2A6P9-CPHMWireless CP adaptor

CONTENT About Product What's in the box Specification How to connect User interface Interfaces How to upgrade your product How to report an issue About Product This product uses a USB data cable to easily connect to the original car's USB interface： 1, it allows the original-wired Car Play to be converted to HDMI high-definition-input, HDMI devices such as TV sticks, screen mirroring devices, X-Box, and other HD devices supported; 2, it’s designed for iPhone smartphones to use Apple Car Play wireless on the factory car multimedia system which has built in Apple Car Play function. Note: When using this product, you can only use the remote control or other control mode of the external HDMI device. What's in the box Car TV mate *1 USB A to C plug adapter *1 USB C to C plug adaptor *1 Car charger *1 User Manual * 1 Specification Compatibility Car with OEM Apple Car Play HDMI input Standard HDMI 1.4 Support common resolutions on the market 2K(2560*1440)60Hz 1080P(1920*1080)60/50Hz 720P(1280*720)60/50Hz Power input USB 5V Wi-Fi 2.4G Connectors USB-C，HDMI Product Size 60*60*11.2mm How to connect 1, Use USB-A to USB-C plug adaptor if the original USB port in the car is USB-A female 2, Use USB-C to USB-C plug adaptor if the original USB port in the car is USB-C female Tips! Some car have two ports, one for power charging ,one for transmitting data. Please use the data port. User interface Home Menu Carplay menu: If the factory car supports Car-play connection via USB cable, please plug the device into the USB port in the car. Usually that USB port marked with Car play or smart-phone icon, select the Car play function in the original car radio system, it goes to above interface: Make sure your iPhone’s Bluetooth and Wi-Fi features are turned on and no other in-car devices are connected, On your iPhone, go to “Settings”>”Bluetooth”, in Other Devices list, you will see a Bluetooth device name started with “Autobox-xxxx”, tap to paid, allow permission and tap Use Car-play box to connect wirelesssly BT/Wi-Fi Name Car Play HDMI HDMI input When HDMI signal projected to the original car multimedia: 1,Press and hold the screen for 3s to return to the original car interface 2,Tap the screen : zoom the display Interfaces USB C port Reset hole USB Port: Connect to Car Reset hole: Reset the device LED indicator Blue light Flashing: Power on (No HDMI) Blue light on: Connected to the car (HDMI in) Red light Flashing: Upgrading White light: Upgrade completed Green light: P2P mode White Light Flashing: Reset successful HDMI port: Connect to external HDMl devices How to upgrade your product Update on iPhone While the power on, join the adapter's WiFi network [AutoSky-XXXX] and the password is 88888888.Next enter 192.168.2.1 on iPhone's browser, and tap "Update” Update on Android smartphone Connect the adapter's WiFi network [AutoSky-XXXX](you can find it in the car screen) in your Android phone and the password is 88888888. Tap YES if there is a pop-up notification of internet access. Enter 192.168.2.1 on smartphone browser, go to the bottom of the page, and tap "Switch P2P" On your phone, go to WiFi >> Advanced settings >>WiFi direct, tap [AutoSky-XXXX] and make sure it has connected. Enter 192.168.2.1 again on smartphone browser,next tap "Update" Note: 1.The led indicator will flash rapidly while updating.Wait for more 30s after the light is always on, then disconnect and reconnect the adapter from USB port to finish the whole update. 2. Android phone interface may be different, the above link is a rough description. How to report an issue How to report an issue Any issue while using the adapter, you could directly report the issue online and send us the feedback screenshot. We will fix it as soon as possible. For iPhone users, please enter 192.168.2.1 on your iPhone browser to submit the issue details after connected to the WiFi network [ AutoSky-XXXX ] While the power on; For Android users, please follow the steps of [update on Android smartphone] on the previous page, then enter 192.168.2.1 to submit the issue. FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection againstharmful interference in a residential installation. This equipment generates, uses and can radiateradio frequency energy and, if not installed and used in accordance with the instructions, maycause harmful interference to radio communications. However, there is no guarantee thatinterference will not occur in a particular installation. If this equipment does cause harmfulinterference to radio or television reception, which can be determined by turning the equipmentoff and on, the user is encouraged to try to correct the interference by one or more of thefollowing measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.

Promaster Electronic LLC 25275 Budde Rd Suite 31 Spring Texas United States Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-7-22 To whom it may concern: We, Promaster Electronic LLC, hereby certify that the equipment for which authorization is sought (FCC ID: 2A6P9-CPHM) is not “covered” equipment prohibited from receiving an equipment authorization pursuant to § 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, we are not identified on the Covered List (https://www.fcc.gov/supplychain/coveredlist) as an entity producing “covered” equipment. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(b) and (d)(5) and (6). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. Sincerely, Signature Antonio Lopez Manager Promaster Electronic LLC 62_[model] CoveredEqu_2.911(d)(5)(i) and (ii) - U, V03

Promaster Electronic LLC 25275 Budde Rd Suite 31 Spring Texas United States Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-7-22 U.S. Agent Designation Promaster Electronic LLC acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2A6P9-CPHM): Name and company of U.S. agent: Promaster Electronic LLC Physical U.S. address of agent: 25275 Budde Rd Suite 31 Spring Texas United States FRN of U.S. agent: 0032356586 Email address of U.S. agent: [email protected] Promaster Electronic LLC acknowledges their obligation to accept service of process on behalf of Promaster Electronic LLC. Promaster Electronic LLC with the FRN [0032356586] accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Sincerely, Signature Antonio Lopez Manager Promaster Electronic LLC Signature Antonio Lopez Manager Promaster Electronic LLC 48_[mo del] US_Agent_2.911(d)(7) - U, V0 5

Promaster Electronic LLC Add: 25275 Budde Rd Suite 31 Spring Texas United States Date: 2024-7-22 FCC ID: 2A6P9-CPHM Dear Sir/Madam, We, Promaster Electronic LLC Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: Wireless CP adaptor Model no.: CPHM-1, CPHM-2, CPHM-3 Sincerely, Name/Title： Antonio Lopez/Manager Company: Promaster Electronic LLC Address: 25275 Budde Rd Suite 31 Spring Texas United States Phone: (832) 813-5123 Fax: N/A E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2024-7-22> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2A6P9-CPHM CPHM-1 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Antonio Lopez/Manager Company: Promaster Electronic LLC Address: 25275 Budde Rd Suite 31 Spring Texas United States Phone: (832) 813-5123 Fax: N/A E-Mail: [email protected]

Promaster Electronic LLC 25275 Budde Rd Suite 31 Spring Texas United States Date: 2024-7-22 FCC ID: 2A6P9-CPHM Model Number: CPHM-1 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To Whom It May Concern, We, Promaster Electronic LLC, declare that this EUT (FCC ID: 2A6P9-CPHM) doesn’t have Ad Hoc mode function on “non-US/Canada frequencies”. In addition. The frequency selection feature is disabled by firmware for devices marked to the US/Canada. For DTS part of this device, only channels 1-11 will be used in North America, Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, Name/Title： Antonio Lopez/Manager Company: Promaster Electronic LLC Address: 25275 Budde Rd Suite 31 Spring Texas United States Phone: (832) 813-5123 Fax: N/A E-Mail: [email protected]

Promaster Electronic LLC 25275 Budde Rd Suite 31 Spring Texas United States Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-7-22 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2A6P9-CPHM including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. By signing this application form, we agree to Eurofins’ current valid General Terms and Conditions (AGB),Testing and Certification Regulations (PZO) which can be viewed on following website www.eurofins.de/ee or retrieved on request. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Antonio Lopez/Manager Company: Promaster Electronic LLC Address: 25275 Budde Rd Suite 31 Spring Texas United States Phone: (832) 813-5123 Fax: N/A E-Mail: [email protected]

FCC ID: 2A6P9-CPHM External Photos of the EUT FCC ID: 2A6P9-CPHM

Label and Location Size: L: 1.0cm*W: 0.2cm Label and Location FCC ID : 2A6P9-CPHM

FCC ID: 2A6P9-CPHM Internal Photos of the EUT FCC ID: 2A6P9-CPHM FCC ID: 2A6P9-CPHM ANT

RF Exposure evaluation FCC ID: 2BCQ3FLY400 Exposure category: General population/uncontrolled environment EUT Type: Production Unit Device Type: Mobile Device 1. Reference According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. KDB447498 D01: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 2. Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 3. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 4. Antenna Information CPHM-1 can only use antennas certificated as follows provided by manufacturer; Antenna No. Model No. of antenna: Type of antenna: Gain of the antenna (Max.) Frequency range: BT/2.4GWIFI / PCB antenna 0.72dBi for 2400-2500MHz; 5GWIFI / PCB antenna 5180MHz-5240MHz :0.88dBi 5745MHz-5825MHz : 1.01dBi 5. Manufacturing Tolerance Mode Max. Peak Conducted Output Power (dBm) Max. tune-up BT -1.25 -1.0±1 BLE 2.29 2.0±1 2.4GWIFI 15.78 15.0±1 Mode Max. Average Conducted Output Power (dBm) Max. tune-up 5.2GWIFI 13.02 13±1 5.8GWIFI 12.84 13±1 6. Standalone MPE Result As declared by the Applicant, the EUT is a wireless device used in a fix application, at least 20 cm from any body part of the user or nearby persons; from the maximum EUT RF output power, the minimum separation distance, r =20cm, as well as the gain of the used antenna is refer to section, the RF power density can be obtained. Modulation Type Output power Antenna Gain (dBi) Antenna Gain (linear) MPE (mW/cm 2 ) MPE Limits (mW/cm 2 ) dBm mW BT 0.0 1.0000 0.72 1.1803 0.0002 1.0000 BLE 3.0 1.9953 0.72 1.1803 0.0005 1.0000 2.4GWIFI 16.0 39.8107 0.72 1.1803 0.0094 1.0000 5.2GWIFI 13.0 19.9526 0.88 1.2246 0.0049 1.0000 5.8GWIFI 13.0 19.9526 1.01 1.2618 0.0050 1.0000 Remark: 1. Output power (Peak) including turn-up tolerance; 2. MPE evaluate distance is 20cm from user manual provide by manufacturer. 7. Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure of mobile device. ----------------THE END OF REPORT---------------

1. Antenna Description: Antenna type PCB antenna Model CPHM-1 Frequency range 2400-2500MHz, 5180-5240MHz, 5745-5825MHz Manufacturer Huizhou Funnavi Electronics Co., Ltd ANT Peak Gain 2400-2500MHz: 0.72dBi 5180MHz-5240MHz : 0.88dBi 5745MHz-5825MHz : 1.01dBi 2. Antenna Photo: Length :8.82mm Width:2.54mm 3. Test Equipment & Conditions 3.1 Test instrument VSWR is tested using Agilent E5071B connected to a hand mechanism, and the status is free space. 3.2 Test environment and methods 4．Antenna Radiation Pattern 2400MHz 2450MHz 2500MHz 5180MHz 5220MHz 5240MHz 5745MHz 5785MHz 5825MHz

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID. ............................................ : CTA24070900101 2A6P9-CPHM Compiled by ( position+printed name+signature) .. : File administrators Jinghua Xiao Supervised by ( position+printed name+signature) .. : Project Engineer Xudong Zhang Approved by ( position+printed name+signature) .. : RF Manager Eric Wang Date of issue ..................................... : Jul. 15, 2024 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Applicant’s name ............................ : Promaster Electronic LLC Address ............................................ : 25275 Budde Rd Suite 31, Spring, Texas, United States, 77380 Test specification ...........................: Standard ........................................... : FCC Part 15.247 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Equipment description...................: Wireless CP adaptor Trade Mark ....................................... : AutoSky Manufacturer .................................... : Huizhou Funnavi Electronics Co., Ltd Model/Type reference....................... : CPHM-1 Listed Models .................................. : CPHM-2, CPHM-3 Modulation ....................................... : GFSK Frequency .......................................... From 2402MHz to 2480MHz Ratings ............................................. : DC 5.0V From external circuit Result................................................ : PASS Report No.: CTA24070900101 Page 2 of 36 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : Wireless CP adaptor Model /Type : CPHM-1 Listed Models : CPHM-2, CPHM-3 Applicant : Promaster Electronic LLC Address : 25275 Budde Rd Suite 31, Spring, Texas, United States, 77380 Manufacturer : Huizhou Funnavi Electronics Co., Ltd Address : 3rd floor, No.:25 Xiangda road Xiao Jin kou street, Huicheng district, Huizhou city, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA24070900101 Page 3 of 36 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 T E S T S T A N D A R D S ................................................................. 4 2 S U M M A R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description* 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 EUT operation mode 6 2.6 Block Diagram of Test Setup 6 2.7 Related Submittal(s) / Grant (s) 6 2.8 Modifications 6 3 T E S T E N V I R O N M E N T .............................................................. 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Summary of measurement results 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D R E S U L T S ........................................... 11 4.1 AC Power Conducted Emission 11 4.2 Radiated Emissions and Band Edge 14 4.3 Maximum Peak Output Power 21 4.4 Power Spectral Density 22 4.5 6dB Bandwidth 24 4.6 Out-of-band Emissions 26 4.7 Antenna Requirement 30 5 T E ST SE T U P P H O T O S O F T H E E U T ......................................... 31 6 P H O T O S O F T H E E U T ........................................................... 32 Report No.: CTA24070900101 Page 4 of 36 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 V05r02: Guidance for Performing Compliance Measurements on Digital Transmission Systems (DTS) Operating Under §15.247 Report No.: CTA24070900101 Page 5 of 36 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : Jul. 08, 2024 Testing commenced on : …
