2A7OT-F2Portable Apple Watch Charger

Portable Apple Watch Charger User Manual This product is designed in a portable design, we wantedto make charging your Apple Watch utterly effortless.Simply hold the connector near the back of the watch,where magnets cause it to snap into place automatically.It charges all Apple Watch models and sizes.You cangive emergency power to the Apple Watch when you areoutdoors. Tech Specs: Input: 5V / 1AOutput: 5V/1ACapacity: 1200mAhBattery Type: Polymer batteryProduct Size: 78x37x12mmFCC ID ： 2A7OT-F2 Packing list: 1 .Power Bank 1pcs2.Charging Cable 1 pcs3.User Manual 1pcs Manufacturer:Shenzhen View Lighting Technology Co.,Ltd Schematic Diagram Key buckle O PEN THE KEY WATCH CHARGING AREA BATTERYINDICATOR INPUT PORT 1 .Click the power button to turn on the power output, and the b attery indicator light turns on, and the Apple Watch can be attached to the magnetic charging position for charging. If thecharger does not detect the Apple Watch within 45 seconds, it willautomatically turn off.2. Double-click the power button to turn off the power output. 3. Four LED indicators to indicate the current battery capacity , one to four LEDs indicate the current power is25%,50%,75%,100%.4. When only one LED is flashing, it indicates that the battery is t oo low and needs to be charged.Plug in the charging cable, connect the charger, and the battery indicator light starts flashingto indicate that it is charging. The battery indicator shows thecurrent charging capacity.When all four LEDs are on, the batteryis fully charged.5. After the Apple Watch is fully charged, you need to remove the w atch and double-click the power button to turn off the power output.Attention: The magnet attraction of the charging position is the role of the Apple Watch in aligning the position when charging. Itcan't be used as a function to fix the watch. Please put ithorizontally and do not move when charging. Do not hang orsway, otherwise the Apple Watch may fall off and cause damage.1 .Please don't dismount and remodel the product.2. Pay attention to water-proof, moisture-proof. 3. Please don't charge in hot environment. 4. Please stop to use immediately if battery is bulge, leaking or s mell. 5. Please stop charging immediately when the product temperatu re is high. FCC warning:Any Changes or modifications not expressly approved by the partyresponsible for compliance could void the user's authority to operatethe equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCCRules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and(2) this device must accept any interference received, includinginterference that may cause undesired operation.These limits are designed to provide reasonable protection againstharmful interference in a residential installation. This equipmentgenerates uses and can radiate radio frequency energy and, if notinstalled and used in accordance with the instructions, may causeharmful interference to radio communications. However, there is noguarantee that interference will not occur in a particular installation.If this equipment does cause harmful interference to radio ortelevision reception, which can be determined by turning theequipment off and on, the user is encouraged to try to correct theinterference by one or more of the following measures:-Reorient or relocate the receiving antenna.-Increase the separation between the equipment and receiver.-Connect the equipment into an outlet on a circuit different from thatto which the receiver is connected.-Consult the dealer or an experienced radio/TV technician for help.The device has been evaluated to meet general RF exposure requirement. The device can be used in portableexposure condition without restriction.
