發生 AS Draw + - 0 mm 0.1mm Lasering ( Design Description Designer 設 計 Approver 審核 Date 日 期 設計描述 Version 版 本 1 ECN 2 3 4 5 Alisa2023.05.30 DVT1 FCC:2A69E/IC:RGHHDPBK01) N/A Alisa2023.06.21 PVT1 (0530PVT) N/A Alisa2023.09.28 PVT1 () N/A Rad Golf, Inc. | Scottsdale, AZ Rad Hand+ | Model: RGHHDPBK-01 FCC ID: 2A69E-RGHHDPBK-01 IC: 28643-RGHHDPBK01 S/N-G2311HHDPBK01001 Made in Taiwan Rad Golf, Inc. | Scottsdale, AZ Rad Hand+ | Model: RGHHDPBK-01 FCC ID: 2A69E-RGHHDPBK-01 IC: 28643-RGHHDPBK01 S/N-G2310HHDPBK01001 Made in Taiwan Laser Printing Artwork 產品雷雕位置示意圖 S/N - GAABBCDDDEEXXXXX G : Manufacturer AA : Year manufactured BB : Month of manufacture C : Categories ”H” DDD : Model “HDP” EE: ,BLACK ”BK” XXXXX: 5 Serial code 01001~ 03000 01001~ 0300003001~ : S/N - G2310HHDPBK01001 Serial Number 16code 128 01001~ 03000 H HDP BK 20.3mm 18.2mm

Compliance Certification Services (Kunshan) Inc. Page: 1 of 6 Internal Photos for KSCR2312002274AT Test Model No.: RGHHDPBK-01 Compliance Certification Services (Kunshan) Inc. Page: 2 of 6 EUT Constructional Details (EUT Photos) Compliance Certification Services (Kunshan) Inc. Page: 3 of 6 Compliance Certification Services (Kunshan) Inc. Page: 4 of 6 Compliance Certification Services (Kunshan) Inc. Page: 5 of 6 Compliance Certification Services (Kunshan) Inc. Page: 6 of 6

Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR231200227301 Page: 1 of 18 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 30 days only. Member of the SGS Group (SGS SA) TEST REPORT Application No.: FCC ID: KSCR2312002273AT 2A69E-RGHHDPBK-01 Applicant: Rad Golf, Inc. Address of Applicant: 4026 N. Miller road Suite 102, Scottsdale, Arizona 85251, US Manufacturer: GlobalSat WorldCom Corporation Address of Manufacturer: 16F., No.186, Jian 1st Rd. Zhonghe Dist., New Taipei City 23553 Taiwan Factory: GlobalSat WorldCom Corporation Address of Factory: 16F., No.186, Jian 1st Rd. Zhonghe Dist., New Taipei City 23553 Taiwan Equipment Under Test (EUT): EUT Name: HAND+ Model No.: RGHHDPBK-01 Trade Mark: Rad Golf Standard(s) : 47 CFR Part 15, Subpart B Date of Receipt: 2023-12-14 Date of Test: 2023-12-29 to 2023-12-30 Date of Issue: 2024-01-09 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR231200227301 Page: 2 of 18 Revision Record Version Description Date Remark 00 Original 2024-01-09 / Authorized for issue by: Tested By Eric_Liu/Project Engineer Approved By Terry Hou /Reviewer Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR231200227301 Page: 3 of 18 2 Test Summary Emission Part Item Standard Method Requirement Result Conducted Emissions at Mains Terminals (150kHz-30MHz) 47 CFR Part 15, Subpart B ANSI C63.4:2014 15.107(a);Class B Pass Radiated Emissions (30MHz-1GHz) ANSI C63.4:2014 15.109(a);Class B Pass Radiated Emissions (Above 1GHz) ANSI C63.4:2014 15.109(g);Class B Pass Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR231200227301 Page: 4 of 18 3 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 Test Summary ........................................................................................................................................... 3 3 Contents .................................................................................................................................................... 4 4 General Information .................................................................................................................................. 5 4.1 Details of E.U.T. ................................................................................................................................. 5 4.2 Description of Support Units .............................................................................................................. 5 4.3 Measurement Uncertainty & Decision Rule ....................................................................................... 5 4.4 Test Location ...................................................................................................................................... 6 4.5 Test Facility ........................................................................................................................................ 6 4.6 Deviation from Standards ................................................................................................................... 6 4.7 Abnormalities from Standard Conditions ........................................................................................... 6 5 Equipment List .......................................................................................................................................... 7 6 Emission Test Results ............................................................................................................................. 8 6.1 Conducted Emissions at Mains Terminals (150kHz-30MHz) ............................................................ 8 6.2 Radiated Emissions (30MHz-1GHz) ................................................................................................ 11 6.3 Radiated Emissions (Above 1GHz).................................................................................................. 15 7 Test Setup Photo .................................................................................................................................... 18 8 EUT Constructional Details (EUT Photos) ........................................................................................... 18 Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR231200227301 Page: 5 of 18 4 General Information 4.1 Details of E.U.T. Power supply: DC 5V by adapter 4.2 Description of Support Units Des…

Text truncated - open the document above for the full version.

Compliance Certification Services (Kunshan) Inc. Page: 1 of 3 Appendix Photographs of Test Setup for KSCR2312002273AT Test Model No.: RGHHDPBK-01 Compliance Certification Services (Kunshan) Inc. Page: 2 of 3 Test Setup Photo Conducted Emissions at Mains Terminals (150kHz-30MHz) Radiated Emissions (30MHz-1GHz) Compliance Certification Services (Kunshan) Inc. Page: 3 of 3 Radiated Emissions (Above 1GHz)
