2A6UH-UGW800PUBuGW800PUB

uGW800 USER MANUAL 1. Introduction uGW800 is an IoT hotspot, designed by Amber-Link, supporting LoRaWAN, LongFi and Helium block-chain protocol, compatible with all standard LoRaWAN devices. Its runtime power consumption < 5W, but the signal coverage is more than 10 miles. One hotpsot can connect with thousands IoT devices and support real-time data transactions. 2. Network ItemDescription CPUQuad core Cortex-A35 64-bits [email protected] RAM2GB DDR3 FLASH64GB eMMC Wi-FiIEEE 802.11b/g/n 2.4G Ethernet10/100M SecurityATECC608 LoRa BasebandSX1303 + SX1250x2 (8+1 channels) LoRa BandsUS915, 923 GNSSGPS/Beidou Antenna PortRP-SMA x3 (SubGHz LoRa, GNSS, Ext.) Power SupplyType-C, DC-12V LEDColorful LED x1 for system status (power on, configure, network, etc.) Casingnylon & fiberglass, IP65 Size (mm)146 * 123 * 40 Enclosure(Optional)FRP antenna (700mm), wall installation kit 2. Network uGW800 integrates the Helium Miner firmware and LoRaWAN packet forward module. The hotspot sends the received packet to cloud or block-chain by either Ethernet or Wi-Fi network. 3. Specifications 4. Structure size 5. Interface 6. LED Indicator ColorIndicator status RedHotspot power-on and doing initialization YellowHotspot is running at data synchonizing GreenHotspot is ready for radio receive and uplink BlueHotspot is in configurate mode ---Turned off 7. Package Content 8. User guide Download the mobile App iPhone users search "uGWAN Hotspot" APP in Apple store and follow the guide for APP installation. Android users download and install the APPs by either uGWAN.io website or from Google Play store. Hotspot assembly Open the package, take out the device, power adapter and antenna Insert the RP-SMA connector of the antenna feeder Connect ethenet cable if needed Connect to 12V-DC power adapter (in packet) or power the device by USB Type-C adapter (not in the packet). Configure network and connect App with hotspot Open the uGWAN Hotspot App in your phone, register to enter, and select "Add Hotspot". Select uGW800-serier hotspot, you can read the network configuration instructions first, or select "Skip" to operate step by step according to the prompts on the page. Power on hotspot and insert a pin into the configuration hole (at the bottom of the device), press and hold the button for 5 seconds, the hotspot's LED turn to blue (may flickering). If you use Wi-Fi connection, select the Wi-Fi network in APP and enter password, then APP will send the configuration to the device. If you use Ethernet connection, select "Use Ethernet", make sure the network cable has connected with the device. Please note that the Ethernet connection currently only supports automatic IP acquisition. Enable 'remote control' feature if user wants to check hotpspot's status and control it remotely. At this step, the network configuration is completed, LED changes from blue to either yellow or green. 9. Installation guide uGW800 hotspot support both indoor and outdoor installation: Indoor: Place the hotspot on desk Connect antenna or antenna extension cable to the hotspot, place the antenna close to window as near as possible. Ethernet cable is needed. Connect 12V-DC power supply or USB Type-C cable Wall-mounted (outdoor): Check with uGWAN sales to get the wall-mount kit (not in the packet) Follow the guide to fix both hotpsot and FRP antenna solidly. Power the hotspot by either 12V-DC or Ethernet PoE (with PoE converter) Caution: Hotspot designed as IP65, DO NOT drop the device in water. The product installation MUST be safety and carefully, the wall should be solid enough to avoid collisions and drops. Place it close to the window or balcony as near as possible, outdoor is better, the hostpot can receive GPS signals, and the Sub-GHz antenna has a wide coverage. 10. FCC Caution This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. -- Amber-Link Network Technology Co., Ltd. --

C5266091_X8_Ed.1 1/1 Letter of Authorization <Amber-Link Network Technology Co., Ltd.> Company: Amber-Link Network Technology Co., Ltd. Address: Building 1,No.356, Guoshoujin Road, Shanghai, China Product Name: uGW800PUB Model Number: uGW800PUB FCC Identifier: 2A6UH-UGW800PUB We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Yijia Wang Date: 2022.5.26 Title: Up Engineering Signature of applicant:

C5266091_X10_Ed.2 1/1 <Amber-LinkNetworkTechnologyCo.,Ltd.> OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 Date: 2022/5/18 Subject:RequestforConfidentiality FCCID:2A6UH-UGW800PUB ToWhomItMayConcern, PursuanttotheprovisionsofSections0.457and0.459ofCommission'srules (47CFR0.457,0.459),wearerequestingtheCommissiontowithholdthefollowing attachment(s)asconfidentialdocumentfrompublicdisclosure. ExhibitsLong-Term Confidentiality Short-Term Confidentiality NOTE2 IDLabel/LocationNoNo AttestationStatementNoNo ExternalPhotosNo ☐ BlockDiagram ☒☐ Schematics ☒☐ TestReportNoNo TestSetupPhotosNo ☐ User’sManual ☐ NOTE 1 ☐ InternalPhotos ☐ NOTE 1 ☐ PartsList/TuneUp ☒☐ RFExposureInfoNoNo OperationalDescription ☒☐ CoverLetter(s)NoNo SDRSoftware/SecurityInfo ☐ No NOTE1:Long-TermConfidentialitymaybepermittedunderspecialconditions(SeeII.LONG-TERMCONFIDENTIALITY,Section3of KDB726920,uselastinforce) NOTE2:Short-TermConfidentialitycanberequestedforamaximumof180daysfromthedateofthegrant. Abovementioneddocumentcontainsdetailedsystemandequipmentdescriptionare consideredasproprietaryinformationinoperationoftheequipment.Thepublic disclosureofabovedocumentsmightbeharmfultoourcompanyandwouldgive competitoranunfairadvantageinthemarket. Incaseofshort-termConfidentiality,theapplicantrequeststheexhibitsselected abovearewithheldfrompublicviewforaperiodof_ _daysfromthedateofthe GrantofEquipmentAuthorizationandpriortomarketing. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondentduringcertificationreviewprocesscannotbegrantedasconfidential documentsandthoseinformationwillbeavailableforpublicreviewoncethegrantof equipmentauthorizationisissued.

EUT Appearance TA Technology (Shanghai) Co., Ltd. This report shall not be reproduced except in full, without the written approval of EUT Appearance Report No (Shanghai) Co., Ltd. This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. Report No.: R2203A0212 Page 1 of 5 (Shanghai) Co., Ltd. EUT Appearance TA Technology (Shanghai) Co., Ltd. This report shall not be reproduced except in full, without the written approval of Report No (Shanghai) Co., Ltd. This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. Report No.: R2203A0212 Page 2 of 5 (Shanghai) Co., Ltd. EUT Appearance TA Technology (Shanghai) Co., Ltd. This report shall not be reproduced except in full, without the written approval of Report No (Shanghai) Co., Ltd. This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. a: EUT Report No.: R2203A0212 Page 3 of 5 (Shanghai) Co., Ltd. EUT Appearance TA Technology (Shanghai) Co., Ltd. This report shall not be reproduced except in full, without the written approval of Report No (Shanghai) Co., Ltd. This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. b: Adapter Report No.: R2203A0212 Page 4 of 5 (Shanghai) Co., Ltd. EUT Appearance TA Technology (Shanghai) Co., Ltd. This report shall not be reproduced except in full, without the written approval of Report No (Shanghai) Co., Ltd. This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. c: Antenna Picture 1: Constituents of EUT Report No.: R2203A0212 Page 5 of 5 (Shanghai) Co., Ltd.

Internal photo FCC ID: 2A6UH-UGW800PUB TA Technology (Shanghai) Co., Ltd. Page 1 of 7 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. Internal photo Internal photo FCC ID: 2A6UH-UGW800PUB TA Technology (Shanghai) Co., Ltd. Page 2 of 7 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2A6UH-UGW800PUB TA Technology (Shanghai) Co., Ltd. Page 3 of 7 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2A6UH-UGW800PUB TA Technology (Shanghai) Co., Ltd. Page 4 of 7 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2A6UH-UGW800PUB TA Technology (Shanghai) Co., Ltd. Page 5 of 7 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2A6UH-UGW800PUB TA Technology (Shanghai) Co., Ltd. Page 6 of 7 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. Internal photo FCC ID: 2A6UH-UGW800PUB TA Technology (Shanghai) Co., Ltd. Page 7 of 7 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd.

MPE TEST REPORT ApplicantAmber-Link Network Technology Co., Ltd. FCC ID2A6UH-UGW800PUB ProductuGW800 Pro BranduG ModeluGW800PUB Report No.R2203A0212-M1 Issue DateMay 12, 2022 TA Technology (Shanghai) Co., Ltd. tested the above equipment in accordance with the requirements inFCC 47 CFR Part 1 1.1310.The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Prepared by: Fangying WeiApproved by: Guangchang Fan TA Technology (Shanghai) Co., Ltd. No.145, Jintang Rd, Tangzhen Industry Park, Pudong Shanghai, China TEL: +86-021-50791141/2/3 FAX: +86-021-50791141/2/3-8000 MPE Test ReportReport No.: R2203A0212-M1 TA Technology (Shanghai) Co., Ltd.TA-MB-01-013SPage 2 of 9 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. Table of Contents 1 Test Laboratory...................................................................................................................................3 1.1 Notes of the Test Report.............................................................................................................3 1.2. Test facility.................................................................................................................................3 1.3 Testing Location..........................................................................................................................3 1.4 Laboratory Environment..............................................................................................................4 2 Description of Equipment under Test.................................................................................................5 3 Maximum output power (measured) and antenna Gain....................................................................6 4 Test Result.......................................................................................................................................... 7 ANNEX A: The EUT Appearance.............................................................................................................. 9 MPE Test ReportReport No.: R2203A0212-M1 TA Technology (Shanghai) Co., Ltd.TA-MB-01-013SPage 3 of 9 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. 1 Test Laboratory 1.1 Notes of the Test Report This report shall not be reproduced in full or partial, without the written approval ofTA technology (shanghai) co., Ltd.The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein .Measurement Uncertainties were not taken into account and are published for informational purposes only. This report is written to support regulatory compliance of the applicable standards stated above. 1.2. Test facility FCC (Designation number: CN1179, Test Firm Registration Number: 446626) TA Technology (Shanghai) Co., Ltd. has been listed on the US Federal Communications Commission list of test facilities recognized to perform measurements. 1.3 Testing Location Company:TA Technology (Shanghai) Co., Ltd. Address:No.145, Jintang Rd, Tangzhen Industry Park, Pudong Shanghai, China City:Shanghai Post code:201201 Country:P. R. China Contact:Fan Guangchang Telephone:+86-021-50791141/2/3 Fax:+86-021-50791141/2/3-8000 Website:http://www.ta-shanghai.com E-mail:[email protected] MPE Test ReportReport No.: R2203A0212-M1 TA Technology (Shanghai) Co., Ltd.TA-MB-01-013SPage 4 of 9 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. 1.4 Laboratory Environment Temperature Min. = 18C,Max. = 25C Relative humidityMin. = 30%, Max. = 70% Ground system resistance< 0.5 Ambient noise is checked and found very low and in compliance with requirement of standards. Reflection of surrounding objects is minimized and in compliance with requirement of standards. MPE Test ReportReport No.: R2203A0212-M1 TA Technology (Shanghai) Co., Ltd.TA-MB-01-013SPage 5 of 9 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. 2 Description of Equipment under Test Client Information ApplicantAmber-Link Network Technology Co., Ltd. Applicant address Room 209, Building 1, Block 356, Guoshoujin Road, Pudong SH, China ManufacturerSHANGHAI FOJOAUTO COMPONENTS CO.,LTD Manufacturer addressNO 767 XINGE ROAD SONGJIANG SHANGHAI CHINA General Technologies ModeluGW800PUB SN2909469160010339 Hardware Version2022.7 Software Version2022.12.3 Date of TestingApril 18, 2022 ~ April 25, 2022 Date of Sample ReceivedMarch 8, 2022 Note: 1. The EUT is sent from the applicant to TA and the information of the EUT is declared by the applicant. 2. All indications of Pass/Fail in this report are opinions expressed by TA Technology (Shanghai) Co., Ltd. based on interpretations and/or observations of test results. Measurement Uncertainties were not taken into account and are published for informational purposes only. MPE Test ReportReport No.: R2203A0212-M1 TA Technology (Shanghai) Co., Ltd.TA-MB-01-013SPage 6 of 9 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. 3 Maximum output power (measured) and antenna Gain The numeric gain (G) of the antenna with a gain specified in dB is determined by Numeric gain (G)=10^(antenna gain/10) Band Maximum Output Power Antenna Gain (dBi) Numeric gain (dBm)(mW) Wi-Fi 2.4G14.2826.7921.71.479 Model 900MHz20.75118.8503.01.995 US91524.10257.0403.01.995 AS92312.9719.8153.01.995 MPE Test ReportReport No.: R2203A0212-M1 TA Technology (Shanghai) Co., Ltd.TA-MB-01-013SPage 7 of 9 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. 4 Test Result According to section 1.1310 of FCC 47 CFR Part 1, limits for maximum permissible ex…

Text truncated - open the document above for the full version.

Prepared by: Peng Tao Approved by: Kai Xu TA Technology (Shanghai) Co., Ltd. No.145, Jintang Rd, Tangzhen Industry Park, Pudong Shanghai, China TEL: +86-021-50791141/2/3 FAX: +86-021-50791141/2/3-8000 RF TEST REPORT Applicant Amber-Link Network Technology Co., Ltd. FCC ID 2A6UH-UGW800PUB Product uGW800 Pro Brand uG Model uGW800PUB Report No. R2203A0212-R2V3 Issue Date May 30, 2022 TA Technology (Shanghai) Co., Ltd. tested the above equipment in accordance with the requirements in FCC CFR47 Part 15C. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. RF Test Report Report No.: R2203A0212-R2V3 TA Technology (Shanghai) Co., Ltd. TA-MB-04-005R Page 2 of 46 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. TABLE OF CONTENT 1. Test Laboratory ............................................................................................................................ 5 1.1. Notes of the test report ......................................................................................................... 5 1.2. Test facility ........................................................................................................................... 5 1.3. Testing Location ................................................................................................................... 5 2. General Description of Equipment under Test .............................................................................. 6 2.1. Applicant and Manufacturer Information ............................................................................... 6 2.2. General information .............................................................................................................. 6 3. Applied Standards ........................................................................................................................ 7 4. Test Configuration ........................................................................................................................ 8 5. Test Case Results ........................................................................................................................ 9 5.1. Maximum output power ........................................................................................................ 9 5.2. 99% Bandwidth and 6dB Bandwidth .................................................................................. 11 5.3. Band Edge ......................................................................................................................... 15 5.4. Power Spectral Density ...................................................................................................... 18 5.5. Spurious RF Conducted Emissions ............................... ..................................................... 21 5.6. Unwanted Emission ........................................................................................................... 24 5.7. Conducted Emission .......................................................................................................... 41 6. Main Test Instruments ................................................................................................................ 44 ANNEX A: The EUT Appearance ...................................................................................................... 45 ANNEX B: Test Setup Photos ........................................................................................................... 46 RF Test Report Report No.: R2203A0212-R2V3 TA Technology (Shanghai) Co., Ltd. TA-MB-04-005R Page 3 of 46 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. Version Revision description Issue Date Rev.0 Initial issue of report. May 12, 2022 Rev.1 Update description. May 25, 2022 Rev.2 Update data. May 27, 2022 Rev.3 Update description. May 30, 2022 Note: This revised report (Report No. R2203A0212-R2V3) supersedes and replaces the previously issued report (Report No. R2203A0212-R2V2). Please discard or destroy the previously issued report and dispose of it accordingly. RF Test Report Report No.: R2203A0212-R2V3 TA Technology (Shanghai) Co., Ltd. TA-MB-04-005R Page 4 of 46 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. Summary of measurement results Number Test Case Clause in FCC rules Verdict 1 Maximum output power 15.247(b)(3) PASS 2 6 dB bandwidth 15.247(a)(2) PASS 3 Power spectral density 15.247(e) PASS 4 Band Edge 15.247(d) PASS 5 Spurious RF Conducted Emissions 15.247(d) PASS 6 Unwanted Emissions 15.247(d),15.205,15.209 PASS 7 Conducted Emissions 15.207 PASS Date of Testing: April 18, 2022 ~ May 12, 2022 and May 27, 2022 Date of Sample Received: March 8, 2022 Note: All indications of Pass/Fail in this report are opinions expressed by TA Technology (Shanghai) Co., Ltd. based on interpretations and/or observations of test results. Measurement Uncertainties were not taken into account and are published for informational purposes only. RF Test Report Report No.: R2203A0212-R2V3 TA Technology (Shanghai) Co., Ltd. TA-MB-04-005R Page 5 of 46 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. 1. Test Laboratory 1.1. Notes of the test report This report shall not be reproduced in full or partial, without the written approval of TA technology (shanghai) co., Ltd. The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein .Measurement Uncertainties were not taken into account and are published for informational purposes only. This report is written to support regulatory compliance of the applicable standards stated above. 1.2. Test facility FCC (Designation number: CN1179…

Text truncated - open the document above for the full version.

Prepared by: Peng Tao Approved by: Kai Xu TA Technology (Shanghai) Co., Ltd. No.145, Jintang Rd, Tangzhen Industry Park, Pudong Shanghai, China TEL: +86-021-50791141/2/3 FAX: +86-021-50791141/2/3-8000 RF TEST REPORT Applicant Amber-Link Network Technology Co., Ltd. FCC ID 2A6UH-UGW800PUB Product uGW800 Pro Brand uG Model uGW800PUB Report No. R2203A0212-R3V1 Issue Date May 30, 2022 TA Technology (Shanghai) Co., Ltd. tested the above equipment in accordance with the requirements in FCC CFR47 Part 15C. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. RF Test Report Report No.: R2203A0212-R3V1 TA Technology (Shanghai) Co., Ltd. TA-MB-04-005R Page 2 of 63 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. TABLE OF CONTENT 1. Test Laboratory ............................................................................................................................ 5 1.1. Notes of the test report ......................................................................................................... 5 1.2. Test facility ........................................................................................................................... 5 1.3. Testing Location ................................................................................................................... 5 2. General Description of Equipment under Test .............................................................................. 6 2.1. Applicant and Manufacturer Information ............................................................................... 6 2.2. General information .............................................................................................................. 6 3. Applied Standards ........................................................................................................................ 7 4. Test Configuration ........................................................................................................................ 8 5. Test Case Results ........................................................................................................................ 9 5.1. Maximum output power ........................................................................................................ 9 5.2. 99% Bandwidth and 6dB Bandwidth .................................................................................. 11 5.3. Band Edge ......................................................................................................................... 17 5.4. Power Spectral Density ...................................................................................................... 20 5.5. Spurious RF Conducted Emissions ............................... ..................................................... 25 5.6. Unwanted Emission ........................................................................................................... 30 5.7. Conducted Emission .......................................................................................................... 58 6. Main Test Instruments ................................................................................................................ 61 ANNEX A: The EUT Appearance ...................................................................................................... 62 ANNEX B: Test Setup Photos ........................................................................................................... 63 RF Test Report Report No.: R2203A0212-R3V1 TA Technology (Shanghai) Co., Ltd. TA-MB-04-005R Page 3 of 63 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. Version Revision description Issue Date Rev.0 Initial issue of report. May 12, 2022 Rev.1 Add data. May 30, 2022 Note: This revised report (Report No. R2203A0212-R3V1) supersedes and replaces the previously issued report (Report No. R2203A0212-R3). Please discard or destroy the previously issued report and dispose of it accordingly. RF Test Report Report No.: R2203A0212-R3V1 TA Technology (Shanghai) Co., Ltd. TA-MB-04-005R Page 4 of 63 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. Summary of measurement results Number Test Case Clause in FCC rules Verdict 1 Maximum output power 15.247(b)(3) PASS 2 6 dB bandwidth 15.247(a)(2) PASS 3 Power spectral density 15.247(e) PASS 4 Band Edge 15.247(d) PASS 5 Spurious RF Conducted Emissions 15.247(d) PASS 6 Unwanted Emissions 15.247(d),15.205,15.209 PASS 7 Conducted Emissions 15.207 PASS Date of Testing: April 18, 2022 ~ April 29, 2022 Date of Sample Received: March 8, 2022 Note: All indications of Pass/Fail in this report are opinions expressed by TA Technology (Shanghai) Co., Ltd. based on interpretations and/or observations of test results. Measurement Uncertainties were not taken into account and are published for informational purposes only. RF Test Report Report No.: R2203A0212-R3V1 TA Technology (Shanghai) Co., Ltd. TA-MB-04-005R Page 5 of 63 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. 1. Test Laboratory 1.1. Notes of the test report This report shall not be reproduced in full or partial, without the written approval of TA technology (shanghai) co., Ltd. The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein .Measurement Uncertainties were not taken into account and are published for informational purposes only. This report is written to support regulatory compliance of the applicable standards stated above. 1.2. Test facility FCC (Designation number: CN1179, Test Firm Registration Number: 446626) TA Technology (Shanghai) Co., Ltd. has been listed on the…

Text truncated - open the document above for the full version.

RF Test Setup Report No: R2203A0212 TA Technology (Shanghai) Co., Ltd. TA-MB-04-005R Page 1 of 2 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. Part15C Test Setup 30MHz-1GHz 1GHz-18GHz RF Test Setup Report No: R2203A0212 TA Technology (Shanghai) Co., Ltd. TA-MB-04-005R Page 2 of 2 This report shall not be reproduced except in full, without the written approval of TA Technology (Shangha…
