FCC ID: 2A783-DTPM006 RF Exposure Evaluation LIMIT The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 - - f/300 6 1500–100,000 - - 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 - - f/1500 30 1500–100,000 - - 1.0 30 Note: f = frequency in MHz EVALUATION METHOD Transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW, G = gain of antenna in linear scale; Pi = 3.1416, R = distance between observation point and center of the radiator in cm TEST RESULT Passed Not Applicable FCC ID: 2A783-DTPM006 Frequency range (MHz) Type Conducted Power (dBm) Maximum Tune-up (dBm) Power Density (mW/cm2) Limit (mW/cm2) Result 836.6 GSM850 32.84 33.00 0.5273 0.5577 Fail 1909.8 PCS1900 29.00 29.50 0.2178 1.0000 Pass 1907.6 WCDMA Band 2 24.43 24.50 0.0760 1.0000 Pass 1752.6 WCDMA Band 4 23.25 23.50 0.0580 1.0000 Pass 836.4 WCDMA Band 5 24.67 25.00 0.0804 0.5576 Pass 1909.3 LTE Band 2 24.25 24.50 0.0730 1.0000 Pass 1732.5 LTE Band 4 23.60 24.00 0.0628 1.0000 Pass 829.0 LTE Band 5 25.29 25.50 0.0927 0.5527 Pass 707.5 LTE Band 12 26.23 26.50 0.1151 0.4717 Pass 782.0 LTE Band 13 26.30 26.50 0.1170 0.5213 Pass 709.0 LTE Band 17 25.55 26.00 0.0984 0.4727 Pass 2437.0 802.11g 12.81 13.00 0.0052 1.0000 Pass Considering that GSM850 and 802.11g can transmit simultaneously, the total transmission MPE rate is as follows: (GSM850 power density / limit) + (802.11g power density / limit) < 1 The worst case is GSM850, 802.11g transmitting simultaneously, the result as below: Evaluation mode Power density/limit Sum of the MPE rate limit GSM850 0.9455 0.9504 1 802.11g 0.0049 Note: 1) The maximum antenna gain is 4dBi (2G,3G,4G,2.4G WiFi ) 2) The exposure evaluation safety distance is 27cm.

ProjectNo.:SHT2207038406EWRadioSpecification:GSM ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 1 of31 APPENDIXREPORT ProjectNo.SHT2207038406EWRadioSpecificationGSM Test sampleNo.YPHT22070384014ModelNo.MT1100 Start test date2022/8/2Finishdate2022/8/2 Temperature24.8°CHumidity34% Test EngineerTiancheng.HuangAuditor Appendix clause Test itemResult A ConductedOutputPower PASS BPeak-to-AverageRatioPASS C26 dB Bandwidthand OccupiedBandwidthPASS DBand edgePASS EConductedSpuriousEmissionPASS FFrequencyStabilityPASS GERP and EIRPPASS ProjectNo.:SHT2207038406EWRadioSpecification:GSM ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 2 of31 8.1 AppendixA: ConductedOutputPower Test Result BandChannelPCLSlotPower(dBm)Limit(dBm)Verdict GPRS8501285132.7638.5PASS GPRS8501285231.4138.5PASS GPRS8501285329.5238.5PASS GPRS8501285427.9138.5PASS GPRS8501905132.8438.5PASS GPRS8501905231.4438.5PASS GPRS8501905329.3438.5PASS GPRS8501905427.8238.5PASS GPRS8502515132.7638.5PASS GPRS8502515230.9038.5PASS GPRS8502515329.0338.5PASS GPRS8502515427.5038.5PASS GPRS19005120128.8833PASS GPRS19005120228.5233PASS GPRS19005120327.1733PASS GPRS19005120425.0033PASS GPRS19006610128.9533PASS GPRS19006610228.3033PASS GPRS19006610327.6433PASS GPRS19006610425.7233PASS GPRS19008100129.0033PASS GPRS19008100228.5533PASS GPRS19008100327.5633PASS GPRS19008100425.7533PASS ProjectNo.:SHT2207038406EWRadioSpecification:GSM ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 3 of31 BandChannelPCLSlotPower(dBm)Limit(dBm)Verdict EGPRS8501288127.9338.5PASS EGPRS8501288225.7638.5PASS EGPRS8501288323.9938.5PASS EGPRS8501288422.0838.5PASS EGPRS8501908128.0338.5PASS EGPRS8501908225.9138.5PASS EGPRS8501908324.0938.5PASS EGPRS8501908421.9638.5PASS EGPRS8502518127.6538.5PASS EGPRS8502518225.7138.5PASS EGPRS8502518323.8138.5PASS EGPRS8502518424.2738.5PASS EGPRS19005122126.8733PASS EGPRS19005122224.9333PASS EGPRS19005122323.4633PASS EGPRS19005122422.9633PASS EGPRS19006612127.0333PASS EGPRS19006612225.1533PASS EGPRS19006612323.6433PASS EGPRS19006612423.8433PASS EGPRS19008102127.1133PASS EGPRS19008102225.1233PASS EGPRS19008102323.6833PASS EGPRS19008102423.7433PASS ProjectNo.:SHT2207038406EWRadioSpecification:GSM ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 4 of31 8.2 AppendixB: Peak -to -AverageRatio Test Result BandChannelPeak-to-AverageRatio(dB)Limit(dBm)Verdict GPRS8501282.8413PASS GPRS8501902.8113PASS GPRS8502512.8013PASS EGPRS8501285.7513PASS EGPRS8501905.7613PASS EGPRS8502515.7013PASS GPRS19005122.7313PASS GPRS19006612.7113PASS GPRS19008102.7313PASS EGPRS19005125.7513PASS EGPRS19006615.5513PASS EGPRS19008105.5413PASS ProjectNo.:SHT2207038406EWRadioSpecification:GSM ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 5 of31 Test Graphs GPRS850-128 GPRS850-190 GPRS850-251 ProjectNo.:SHT2207038406EWRadioSpecification:GSM ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 6 of31 EGPRS850-128 EGPRS850-190 EGPRS850-251 ProjectNo.:SHT2207038406EWRadioSpecification:GSM ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 7 of31 GPRS1900-512 GPRS1900-661 GPRS1900-810 ProjectNo.:SHT2207038406EWRadioSpecification:GSM ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 8 of31 EGPRS1900-512 EGPRS1900-661 EGPRS1900-810 ProjectNo.:SHT2207038406EWRadioSpecification:GSM ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 9 of31 8.3 AppendixC: 26dB Bandwidthand OccupiedBandwidth Test Result BandChannel OccupiedBandwidth (k Hz) 26dB Bandwidth (k Hz) Limit( kHz )Verdict GPRS850128246.50315.9---PASS GPRS850190244.27314.4---PASS GPRS850251241.29319.1---PASS EGPRS850128246.02316.9---PASS EGPRS850190241.24308.3---PASS EGPRS850251242.79301.6---PASS GPRS1900512244.34315.7---PASS GPRS1900661243.47315.7---PASS GPRS1900810245.48322.1---PASS EGPRS1900512243.69316.5---PASS EGPRS1900661246.29313.3---PASS EGPRS1900810244.95318.5---PASS ProjectNo.:SHT2207038406EWRadioSpecification:GSM ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 10of31 Test Graphs GPRS850-128 GPRS850-190 GPRS850-251 ProjectNo.:SHT2207038406EWRadioSpecification:GSM ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 11of31 EGPRS850-128 EGPRS850-190 EGPRS850-251 ProjectNo.:SHT2207038406EWRadioSpecification:GSM ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 12of31 GPRS1900-512 GPRS1900-661 GPRS1900-810 ProjectNo.:SHT2207038406EWRadioSpecification:GSM ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 13of31 EGPRS1900-512 EGPRS1900-661 EGPRS1900-810 ProjectNo.:SHT2207038406EWRadioSpecification:GSM ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 14of31 8.4 AppendixD: Band Edge Test Result BandChannelValue (dB m)Limit(dBm)Verdict GPRS850128-27.04-13PASS GPRS850251-27.13-13PASS EGPRS850128-36.51-13PASS EGPRS850251-37.28-13PASS GPRS1900512-29.82-13PASS GPRS1900810-28.85-13PASS EGPRS1900512-34.85-13PASS EGPRS1900810-37.47-13PASS ProjectNo.:SHT2207038406EWRadioSpecification:GSM ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 15of31 Test Graphs GPRS850-128 GPRS850-251 EGPRS850-128 ProjectNo.:SHT2207038406EWRadioSpecification:GSM ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 16of31 EGPRS850-251 GPRS1900-512 GPRS1900-810 ProjectNo.:SHT2207038406EWRadioSpecification:GSM ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 17of31 EGPRS1900-512 EGPRS1900-810 ProjectNo.:SHT2207038406EWRadioSpecification:GSM ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Appendixreportpage: 18of31 8.5 AppendixE: ConductedSpuriousEmission Test Result BandChannel FrequencyRange(Mhz) Value (dB m)Limit(dBm)Verdict GPRS85012830~1000-40.35-13PASS GPRS8501281000~10000-26.19-13PASS GPRS85019030~1000-40.45-13PASS GPRS8501901000~10000-26.49-13PASS GPRS85025130~1000-40.82-13PASS GPRS8502511000~10000-25.87-13PASS EGPRS85012830~1000-40.69…

Text truncated - open the document above for the full version.

Page: 1 of 31 TEST REPORT For GSM Report No. ...................................... : CHTEW22080302 Report Verification: Project No： SHT2207038406EW FCC ID ............................................. : 2A783-DTPMS006 Applicant ........................................ : Wuhan Huchuang Union Technology Co., Ltd. Address ............................................. : No. 1 Workshop, 1F, Building B10, Wuhan Hi-tech Medical Device Park, No. 818 Gaoxin Avenue, East Lake Hi-tech Development Zone, Wuhan, Hubei, China Product Name ................................ : Data transceiving & Power Monitoring series Trade Mark ....................................... : Metice Model No. ......................................... : MT1100 Listed Model(s) ................................. : MT500 ,MT700 Standard ......................................... : FCC CFR Title 47 Part 2 FCC CFR Title 47 Part 22 FCC CFR Title 47 Part 24 Date of receipt of test sample555.: Jul.21, 2022 Date of testing555555555...: Jul.21, 2022-Aug.24, 2022 Date of issue5555555555.: Aug.25, 2022 Result .................. ...: Pass Compiled by ( position+printedname+signature) ... : File administrators Fanghui Zhu Supervised by (position+printedname+signature) .... : Project Engineer Caspar Chen Approved by (position+printedname+signature) .... : Manager Hans Hu Testing Laboratory Name ............. : Shenzhen Huatongwei International Inspection Co., Ltd. Address ............................................. : 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report merely correspond to the test sample. Report No.: CHTEW22080302 Page: 2 of 31 Date of issue: 2022-08-25 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V04 (2022-01) Contents 1. TEST STANDARDS AND REPORT VERSION 3 1.1. Applicable Standards 3 1.2. Report version information 3 2. TEST DESCRIPTION 4 3. SUMMARY 5 3.1. Client Information 5 3.2. Product Description 5 3.3. Radio Specification Description 6 3.4. Testing Laboratory Information 6 4. TEST CONFIGURATION 7 4.1. Test frequency list 7 4.2. Descriptions of Test mode 7 4.3. Test sample information 7 4.4. Support unit used in test configuration and system 7 4.5. Testing environmental condition 8 4.6. Statement of the measurement uncertainty 8 4.7. Equipments Used during the Test 9 5. TEST CONDITIONS AND RESULTS 10 5.1. Conducted Output Power 10 5.2. Peak-to-Average Ratio 11 5.3. 99% Occupied Bandwidth & 26 dB Bandwidth 12 5.4. Band Edge 13 5.5. Conducted Spurious Emissions 14 5.6. Frequency stability VS Temperature measurement 15 5.7. Frequency stability VS Voltage measurement 16 5.8. ERP and EIRP 17 5.9. Radiated Spurious Emission 18 6. TEST SETUP PHOTOS OF THE EUT 22 7. EXTERNAL AND INTERNAL PHOTOS OF THE EUT 23 7.1. External photos 23 7.2. Internal photos 26 8. APPENDIX REPORT 31 Report No.: CHTEW22080302 Page: 3 of 31 Date of issue: 2022-08-25 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V04 (2022-01) 1. TEST STANDARDS AND REPORT VERSION 1.1. Applicable Standards The tests were performed according to following standards: FCC Rules Part 2: FREQUENCY ALLOCATIONS AND RADIO TREATY MATTERS; GENERAL RULES AND REGULATIONS FCC Rules Part 22: PUBLIC MOBILE SERVICES FCC Rules Part 24: PERSONAL COMMUNICATIONS SERVICES TIA/EIA 603 E March 2016: Land Mobile FM or PM Communications Equipment Measurement and Performance Standards. ANSI C63.26-2015: American National Standard for Compliance Testing of Transmitters Used in Licensed Radio Services KDB 971168 D01 Power Meas License Digital Systems v03: MEASUREMENT GUIDANCE FOR CERTIFICATION OF LICENSED DIGITAL TRANSMITTERS 1.2. Report version information Revision No. Date of issue Description N/A 2022-08-25 Original Report No.: CHTEW22080302 Page: 4 of 31 Date of issue: 2022-08-25 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V04 (2022-01) 2. TEST DESCRIPTION Section Test Item Section in CFR 47 Result #1 Test Engineer 5.1 Conducted Output Power Part 2.1046 Part 22.913(a) Part 24.232(c) Pass Tiancheng Huang 5.2 Peak-to-Average Ratio Part 24.232 Pass Tiancheng Huang 5.3 99% Occupied Bandwidth & 26 dB Bandwidth Part 2.1049 Part 22.917(b) Part 24.238(b) Pass Tiancheng Huang 5.4 Band Edge Part 2.1051 Part 22.917 Part 24.238 Pass Tiancheng Huang 5.5 Conducted Spurious Emissions Part 2.1051 Part 22.917 Part 24.238 Pass Tiancheng Huang 5.6 Frequency stability vs temperature Part 2.1055(a)(1)(b) Part 22.355 Part 24.235 Pass Tiancheng Huang 5.7 Frequency stability vs voltage Part 2.1055(d)(1)(2) Part 22.355 Part 24.235 Pass Tiancheng Huang 5.8 ERP and EIRP Part 22.913(a) Part 24.232(b) Pass Tiancheng Huang 5.9 Radiated Spurious Emissions Part 2.1053 Part 22.917 Part 24.238 Pass Pan Xie Note: #1: The test result does not include measurement uncertainty value Report No.: CHTEW22080302 Page: 5 of 31 Date of issue: 2022-08-25 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V04 (2022-01) 3. SUMMARY 3.1. Client Information Applicant: Wuhan Huchuang Union Technology Co., Ltd. Address: No. 1 Workshop, 1F, Building B10, Wuhan Hi-tech Medical Device Park, No. 818 Gaoxin Avenue, East Lake Hi-tech Development Zone, Wuhan, Hubei, China Manufacturer: Wuhan Huchuang Union Technology Co., Ltd. Address: No. 1 Workshop, 1F, Building B10, Wuhan Hi-tech Medical Device Park, No. 818 Gaoxin Avenue, East Lake H…

Text truncated - open the document above for the full version.

Project No.: SHT2207038406EW Radio Specification: WCDMA Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 1 of 27 APPENDIX REPORT Project No. SHT2207038406EW Radio Specification WCDMA Test sample No. YPHT22070384014 Model No. MT1100 Start test date 2022/8/2 Finish date 2022/10/17 Temperature 24.8°C Humidity 34% Test Engineer Tiancheng.Huang Auditor Appendix clause Test item Result A Conducted Output Power PASS B Peak-to-Average Ratio PASS C 26 dB Bandwidth and Occupied Bandwidth PASS D Band edge PASS E Conducted Spurious Emission PASS F Frequency Stability PASS G ERP and EIRP PASS Project No.: SHT2207038406EW Radio Specification: WCDMA Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 2 of 27 8.1 Appendix A: Conducted Output Power Test Result Band Channel Power(dBm) Limit(dBm) Verdict Band II 9262 23.65 33 PASS Band II 9400 24.09 33 PASS Band II 9538 24.43 33 PASS Band IV 1312 23.09 30 PASS Band IV 1413 22.97 30 PASS Band IV 1513 23.25 30 PASS Band V 4132 23.19 38.5 PASS Band V 4182 23.33 38.5 PASS Band V 4233 22.82 38.5 PASS Band Channel SubTest Power(dBm) Limit(dBm) Verdict Band II 9262 HSDPA_Sub1 23.27 33 PASS Band II 9262 HSDPA_Sub2 22.92 33 PASS Band II 9262 HSDPA_Sub3 22.98 33 PASS Band II 9262 HSDPA_Sub4 22.86 33 PASS Band II 9400 HSDPA_Sub1 23.45 33 PASS Band II 9400 HSDPA_Sub2 23.27 33 PASS Band II 9400 HSDPA_Sub3 23.34 33 PASS Band II 9400 HSDPA_Sub4 23.23 33 PASS Band II 9538 HSDPA_Sub1 23.94 33 PASS Band II 9538 HSDPA_Sub2 23.73 33 PASS Band II 9538 HSDPA_Sub3 23.63 33 PASS Band II 9538 HSDPA_Sub4 23.62 33 PASS Band IV 1312 HSDPA_Sub1 22.72 30 PASS Band IV 1312 HSDPA_Sub2 22.27 30 PASS Band IV 1312 HSDPA_Sub3 22.27 30 PASS Band IV 1312 HSDPA_Sub4 22.24 30 PASS Band IV 1413 HSDPA_Sub1 22.51 30 PASS Band IV 1413 HSDPA_Sub2 22.17 30 PASS Band IV 1413 HSDPA_Sub3 22.11 30 PASS Band IV 1413 HSDPA_Sub4 22.11 30 PASS Band IV 1513 HSDPA_Sub1 22.83 30 PASS Band IV 1513 HSDPA_Sub2 22.23 30 PASS Band IV 1513 HSDPA_Sub3 22.31 30 PASS Band IV 1513 HSDPA_Sub4 22.34 30 PASS Band V 4132 HSDPA_Sub1 24.67 38.5 PASS Band V 4132 HSDPA_Sub2 24.07 38.5 PASS Band V 4132 HSDPA_Sub3 24.03 38.5 PASS Project No.: SHT2207038406EW Radio Specification: WCDMA Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 3 of 27 Band V 4132 HSDPA_Sub4 24.10 38.5 PASS Band V 4182 HSDPA_Sub1 24.62 38.5 PASS Band V 4182 HSDPA_Sub2 24.15 38.5 PASS Band V 4182 HSDPA_Sub3 24.17 38.5 PASS Band V 4182 HSDPA_Sub4 24.16 38.5 PASS Band V 4233 HSDPA_Sub1 24.04 38.5 PASS Band V 4233 HSDPA_Sub2 23.71 38.5 PASS Band V 4233 HSDPA_Sub3 23.75 38.5 PASS Band V 4233 HSDPA_Sub4 23.63 38.5 PASS Project No.: SHT2207038406EW Radio Specification: WCDMA Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 4 of 27 Band Channel SubTest Power(dBm) Limit(dBm) Verdict Band II 9262 HSUPA_Sub1 22.36 33 PASS Band II 9262 HSUPA_Sub2 22.19 33 PASS Band II 9262 HSUPA_Sub3 22.75 33 PASS Band II 9262 HSUPA_Sub4 22.08 33 PASS Band II 9262 HSUPA_Sub5 23.45 33 PASS Band II 9400 HSUPA_Sub1 23.49 33 PASS Band II 9400 HSUPA_Sub2 22.56 33 PASS Band II 9400 HSUPA_Sub3 22.83 33 PASS Band II 9400 HSUPA_Sub4 22.68 33 PASS Band II 9400 HSUPA_Sub5 23.64 33 PASS Band II 9538 HSUPA_Sub1 22.97 33 PASS Band II 9538 HSUPA_Sub2 23.18 33 PASS Band II 9538 HSUPA_Sub3 23.44 33 PASS Band II 9538 HSUPA_Sub4 23.15 33 PASS Band II 9538 HSUPA_Sub5 24.67 33 PASS Band IV 1312 HSUPA_Sub1 22.35 30 PASS Band IV 1312 HSUPA_Sub2 21.32 30 PASS Band IV 1312 HSUPA_Sub3 21.17 30 PASS Band IV 1312 HSUPA_Sub4 21.61 30 PASS Band IV 1312 HSUPA_Sub5 22.71 30 PASS Band IV 1413 HSUPA_Sub1 22.03 30 PASS Band IV 1413 HSUPA_Sub2 21.13 30 PASS Band IV 1413 HSUPA_Sub3 20.86 30 PASS Band IV 1413 HSUPA_Sub4 21.06 30 PASS Band IV 1413 HSUPA_Sub5 22.67 30 PASS Band IV 1513 HSUPA_Sub1 22.23 30 PASS Band IV 1513 HSUPA_Sub2 21.31 30 PASS Band IV 1513 HSUPA_Sub3 21.04 30 PASS Band IV 1513 HSUPA_Sub4 21.35 30 PASS Band IV 1513 HSUPA_Sub5 22.70 30 PASS Band V 4132 HSUPA_Sub1 23.32 38.5 PASS Band V 4132 HSUPA_Sub2 22.67 38.5 PASS Band V 4132 HSUPA_Sub3 22.38 38.5 PASS Band V 4132 HSUPA_Sub4 23.12 38.5 PASS Band V 4132 HSUPA_Sub5 24.01 38.5 PASS Band V 4182 HSUPA_Sub1 23.46 38.5 PASS Band V 4182 HSUPA_Sub2 23.06 38.5 PASS Band V 4182 HSUPA_Sub3 22.95 38.5 PASS Band V 4182 HSUPA_Sub4 23.38 38.5 PASS Band V 4182 HSUPA_Sub5 24.27 38.5 PASS Band V 4233 HSUPA_Sub1 23.32 38.5 PASS Project No.: SHT2207038406EW Radio Specification: WCDMA Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 5 of 27 Band V 4233 HSUPA_Sub2 21.11 38.5 PASS Band V 4233 HSUPA_Sub3 21.69 38.5 PASS Band V 4233 HSUPA_Sub4 22.50 38.5 PASS Band V 4233 HSUPA_Sub5 23.67 38.5 PASS Project No.: SHT2207038406EW Radio Specification: WCDMA Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 6 of 27 8.2 Appendix B: Peak-to-Average Ratio Test Result Band Channel Peak-to-Average Ratio(dB) Limit(dB) Verdict Band II 9262 3.29 13 PASS Band II 9400 3.55 13 PASS Band II 9538 3.58 13 PASS Band IV 1312 3.37 13 PASS Band IV 1413 3.28 13 PASS Band IV 1513 3.46 13 PASS Band V 4132 3.31 13 PASS Band V 4182 3.37 13 PASS Band V 4233 3.40 13 PASS Project No.: SHT2207038406EW Radio Specification: WCDMA Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 7 of 27 Test Graphs Band II_9262 Band II_9400 Band II_9538 Project No.: SHT220…
