2A73O-AQ-2ERAARK SMART FISH TANK MAX

01 PRODUCT INTRODUCTION Product Introduction Product List Video Guidance Product Installation Product Usage Intelligent App Control Cleaning and Maintenance Feeding Suggestions FAQ Product Parameters Safety Warning Instructions 3 5 6 6 ，7 ，8 ，9 10，11 12，13，14 15，16，17 18，19 19 19 19,20 ERAARK SMART FISH TANK MAX Please read the user manual carefully before using the product, and keep it properly User Manual Glass aquarium body *1 (Including the back filter chamber) UV water pump assembly (Assembled) Filter cover *1 Feeding lid *1 Integrated Host Upper Cover*1 Cable Clip*1Magnetic Cleaner Brush*1 User Manual *1 *Before installation and use, please check whether all the accessories are complete according to the following list. Non-conductive Power Adapter*1 Fine-mesh filter cotton *1 Biochemical filter media pack*1 PRODUCT LIST 03 VIDEO GUIDANCE 09 FAQ 8.3 Prepare Clean Water 8.4 Water Change Guide 9.1 What if the panel buttons do not work? 125 3 6108711 161415 13 1718 2220 19 23 3.1 Installation and Usage Video3.2 Maintenance and Cleaning Video ⑦ Align the UV water pump assembly’s power cable port with the waterproof joint on the Integrated Host Upper Cover. Rotate the locking cap clockwise until fully secured.Route the cables neatly to avoid tangling. ⑧ Close the integrated host upper cover, feeding lid, and filter compartment cover.Connect the adapter’s power cable to the power port on the integrated host upper cover. ⑨Attach the cable clip (included) to the back of the aquarium using its adhesive backing.Thread the power cable through the clip to secure it neatly. 08 FEEDING SUGGESTIONS 8.1 Fish Species Suggestions 8.2 Dietary Recommendations Small ornamental fishMedium-sized ornamental fish Fish size: 2cm3cm Suggested quantity: within 10 Fish size: 5cm8cm Suggested quantity: within 5 06 INTELLIGENT App CONTROL Scan the QR code to download the PETKIT app. 6.1 Download and Install The App ④ Sunlight Tracking Mode 6.3 Water Pump Timer & Speed Adjustment 6.2 Four Lighting Modes ① Natural Light Mode ② RGB Color Mode Utilizes RGB color LEDs for vibrant lighting effects. Select a color from the app and adjust its brightness. ➂ Flow Light Mode In this mode, the lights cycle through dynamic color transitions. Adjust the speed of color changes and brightness via the app. 5.3 Oxygen Regulating Valve 5.4 Feeding Lid Rotate counterclockwise · The amount of bubbles increases · Increasing intake of oxygen · The amount of bubbles decreases · Decreasing intake of oxygen Rotate clockwise Note: This device uses Bluetooth connectivity, and app control is only available after successful pairing. ④ Remove both filter cottons.Rinse them lightly under running water with gentle agitation. 04 PRODUCT INSTALLATION 4.1 Installation of Filter Components 05 PRODUCT USAGE 5.1 Heat Dissipation Lamp Panel Note: When the lighting system is not in use, it is recommended to keep the light panel lifted to allow ventilation and heat dissipation. 07 CLEANING AND MAINTENANCE 7.1 Initial Cleaning Guide 7.2 Daily Maintenance of Fish Tanks 7.3 Clean the Back Filter Chamber 6.4 Feeding Mode Switch the lights The sunlight tracking mode has been terminated Turn on the sunlight tracking mode Maintenance Procedure: ① Remove the biochemical filter media pack, fine-mesh filter cotton, coarse-mesh filter cotton and water pump assembly from the back filter module in sequence. Biochemical filter media pack Fine-mesh filter cotton Coarse-mesh filter cotton Water pump assembly ② Rinse the two filter cottons under running water by gently scrubbing.Reinsert them into the filter module in their original order. ③ During deep cleaning, lightly rinse biochemical filter media with tank water only (never use tap water). 7.4 Clean The Water Pump Assembly 7.5 Reinstall the filter chamber. Refer to the product installation section in the manual. T-shaped connector outlet hose (thick) oxygen regulating valve intake hose clip UV water pump Note:Avoid vigorous scrubbing, as this may generate excess debris and shorten the bio-media’s lifespan. Not Suitable:Turtles, large goldfish (e.g., Common Goldfish, Koi), Arowanas, or any species exceeding 15 cm (6 inches) in adult size. * Warning: Overstocking or housing incompatible species may stress fish and compromise water quality. Sunlight Tracking Mode 材质：80g书纸，2色印刷， 封装：钉装, 24P 尺寸：140*140mm Note: Coarse-mesh filter cotton *1 Anti-slip pad *1 ② Remove the biochemical filter media pack.Rinse the biochemical filter media pack under running water until the water runs clear.(Note: Minor shedding or dusting is unavoidable due to the material properties of the biochemical filter media. Avoid vigorous scrubbing during rinsing to prevent excessive particle release.) ① Open the filter compartment cover.Place the UV water pump assembly at the base of Compartment 4 as illustrated.Insert the T-shaped connector into the outlet hose interface as shown, ensuring a secure fit. ③ Gently place the rinsed biochemical filter media pack into the base of Compartment 3.If the pack gets stuck, gently compress it to adjust its position for even distribution before reinserting.Ensure the biochemical filter media remains fully submerged during operation. ⑤ Insert the coarse-mesh filter cotton into Compartment 1 and the fine-mesh filter cotton into Compartment 2.Press firmly on the upper edge of each pad during installation, allowing it to naturally expand, and ensure proper seating.(Critical: Do not trim the original filter cottons. Full compartment coverage is essential for optimal filtration.) ⑥To install additional equipment (e.g., a heater), place it in Compartment 4.For best compatibility and performance, use the ERAARK Constant-Temperature Aquarium Heater. ② When the light panel is fully closed, the lighting system will be forcibly deactivated, and neither the touch controls nor the app will be able to operate the lights. (Keeping the light panel lifted helps maintain optimal airflow and cooling for the aquarium. We recommend mai…

Text truncated - open the document above for the full version.

(FOOFEE intelligent manufacturing Technology (dongguan) Co., Ltd.) (2026/1/26) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2A73O-AQ-2) [FOOFEE intelligent manufacturing Technology (dongguan) Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, the equipment does not utilize cyber-security or anti-virus software from Kaspersky Lab, Inc, or any of its successors and assignees, which is also on the “covered list”. Sincerely, (Applicant signature) (Applicant printed name) Jie Li (FOOFEE intelligent manufacturing Technology (dongguan) Co., Ltd.) (2026/1/26) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID: 2A73O-AQ-2) [FOOFEE intelligent manufacturing Technology (dongguan) Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Jie Li

FOOFEE intelligent manufacturing Technology (dongguan) Co., Ltd. 2026/1/26 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen STS Test Services Co., Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s signature: Client’s name / title : Jie Li / Manager Contact information / address: Room 401,Building 15,No.1 Pushi First Road Qiaotou Town, Dongguan City, Guangdong Province, China

FOOFEE intelligent manufacturing Technology (dongguan) Co., Ltd. 2026/1/26 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: CONFIDENTIALITY REQUEST FOR EUT NAME: ERAARK SMART FISH TANK MAX Trademark: N/A MODEL: AQ-2 FCC ID: 2A73O-AQ-2 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Client’s signature: Client’s name / title : Jie Li / Manager Contact information / address: Room 401,Building 15,No.1 Pushi First Road Qiaotou Town, Dongguan City, Guangdong Province, China

Page 1 of 9 FCC ID: 2A73O-AQ-2 External Photos Page 2 of 9 FCC ID: 2A73O-AQ-2 Page 3 of 9 FCC ID: 2A73O-AQ-2 Page 4 of 9 FCC ID: 2A73O-AQ-2 Page 5 of 9 FCC ID: 2A73O-AQ-2

Location： Label FCC ID: 2A73O-AQ-2 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation

Page 6 of 10 FCC ID: 2A73O-AQ-2 Internal Photos Page 7 of 10 FCC ID: 2A73O-AQ-2 Antenna Page 8 of 10 FCC ID: 2A73O-AQ-2 Page 9 of 10 FCC ID: 2A73O-AQ-2 Page 10 of 10 FCC ID: 2A73O-AQ-2

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. MPE Report Report No.: STS2601318H01 Issued for FOOFEE intelligent manufacturing Technology (dongguan) Co., Ltd. Floor 4, Building 10, Pushi Industrial Park, Qiaotou Town, Dongguan City, Guangdong Province, China Product Name: ERAARK SMART FISH TANK MAX Brand Name: N/A Model Name: AQ-2 Series Model(s): N/A FCC ID: 2A73O-AQ-2 Test Standard: FCC 47CFR §2.1091 Page 2 of 7 Report No.: STS2601318H01 TEST REPORT Applicant’s Name ................. : FOOFEE intelligent manufacturing Technology (dongguan) Co., Ltd. Address ................................. : Room 401,Building 15,No.1 Pushi First Road Qiaotou Town, Dongguan City, Guangdong Province, China Manufacturer's Name ........... : FOOFEE intelligent manufacturing Technology (dongguan) Co., Ltd. Address ................................. : Room 401,Building 15,No.1 Pushi First Road Qiaotou Town, Dongguan City, Guangdong Province, China Product Description Product Name ........................ : ERAARK SMART FISH TANK MAX Brand Name .......................... : N/A Model Name .......................... : AQ-2 Series Model(s) ...................... : N/A Test Standards ..................... : FCC 47CFR §2.1091 447498 D01 Interim General RF Exposure Guidance v06 The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ...................... : 04 Jan. 2025 Date (s) of performance of tests ............. : 04 Jan. 2025 to 19 Jan. 2026 Date of Issue .......................................... : 19 Jan. 2026 Test Result .............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 7 Report No.: STS2601318H01 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 5 2. FCC 47CFR §2.1091 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 7 Page 4 of 7 Report No.: STS2601318H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 19 Jan. 2026 STS2601318H01 ALL Initial Issue Page 5 of 7 Report No.: STS2601318H01 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name ERAARK SMART FISH TANK MAX Brand Name N/A Model Name AQ-2 Series Model(s) N/A Model Difference N/A Product Description The EUT is a ERAARK SMART FISH TANK MAX Operation Frequency: 2402~2480 MHz Modulation Type: GFSK Radio Technology: BLE Bluetooth Configuration: LE(Support 1M PHY, 2M PHY) Number Of Channel: 40 Antenna Type: Internal antenna Antenna Gain (dBi) -5.45 Power Rating DC 12V from adapter Adapter MODEL: TEKA-TB120100US INPUT: 100-240V~50/60Hz 0.35A MAX OUTPUT: DC 12.0V/1.0A Battery N/A Hardware Version N/A Software Version N/A 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 6 of 7 Report No.: STS2601318H01 2. FCC 47CFR §2.1091 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of the human exposure to radio-frequency (RF) radiation as specified in 1.1307 (b) Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm²) Limits for Occupational / controlled Exposures 300 - 1500 -- -- F/300 3.0-30 1842/f 4.89/f *(900/f²) 1500 – 100000 -- -- 5.0 Limits for General population / Uncontrolled Exposure 300 - 1500 -- -- F/1500 1.34-30 824/f 2.19/f *(180f²) 1500 – 100000 -- -- 1.0 F= Frequency in MHz Friss Formula Friss Transmission Formula: Pd = (Pout * G) / (4*pi*r²) Where Pd = power density in mW/cm² Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = Distance between observation point and the center of radiator in cm If we know the maximum gain of the antenna and the total output power to the antenna, through calculation, we will know MPE value at distance 20cm. Page 7 of 7 Report No.: STS2601318H01 2.3 TEST RESULT Tune up Mode Detector Tune up Power GFSK Peak 1±1dBm Note: 1. The Maxinum power is less than the limit, complies with the exemption requirements. 2. ERP = EIRP - 2.15 ※※※※※END OF THE REPORT※※※※※ Protocol Fre. (GHz) Separati on distance (cm) Max Tune up power (dBm) ANT Gain (dBi) Max EIRP (dBm) Max EIRP (mW) Power Density (mW/cm²) Limit (mW/ cm²) Ratio Result GFSK 2.480 20 2 -5.45 -3.45 0.452 0.0001 1 0.0001 Pass

Prepared by: Xu Ying Approved by: Xu Kai TA Technology (Shanghai) Co., Ltd. Building 3, No.145, Jintang Rd, Pudong Shanghai, P.R.China TEL: +86-021-50791141/2/3 FAX: +86-021-50791141/2/3-8000 OTA TEST REPORT TA Technology (Shanghai) Co., Ltd. tested the above equipment in accordance with the requirements in ANSI/IEEE Std 149-2008. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Applicant PETKIT Network Technology (Shanghai) Co., Ltd. Product PETKIT AIRSALON MAX Model PD10 Report No. Y2210A1061-T1 Issue Date November 2, 2022 OTA Test Report Report No: Y2210A1061-T1 TA Technology (Shanghai) Co., Ltd. TA-MB-04-008O P age 2 of 13 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. TABLE OF CONTENTS 1. Test Laboratory ................................................................................................................................ 3 1.1. Notes of the Test Report ...................................................................................................... 3 1.2. Test facility ........................................................................................................................... 3 1.3. Testing Location ................................................................................................................... 3 1.4. Laboratory Environment ...................................................................................................... 4 2. General Description of Equipment under Test ................................................................................. 5 2.1. Applicant and Manufacturer Information ............................................................................. 5 2.2. General information ............................................................................................................. 5 2.3. Antenna Size ........................................................................................................................ 6 2.4. Test Date .............................................................................................................................. 6 2.5. Received Date ..................................................................................................................... 6 2.6. Applied Standards ............................................................................................................... 7 3. Test Conditions................................................................................................................................. 8 3.1. Test Configuration................................................................................................................ 8 3.2. Test Measurement ............................................................................................................... 8 4. Test Results ...................................................................................................................................... 9 4.1. Gain and Efficiency .............................................................................................................. 9 4. 2. Antenna S11 ...................................................................................................................... 10 5. Equipment List ................................................................................................................................ 11 ANNEX A: 3-D Pattern Plots .................................................................................................................. 12 ANNEX B: The Test Configuration ........................................................................................................ 13 OTA Test Report Report No: Y2210A1061-T1 TA Technology (Shanghai) Co., Ltd. TA-MB-04-008O P age 3 of 13 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. 1. Test Laboratory 1.1. Notes of the Test Report This report shall not be reproduced in full or partial, without the written approval of TA Technology (Shanghai) Co., Ltd. The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein .Measurement Uncertainties were not taken into account and are published for informational purposes only. This report is written to support regulatory compliance of the applicable standards stated above. 1.2. Test facility A2LA (Certificate Number: 3857.01) TA Technology (Shanghai) Co., Ltd. has been listed by American Association for Laboratory Accreditation to perform measurement. 1.3. Testing Location Company: TA Technology (Shanghai) Co., Ltd. Address: Building 3, No.145, Jintang Rd, Pudong Shanghai, P.R.China City: Shanghai Post code: 201201 Country: P. R. China Contact: Xu Kai Telephone: +86-021-50791141/2/3 Fax: +86-021-50791141/2/3-8000 Website: http://www.ta-shanghai.com E-mail: [email protected] OTA Test Report Report No: Y2210A1061-T1 TA Technology (Shanghai) Co., Ltd. TA-MB-04-008O P age 4 of 13 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. 1.4. Laboratory Environment Temperature Min. =19°C，Max. = 25°C Relative humidity Min. =40%，Max. =72% Shield effect 0.7-6GHz > 100dB Ground resistance <0.5Ω OTA Test Report Report No: Y2210A1061-T1 TA Technology (Shanghai) Co., Ltd. TA-MB-04-008O P age 5 of 13 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. 2. General Description of Equipment under Test 2.1. Applicant and Manufacturer Information Applicant Name PETKIT Network Technology (Shanghai) Co., Ltd. Applicant address Room 4139, Building 2, 588 Zixing Road, Minhang District, Shanghai Manufacturer Name PETKIT Network Technology (Shanghai) Co., Ltd. Manufacturer address Room 4139, Buildi…

Text truncated - open the document above for the full version.

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Radio Test Report Report No.: STS2601318W01 Issued for FOOFEE intelligent manufacturing Technology (dongguan) Co., Ltd. Room 401,Building 15,No.1 Pushi First Road Qiaotou Town, Dongguan City, Guangdong Province, China Product Name: ERAARK SMART FISH TANK MAX Brand Name: N/A Model Name: AQ-2 Series Model(s): N/A FCC ID: 2A73O-AQ-2 Test Standards: FCC Part15.247 Page 2 of 70 Report No.: STS2601318W01 TEST REPORT Applicant’s Name ................. : FOOFEE intelligent manufacturing Technology (dongguan) Co., Ltd. Address ................................. : Room 401,Building 15,No.1 Pushi First Road Qiaotou Town, Dongguan City, Guangdong Province, China Manufacturer's Name .......... : FOOFEE intelligent manufacturing Technology (dongguan) Co., Ltd. Address ................................. : Room 401,Building 15,No.1 Pushi First Road Qiaotou Town, Dongguan City, Guangdong Province, China Product Description Product Name ....................... : ERAARK SMART FISH TANK MAX Brand Name .......................... : N/A Model Name .......................... : ... : AQ-2 Series Model(s) .................... : N/A Test Standards ..................... : FCC Part15.247 Test Procedure ...................... : ANSI C63.10-2020 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the IC requirements. And it is applicable only to the tested sample identified in the report. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ..................... : 04 Jan. 2025 Date (s) of performance of tests ............. : 04 Jan. 2025 to 19 Jan. 2026 Date of Issue .......................................... : 19 Jan. 2026 Test Result.............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 70 Report No.: STS2601318W01 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 TEST SOFTWARE AND POWER LEVEL 10 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 11 2.6 EQUIPMENTS LIST 12 3. EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.2 TEST PROCEDURE 14 3.3 TEST SETUP 14 3.4 EUT OPERATING CONDITIONS 14 3.5 TEST RESULTS 15 4. RADIATED EMISSION MEASUREMENT 17 4.1 RADIATED EMISSION LIMITS 17 4.2 TEST PROCEDURE 19 4.3 TEST SETUP 20 4.4 EUT OPERATING CONDITIONS 20 4.5 FIELD STRENGTH CALCULATION 21 4.6 TEST RESULTS 22 5. CONDUCTED SPURIOUS & BAND EDGE EMISSION 37 5.1 LIMIT 37 5.2 TEST PROCEDURE 37 5.3 TEST SETUP 37 5.4 EUT OPERATION CONDITIONS 37 5.5 TEST RESULTS 37 6. POWER SPECTRAL DENSITY TEST 38 6.1 LIMIT 38 6.2 TEST PROCEDURE 38 Page 4 of 70 Report No.: STS2601318W01 Table of Contents Page 6.3 TEST SETUP 38 6.4 EUT OPERATION CONDITIONS 38 6.5 TEST RESULTS 38 7. BANDWIDTH TEST 39 7.1 LIMIT 39 7.2 TEST PROCEDURE 39 7.3 TEST SETUP 39 7.4 EUT OPERATION CONDITIONS 39 7.5 TEST RESULTS 39 8. PEAK OUTPUT POWER TEST 40 8.1 LIMIT 40 8.2 TEST PROCEDURE 40 8.3 TEST SETUP 40 8.4 EUT OPERATION CONDITIONS 40 8.5 TEST RESULTS 40 9. ANTENNA REQUIREMENT 41 9.1 STANDARD REQUIREMENT 41 9.2 EUT ANTENNA 41 APPENDIX 1-TEST DATA 42 DUTY CYCLE 42 MAXIMUM CONDUCTED OUTPUT POWER 46 -6DB BANDWIDTH 50 MAXIMUM POWER SPECTRAL DENSITY LEVEL 54 BAND EDGE 58 CONDUCTED RF SPURIOUS EMISSION 63 APPENDIX 2- EUT TEST PHOTO 70 Page 5 of 70 Report No.: STS2601318W01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 19 Jan. 2026 STS2601318W01 ALL Initial Issue Page 6 of 70 Report No.: STS2601318W01 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted bands of operation PASS -- Part 15.247(d)/ Part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- Note: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020. Page 7 of 70 Report No.: STS2601318W01 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.751dB 2 Unwanted Emissions, conducted ±2.888dB 3 All emissions, radiated 9K-30MHz ±2.48dB 4 All emissions, radiated 30M-1GHz ±2.52dB 5 All emissions, radiated 1G-18GHz ±3.48dB 6 All emissions, radiated>18GHz ±4.18dB 7 Conducted Emission (9KHz-150KHz) ±2.48dB 8 Conducted Emission (150KHz-30MHz) ±2.52dB 9 Occupied Channel Bandwidth ±3.6% 10 Power Spectral Density, conducted ±1.214dB 11 Duty Cycle ±3.2% Page 8 of 70 Report No.: STS2601318W01 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Produ…

Text truncated - open the document above for the full version.

Page 1 of 2 FCC ID: 2A73O-AQ-2 Conducted emissions 30MHz-1GHz Page 2 of 2 FCC ID: 2A73O-AQ-2 Spurious emissions
