Temperature Monitoring Series MT100 Operation and Installation Manual A1-MT100 1 [Manufacturer]: Wuhan Huchuang Union Technology Co., Ltd. [Production Address]: No.1 Workshop, 1F, Building B10, Wuhan Hi-Tech Medical Device Park, No. 818 Gaoxin Avenue, East Lake Hi-Tech Development Zone, Wuhan, Hubei, China [After-Sales Service Unit]: Wuhan Huchuang Union Technology Co., Ltd. Date of Approval and Revision: December 10, 2018 A1-MT100 2 Contents 1 Overview .................................................................................................................................................................3 1.1 Operation Instructions of Manual .................................................................................................................3 1.2 Overview ......................................................................................................................................................3 1.3 Environmental Requirements .......................................................................................................................4 1.4 Environmental Protection Instructions .........................................................................................................4 2 Structure Features and Equipment Parameters ........................................................................................................4 2.1 Structure Features .........................................................................................................................................5 2.2 Equipment Parameters ..................................................................................................................................5 3 Basic Operation Instructions ....................................................................................................................................6 3.1 Overview ......................................................................................................................................................6 3.2 Operation Instructions ..................................................................................................................................6 4 Installation Instructions ...........................................................................................................................................7 4.1 Installation Method .......................................................................................................................................7 4.2 Installation Precautions .................................................................................................................................7 5 Notices for Use of Equipment .................................................................................................................................8 6 FCC Warning ........................................................................................................................................................9 A1-MT100 3 1 Overview 1.1 Operation Instructions of Manual 1.1.1 It is not allowed to print or disclose any content of this Manual, including pictures and audio products, under any name without the consent of Huchuang Union; 1.1.2 The equipment operator may copy some sections of this Operation Manual for internal use only, such as for instructing the user how to deal with emergencies. These sections are clearly listed in the catalogue of this manual; 1.1.3 Wuhan Huchuang Union Technology Co., Ltd. reserves the copyright of the Manual. The manual contains the information protected by copyright laws. No part of the Manual is allowed to be copied and sent to the users without the prior written permission of the copyright holder; 1.1.4 The contents of the Manual are subject to change without prior notice. 1.2 Overview MT100 Temperature Monitoring Series MT100 is mainly used to monitor the temperature of the incubator and is placed in the dish tank of the incubator tray. Upload the temperature data every 3 minutes (modifiable), reflect the temperature control stability of the incubator through the temperature change trend, and give the alarm when the A1-MT100 4 incubator temperature is abnormal. 1.3 Environmental Requirements 1.3.1 Only for indoor use, no high temperature, moisture, water or dust; 1.3.2 Atmospheric pressure: 70kPa～105kPa; 1.3.3 Working ambient temperature: 0°C～+50°C; 1.3.4 Storage ambient temperature: 0°C～+50°C; 1.3.5 Relative humidity in the working environment: ≤80% (non-condensing); 1.3.6 No metal objects around the equipment (Keep it away from metal wall). 1.4 Environmental Protection Instructions 1.4.1 MT100 device contains reusable materials, and its components can be recycled after being cleaned and sterilized. 1.4.2 During recycling and handling MT100 device, it is recommended that the company's technical personnel dismantle it and recycle it according to different waste groups; 1.4.3 According to national regulations, the compositions of the main raw materials of MT100 equipment shall be are shown in (Table 1). Table 2 Compositions of Main Raw Materials of MT100 Name Composition Casing Steel/ polyformaldehyde Battery Lithium-Manganese battery PCB Including electrical components 2 Structure Features and Equipment Parameters A1-MT100 5 2.1 Structure Features a) MT100； b) Equipment SN； 2.2 Equipment Parameters Table 2 Equipment Parameters Item Parameter Overall dimensions (unit: mm) 38.5mm × 38.5mm × 15mm (W×D×H) Weight 120g Data upload frequency 3 min/time (modifiable) Endurance More than 6 months when the data is uploaded every 3 minutes Dish tray MT100 Bottom SN A1-MT100 6 Storage temperature 0°C～50°C Operating temperature 0°C～50°C Resolution 0.01°C Temperature measurement error ±0.5°C(0°C ~ +15.0°C) ±0.3°C(+15.0°C ~ +35.8°C) ±0.2°C(+35.8°C ~ +37.0°C) ±0.1°C(+37.0°C ~ +39.0°C) ±0.2°C(+39.0°C ~ +41.0°C) ±0.3°C(+41.0°C ~ +45.0°C) ±0.5°C(+45.0°C ~ +50.0°C) Power supply mode Powered by button battery (CR2477, u…
