2A7V5-IN90-1Multimedia Control System

Safety and Warranty information V3.5 Overseas Project Multimedia Domain Controller Host Manual Manufacturer: NOBO AUTOMOTIVE TECHNOLOGIES CO., LTD. Address: No. 668, Caihong Road, Zhangjiagang Economic and Technological Development Zone, Suzhou , Jiangsu, P.R. China Product Description Product Name: Multimedia Control System Specification & Model: IN9.0 Installation Location: Behind the vehicle dashboard Hardware: AA Software: AA Product Features 1. This product can output video signals and play multimedia files on the display screen. It can also receive the touch signal input by the display screen to realize the user's control of this product. 2. This product can process the video input of the vehicle's Surround View camera and output it to the display screen. 3. This product can output audio signals to make the vehicle's speaker sound. 4. This product accepts microphone input signals, allowing users to make phone calls or use voice assistants. 5. This product can communicate with the user's mobile phone through Bluetooth, WIFI, USB, etc., and provide functions such as Bluetooth phone and mobile phone interconnection. 6. This product also supports many upper-layer applications, and can realize functions such as navigation, occupant monitoring, and OTA upgrade. Technical Parameters Dimensions: 190*55*160mm Safety and Warranty information Weight: 1.1kg Working voltage: 7V-18V Rated voltage: 12V Normal working temperature: -40°C-70°C (full performance and full function) 70°C-85°C (full function) Feature Description Schematic diagram of the back-end interface of the full-featured host: Safety and Warranty information Camera 4-in-1 connector port: It can connect up to four 2-megapixel cameras for inputting video data from DVR, DMS, and OMS cameras. Built-in 360 Surround View: It can connect up to four 2-megapixel cameras for inputting video data from the AVM Surround View camera. Passenger: The video data output port of the passenger display. HVAC: The video data output port of the air conditioning control panel. IVI: The video data output port of the central display. USB3.0: A data transmission interface that supports the USB3.0 protocol. HUD: The video data output port of the HUD display. Cluster: The video data output port of the instrument display. Main connector: integrated power input, speaker audio output, microphone audio input, CAN bus signal transmission port, display enable signal, and fuel sensor signal input. SXM: SDARS antenna signal input port. GNSS: GNSS antenna signal input port. FM2: FM sub-antenna signal input port. FM1/AM: FM/AM main antenna signal input port. RVC: RVC camera video data input port. Gigabit Ethernet: Gigabit Ethernet cable access port. Fast Ethernet: Fast Ethernet cable access port. USB2.0: A data transmission interface that supports the USB2.0 protocol. Installation method; Bracket mounting Safety and Warranty information WARNING: 1. When using the voice assistant to control the vehicle, pay attention to the surrounding environment and personal safety to prevent serious accidents such as pinching and bumping. 2. For driving safety, do not operate the Vehicle Settings while driving. FCC compliance statement FCC ID: 2A7V5-IN90-1 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution: The user is cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause Safety and Warranty information harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Human RF Exposure: This equipment complies with the FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The antennas used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be located or operating in conjunction with any other antenna or transmitter.

NOBO AUTOMOTIVE TECHNOLOGIES CO., LTD. No. 668, Caihong Road, Zhangjiagang Economic and Technological Development Zone, Suzhou , Jiangsu, P.R. China UNII Device Declaration Letter To whom it may concern: We have declared below featured for FCC equipment authorization, Device FCC ID: 2A7V5-IN90-1 (1) DFS Device: Master Client with Radar detection capability N/A Client without radar detection capability, (2) Active / Passive Scanning , adhoc mode access point capability Frequency Band (MHz) Active Scanning (the device can transmit a probe (beacon)) passive scanning (where the device is can listen only with no probes) Ad Hoc Mode capability Access point capability 5180-5240 Yes No Yes No Yes No Yes No 5745-5825 Yes No Yes No Yes No Yes No (3) Country code selection ability Yes No If yes, pls explain how it was implemented: (4) Meet 15.202 requirement Yes No pls check below : A master device is defined as a device operating in a mode in which it has the capability to transmit without receiving an enabling signal. In this mode it is able to select a channel and initiate a network by sending enabling signals to other devices A client device is defined as a device operating in a mode in which the transmissions of the device are under control of the master. A device in client mode is not able to initiate a network. (5) For client devices that have software configuration control to operate in different modes (active scanning in some and passive scanning in others) in different bands (devices with multiple equipment classes or those that operate on non-DFS frequencies) or modular devices which configure the modes of operations through software, the application must provide software and operations description on how the software and / or hardware is implemented to ensure that proper operations modes cannot be modified by end user or an installer. Apply Does not apply (If apply, pls help to provide explanation on it was implement, and how software was controlled) Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, (Signed) Name/Title： Wenjuan Dou / Certification Engineer Company: NOBO AUTOMOTIVE TECHNOLOGIES CO., LTD. Address: No. 668, Caihong Road, Zhangjiagang Economic and Technological Development Zone, Suzhou , Jiangsu, P.R. China Phone: +86-512-80616208 Fax: E-Mail: [email protected]

NOBO AUTOMOTIVE TECHNOLOGIES CO., LTD. No. 668, Caihong Road, Zhangjiagang Economic and Technological Development Zone, Suzhou , Jiangsu, P.R. China Declaration concerning Antenna Specification Date: 2022/9/6 To: Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: It is hereby declared that the product FCC ID: 2A7V5-IN90-1 Model Number: IN9.0 Fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for ceramic antenna type(s) described below: Antenna No. Model No. of antenna: Type of antenna: Gain of the antenna (Max.) Frequency range: Bluetooth / Dipole 2402-2480MHz：2.34dBi Wi-Fi / Dipole 2412-2472MHz：2.34dBi 5180-5240MHz：3.90dBi 5745-5825MHz：3.90dBi The antenna will be fixed to the radio module by integral connector, and no other antennas not listed above should be used. Sincerely, Wenjuan Dou / Certification Engineer NOBO AUTOMOTIVE TECHNOLOGIES CO., LTD. No. 668, Caihong Road, Zhangjiagang Economic and Technological Development Zone, Suzhou , Jiangsu, P.R. China Tel: +86-512-80616208 NOBO AUTOMOTIVE TECHNOLOGIES CO., LTD. No. 668, Caihong Road, Zhangjiagang Economic and Technological Development Zone, Suzhou , Jiangsu, P.R. China Fax: Email: [email protected]

NOBO AUTOMOTIVE TECHNOLOGIES CO., LTD. No.668 caihong Road Zhangjiagang Economic and Technological Development Zone Model Declaration Letter Date: 2022/8/24 Model Number: IN9.0 To Whom It May Concern: We, NOBO AUTOMOTIVE TECHNOLOGIES CO., LTD., hereby declare that the Multiple Configurations are identical with Testing products except the information in the below table. NOBO AUTOMOTIVE TECHNOLOGIES CO., LTD. No.668 caihong Road Zhangjiagang Economic and Technological Development Zone NOBO AUTOMOTIVE TECHNOLOGIES CO., LTD. No.668 caihong Road Zhangjiagang Economic and Technological Development Zone Notes: "×" indicates that the configuration is different from that of Full Testing Sample. "√" indicates that the configuration is the same as that of Full Testing Sample. Full Testing Sample(components include K4UBE3D4AM-THCL 6GBx2, 64GB, DS90UB981, DS90UB983, DS90UB981, MAX96714F, MAX96722, MAX96718F, MAX96718F, AK7707VQ, ADAU1978, AD2428, TDF8532 #1, TDF8532 #2, TJA1044, Marvel 88Q2112, UM220-IV NV, ASM330lhh, RA8900CE, 9472B-80Z57-TM, D4S20L- 40MA5-A, D4S20L-40MA5-D, D4S20L-40MA5-C, E6S20A-40MT5-A, 59S2AQ-40MT5- D_1, AMS22D-40MZ5-A, AMS22D-40MZ5-E, 34861-1406, D4S20L-40MA5-B, 59S2AQ- 40MT5-B_1, 59S2AQ-40MT5-F_1 and 2349217-1) design covers all complete product functions and complete components. Other configurations are only based on Full Testing Sample remove/change related components, interfaces and functions, that do not affect RF performance. All configurations have the same PCB layout and RF parts.. "note1: Memory Chip Specification include K4UBE3D4AM-THCL, 8GBx2, 6GBx2" *note2: Flash Specification include 64GB, 256GB *note3: Display Processing Chip Specification include DS90UB981, DS90UB983, *note4: Camera Processing Chip Specification include MAX96714F, MAX96722, MAX96718F *note5: Audio Digital Processing Chip Specification include AK7707FAVQ (DTS), AK7707VQ (normal), ADAU1978, AD2428, TDF8532 #1, TDF8532 #2 *note6: Digital Communication Chip Specification include TJA1044, Marvel 88Q5030, MX25L3233FM1R-08Q, Marvel 88Q2112(Chip TJA1044 is used all Configurations, only connect different external device) *note7: GNSS Processing Chip include UM220-IV NV, ASM330lhh *note8: Crystal Specification include RA8900CE *note9: Connector Interface include 9472B-80Z57-TM, D4S20L-40MA5-A, D4S20L- 40MA5-D, D4S20L-40MA5-C, E6S20A-40MT5-A, D4S20L-40MA5-F, 59S2AQ-40MT5- D_1, AMS22D-40MZ5-A, AMS22D-40MZ5-E, 34861-1406, D4S20L-40MA5-B, 59S2AQ- 40MT5-B_1, 59S2AQ-40MT5-H_1, 59S2AQ-40MT5-K_1, 59S2AQ-40MT5-F_1, 2349217- NOBO AUTOMOTIVE TECHNOLOGIES CO., LTD. No.668 caihong Road Zhangjiagang Economic and Technological Development Zone 1, 34826-X124 *note10: USB chip and Interface include TPS25846 Sincerely, Wenjuan Dou / PM NOBO AUTOMOTIVE TECHNOLOGIES CO., LTD.: No. 668, Caihong Road, Zhangjiagang Economic and Technological Development Zone, Suzhou , Jiangsu, P.R. China Tel: 0512-80616208 Email: [email protected]

Confidentiality Request Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we request confidentiality for the documentation of the following products: FCC ID Model name 2A7V5-IN90-1 IN9.0 For the products listed above, we request permanent confidentiality for all applicable exhibits as there are:  the Operational Description  the Block Diagram  the Schematics  the Parts Lists  the Tune Up Information The above listed exhibits contain trade secrets and proprietary information that could be of benefit to our competitors. If you have any questions, please feel free to contact us at the address shown below. Sincerely, Signature Date Printed Name of Signee: Company: NOBO AUTOMOTIVE TECHNOLOGIES CO., LTD. Address: No. 668, Caihong Road, Zhangjiagang Economic and Technological Development Zone, Suzhou , Jiangsu, P.R. China Phone: +86-512-80616208 Fax: Email: [email protected] 2022-9-28
