2A7H7-GY1025iFory LeapBuds E, TWS Earphones

FCC ID: 2AUTE-SPP External photos FCC ID: 2A7H7-GY1025 FCC ID: 2A7H7-GY1025 FCC ID: 2A7H7-GY1025 FCC ID: 2A7H7-GY1025

Label & location The device is so small, so the FCC ID number is on User manual.

FCC ID: 2A7H7-GY1025 Internal photos FCC ID: 2A7H7-GY1025 RF Chip FCC ID: 2A7H7-GY1025 RF Antenna

Dongguan Nore Testing Center Co., Ltd. Report No.: NTC2210256F-1 FCC ID: 2A7H7-GY1025 RF EXPOSURE EVALUATION EUT Specification EUT iFory LeapBuds E, TWS Earphones Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.18GHz ~ 5.32GHz / 5.50GHz ~ 5.70GHz WLAN: 5.745GHz ~ 5825GHz Others(Bluetooth: 2.402GHz ~ 2.480GHz) Device category Portable (<20cm separation) Mobile (>20cm separation) Others ___ Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power -2.515dBm (0.56mW) Antenna gain 1.5dBi Evaluation applied MPE Evaluation SAR Evaluation Standard Requirement Portable Device According to §15.247(i) and §1.1307b(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. See KDB 447498 D01 General RF Exposure Guidance v06, section 4.3.1. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, 16 where ·f(GHz) is the RF channel transmit frequency in GHz ·Power and distance are rounded to the nearest mW and mm before calculation17 ·The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Dongguan Nore Testing Center Co., Ltd. Report No.: NTC2210256F-1 FCC ID: 2A7H7-GY1025 Measurement Result Channel Channel Frequency (MHz) Max Output power (dBm) Max Output power (mW) Calculati on Value (Note 1) Threshold Value GFSK Low 2402 -4.942 0.32 0.0992 3.0 Middle 2441 -5.610 0.27 0.0844 3.0 High 2480 -5.035 0.31 0.0976 3.0 π/4-DQPSK Low 2402 -3.026 0.50 0.1550 3.0 Middle 2441 -3.480 0.45 0.1406 3.0 High 2480 -2.999 0.50 0.1575 3.0 8DPSK Low 2402 -2.515 0.56 0.1736 3.0 Middle 2441 -3.142 0.49 0.1531 3.0 High 2480 -2.706 0.54 0.1701 3.0 Note 1: Calculation Value =[(max. power of channel, mW)/(min. test separation distance, mm)] ·[√f(GHz)]. Fox example: 0.56/5*√2.402=0.1736 ≤ 3.0 According to KDB447498 D01 V06, threshold at which no SAR required is ≤3.0 for 1-g SAR, separation distance is 5mm, and no simultaneous SAR measurement is required.

2.4GHz 3216 Chip Antenna: ANT3216R24003KL1 1 / 6 Applications: WLAN, 802.11b/g, Bluetooth, etc... Features SMD, high reliability, ultra compact, Omni-directional... Part number Electrical Specification Working Frequency Range 2400 ~2484 MHz Peak Gain 1.5 dBi (Typ.) Impedance 50 Ohm VSWR 2.5 (Max) Polarization Linear Azimuth Beamwidth Omni-directional Operation Temperature(°C) -40 ~85°C The specification is defined on EVB. Dimension and Terminal Configuration ANT 3216 R 2400 3K L1 (1) (2) (3) (4) (5) (1) Size Code 3.2x1.6mm (2) Packing Tape and reel (3) Frequency 2.4GHz (4) Packing Number 3K (5) Code L1 Dimension (mm) No. Terminal Name L 3.20+-0.15 1 Feeding W 1.60+-0.15 2 Soldering T 0.55+-0.10 D 0.50+-0.15 2.4GHz 3216 Chip Antenna: ANT3216R24003KL1 2 / 6 Evaluation Board Reference PCB Dimension Antenna Layout Reference Unit : mm : Chip Antenna : Land Pattern Matching circuit 2.4GHz 3216 Chip Antenna: ANT3216R24003KL1 3 / 6 Electrical Characteristics VSWR&Efficiency Radiation Pattern ZX-Plane -40 -30 -20 -10 0 10 0 45 90 135 180 225 270 315 dBi -4 0 -3 0 -2 0 -1 0 0 10 0 45 90 135 18 0 225 270 315 dBi Horizontal PolarizationVertical Polarization 0° 270°90° Y Z X 0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% 2.32.42.52.6 Efficiency Frequency (GHz) Efficiency 1 2 3 4 5 6 7 8 9 10 2.32.42.52.6 VSWR Frequency (GHz) VSWR X Y Z X 2400MHz 2.4GHz 3216 Chip Antenna: ANT3216R24003KL1 4 / 6 ZY-Plane XY-Plane -4 0 -3 0 -2 0 -1 0 0 10 0 45 90 135 18 0 225 270 315 dBi -40 -30 -20 -10 0 10 0 45 90 13 5 180 225 27 0 315 dBi Vertical Polarization Horizontal Polarization 0° 270°90° X Z Y -4 0 -3 0 -2 0 -1 0 0 10 0 45 90 135 180 225 270 315 dBi -40 -30 -20 -10 0 10 0 45 90 135 180 225 270 315 dBi Vertical PolarizationHorizontal Polarization 0° 270°90° Z X Y 2400MHz 2400MHz 2.4GHz 3216 Chip Antenna: ANT3216R24003KL1 5 / 6 Taping Specifications Reel and Taping Specification Reel Specification TYPE SIZE A ψB ψC ψD W ψM 3216 7” 3K/Reel 2.0±0.5 13.5±1.021±1.060±1.0 11.5±2.0 178±2.0 Taping Specification Packaging Type A B W E F G H T ψD P Paper Type 3216 1.90±0.20 3.50±0.20 8.0±0.20 1.75±0.10 3.5±0.054.0±0.102.0±0.05 0.75±0.10 +0.10 1.50 -0 4.0±0.1 2.4GHz 3216 Chip Antenna: ANT3216R24003KL1 6 / 6 Recommended Reflow Profile Pb free solder Soaking Working Soldering Peak Temp. Time Temp. Time Temp. Time Temp. T1 T2 t1 T3 t2 T4 t3 T5 150°C 180°C 60 to 120sec230°C more than 30sec 247 to 253°Cwithin 10sec 260°C Max. March 2019 Ver.H01

Report No.: NTC2210256FV00 Page 2 of 48 Table of Contents 1. Summary of Test Result ........................................................................................................................... 4 2. General Description of EUT ...................................................................................................................... 5 3. Test Channels and Modes Detail ............................................................................................................... 8 4. Configuration of EUT ................................................................................................................................ 8 5. Modification of EUT .................................................................................................................................. 8 6. Description of Support Device ................................................................................................................... 9 7. Test Facility and Location ....................................................................................................................... 10 8. Applicable Standards and References ..................................................................................................... 11 9. Deviations and Abnormalities from Standard Conditions ........................................................................... 11 10. Test Conditions .................................................................................................................................... 12 11. Measurement Uncertainty ..................................................................................................................... 13 12. Sample Calculations ............................................................................................................................. 14 13. Test Items and Results ......................................................................................................................... 15 13.1 Conducted Emissions Measurement .................................................................................................... 15 13.2 Radiated Spurious Emissions and Restricted Bands Measurement ....................................................... 17 13.3 Channel Separation test ...................................................................................................................... 24 13.4 20dB Bandwidth ................................................................................................................................. 28 13.5 Hopping Channel Number ................................................................................................................... 32 13.6 Time of Occupancy (Dwell Time) ......................................................................................................... 34 13.7 Maximum Peak Output Power ............................................................................................................. 38 13.8 Band Edge Conducted Spurious Emission Measurement ...................................................................... 42 13.9 Antenna Requirement ......................................................................................................................... 43 14. Test Equipment List .............................................................................................................................. 48 Report No.: NTC2210256FV00 Page 3 of 48 Revision History Report Number Description Issued Date NTC2210256FV00 Initial Issue 2022-11-07 Report No.: NTC2210256FV00 Page 4 of 48 1. Summary of Test Result FCC Rules Description of Test Result Remarks §15.247(a)(1) Channel Separation test PASS --- §15.247(a)(1) 20dB Bandwidth PASS --- §15.247(a)(1)(iii) Hopping Channel Number PASS --- §15.247(a)(1)(iii) Time of Occupancy (Dwell Time) PASS --- §15.247(b) Max Peak output Power test PASS --- §15.247(d) Band edge test PASS --- §15.207 (a) AC Power Conducted Emission N/A --- §15.247(d),§15.209, §15.205 Radiated Emission PASS --- §15.203 Antenna Requirement PASS --- §15.247(d) Conducted Spurious Emission PASS --- Report No.: NTC2210256FV00 Page 5 of 48 2. General Description of EUT Product Information Product Name: iFory LeapBuds E, TWS Earphones Main Model Name: TST001 Additional Model Name: TST002, TST003, TST004, TST005, TST006, TST007, TST008, TST009, TST010, TST011, TST012, TST013 Model Difference: These models have the same circuit schematic, construction, PCB Layout and critical components. Their difference is model number and color due to trading purpose. S/N: 2210-5514 Brand Name N/A Hardware Version: V01 Software Version: V01 Rating: DC 3.7V from each earphone Classification: Class B Typical Arrangement: Tabletop I/O Port: Refer to the user manual Accessories Information Adapter: N/A Cable: N/A Other: N/A Additional Information Note: According to the model difference, all tests were performed on model TST001. Remark: All the information above are provided by the manufacturer. More detailed feature of the EUT please refers to the user manual. Report No.: NTC2210256FV00 Page 6 of 48 Technical Specification Bluetooth Version: V5.2 Frequency Range: 2402-2480MHz Modulation Type: GFSK, π/4-DQPSK, 8DPSK Number of Channel: 79 (refer to following channel list for details) Channel Space: 1MHz Antenna Type: Chip Antenna Antenna Gain: 1.5 dBi (Declared by the manufacturer) The EUT does not support Bluetooth Low Energy feature in accordance with the manufacturer declaration. Report No.: NTC2210256FV00 Page 7 of 48 Channel List Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 0 2402 20 2422 40 2442 60 2462 1 2403 21 2423 41 2443 61 2463 2 2404 22 2424 42 2444 62 2464 3 2405 23 2425 43 2445 63 2465 4 2406 24 2426 44 2446 64 2466 5 2407 25 2427 45 2447 65 2467 6 2408 26 2428 46 2448 66 2468 7 2409 27 2429 47 2449 67 2469 8 2410 28 2430 48 2450 68 2470 9 2411 29 2431 49 2451…
