2A6JE-S110BBL-FSmart Door Lock

Smart Door Lock S110BBL-F FOR CUSTOMER SERVICE PLEASE CALL: (800)-315-9607 WWW.ELEMAKELOCKS.COM Elemake keeps on working hard to provide customers top-grade quali ty hardware at affordable price. Gracing customers’ doors with stylish designs and excellent craftsmanship since 1976, Elemake is always dedicated to making your life more safe and stylish. Series-ITD locks are a family of touch screen and fingerprint internet deadbolts. They are ideal for residential homes, apartment buildings, offices, schools, hospitals, and other applications where restricted access to an area is needed. All of ELEMAKE ITD series keyless deadbolt products come with a 5 years’ warranty. NOTE TO INSTALLER Watching the videos are highly recommended, the video will help the customer to understand the installation and functions more easily. Installation Video Linkage: Functions Instruction Video Linkage: FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN DAMAGE TO THE PRODUCT AND VOID THE FACTORY WARRANTY For Technical Assistance call Elemake at 1 (800)315-9607 QUICK SOLUTIONS TO COMMON PROBLEMS: Initial Password: 123456 TABLE OF CONTENT 1. Warnings.........................................................................................2 2. Reset Lock To Factory Default...........................................................3 3. Introduction.....................................................................................4 3.1 Installation (1) Step 1----Define the right-handed or left-handed door......5 (2) Step 2----Components and Tools.......................................5 (3) Step 3----Prepare Deadbolt for Installation.......................6 (4) Step 4 ---Install Deadbolt and door position sensor .........................................................................7-8 4. Setting up.........................................................................................4 4.1 Steps to setup ..................................................................4 4.2 Add members ...................................................................4 4.3 Connect to Wifi .................................................................4 5. How to use the Elemake touchscreen deadbolt 3.2.1 Basic Functions(Local Operation) ...............................9-10 3.2.2 Internet Functions.....................................................11-13 5. Trouble shooting................................................................................4 6. Quality Policy.....................................................................................20 TABLE OF CONTENTS 1.WARNINGS FCC: Class B Equipment Series ITD series deadbolt has been tested and found to comply with the limits for a Class B digital device---Part 15 of the FCC Rules. These limits are purposed to provide protection against harmful interference in a residential environment. The deadbolt generates, uses, and can radiate RF energy and, if not installed and used as the instructions on users’ manual, may have harmful interference to radio communications. However, If this deadbolt does cause harmful Interference to radio or television reception, which can be determined by turning the deadbolt off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Relocate the radio communication devices’ receiving antenna. •Make separation between the deadbolt and receiver. •Consult the customer service or professional radio/ technician for help. . 2. RESET DEADBOLT TO FACTORY DEFAULT The following procedure clears all the setting of the deadbolt, and returns the deadbolt to default – deleting all user password/fingerprint/card. 2.1 RESET METHOD 1( see Figure A-1 to Figure A-4) Figure A-1 Remove the batteries and wait for 20 seconds, Hold down the reset button at the bottom of the inside escutcheon RESET BUTTON Figure A-2 2.2 RESET METHOD 2( see Figure B-1) This method is only for the family member who already get the password/fingerprint enrolled(Please must keep the door opened when doing the reset) Install the batteries into the inside escutcheon Hold down the reset button 10-30s till voice says “reset success” Figure A-3 Figure A-4 Touch the screen with the back of hand to activate the deadbolt,and input 888, The voice will remind family member to input the enrolled password or touch the fingerprint for validation. After validation, the deadbolt will be reset till the voice says ”Reset success” Figure B-1 3. INSTALLATION IMPORTANT THINGS INSTALLER NEED TO KNOW PRIOR TO INSTALLATION a. Initial password “123456” b. Bolt Direction Please make sure the bolt is installed in correct direction according to ”up” mark on the bolt. (see Figure C1) c. The bolt must be in a retracted (unlocked) position when installing the lockset. (see Figure C2) d. The cable from the outside escutcheon should go under the bolt, (see Figure C-3) and should go through the slot at the right side of the mounting bracket. (see Figure C-4) Figure C-1 Figure C-2 Figure C-3 Figure C-4 e. Thumb turn on inside escutcheon need to be turned to different position for right handed door or left handed door in inside escutcheon installation. (see Figure C-5) f. Before installing the batteries, test the mechanical operation of the lock by using Both thumb turn and the key. The movement of the bolt should be smooth and unobstructed. If operation is not smooth, review the previous steps to ensure proper installation. (see Figure C-6) Vertical Position For Right Handed Door Horizontal Position For Right Handed Door Figure C-5 g. After the installation, connect the deadbolt to Smartlife APP, choose the correct setting for door direction(setting>motor rotation direction>clockwise unlock/counterclockwise unlock) (see Figure C-7) Choose COUNTERCLOCKWISE for RIGHT HANDED DOOR Choose CLOCKWISE for LEFT HANDED DOOR Figure C-6 Figure C-7 h. Assembly drawing(See Figure C-8) 3.1 STEP 1----DEFINE THE RIGHT HANDED OR LEFT HANDED DOOR. To Ensure Proper Lock Handing and fo…

Text truncated - open the document above for the full version.

GUANGZHOU ONLENSE ELECTRONIC SCIENCE & TECHNOLOGY CO., LTD. Model Difference Product Name: Smart Door Lock Model Number: S110BBL-F, S110D, S110W, S110DBL, S110WBL, S110DBL-F, S110WBL-F, S110BTY-F, S110DTY-F, S110WTY-F, S110BTY, S350BBL, S350BBL-F, N1TY, S110DTY, S110WTY FCC Identifier: 2A6JE-S110BBL-F All the models are the same circuit and RF module, except the model names and outlook color. Regards Sincerely Client’s signature Client’s name / title : Chen Hong / Manager Contact information / address: Unit 201, No. 6, Zhongjiazhuang Xi RD, Dalong, Panyu, Guangzhou, China

GUANGZHOU ONLENSE ELECTRONIC SCIENCE & TECHNOLOGY CO., LTD. 1/1 Letter of Authorization Company: GUANGZHOU ONLENSE ELECTRONIC SCIENCE & TECHNOLOGY CO., LTD. Address: Unit 201, No. 6, Zhongjiazhuang Xi RD, Dalong, Panyu, Guangzhou, China Product Name: Smart Door Lock Model Number: S110BBL-F, S110D, S110W, S110DBL, S110WBL, S110DBL-F, S110WBL-F, S110BTY-F, S110DTY-F, S110WTY-F, S110BTY, S350BBL, S350BBL-F, N1TY, S110DTY, S110WTY FCC Identifier: 2A6JE-S110BBL-F We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Chen Hong Date: 2022-04-20 Title: Manager Signature of applicant:

GUANGZHOU ONLENSE ELECTRONIC SCIENCE & TECHNOLOGY CO., LTD. 1/1 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2022-04-20 Subject: Request for Confidentiality FCC ID: 2A6JE-S110BBL-F To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual No ☐ Internal Photos No ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Chen Hong Title: Manager

Size:18*12mm M/N: S110BBL-F FCC ID: 2A6JE-S110BBL-F Label location

ANT

Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220406028E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 1 of 33 FCC Part 15C Test Report FCC ID: 2A6JE-S110BBL-F Applicant: GUANGZHOU ONLENSE ELECTRONIC SCIENCE & TECHNOLOGY CO., LTD. Address: Unit 201, No. 6, Zhongjiazhuang Xi RD, Dalong, Panyu, Guangzhou, China Manufacturer: GUANGZHOU ONLENSE ELECTRONIC SCIENCE & TECHNOLOGY CO., LTD. Address: Unit 201, No. 6, Zhongjiazhuang Xi RD, Dalong, Panyu, Guangzhou, China EUT: Smart Door Lock Trade Mark: N/A Model Number: S110BBL-F, S110D, S110W, S110DBL, S110WBL, S110DBL-F, S110WBL-F, S110BTY-F, S110DTY-F, S110WTY-F, S110BTY, S350BBL, S350BBL-F, N1TY, S110DTY, S110WTY Date of Receipt: Mar. 28, 2022 Test Date: Mar. 28, 2022 - Apr. 07, 2022 Date of Report: Apr. 07, 2022 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Building C, Shuanghuan, No.8, Baoqing Road, Baolong Industrial Zone, Baolong Street, Longgang District, Shenzhen, Guangdong, China Applicable Standards: FCC PART 15 C 15.249 ANSI C63.10:2013 Test Result: Pass Report Number: DL-20220406028E Prepared (Test Engineer): Pxing Huang Reviewer (Supervisor): Jack Bu Approved (Manager): Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220406028E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 33 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 MEASUREMENT UNCERTAINTY 4 2 . GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 DESCRIPTION OF TEST MODES 6 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 7 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 7 2.5 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 7 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 8 3 . EMC EMISSION TEST 9 3.1 CONDUCTED EMISSION MEASUREMENT 9 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 9 3.1.2 TEST PROCEDURE 9 3.1.3 DEVIATION FROM TEST STANDARD 9 3.1.4 TEST SETUP 10 3.1.5 EUT OPERATING CONDITIONS 10 3.1.6 TEST RESULTS 10 3.2 RADIATED EMISSION MEASUREMENT 11 3.2.1 RADIATED EMISSION LIMITS 11 3.2.2 TEST PROCEDURE 12 3.2.3 DEVIATION FROM TEST STANDARD 12 3.2.4 TEST SETUP 12 3.2.5 EUT OPERATING CONDITIONS 13 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 14 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 15 3.2.8 TEST RESULTS (1GHZ~25GHZ) 17 3.3 RADIATED BAND EMISSION MEASUREMENT 18 3.3.1 TEST REQUIREMENT: 18 3.3.2 TEST PROCEDURE 18 3.3.3 DEVIATION FROM TEST STANDARD 18 3.3.4 TEST SETUP 19 3.3.5 EUT OPERATING CONDITIONS 19 4 . BANDWIDTH TEST 21 4.1 APPLIED PROCEDURES / LIMIT 21 4.1.1 TEST PROCEDURE 21 4.1.2 DEVIATION FROM STANDARD 21 4.1.3 TEST SETUP 21 4.1.4 EUT OPERATION CONDITIONS 21 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220406028E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 3 of 33 Table of Contents Page 4.1.5 TEST RESULTS 22 5 . ANTENNA REQUIREMENT 23 5.1 STANDARD REQUIREMENT 23 5.2 EUT ANTENNA 23 6 . TEST SEUUP PHOTO 24 7 . EUT PHOTO 25 Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220406028E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 4 of 33 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.249) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A 15.249(c) Fundamental &Radiated Spurious Emission Measurement PASS 15.205 Band Edge Emission PASS 15.215 20dB Bandwidth PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2,providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 Conducted Emission Test ±2.56dB 2 RF power,conducted ±0.42dB 3 Spurious emissions,conducted ±2.76dB 4 All emissions,radiated(<1G) ±3.65dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220406028E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 5 of 33 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product Name: Smart Door Lock Trademark N/A Model No.: S110BBL-F, S110D, S110W, S110DBL, S110WBL, S110DBL-F, S110WBL-F, S110BTY-F, S110DTY-F, S110WTY-F, S110BTY, S350BBL, S350BBL-F, N1TY, S110DTY, S110WTY Model Difference All samples are the same except the model name and outlook color, so we prepare "S110BBL-F" for test only. Operation Frequency: 2402~2480MHz Channel numbers: 40 Channels Channel separation: 2M Modulation technology: GFSK Antenna Type: Internal Antenna Antenna gain: 0dBi Power supply: DC 6V from battery Note: 1.For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2.The EUT’s all information provided by client. Shenzhen DL Testing Technology Co., Ltd. Report No.: DL-20220406028E Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 6 of 33 3. Channel List Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 00 2402 14 2430 27 2456 01 2404 15 2432 28 2458 02 2406 16 2434 29 2460 03 2408 17 2436 30 2462 04 2410 18 2438 31 2464 05 2412 19 2440 32 2466 06 2414 20 2442 33 2468 07 2416 21 2444 34 2470 08 2418 22 2446 35 2472 09 2420 23 2448 36 2474 10 2422 24 2450 37 2476 11 2424 25 2452 38 2478 12 2426 26 2454 39 2480 13 2428 / / / / 2.2 DESCRIPTION OF TEST MODES Note: (1) The measurements are performed at the highest, middle, lowest available channels. To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following E…
