100908000076 SmartWiFiCamera UserManual 1 What’sintheBox •SmartCamera×1 •USBCable×1 •Powerplug×1（Notincludedforsolarcamera） •UserManual×1 •Screwbag×1 •MountingBracket×1 •SolarPanel(Onlyforsolarpoweredcamera) ★Differentproductshavedifferentaccessories, Pleaserefertotheactualpackinglist. 2 GetStarted •Inordertoeasilyconnectingtowifi,pleaseturn onBluetoothandfindthenearbydevicepermission fortheApp. •Connectphonetothe2.4GHzWiFi(5GHzWiFiis notworking) 1DownloadtheWiseEyerapp ScantheQRcodetodownloadtheapponApp Store(IOS)orGooglePlay(Android) 3 2RegisteranAccount Step1: •Clickregisterand enteremailaddress. Step2: •Entertheverification codeandcreatea password. 4 3AddDevice Method1:AddcameraviaBluetooth ClickaddmydeviceandtheWiseEyerAppwill promptwindowtotellyoutoturnonBluetoothand allowtheapptofindandconnecttodevicesonlocal network.Makesureyouenabledthe2permissions. • OpenWiseEyerApp, andclick+,waitfor Bluetoothtosearchthe device. • Theappwill automaticallyfind nearbydevice. Thenclick“+” 5 • CheckWiFiinfo, pleasemakesure theWiFiis2.4GHz andclickNext. •Waitforthedevice tofinishconnecting, andmakeanameto completetheprocess. 6 Method2:AddDeviceManually •Turnonthecamera,thelightsshowingflashing redandblue.It’sinsyncingmode. •Ifthereisnolight,pleasechargethecamerawith usbchargerfor4-5hours. •On Apphomepage,Click “+”andManuallyAdd devicethenselectthe camera, 7 •Followtheinstructionto resetcamera,checkmark” Followedthesteps”and click“Camerahasbeen reset” • CheckWiFiinfo, pleasemakesurethe WiFiis2.4GHzandclick nextstep. 8 •ShowtheQRCodein frontofcamerauntilyou hearthepromptvoice “Receivenetwork configurationinfo”,Then clickHeardtheprompt voice. •Waituntilyouheard thepromptvoice “networkconnection successful” •Andthenmakea nametocomplete. 9 FCCCaution. Thisdevicecomplieswithpart15oftheFCCRules. Operationissubjecttothefollowingtwoconditions:(1) Thisdevicemaynotcauseharmfulinterference,and(2) thisdevicemustacceptanyinterferencereceived, includinginterferencethatmaycauseundesired operation. AnyChangesormodificationsnotexpresslyapprovedby thepartyresponsibleforcompliancecouldvoidtheuser's authoritytooperatetheequipment. Note:Thisequipmenthasbeentestedandfoundto complywiththelimitsforaClassBdigitaldevice, pursuanttopart15oftheFCCRules.Theselimitsare designedtoprovidereasonableprotectionagainst harmfulinterferenceinaresidentialinstallation.This equipmentgeneratesusesandcanradiateradio frequencyenergyand,ifnotinstalledandusedin accordancewiththeinstructions,maycauseharmful interferencetoradiocommunications.However,thereis 10 no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. 11 FrequentlyAskedQuestions Q1What’stherequirementforSDcard? WerecommendaMicroSDcard,8GB-128GBare supported(SDcardmustbeformattedasFAT32) Q2.Howmanycamerascanbeaddontheapp? Youcanaddanunlimitedcamerasontheapp,your routermayhavealimitofhowmanydevicescanbe connectedtoonerouter. Q3.Howtosharethecameratomyfamily. DownloadingthesameAppandcreateanew accountonthetheshareddevice,andonthemain phone,clickdeviceshare,youcansharethedevice byscanningQRcodeorenteraccountname. Q4.MycamerashowsofflineontheApp. •Makesurecamerahavepower,andgetstrong andstableWiFi. •IfWiFiisnormal,anditstilloffline,plsreboot routerandrefreshontheapptocheckthestatus. 12 CustomerService •Warranty 12monthlimitedwarranty(Theactualwarranty periodshallbeimplementedaccordingtothe requirementsoflocallawsandregulations) •Emailus CustomerSupport:[email protected] •LiveChatonApp Click“CustomerService”onApp,youcanchatwith Customerservicerepresentative. •Callus UnitedStates:+1800-601-7094Mon-Fri9am-6pmEST
