2A6IQ-VTL202302VERTU IRONFLIP 5G digital mobile phone

Quick Guide Welcome to use VERTU IRONFLIP Device Model：VTL-202302 Device Name：VERTU IRONFLIP 5G Digital Mobile Phone Manufactuer：Chengdu VERTU Business And Service Management Co., Ltd. OVERVIEW About Your VERTU IRONFLIP The User Guide is designed to show you how to work with main features of VERTU IRONFLIP. To get premium privileges and benefits, such as My Vertu, Vertu Life and Find My Vertu, you need to register VERTU. The images used in the User Guide are only for illustration and may differ from the actual product. Help and Support To learn more about your device: Press use Vertu Life app to contact VERTU. Refer to the User Guide by visiting website: https://www.vertu.com Caution This product is a fold type phone with an internal screen that can be folded inward. Please note the following items: •The inner screen has been coated with a special protective film before leaving the factory. Please do not remove or paste other protective films on your own, otherwise it may cause damage to the screen. If replacement is necessary, please go to the official VERTU authorized customer service center for support. •When folding a phone, do not place any items such as cards, coins, or keys on the internal screen. This can cause serious damage to the screen. •Do not use any hard or sharp objects (such as pens or keys) to press the inner screen or the camera area on the screen, or apply excessive pressure, as this may cause damage to the screen. •Please do not fold your phone towards the back to avoid damaging it. •Before storing the phone, it is recommended to fold it first to avoid hard or sharp objects that may scratch or damage the internal screen. •Slight creases and bends in the folding area of the inner screen, as well as slight noises when folding or flipping the phone, are all normal phenomena. PRODUCT OVERVIEW Front Camera Touch Screen Speaker USB T ype-C / Headphone Jack nano-SIM /nano-UIM Card Card slot Fingerprint Rear Camera And Flash NFC area Rear screen Microphone Power Key Volume Key Microphone Receiver Distance and Light Sensor • Description: •You may insert or take out the nano-SIM/ nano-UIM card when the mobile phone is on. •When the mobile phone needs to be rebooted in the case of errors, you may attempt to tap and hold the Power Button for more than 10 seconds to reboot the mobile phone. •In the case of low battery level, the mobile phone may not be turned on even when it is in charging state. In that case, please keep charging the mobile phone for 30 minutes to restore the battery level. If the mobile phone still cannot be turned on after being charged for 30 minutes,please contact the After-Sales Service Center of VERTU. •Please use the standard charger and data cable provided by VERTU. Charging with unauthorized charger or data cable may cause battery explosion or damage your phone. GET STARTED •Take out the cardholder with the needle and install the nano-SIM card or nano-UIM card, as shown in the figure. •5G SA/NSA are supported. Both card 1 and card 2 support the 5G/4G/3G/2G network of China Unicom, 5G/4G/2G network of China Mobile, 5G/4G of China Telecom and 5G of CBN. •Attention! •If both cards are issued by China Telecom, the Volte function must be enabled before use of the auxiliary card (non-data card). •Please consult local network operator to learn whether the Volte function is supported. •Whether SA/NSA is supported depends on the deployment of local network operator. •Warning! •Please use standard needle rather than sharp objects. The card may not be taken out if non-standard needle is used. •Please align with the circular center of the cardholder to poke it out to avoid any damage to the phone. •Please use the standard nano-SIM card/ nano-UIM card provided by the operator. Don’t insert cards of other specifications or cut the cards to avoid any damage to the phone. •Don’t insert or take out the card when the phone is connected to external power supply. •Do not attempt to disassemble the rear cover and battery of the mobile phone. To replace battery, please contact the After-Sales Service Center of VERTU. •The tempered film on the curved screen may squeeze out excessive glue on both sides of the left and right radians, and may affect the gesture navigation function, which is not the quality defect the mobile phone. Card 1 Card 2 PHONE PROTECTION Overall Protection •Please use VERTU IRONFLIP product as described in the documentation. Improper use may affect the performance. •Don’t try to disassemble VERTU IRONFLIP mobile phone. You only need to open SIM card slot. Your VERTU IRONFLIP mobile phone shall be only repaired by service personnel authorized by VERTU. •Don’t use the VERTU IRONFLIP mobile phone rudely or improperly. •Only use the accessories permitted by VERTU. •The accompanying charger is only used for charging VERTU IRONFLIP mobile phone. It shall not be used for any other devices,otherwise permanent damage may be caused to the mobile phone, battery or charger. •Please keep your VERTU IRONFLIP mobile phone and all parts and accessories out of reach of children and pets. •Please don’t make VERTU IRONFLIP mobile phone, battery or accessories in contact with liquid or moisture and dust and dirt. •Don’t expose your VERTU IRONFLIP mobile phone to extreme humidity, otherwise this may cause the battery to temporarily stop working. When the temperature is below the freezing point, its performance will be significantly reduced. •Don’t smear paint or other similar substances on your VERTU IRONFLIP mobile phone. •Clean your VERTU IRONFLIP mobile phone only using soft and clean cloth. Don’t use chemicals, detergents, abrasives or any liquids. Clean the camera before use. •Don’t insert any sharp object into speaker or data port. If VERTU IRONFLIP mobile phone or any accessory cannot work normally, please contact VERTU dealer. Copyright © 2023 VERTU. All Rights Reserved. Imported Leather Leather is natural material, which will result in non-erasable pollution, etc. fo…

Text truncated - open the document above for the full version.

Rev 1/26/2023 VERTU INTERNATIONAL CORPORATION LIMITED. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Company name: VERTU INTERNATIONAL CORPORATION LIMITED. Address: Chase Business Centre 39-41 Chase Side London England N14 5BP Product Name: VERTU IRONFLIP 5G digital mobile phone FCC ID: 2A6IQ-VTL202302 Model(s): VTL-202302 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing We, [VERTU INTERNATIONAL CORPORATION LIMITED. ] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Yours Sincerely, Name: Ziyu Wang Date: 2024-04-17 Title: Manager Signature of applicant:

Rev 1/26/2023 VERTU INTERNATIONAL CORPORATION LIMITED Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Company name: VERTU INTERNATIONAL CORPORATION LIMITED. Address: Chase Business Centre 39-41 Chase Side London England N14 5BP Product Name: METAVERTU 2 5G digital mobile phone FCC ID: 2A6IQ-VTL202302 Model(s): VTL-202302 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing We, [VERTU INTERNATIONAL CORPORATION LIMITED ] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Yours Sincerely, Name: Ziyu Wang Date: 2024-04-17 Title: Manager Signature of applicant:

Rev 1/26/2023 VERTU INTERNATIONAL CORPORATION LIMITED Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2023.12.28 Company name: VERTU INTERNATIONAL CORPORATION LIMITED. Address:Chase Business Centre 39-41 Chase Side London England N14 5BP FRN: 0032278830 Contact Person: Ziyu Wang Tel.: +86 173 6010 0716 Email: [email protected] Product Name: METAVERTU 2 5G digital mobile phone FCCID:2A6IQ-VTL202302 Model(s):VTL-202302 Ref: Attestation Statements Part 2.911(d)(7) Filing We, [ VERTU INTERNATIONAL CORPORATION LIMITED] (“the applicant”) certifies that, as of the date of the filing of the application,FCC US Agent,LLCis our designated U.S. agent for service of process for the above referenced FCC ID. [ VERTU INTERNATIONAL CORPORATION LIMITED] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. FCC US Agent,LLCaccepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Company Name: FCC US Agent, LLC Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Contact Person: Tim Payne Tel.: 708-571-3148 Email: [email protected] FRN: 0033402884 Sincerely, Applicant printed name: Ziyu Wang U.S. Agent printed name: Tim Payne Applicant signature: U.S. Agent signature:

VERTU INTERNATIONAL CORPORATION LIMITED Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2024/04/17 Subject; Request for Confidentiality FCC ID: 2A6IQ-VTL202302 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description BOM List Tune up procedure Software Security Info In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Ziyu Wang

FCC E-Label Information A. Images of the e-label screen are provided below: B. Access to the required information on the e-label Users are able to access the information in no more than three steps in a device’s menu. The actual steps are: Settings > About phone > Legal information No any special accessories, access codes, or SIM card are required to go through the above steps. C. Devices have physical labels at point of marketing/sale visible to the purchaser (or in the alternative, on the packaging), and at time of importation? At the time of importation, marketing, and sale, the device will have the required physical label on the packaging, which will include the device’s FCC ID. D. Electronic labeling information is programmed into the device by the manufacturer at the time of manufacture. Yes. E. Electronic labeling information not modifiable by any third party. The e-label of the device is programmed by the grantee and secured in such a manner that it cannot be modified by third parties. F. All the applicable regulatory information required on the packaging or user instructions is provided according to the rules. Applicable regulatory information not found in the e-label is contained in the user manual.

Chengdu VERTU Business And Service Management Co.,Ltd. Made in China VERTU IRONFLIP 5G DIGITAL MOBILE PHONE Model: VTL-202302 FCC ID:2A6IQ-VTL202302 IC:28629-VTL202302 VERTU IRONFLIP 5G DIGITAL MOBILE PHONE Model: VTL-202302 FCC ID:2A6IQ-VTL202302 IC:28629-VTL202302 Chengdu VERTU Business And Service Management Co.,Ltd. Made in China

Report No.: 20240117G01519X-W1 CCIC-SET/TRF: GJ-EMC-E (2020-01-09) Page 1 of 20 EMC TEST REPORT Report No.: 20240117G01519X-W1 Product Name: VERTU IRONFLIP 5G digital mobile phone Model No. : VTL-202302 FCC ID: 2A6IQ-VTL202302 Applicant: VERTU INTERNATIONAL CORPORATION LIMITED Address: Chase Business Centre 39-41 Chase Side London England N14 5BP Received Date: 2024.01.22 Dates of Testing: 2024.01.23-2024.01.30 Issued by: CCIC Southern Testing Co., Ltd. Lab Location: Electronic Testing Building, No. 43 Shahe Road, Xili Street, Nanshan District, Shenzhen, Guangdong, China. Tel: 86 755 26627338 Fax: 86 755 26627238 This test report consists of 20 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CCIC-SET. The test results in the report only apply to the tested sample. The test report shall be invalid without all the signatures of testing engineers, reviewer and approver. Any objections must be raised to CCIC-SET within 15 days since the date when the report is received. It will not be taken into consideration beyond this limit. Report No.: 20240117G01519X-W1 CCIC-SET/TRF: GJ-EMC-E (2020-01-09) Page 2 of 20 Test Report Product Name ....................... : VERTU IRONFLIP 5G digital mobile phone Model No. ............................ : VTL-202302 Trade name VERTU Applicant ............................... : VERTU INTERNATIONAL CORPORATION LIMITED Applicant Address................ : Chase Business Centre 39-41 Chase Side London England N14 5BP Manufacturer ........................ : Chengdu VERTU Business And Service Management Co., Ltd Manufacturer Address ......... : Room 2308, 23rd Floor, Building 2, No.1199,North Tianfu Avenue, High-tech Zone, Chengdu, China (Sichuan) Pilot Free Trade Zone Test Standards ...................... : 47 CFR Part 15 Subpart B, ICES-003 Issue 7 Test Result ............................ : PASS Tested by ............................. : Sun Jiaohui Test Engineer 2024.04.08 Reviewed by ......................... : Chris You Senior Engineer 2024.04.08 Approved by ......................... : 2024.04.08 Yang Fan, Manager[盖章] Report No.: 20240117G01519X-W1 CCIC-SET/TRF: GJ-EMC-E (2020-01-09) Page 3 of 20 TABLE OF CONTENTS 1. GENERAL INFORMATION .................................................................................................... 5 1.1 EUT Description ......................................................................................................................... 5 1.2 Test Standards and Results ........................................................................................................ 6 Facilities and Accreditations ................................................................................................................ 7 1.2.1 Facilities .................................................................................................................................... 7 1.2.2 Test Environment Conditions .................................................................................................... 7 1.2.3 Measurement Uncertainty ......................................................................................................... 7 2. TEST CONDITIONS SETTING .............................................................................................. 8 2.1 Test Peripherals .......................................................................................................................... 8 2.2 Test Mode .................................................................................................................................... 8 2.3 Test Setup and Equipments List ................................................................................................ 9 2.3.1 Conducted Emission ................................................................................................................. 9 2.3.2 Radiated Emission ................................................................................................................... 10 3. TEST REQUIREMENTS ........................................................................................................ 12 3.1 Conducted Emission ................................................................................................................. 12 3.1.1 Requirement ............................................................................................................................ 12 3.1.2 Test Description ...................................................................................................................... 12 3.1.3 Test Result ............................................................................................................................... 12 3.2 Radiated Emission .................................................................................................................... 15 3.2.1 Requirement ............................................................................................................................ 15 3.2.2 Test Description ...................................................................................................................... 16 3.2.3 Test Result ............................................................................................................................... 16 Report No.: 20240117G01519X-W1 CCIC-SET/TRF: GJ-EMC-E (2020-01-09) Page 4 of 20 Change History Issue Date Reason for change 1.0 2024.04.08 First edition Report No.: 20240117G01519X-W1 CCIC-SET/TRF: GJ-EMC-E (2020-01-09) Page 5 of 20 1. GENERAL INFORMATION 1.1 EUT Description EUT Name .......................... .: VERTU IRONFLIP 5G digital mobile phone Trade Name.....................: VERTU Brand Name.....................: VERTU Hardware Version............ : P10 Software Version .................. : 13.0.0_6.0…

Text truncated - open the document above for the full version.

Antenna Specification Applicant VERTU INTERNATIONAL CORPORATION LIMITED Model VTL-202302 Product Name VERTU IRONFLIP 5G digital mobile phone Support Band 2.4G:802.11b/g/n/ax, BT 5G :802.11a/n/ac/ax Max. Gain 2.4G(WIFI/BT) ch0: 1.0dBi, ch1:-1.5dBi 5GWIFI ch0 : -1.2dBi, ch1:-0.8dBi Antenna pattern 2.4G CH0 2.4G CH1 WiFi 5G CH0 WiFi 5G CH1 beamforming Not support NFC antenna Size: 41.8mm×32.4mm

Antenna Support Band ANT 1 GSM 850,CDMA BC 0,WCDMA 850,LTE Band 5 / 12 / 17,5G NR 5 ANT 2 GSM 1900,WCDMA 1700 / 1900,LTE Band 2 / 4 / 7 / 41,5G NR 41 ANT 3 GSM 850,CDMA BC 0,WCDMA 850,LTE Band 5 / 12 / 17,5G NR 5 ANT 4 LTE Band 41,5G NR 41 ANT 5 5G NR 77 / 78 ANT 6 GSM 1900,WCDMA 1700 / 1900,LTE Band 2 / 4 / 7 / 41,5G NR 41 ANT 7 5G NR 77 / 78 ANT 8 LTE Band 41,5G NR 38 / 77 / 78 ANT 10 5G NR 77 / 78 ANT 11 5GWIFI ANT 12 2.4GWIFI, Bluetooth ANT 13 2.4GWIFI, 5GWIFI, Bluetooth ANT10 NFC ANT ANT 1 ANT 2 ANT 8 ANT 4 ANT 5 ANT 6, 7 ANT 9 ANT 13 ANT 3 ANT 11, 12
