2A767-SWT0002501RF Remote

ACTIVATING THE TRANSMITTER BATTERY • INGESTION HAZARD: This product contains a button cell or coin battery. • DEATH or serious injury can occur if ingested. • A swallowed button cell or coin battery can cause Internal Chemical Burns in as little as 2 hours. • KEEP new and used batteries OUT OF REACH of CHILDREN. • Seek immediate medical attention if a battery is suspected to be swallowed or inserted inside any part of the body. • Remove and immediately recycle or dispose of used batteries according to local regulations and keep away from children. Do NOT dispose of batteries in household trash or incinerate. • Even used batteries may cause severe injury or death. • Call a local poison control center for treatment information. • Battery Type: CR2032 and Nominal Battery Voltage: 3V. • Non-rechargeable batteries are not to be recharged. • Do not force discharge, recharge, disassemble, heat above 40º C or incinerate. Doing so may result in injury due to venting, le akage or explosion resulting in chemical burns. • Ensure the batteries are installed correctly according to polarity (+ and -). • alkaline, carbon-zinc, or rechargeable batteries. Do not mix old and new batteries, different brands or types of batteries, such as • Remove and immediately recycle or dispose of batteries from equipment not used for an extended period of time according to local regulations. • Always completely secure the battery compartment. If the battery compartment does not close securely, stop using the product, remove the batteries, and keep them away from children. WARNING PAIRING A TRANSMITTER TO A RECEIVER Transmitter Battery Cover Safety Screw Hole LEARN button LEARN SIM card WARNING: Make sure the power is completely disconnected at the circuit breaker or fusebox before starting this process. IMPORTANT: Fan motor, fan blades, and light kit (if applicable) MUST be installed before the pairing process can begin. NOTE: Only one transmitter at a time can be paired using this process.To pair an additional transmitter, repeat this process. NOTE: A maximum of 2 transmitters can be paired to a receiver. If pairing more than 2 transmitters to the same receiver is attempted, the receiver will begin to remove previous pairings from memory. NOTE: If you turn on a fan now to pair the receiver with the transmitter, but another fan was turned on within the past two minutes and no action was taken with the transmitter, both fans may be paired with this transmitter. NOTE: Please keep this page in case future reprogramming is needed, or an additional transmitter is added. There is a LEARN hole on the battery cover .The LEAR button is inside this hole.Prepare a SIM card ejector tool for use later . Or if you did not have SIM card ejector tool, you can loosen the safety screw and remove the battery cover. You will find the LEARN button under the battery cover. (Fig.20-B) ejector tool Learn LEARN PAIRING A TRANSMITTER TO A RECEIVER(continued) Step 1. Turn the power to the fan and light off. After 30 seconds, turn the power back on to both the fan and light. (NOTE: After the AC power is on, do not press any other button on the transmitter before pressing the LEARN button . Doing so will cause the procedure to fail.) Step 2. Within 2 Minutes of turning the fan's AC power ON, use the SIM card ejector tool to insert into the hole and push the LEARN button for 3 seconds. The fan will change to medium speed and the light kit will toggle (if the light kit was previously on, it will switch to off. If the light kit was previously off, it will switch to on). This confirms that the pairing process is complete. Step 3. Once the receiver has detected the set frequency.The receiver has now learned the frequency which has been selected on the transmitter. After completing the steps above, you should be able to operate the ceiling fan and light. NOTE: lf the fan is not responding to the transmitter, please turn the power off to the receiver, and repeat above process. UNPAIRING A TRANSMITTER FROM A RECEIVER NOTE: After the pairing process is complete, a transmitter can be unpaired from a receiver by following the “PAIRING A TRANSMITTER TO A RECEIVER” process a second time. NOTE: Please keep this page in case future reprogramming is needed, or an additional transmitter is added. Transmitter Battery Cover Safety Screw Hole LEARN button LEARN SIM card ejector tool Learn LEARN INSTALLING THE MOUNTING PLATE AND WALL PLATE NOTE: The supply to the receiver should be connected through a mains switch, i.e. existing wall switch. NOTE: If the existing wall switch is not a basic “ON/OFF” switch, the existing wall switch should be replaced with a basic “ON/OFF” switch before continuing installation. NOTE:DO NOT replace the existing wall switch with the transmitter. DO NOT attempt to retrofit the mounting plate, wall plate, and transmitter to the existing outlet box. Step 1.Remove the wall plate from the mounting plate (insert a small, flathead screwdriver into the slot at the top of the wall plate, and carefully pry the wall plate off of the mounting plate). Step 2. Select the desired location for the transmitter. Using the mounting plate as a template, anchors. Set the mounting plate aside. Step 3. If you want to install the mounting plate to wall, follow the instruction in below ,use drywall anchors and screws to install the mou nting plate. If you want to install the mounting plate to outlet box , follow the instruction in below. Step 4.Snap the wall plate in place onto the mounting plate. Step 5.Insert the transmitter into the center of the wall plate, and it will magnetically attach to the mounting plate. Transmitter Wall Plate Screws Mounting Plate Drywall Anchors Slot at top of Wall Wall Plate Transmitter Wall Plate Screws Outlet Box Mounting Plate Slot at top of Wall Plate OPERATING INSTRUCTIONS Light Button: Brightness Button: Press this button once ,the light will be turn on at previous brightness. Press and hold this button will dimmer up the light…

Text truncated - open the document above for the full version.

(Summer Wind International Ltd) (2025.12.24) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID:2A767-SWT0002501) [Summer Wind International Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, the equipment does not utilize cyber-security or anti-virus software from Kaspersky Lab, Inc, or any of its successors and assignees, which is also on the “covered list”. Sincerely, (Applicant signature) (Applicant printed name) Deon chen (Summer Wind International Ltd) (2025.12.24) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID:2A767-SWT0002501) [Summer Wind International Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Deon chen

Summer Wind International Ltd 2025.12.24 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: CONFIDENTIALITY REQUEST FOR EUT NAME: RF Remote Trademark: N/A MODEL: SW-T0025-01, SW-T0025-02 FCC ID: 2A767-APLETF150 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Client’s signature: Client’s name / title : Deon chen / Manager Contact information / address: No.39, Jinou Road, Jianghai District, Jiangmen City, Guangdong Province, China

Summer Wind International Ltd 2025/12/25 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen STS Test Services Co., Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s signature: Client’s name / title : Deon chen / Manager Contact information / address: No.39, Jinou Road, Jianghai District, Jiangmen City, Guangdong Province, China

Summer Wind International Ltd Model Difference 2025.12.24 EUT NAME: RF Remote MODEL : SW-T0025-01, SW-T0025-02 FCC ID: 2A767-SWT0002501 All models are identical except for the model name and umber of buttons. Regards Sincerely Client’s signature: Client’s name / title : Deon chen / Manager Contact information / address: No.39, Jinou Road, Jianghai District, Jiangmen City, Guangdong Province, China

FCC ID: 2A767-SWT0002501 External Photos FCC ID: 2A767-SWT0002501 FCC ID: 2A767-SWT0002501 FCC ID: 2A767-SWT0002501

Label & label location FCC ID:2A767-SWT0002501 Label location

FCC ID: 2A767-SWT0002501 Internal Photos FCC ID: 2A767-SWT0002501 Antenna FCC ID: 2A767-SWT0002501

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. MPE Report Report No.:STS2512378H01 Issued for Summer Wind International Ltd No.39, Jinou Road, Jianghai District, Jiangmen City, Guangdong Province, China Product Name: RF Remote Brand Name: N/A Model Name: SW-T0025-01 Series Model(s): SW-T0025-02 FCC ID: 2A767-SWT0002501 Test Standards: FCC 47CFR §2.1093 Page 2 of 8 Report No.: STS2512378H01 TEST REPORT Applicant’s Name ................. : Summer Wind International Ltd Address ................................. : No.39, Jinou Road, Jianghai District, Jiangmen City, Guangdong Province, China Manufacturer's Name ........... : Summer Wind International Ltd Address ................................. : No.39, Jinou Road, Jianghai District, Jiangmen City, Guangdong Province, China Product Description Product Name ........................ : RF Remote Brand Name .......................... : N/A Model Name .......................... : SW-T0025-01 Series Model(s) ...................... : SW-T0025-02 Test Standards ..................... : FCC 47CFR §2.1093 447498 D01 Interim General RF Exposure Guidance v06 The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ...................... : 12 Dec. 2025 Date (s) of performance of tests ............. : 12 Dec. 2025 ~ 19 Dec. 2025 Date of Issue .......................................... : 19 Dec. 2025 Test Result .............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 8 Report No.: STS2512378H01 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 5 2. FCC 47CFR §2.1093 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 8 Page 4 of 8 Report No.: STS2512378H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 19 Dec. 2025 STS2512378W01 ALL Initial Issue Page 5 of 8 Report No.: STS2512378H01 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name RF Remote Brand Name N/A Model Name SW-T0025-01 Series Model(s) SW-T0025-02 Model Difference All models are identical except for the model name and umber of buttons. Product Description The EUT is RF Remote Operation Frequency: 304.25MHz Modulation Type: ASK Antenna Designation: PCB antenna Antenna Gain(Peak) 0 dbi Power Rating DC 3V From Battery Adapter N/A Battery Model:CR2032 Hardware Version N/A Software Version N/A 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 6 of 8 Report No.: STS2512378H01 2. FCC 47CFR §2.1093 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in KDB 447498 D01 General RF Exposure Guidance v06 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. Page 7 of 8 Report No.: STS2512378H01 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] • [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz. Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Page 8 of 8 Report No.: STS2512378H01 2.3 TEST RESULT Trun up Mode Detector Power (dBuV/m) @3m Power (dBm) Max Tune up (dBm) SRD PK 73.87 -21.33 -21±1 Note: Power(dBm)= dBuV/m@3m -95.2 Evaluation Result Mode Frequency MHz Separation distance (cm) Power (dBm) ERP (mW) SAR Test Exclusion Threshold SAR Test Exclusion Estimated SAR SRD 304.25 0.5 -20 0.00001 0.000001 Yes / Note: 1. Remark: The worst case gain of the antenna is 0dBi. 2. Threshold at which no SAR required is 0.000001≤ 3.0 for 1-g SAR, Separation distance ≤ 5mm. ※※※※※END OF THE REPORT※※※※※

Material specification manufacturer: Address: 1. 2. 3. Type:PCB on-board antenna Features 1.*Stable and reliable in performances 2.*RoHS compliance 4. Antenna Dimensions (unit: mm) 5. Antenna Picture

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Radio Test Report Report No.:STS2512378W01 Issued for Summer Wind International Ltd No.39, Jinou Road, Jianghai District, Jiangmen City, Guangdong Province, China Product Name: RF Remote Brand Name: N/A Model Name: SW-T0025-01 Series Model(s): SW-T0025-02 FCC ID: 2A767-SWT0002501 Test Standards: FCC Part 15.231 Page 2 of 30 Report No.: STS2512378W01 TEST REPORT Applicant’s Name .................: Summer Wind International Ltd Address ..................................: No.39, Jinou Road, Jianghai District, Jiangmen City, Guangdong Province, China Manufacturer's Name ...........: Summer Wind International Ltd Address ..................................: No.39, Jinou Road, Jianghai District, Jiangmen City, Guangdong Province, China Product Description Product Name ............................ : RF Remote Brand Name ............................... : N/A Model Name ...........................: SW-T0025-01 Series Model(s) ....................: SW-T0025-02 Test Standards .......................... : FCC Part 15.231 Test Procedure ........................... : ANSI C63.10-2020 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC/IC requirements. And it is applicable only to the tested sample identified in the report. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Date of Test ............................: Date of Receipt of Test Item ...: 12 Dec. 2025 Date of performance of tests ..: 12 Dec. 2025 to 19 Dec. 2025 Date of Issue ..........................: 19 Dec. 2025 Test Result .............................: Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 30 Report No.: STS2512378W01 TABLE OF CONTENTS Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 6 1.2 MEASUREMENT UNCERTAINTY 6 2. GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF THE EUT 7 2.2 DESCRIPTION OF THE TEST MODES 8 2.3 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 9 2.5 EQUIPMENTS LIST 10 3. EMC EMISSION TEST 11 3.1 CONDUCTED EMISSION MEASUREMENT 11 3.2 TEST PROCEDURE 12 3.3 TEST SETUP 12 3.4 TEST RESULTS 12 4. RADIATED EMISSION MEASUREMENT 13 4.1 RADIATED EMISSION LIMITS 13 4.2 TEST PROCEDURE 15 4.3 DEVIATION FROM TEST STANDARD 15 4.4 TEST SETUP 16 4.5 EUT OPERATING CONDITIONS 17 4.6 TEST RESULTS 17 4.7 FIELD STRENGTH CALCULATION 18 5. BANDWIDTH TEST 22 5.1 LIMIT 22 5.2 TEST REQUIREMENTS 22 5.3 TEST PROCEDURE 22 5.4 TEST SETUP 22 5.5 EUT OPERATION CONDITIONS 22 5.6 TEST RESULTS 23 6. DUTY CYCLE 24 6.1 TEST PROCEDURE 24 6.2 TEST SETUP 24 6.3 EUT OPERATION CONDITIONS 24 6.4 TEST RESULTS 25 7. AUTOMATICALLY DEACTIVATE 27 Page 4 of 30 Report No.: STS2512378W01 TABLE OF CONTENTS Page 7.1 STANDARD REQUIREMENT 27 7.2 TEST PROCEDURE 27 8. ANTENNA REQUIREMENT 29 8.1 STANDARD REQUIREMENT 29 8.2 EUT ANTENNA 29 APPENDIX 1-PHOTOS OF TEST SETUP 30 Page 5 of 30 Report No.: STS2512378W01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 19 Dec. 2025 STS2512378W01 ALL Initial Issue Page 6 of 30 Report No.: STS2512378W01 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part 15.231,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A -- 15.205(a)/15.209/ 15.231.(b) Radiated Spurious Emission PASS -- 15.231(a)(1)/ 15.231(b)(2) Transmission requirement PASS -- 15.231(C) 20 dB Bandwidth PASS -- 15.203 Antenna Requirement PASS -- Note: (1) “N/A” denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020. 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. :101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuh ai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.751dB 2 Unwanted Emissions, conducted ±2.888dB 3 All emissions, radiated 9K-30MHz ±2.48dB 4 All emissions, radiated 30M-1GHz ±2.52dB 5 All emissions, radiated 1G-18GHz ±3.48dB 6 All emissions, radiated>18GHz ±4.18dB 7 Conducted Emission (9KHz-150KHz) ±2.48dB 8 Conducted Emission (150KHz-30MHz) ±2.52dB 9 Occupied Channel Bandwidth ±3.6% 10 Power Spectral Density, conducted ±1.214dB 11 Duty Cycle ±3.2% Page 7 of 30 Report No.: STS2512378W01 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name RF Remote Trade Name N/A Model Name SW-T0025-01 Series Model SW-T0025-02 Model Difference All models are identical except for the model name and umber of buttons. Product Description The EUT is a RF Remote Operation Frequency: 304.25MHz Modulation Type: ASK Antenna Designation: PCB antenna Antenna Gain(Peak) 0 dbi More details of EUT technical specification, please refer to the User Manual. Channel List Please refer to the Note 3. Power Rating DC 3V From Battery Adapter N/A Battery Model:CR2032 Hardware version number N/A Software version number/FVIN N/A Connecting I/O Port(s) Please refer to the Note 1. Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications orthe User Manual. 2. Table for filed Antenna Ant. Brand Model Name Antenna Type Connector Gain (dBi) NOTE 1 - SW-T0025-01 PCB antenna N/A 0 Antenna Note: The antenna …

Text truncated - open the document above for the full version.

Page 1 of 1 Report No.:STS2512378 RE (30MHz-1GHz) RE (Above 1GHz)
