2A6P9-ADC940Dash camera

DashcamUserManual Productfeatures Front4K.Left/Right/Back1080 Thereisnogaporomissionbetweenthearchives 2.78-inchscreen High-definitioncamera Videofileformat:TSbitstream Built-inmicrophone Built-inmicrophonespeaker Supportshigh-capacityTF(microSD)memorycardswith amaximumcapacityof512G Built-inWIFIfunction G-sensorimpactsensinggearlockingfunction Built-inGPS(optional） Supportforvoltagereductionlines(optional) Supportsrear-pullcamerafunction(optional) ProductDescription Productstructure 1)Rearviewinterface2)Powerinterface 3)Displayscreen4)Indicatorlight 5)Leftcamera6）Therearealsobuttonsfor flippingup7)Menukey8)Clickthepage-turning button 9)OKbutton10)"Replaybutton"11）Powerbutton 12）Rightcamera 13）Frontcamera14)"Horn" 一：Keydescriptionandfunctiondescription 1.Rearviewinterface:Videoinputportforthe rearviewmirrorhead 2.Powersocket:Itisusedtoconnectanexternal voltagereducinglineorvehiclechargingsourceto provideworkingpowerforthemachine 3.Displayareaofthescreen 4.Workindicatorlight:Afterstartup,thered indicatorlightremainsconstantlyon,whiletheblue indicatorlightflashesslowlyduringvideorecording 5.Leftcamera 6.Thepage-flippingbutton:Inthevideorecording mode,brieflypresstocaptureaphoto.Onthemenupage, brieflypresstoflipupthepage 7.Menukey:Pausethevideobybrieflypressingto enterthemenuSettingspage,andbrieflyreturntothe menuSettingspage 8.Downpage-turningkey:Shortpresstoswitchdisplay Windowswhileinvideorecordingmode,andshortpress toturnpagesuponmenupages 9.OKbutton:Shortpressonthevideorecordingpage tostartorstoptherecording.Shortpressonthemenu pagetoconfirm 10.Playbackbutton:Ashortpresswillenterthe playbackpage 11.Powerbutton:Shortpresstoturnonoroffthescreen, longpresstopoweroff 12.Rightsidecamera 13.Frontcamera 14."Horn" 二：SpecialFunctionDescription 1）G-sensorfunction Whengravityaccelerates(1g=9.80meterspersecond^2), themachinewillautomaticallylockthevideoofthe accidentandsaveitasanunerasablefile. TheG-sensorgravitysensorcanbeselectedinthemenu. Thismachineissetwithfoursensitivityoptions:off, low,mediumandhigh.Thefactorydefaultisoff. 2)One-clickplayback Shortpresstoenterthevideoplaybackpagetoviewthe recordedvideo. 3)WIFIfunction Instandbymode,brieflypressthemenukeytoenterthe WiFiswitchoptionandsetWiFitoontoenterWiFimode. IfyouneedtoexittheWiFimode,re-enterthemenu optionandturnoffthisfunctiontoexit. Youcanconnecttoandoperatethisdevicethroughthe dedicatedmobilephoneAPP. 4)Time-lapsevideorecording(Thisoptionrequiresa voltagereductioncabletobefunctional;carchargers donotsupportthisfeature) Enterthetime-lapsevideorecordingSettings:Youcan choosefrom:off/8hours/12hours/24hours.Afterthis functionisturnedon,thesystemwillcontinuetorecord forthecorrespondingtimeevenafterthecaristurned off(theACCpowerisoff).Systemshutdownbydefault Note:Thisfunctioncannotbeusedwhenthecarbattery iscompletelydisconnected. 5)Parkingmonitoringfunction(Thisoptionrequiresa voltagereductioncabletobefunctional;thecarcharger doesnotsupportthisfunction) Aftertheparkingmonitoringisactivated,whenthe vehicleisturnedoffandthedashcamentersthe automaticshutdownprogram,ifthevehiclebodyis subjectedtovibrationcausedbyexternalforce,the dashcamwillstartrecordingforabout20secondsand thenautomaticallyshutdown.Whenthevehiclebody vibrationisdetectedagain,restartthecamerafunction. Thisfunctioncannotbeusedwhenthecarbatteryis completelypoweredoff. 7)GPSfunction(optional) (1)Wheninstandbymode,pressthemenukeytoenterthe menuoptions.SelectGPSInformationtoviewtheGPS satellitesearchvalue (2)TheGPSicononthedisplayscreenturnsgreenafter aGPSsatelliteisdetected. 三：ApplicationinstallationandWiFiconnection instructions: Openthe"WiFiSwitch"intheSettings.TherearetheQR codefordownloadingtheAPP,theWiFinameandthe connectionpasswordintheSettings ScantheQRcodewithyourcommonlyusedmobilephoneor searchforthe"Viidure"APPinthemobileapplication storetodownloadandinstallit SearchforWiFionyourmobilephone,findtheWiFiname: ZL278-******,enterthepassword:12345678toconnect 注意：同一时间内，一台记录仪只能连接一台手机 3.APPOperation:OpentheAPP,addtherecorder,andafter successfullyaddingitfollowingthesteps,enterthepreview interfaceoftherecorder Six:InstallationGuide 1.Turnoffthecarengine. 2.InserttheTFcardintothecardslotoftherecorder. Pleaseuseahigh-speedTFcard(C10orabove). 3.Fixtherecordertothefrontwindshieldofthecar. 4.InsertthecarchargeroracarchargerwithGPSinto thecarcigarettelighter. Note:Ifusingalower 5.ConnecttheUSBportoftherecordertothecarcharger withachargingextensioncable. Whenwiring,thechargingextensioncablecanbelaid alongtheedgeofthecar'swindshield. 6.Installtherearcameraattherearofthevehicleand payattentiontothedirectionwheninstalling.Wiring canbelaidalongthevehicleroof.Afterinstallation iscompleted,plugtherear-pullplugintotherear-pull interfaceoftherecorder. 7.Adjustthelenspositiontoensurethatthelens remainslevelwiththeground. 8.Starttheengineandcheckifthemachinehasbeen installedcorrectly. Whenthemachineisinstalledcorrectly,thesystem workingindicatorlightwillbeon.Themachinestarts upandenterstherecordingstate,withthevideo recordingindicatorlightflashing.Pleasepayattention tocheckingwhetherthepictureonthedisplayscreenis normal. Ten:Troubleshooting Undernormaloperatingconditions,ifthereisa problemwiththeproduct,pleaserefertothefollowing methodstosolveit Nophotographyorvideorecordingisallowed CheckiftheTFcardhasenoughspaceandislocked. Itwillautomaticallystopwhenrecording Duetothehugeamountofhigh-definitionvideodata, pleaseuseahigh-speedTFcardcompatiblewithSDHC.The high-speedTFcardwillhavetheC10logo. Whenreplayingpicturesandvideos,a"FileError" promptappears AnerroroccurredwhenstoringdataontheTFcard, resultinginanincompletefile.Pleaseusethecamera's "Format"functiontoreformattheTFcard. Thecapturedimagewasallfoggy Pleasecheckifthereisanydirtorfingerprintson thelens.Beforeshooting,wipethelenswithlenspaper. Whenshootingscenessuchastheskyandwatersurface, theimagesareverydark Insceneswithhighcontrast,itwillaffectthe exposurefunctionofthecamera.Thiscanbecorrected byadjustingthe"EV"valueinthemachineS…
